Filename: MEDIT
Read OK:
File size: 18DE bytes
Load address: 2000
Exec address: 1900
Duplicates

There are 3 duplicate copies of this file in the archive:

File contents
   10REM MEDIT
   20REM (C) ELECTRON USER
   30REM By Mark Davidson
   40MODE6
   50PRINT'''" Display size ? L(arge)/S(mall) ";
   60REPEAT:A$=GET$:UNTILA$="L" OR A$="S"
   70PRINT;A$
   80IFA$="L" top=4:height=15 ELSE top=6:height=7
   90PRINT'''" Assembling ..."
  100*K.0 CALL &5A00|M
  110PROCass
  120PRINT''" Saving now ..."''
  130*SAVE MEDIT 5A00 +4B0
  140PRINT''" Finished."
  150END
  160
  170DEFPROCass
  180FORI=0 TO 2 STEP 2
  190P%=&5A00:[OPTI
  200
  210LDA#22:JSR&FFEE:LDA#6:JSR&FFEE
  220LDX #(mess MOD 256):LDY #(mess DIV 256):JSR print
  230LDA#4:LDX#1:JSR&FFF4
  240LDA#&5A:STA 7
  250JSRnblise
  260JSR hex_screen
  270JSRshow_type
  280JSRxy
  290.again
  300LDA#21:LDX#0:JSR&FFF4
  310JSR &FFE0
  320BCC ok:LDA#4:LDX#0:JSR&FFF4
  330LDA#12:JSR&FFEE
  340RTS:.ok
  350CMP#135:BNEn_sw:LDAtype:EOR#&FF:STAtype:JSRshow_type:JSRxy:JMPagain:.n_sw
  360CMP#127:BNEskip
  370JSRaddress:JSRxy:JMPagain:.skip
  380JSRinput
  390.ap2 JSR edit_keys
  400JMP again
  410
  420.print
  430STX P+1:STY P+2:LDX#0
  440.P LDA &FFF,X:CMP#255:BEQ EP:JSR&FFEE:INX:JMP P:.EP RTS
  450
  460.edit_keys
  470CMP#135:BCS edkeys
  480.e_exit
  490RTS
  500.edkeys
  510CMP #139:BNE en1
  520.l
  530LDA yc:CMP #0:BNE n_scr1
  540JSRup_line:RTS
  550.n_scr1 JSR d1pos:DEC yc:JMPsub1
  560
  570.en1 CMP #138:BNE en2
  580.r
  590LDA yc:CMP #height:BNE n_scr2
  600JSRdown_line:RTS
  610.n_scr2 JSR d2pos:INCyc:JMPsub1
  620
  630.en2 CMP#136:BNE en3
  640LDApos:BNEok3:DECpos+1:.ok3 DECpos
  650LDA xc:CMP #0:BEQ up
  660DEC xc:JMPsub1:.up
  670JSRend_line:JMPl
  680
  690.en3 CMP #137:BEQ go3:RTS:.go3
  700INCpos:BNE ok4:INC pos+1:.ok4
  710LDAxc:CMP #7:BEQgo2:INCxc:JMPsub1
  720.go2 JSRstrt_line:JMPr
  730
  740.d1pos
  750LDA pos:SEC:SBC#8:STA pos:BCS d12:DEC pos+1:.d12 RTS
  760
  770.d2pos
  780LDA pos:CLC:ADC#8:STA pos:BCC d22:INC pos+1:.d22 RTS
  790
  800.up_line LDA addr:SEC:SBC#8:STAaddr:BCS u_p:DECaddr+1:.u_p JSR d1pos:JSR hex_screen:JSR sub1:RTS
  810
  820.down_line LDAaddr:CLC:ADC#8:STAaddr:BCC d_p:INCaddr+1:.d_p JSR d2pos:JSR hex_screen:JSRsub1:RTS
  830
  840.strt_line LDApos:SEC:SBC#8:STA pos:BCS strt_p:DECpos+1:.strt_p LDA# 0:STAxc:RTS
  850
  860.end_line LDApos:CLC:ADC#8:STApos:BCCe_p:INCpos+1:.e_p LDA#7:STAxc:RTS:.et EQUB0
  870
  880.hex_screen
  890SEI
  900JSR z_store
  910JSR curs
  920LDX #height
  930.h_outer LDY #0
  940JSR side
  950.h_inner LDA (&70),Y:JSR hex_it
  960LDA#32:JSR&FFEE
  970INY:CPY #8:BNE h_inner
  980.a_outer LDY #0
  990LDA#32:JSR &FFEE
 1000.a_inner LDA (&70),Y
 1010CMP #32:BCC a_not_ok
 1020CMP #128:BCS a_not_ok
 1030JSR &FFEE:BNE a_spaces
 1040.a_not_ok
 1050LDA #46:JSR &FFEE
 1060.a_spaces
 1070INY:CPY #8:BNE a_inner
 1080JSR &FFE7
 1090LDA &70:CLC:ADC #8
 1100STA &70:BCC h_pass
 1110INC &71
 1120.h_pass
 1130DEX:BPL h_outer
 1140JSR z_rstore
 1150JSRsub1
 1160CLI
 1170RTS
 1180
 1190.display
 1200LDY#0:LDA(&70),Y:PHA:LDXxc:LDYyc
 1210LDA#31:JSR&FFEE:LDAdx,X:JSR&FFEE:LDAdy,Y:JSR&FFEE:PLA:PHA:JSR hex_it
 1220LDA#31:JSR&FFEE:LDAx1,X:JSR&FFEE:LDAdy,Y:JSR&FFEE:PLA:JSRlim1:CPY#0:BEQdis_ok
 1230LDA#46:.dis_ok JSR&FFEE:JSRxy:RTS
 1240.dt EQUB0
 1250
 1260.enter
 1270JSRnbler:STAent:LDY#0:LDA(&70),Y
 1280ASL A:ASL A:ASL A:ASL A
 1290ORAent:STA(&70),Y:JSRdisplay:RTS
 1300.ent EQUB 0
 1310
 1320.chk_hex
 1330CMP#48:BCChno:CMP#71:BCShno
 1340CMP#58:BCCchk_ok:CMP#65:BCSchk_ok
 1350.hno SEC:RTS:.chk_ok CLC:RTS
 1360
 1370.nbler
 1380CMP#65:BCSnblter:SEC:SBC#48:RTS
 1390.nblter SEC:SBC#55:RTS
 1400
 1410.hex_it
 1420STA htemp
 1430AND #&F0:LSR A:LSR A:LSR A
 1440LSR A:STA htemp2
 1450JSR digit
 1460LDA htemp
 1470AND#&F:STA htemp2
 1480.digit
 1490CMP #10:BCS select_letter
 1500LDA#48:BNE hprint
 1510.select_letter
 1520LDA #55
 1530.hprint
 1540CLC:ADC htemp2:JSR &FFEE:RTS
 1550
 1560.input
 1570LDX type:BMI type_hex
 1580.type_ascii
 1590CMP#127:BCCinp_ok:RTS:.inp_ok
 1600PHA
 1610LDApos:STA&70:LDApos+1:STA&71:LDY#0:PLA:STA(&70),Y:JSRdisplay:JSRsub1
 1620JSRgo3
 1630RTS
 1640
 1650.type_hex
 1660JSRchk_hex:BCCt_ok:RTS
 1670.t_ok
 1680PHA
 1690LDApos:STA&70:LDApos+1:STA&71
 1700PLA
 1710JSRenter
 1720RTS
 1730
 1740.lim1 LDY#0
 1750CMP#32:BCSiok1:LDY#&FF:RTS:.iok1
 1760CMP#127:BCCiok2:LDY#&FF:RTS:.iok2
 1770RTS
 1780
 1790.type EQUB1
 1800
 1810.z_store
 1820LDX#0:.zlp1 LDA c_off,X:CMP#13:BEQ z1_done:JSR&FFEE:INX:JMP zlp1:.z1_done
 1830LDA &70:STA z1:LDA &71:STA z1+1
 1840LDA addr:STA &70
 1850LDA addr+1:STA &71
 1860RTS
 1870
 1880.show_type
 1890LDAtype:BMIstp:LDA#65:STAmb:BNEsp:.stp:LDA#72:STAmb:.sp
 1900LDX#mtype MOD256:LDY#mtype DIV256:JSR print:RTS
 1910
 1920.mtype EQUB31:EQUB31:EQUB(height+top+2):EQUS"Type : ":.mb EQUB0:EQUB255
 1930
 1940.c_off EQUB 23:EQUB 1:EQUD0:EQUD0:EQUB13
 1950.c_on EQUB 23:EQUB 1:EQUB 1:EQUD0:EQUW0:EQUB0:EQUB13
 1960
 1970.z_rstore
 1980LDX#0:.zlp2 LDA c_on,X:CMP#13:BEQ z2_done:JSR&FFEE:INX:JMP zlp2:.z2_done
 1990LDA z1:STA &70:LDA z1+1:STA &71
 2000RTS
 2010
 2020.side
 2030LDA &71:JSR hex_it:LDA &70:JSR hex_it:LDA #32:JSR &FFEE:JSR &FFEE:RTS
 2040
 2050.curs
 2060LDA#31:JSR&FFEE:LDA#0:JSR &FFEE:LDA#top:JSR &FFEE
 2070RTS
 2080
 2090.sub1
 2100LDA#31:JSR&FFEE:LDA#0:JSR&FFEE:LDA #height+top+2:JSR &FFEE
 2110LDX#txt MOD256:LDY#txt DIV256:JSR print
 2120LDA pos+1:JSR hex_it:LDA pos
 2130JSR hex_it
 2140.xy
 2150LDX xc:LDY yc:LDA #31:JSR &FFEE:LDA dx,X:JSR &FFEE:LDA dy,Y:JSR &FFEE:RTS
 2160
 2170.nblise
 2180LDX#3:.nblp LDA b4,X
 2190CMP#65:BCC number
 2200SBC#55:STA w4,X:JMP n
 2210.number SBC#47:STA w4,X
 2220.n DEX:BPL nblp
 2230LDA w4:ASL A:ASL A:ASL A:ASL A
 2240ORA w4+1:STA pos+1:STA addr+1
 2250LDA w4+2:ASL A:ASL A:ASL A:ASL A
 2260ORA w4+3:STA pos:STA addr
 2270LDA#0:STAxc:STAyc
 2280RTS
 2290
 2300.address
 2310LDA#21:LDX#0:JSR&FFF4
 2320LDX#mess2 MOD256:LDY#mess2 DIV256
 2330JSRprint:LDX#0
 2340.addr_lp
 2350DEX:STXxt:INX
 2360JSR&FFE0:CMP#27:BEQ ignore_addr:CMP#13
 2370BEQrearrange:JSRchk_hex:BCSaddr_lp
 2380STAd4,X:JSR&FFEE:INX:CPX#4
 2390BNEaddr_lp:INCxt
 2400.rearrange
 2410LDXxt
 2420LDA#48:LDY#3:.cl_lp STAb4,Y:DEY:BPL cl_lp
 2430LDY#3:.rearr_lp LDA d4,X:STAb4,Y
 2440DEY:DEX:BPLrearr_lp
 2450JSRnblise:JSRhex_screen
 2460.ignore_addr
 2470LDA#31:JSR&FFEE:LDA#0:JSR&FFEE:LDA#(height+top+4):JSR&FFEE
 2480LDX#20:LDA#32:.sp_lp JSR&FFEE:DEX:BPLsp_lp:RTS:.xt EQUB0
 2490
 2500.b4 EQUS "4F13":EQUB13
 2510.w4 EQUS "****"
 2520.d4 EQUS "****":EQUB13
 2530
 2540.x EQUB 6:.y EQUB top
 2550
 2560.xc EQUB 0:.yc EQUB 0
 2570
 2580.htemp EQUB 0:.htemp2 EQUB 0
 2590.z1 EQUW 0
 2600.addr EQUW A%
 2610.pos EQUW A%
 2620.mess EQUB12:EQUB31:EQUB8:EQUB1:EQUS"*** Memory Editor ***"+CHR$255
 2630.mess2 EQUB31:EQUB0:EQUB(top+height+4):EQUS"Enter address : ":EQUB255
 2640.txt EQUS "Address : "+CHR$255
 2650.dx OPT FNxx
 2660.dy OPT FNyy
 2670.x1 OPT FNxe
 2680
 2690]:NEXT
 2700ENDPROC
 2710
 2720DEFFNxx
 2730FORJ%=0 TO 7:[OPTI:EQUB 6+J%*3:]:NEXT:=I
 2740
 2750DEFFNyy
 2760FORJ%=0 TO height:[OPTI:EQUB top+J%:]:NEXT:=I
 2770
 2780DEFFNxe
 2790FORJ%=0 TO 7:[OPTI:EQUB 31+J%:]:NEXT:=I
