PLOTTER

This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.

Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.

Tape/disk: Home » Personal collection » Acorn DFS disks » dfs_box04_disk09_rgs_robotics_1.scp
Filename: PLOTTER
Read OK:
File size: 1981 bytes
Load address: FF1900
Exec address: FF8023
File contents
   10 REM INTERFACE DRIVER
   15 REM FISCHER COMPUTING <--> ACORN  BBC COMPUTER
   20 REM COPYRIGHT (C) ARTUR FISCHER FORSCHUNG 1984
   30 REM Use the following commands to control your FISCHERTECHNIK model with your Acorn Model B
   35 REM
   40 REM     * * COMMANDS * *
   45 REM
   50 REM - CALL M1,CW%
   55 REM   Rotates Motor #1 clockwise
   60 REM - CALL M1,CCW%
   65 REM   Rotates Motor #1 counter-clockwise
   70 REM - CALL M1,GO%
   75 REM   Switches device connected to M1 on
   80 REM - CALL M1,HALT%
   85 REM   Switches device connected to M1 off
   90 REM Instead of "M1" you may also use M2, M3 or M4
   95 REM - FNUSR (E1)
  100 REM   Returns a '0' or a '1' depending on the current state of the switch
  105 REM Instead of 'E1' you may also use any of the keys 'E2' to 'E8'
  110 REM - FNUSR (EX)
  115 REM   Returns a value depending on the current position of the potentiometer
  120 REM Instead of 'EX' you can also use 'EY' to obtain a value from potentiometer Y
  125 LET drr=&62
  130 LET up=&60
  135 LET til=&68
  140 LET tih=&69
  145 LET tic=&6B
  150 LET avar=&80
  155 LET mask=&81
  160 LET buff=&82
  165 LET asave=&84
  170 LET xsave=&85
  175 LET ysave=&86
  180 DIM M% 500
  185 FOR Z=0 TO 2 STEP 2
  190 P%=M%
  195[
  200 OPT Z
  205 \ * * OUTPUT DRIVER * *
  210 .init:lda #0:beq stvar:lda #3 :bne bout:lda #12:bne bout:lda #&30:bne bout:lda #&C0
  215 .bout :sta mask:lda avar:ora mask:sta avar:jsr check:jmp ok2
  220 .check :lda &0600:cmp #1:beq ok
  225 .err1:brk:]:PROCequb (&FF):PROCequs ("Use exactly one parameter"):PROCequb (0):[OPT Z
  230 .ok:lda&603: cmp #4:beq ok1
  235 .err2:brk:]:PROCequb(&FF):PROCequs("Use integer parameters only"):PROCequb(0):[OPT Z
  240 .ok1:lda &601:sta buff:lda &602:sta buff+1:ldy #0:lda (buff),Y
  245 .back:rts
  250 .ok2:and mask:sta mask: lda avar:eor mask
  255 .stvar:sta avar: tay
  260 .shout:jsr save:ldy #&3F:ldx #drr:jsr write:jsr load:ldx #8
  265 .loop: lda #&30:asl avar: bcc null:ora #4
  270 .null:jsr save:tay:ldx #up:jsr write:jsr load:ora #8:jsr save:tay:ldx #up
  275 jsr write:jsr load:dex:bne loop:jsr save:ldy #&31:ldx #up:jsr write:jsr load:sty avar:rts
  280 .E1:ldx #1:jmp test
  285 .E2:ldx #2:jmp test
  290 .E3:ldx #4:jmp test
  295 .E4:ldx #8:jmp test
  300 .E5:ldx #16:jmp test
  305 .E6:ldx #32:jmp test
  310 .E7:ldx #64:jmp test
  315 .E8:ldx #128
  320 .test:stx mask:lda #&32:jsr save:ldy asave:ldx #up:jsr write:jsr load:ora #8:jsr save:ldy asave:ldx #up:jsr write:jsr load:ldx #8
  325 .loop2:asl A:jsr save:ldx #up:jsr read:tya:and #&80:beq nul2:jsr load:ora #1:jmp nul3
  330 .nul2:jsr load
  335 .nul3:jsr save:ldy #&30:ldx #up:jsr write:jsr load:ldy #&38:ldx #up:jsr write:jsr load:dex:bne loop2:and mask:beq back1:lda #1
  340 .back1
  345 rts
  350 .EX:ldx #&A0:jmp poti
  355 .EY:ldx #&90
  360 .poti:sei:jsr save:ldy #&20:ldx #tic:jsr write:ldy #&FF:ldx #til:jsr write:ldy #&FF:ldx #tih:jsr write:ldy xsave
  365 ldx #up:jsr write:ldy #&38:ldx #up:jsr write:jsr load
  370 .tst:jsr save:ldx #til:jsr read:sty ysave:jsr load:tya:ldx #200
  375 .delay:dex:bne delay:jsr save:ldx #til:jsr read:sty ysave:jsr load:sec:sbc ysave:bne tst:jsr save:ldx #til:jsr read:sty ysave:jsr load:sec:lda #&FF:sbc ysave:cli:rts
  380 .write:lda #&97:jsr &FFF4:clc:rts
  385 .read:lda #&96:jsr &FFF4:clc:rts
  390 .save:sta asave:stx xsave:sty ysave:rts
  395 .load:lda asave:ldx xsave:ldy ysave:rts
  400]
  405 NEXT Z
  410 LET M1=init+4
  415 LET M2=init+8
  420 LET M3=init+12
  425 LET M4=init+16
  430 LET INIT=init
  435 LET CW%=85
  440 LET CCW%=170
  445 LET GO%=85
  450 LET HALT%=255
  455 REM * * * END OF DRIVER * * *
  460 DEF FNUSR(A)=USR(A) AND &FF
  470 DEFPROCequb(num):?P%=num:P%=P%+1:ENDPROC
  480 DEFPROCequs(text$):$P%=text$:P%=P%+LEN text$:ENDPROC
  500 CALL INIT
  510 REM FISCHERTECHNIK COMPUTING
  520 REM
  530 REM PLOTTER
  540 REM
  550 REM COPYRIGHT (C) 1984
  560 REM BY ARTUR FISCHER FORSCHUNG
  570 REM
  580 REM SEGMENT TABLE
  590 DIM SEG(9)
  600 REM CONSTANTS
  610 LET GR=30 : REM BRAKE PERIOD R
  620 LET GA=5  : REM BRAKE PERIOD A
  630 REM
  640 REM ASSIGNMENTS FOR THE INTERFACE
  650 REM
  660 REM INPUT
  670 REM E3 = TAKE VALUES GIVEN BY POTS
  680 REM E4 = RIGHT
  690 REM E5 = LEFT
  700 REM E6 = FORWARD
  710 REM E7 = BACKWARD
  720 REM EX = RADIAL POSITION
  730 REM EY = ANGLE POSITION
  740 REM
  750 REM OUTPUT
  760 REM M1 = TURNING MOVEMENT
  770 REM M2 = RADIAL MOVEMENT
  780 REM M3 = MAGNET
  790 REM
  800 REM FUNCTION DESCRIPTION :
  810 REM THE PROGRAM CONTROLS THE
  820 REM PLOTTER WHICH DRAWS A GRAPHIC
  830 REM CONSISTING OF SEGMENTS OF A
  840 REM CIRCLE. AFTER THE START OF
  850 REM THE PROGRAM THE PLOTTER IS
  860 REM CALIBRATED. THEREAFTER YOU
  870 REM INPUT THE NUMBERS AND THE
  880 REM GRAPHIC IS DRAWN.
  890 REM
  900 MODE6
  910 PRINT
  920 PRINT "FISCHERTECHNIK"
  930 PRINT "COMPUTING"
  940 PRINT
  950 PRINT "PLOTTER"
  960 PRINT
  970 REM
  980 LET A$="PLEASE POSITION THE PLOTTER USING THE   SWITCHES, TO :-"
  990 PRINT
 1000 PRINT A$
 1010 PRINT "RIGHT - OUTER POSITION"
 1020 GOSUB 1630
 1030 LET RM=R
 1040 LET AM=A
 1050 PRINT A$
 1060 PRINT "LEFT - INNER POSITION"
 1070 GOSUB 1630
 1080 LET R0=R
 1090 LET A0=A
 1100 REM INPUT OF DATA
 1110 PRINT
 1120 INPUT "NUMBER OF SEGMENTS",SG
 1130 IF SG=0 THEN END
 1140 LET SS=0
 1150 FOR S=1 TO SG
 1160 PRINT "AMOUNT #";S;
 1170 INPUT SEG(S-1)
 1180 LET SS=SS+SEG(S-1)
 1190 NEXT S
 1200 REM STANDARDIZE VALUES
 1210 FOR S=1 TO SG
 1220 LET SEG(S-1)=SEG(S-1)/SS
 1230 NEXT S
 1240 PRINT "PLEASE INSERT PAPER !"
 1250 PRINT "DEPRESS KEY E3 WHEN READY !"
 1260 IF FNUSR(E3)=0 THEN GOTO 1260
 1270 REM PLOT
 1280 REM I BOUNDARY
 1290 LET R=R0
 1300 LET PEN%=HALT%
 1310 GOSUB 1860 : REM R-MOVEMENT
 1320 LET A=A0
 1330 LET PEN%=HALT%
 1340 GOSUB 1980 : REM A-MOVEMENT
 1350 LET A=AM
 1360 GOSUB 2100 : REM PEN DOWN
 1370 GOSUB 1980
 1380 LET R=RM
 1390 LET PEN%=GO%
 1400 GOSUB 1860 : REM R-MOVEMENT
 1410 LET A=A0
 1420 GOSUB 2100 : REM PEN DOWN
 1430 GOSUB 1980 : REM A-MOVEMENT
 1440 LET R=R0
 1450 GOSUB 2100 : REM PEN DOWN
 1460 GOSUB 1860 : REM R-MOVEMENT
 1470 REM II PLOT BORDERS OF SEGMENTS
 1480 LET SS=0
 1490 FOR S=1 TO SG-1
 1500 LET SS=SS+SEG(S-1)
 1510 LET A=A0+INT((AM-A0)*SS+.5)
 1520 LET PEN%=HALT%
 1530 GOSUB 1980 : REM A-MOVEMENT
 1540 LET R=RM
 1550 GOSUB 2100 : REM PEN DOWN
 1560 GOSUB 1860 : REM R-MOVEMENT
 1570 LET R=R0
 1580 LET PEN%=HALT%
 1590 GOSUB 1860 : REM R-MOVEMENT
 1600 NEXT S
 1610 GOTO 1110
 1620 END
 1630 REM TAKE THE VALUES
 1640 CALL INIT : REM ALL MOTORS OFF
 1650 IF FNUSR(E4)=0 THEN GOTO 1680
 1660 CALL M1,CW%
 1670 GOTO 1650
 1680 IF FNUSR(E5)=0 THEN GOTO 1710
 1690 CALL M1,CCW%
 1700 GOTO 1680
 1710 CALL M1,HALT%
 1720 IF FNUSR(E6)=0 THEN GOTO 1750
 1730 CALL M2,CW%
 1740 GOTO 1720
 1750 CALL M1,HALT%
 1760 IF FNUSR(E7)=0 THEN GOTO 1790
 1770 CALL M2,CCW%
 1780 GOTO 1760
 1790 CALL M2,HALT%
 1800 IF FNUSR(E3)=0 THEN GOTO 1640
 1810 LET R=FNUSR(EX)
 1820 LET A=FNUSR(EY)
 1830 IF FNUSR(E3)=1 THEN GOTO 1830
 1840 REM WAIT UNTIL SWITCH IS NO LONGER PRESSED
 1850 RETURN
 1860 REM R-MOVEMENT
 1870 CALL M3,PEN%
 1880 LET D=FNUSR(EX)-R
 1890 IF D>0 THEN CALL M2,CW%
 1900 IF D<0 THEN CALL M2,CCW%
 1910 IF D=0 THEN RETURN
 1920 LET D=ABS(D)
 1930 IF D>GR THEN GOTO 1880
 1940 FOR I=0 TO D
 1950 NEXT I
 1960 CALL M2,HALT%
 1970 GOTO 1880
 1980 REM A-MOVEMENT
 1990 CALL M3,PEN%
 2000 LET D=FNUSR(EY)-A
 2010 IF D>0 THEN CALL M1,CW%
 2020 IF D<0 THEN CALL M1,CCW%
 2030 IF D=0 THEN RETURN
 2040 LET D=ABS(D)
 2050 IF D>GA THEN GOTO 2000
 2060 FOR I=0 TO D
 2070 NEXT I
 2080 CALL M1,HALT%
 2090 GOTO 2000
 2100 REM PEN DOWN
 2110 LET PEN%=GO%
 2120 FOR I=0TO 100
 2130 CALL M3,PEN% : REM DELAY LOOP
 2140 NEXT I
 2150 RETURN
