LIENARD

This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.

Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.

Tape/disk: Home » Recent acquisitions » Acorn tapes » tape045b_acorn_acorn_user_1985_04_electron.wav
Filename: LIENARD
Read OK:
File size: 1499 bytes
Load address: FFFF1900
Exec address: FFFF1900
Duplicates

There are 2 duplicate copies of this file in the archive:

File contents
   10REM Budge
   20REM by Brian Lienard
   30REM For BBC and Electron
   40REM (C) Acorn User April 1985
   50:
   60*FX144,0,1
   70IF ?&FFFE=164 THEN E%=0 ELSE E%=96
   80MODE4:VDU19,0,4;0;
   90DIMvdu$(14),val%(14,8),mode$(3)
  100mode$(1)="ERASE":mode$(2)="DRAW "
  110mode$(3)="MOVE "
  120PROCsetchars
  130PROCtitle
  140PROCquestions
  150PROCdisplay(H%,W%)
  160L%=0:R%=W%*8-1:T%=0:D%=H%*8-1
  170M%=3:X%=0:Y%=0
  180PROCcomlist
  190*FX4,1
  200:
  210REPEAT
  220PRINTTAB(X%,Y%);:Z%=GET AND &DF
  230IF Z%=139 AND Y%>T% THEN PROCup
  240IF Z%=138 AND Y%<D% THEN PROCdn
  250IF Z%=136 AND X%>L% THEN PROClt
  260IF Z%=137 AND X%<R% THEN PROCrt
  270IF Z%=68 THEN M%=2:PROCmode
  280IF Z%=69 THEN M%=1:PROCmode
  290IF Z%=77 THEN M%=3:PROCmode
  300IF Z%=86 THEN PROCsave:G%=0:PROCprocess:PROCcomlist:PROCrestore
  310IF Z%=76 THEN PROCload
  320UNTIL Z%=81 OR Z%=113
  330:
  340G%=1:PROCprocess
  350CLS:PRINT'"Do you want to save ";
  360PRINT"VDU23 statements in a file";
  370PRINT" or print them on the";
  380PRINT" screen?"''
  390PRINT"Press : F for file"
  400PRINTSPC(8);"S for screen";
  410REPEAT Z%=GET AND &DF
  420UNTIL Z%=70 OR Z%=83
  430IF Z%=70 THEN PROCfile : END
  440CLS:FORC%=0TO14:PRINTvdu$(C%):NEXT
  450PRINT"Now LOAD your program and COPY over'"
  460PRINT"the statements to merge them with it."
  470*FX4,0
  480END
  490:
  500DEF PROCfile
  510PRINT''"Please enter File name :";
  520REPEAT:INPUT F$:UNTIL F$<>""
  530F$=LEFT$(F$,7):CHAN=OPENOUT(F$)
  540FOR C%=0 TO W%*H%-1
  550FOR I%=1 TO LEN(vdu$(C%))
  560BPUT#CHAN,ASC(MID$(vdu$(C%),I%,1))
  570NEXT
  580BPUT#CHAN,13:NEXT:CLOSE#CHAN
  590PRINT''"Now LOAD your program ";
  600PRINT"and *EXEC ";F$;" to"
  610PRINT" merge the VDU23 statements with it"
  620*FX4,0
  630ENDPROC
  640:
  650DEFPROCprocess
  660PROCcls
  670PRINT TAB(15,27);"Processing";
  680FOR C%=0 TO W%*H%-1
  690P%=(C% MOD W%)*8-1
  700Q%=(C% DIV W%)*8-1
  710IF G%=1 THEN vdu$(C%)=STR$(LI+C%*10)+"VDU23,"+STR$(U%+C%)
  720FORI%=1 TO 8:V%=128:S%=0
  730FORJ%=1 TO 8
  740PRINTTAB(P%+J%,Q%+I%);
  750A%=135
  760IF(USR(&FFF4)AND&FFFF)DIV &100=233-E% THEN S%=S%+V%:IF G%=1 THEN PRINT"#";
  770V%=V%/2
  780NEXT J%
  790IF G%=1 THEN vdu$(C%)=vdu$(C%)+","+STR$(S%) ELSE val%(C%,I%)=S%
  800NEXT I%
  810IF G%=1 THEN PRINTTAB(P%+1,Q%+1);STR$(U%+C%);
  820NEXT C%
  830IF G%=0 THEN PROCview
  840PRINTTAB(8,27);"Press any key to continue";:Z%=GET
  850ENDPROC
  860:
  870DEFPROCmode
  880PRINTTAB(25,30);mode$(M%);
  890PROCupdate:ENDPROC
  900:
  910DEFPROCcls
  920 FORY%=24 TO 31
  930PRINTTAB(0,Y%);SPC(39);
  940NEXT:ENDPROC
  950:
  960DEFPROCsave
  970K%=X%:O%=Y%:ENDPROC
  980:
  990DEFPROCrestore
 1000X%=K%:Y%=O%
 1010PRINTTAB(X%,Y%);
 1020ENDPROC
 1030:
 1040DEFPROCsetchars
 1050VDU23,224,255,128,128,128,128,128,128,129
 1060VDU23,225,255,1,1,1,1,1,1,129
 1070VDU23,226,129,128,128,128,128,128,128,255
 1080VDU23,227,129,1,1,1,1,1,1,255
 1090VDU23,228,129,0,0,0,0,0,0,255
 1100VDU23,229,255,0,0,0,0,0,0,129
 1110VDU23,230,129,128,128,128,128,128,128,129
 1120VDU23,231,129,1,1,1,1,1,1,129
 1130VDU23,232,129,0,0,0,0,0,0,129
 1140VDU23,233,255,255,255,255,255,255,255,255
 1150VDU23,234,60,66,153,161,161,153,66,60
 1160ENDPROC
 1170:
 1180DEF PROCdisplay(H%,W%)
 1190CLS:FOR B%=0 TO H%-1
 1200FOR A%=0 TO W%-1
 1210X%=A%*8:Y%=B%*8:PROCtile(X%,Y%)
 1220NEXT:NEXT:ENDPROC
 1230:
 1240DEFPROCtile(X%,Y%)
 1250PRINTTAB(X%,Y%);CHR$(224);
 1260FOR I%=1 TO 6:PRINTCHR$(229);:NEXT
 1270PRINTCHR$(225)
 1280FOR J%=Y%+1 TO Y%+6
 1290PRINTTAB(X%,J%);CHR$(230);
 1300FOR I%=1 TO 6:PRINTCHR$(232);:NEXT
 1310PRINTCHR$(231);
 1320NEXT
 1330PRINTTAB(X%,Y%+7);CHR$(226);
 1340FOR I%=1 TO 6:PRINTCHR$(228);:NEXT
 1350PRINTCHR$(227);
 1360ENDPROC
 1370:
 1380DEFPROCcomlist
 1390PRINTTAB(0,24);"Mode: Press D=draw, E=erase, M=move."
 1400PRINT"Move: Cursor keys = up,down,left,right."
 1410PRINT"View: Press V to view at normal size."
 1420PRINT"Load: Press L to load VDU23 statement."
 1430PRINT"Quit: Press Q to quit definition."
 1440PRINTTAB(8,30);"Current mode is: ";:COLOUR1:PRINTmode$(M%):COLOUR3
 1450ENDPROC
 1460:
 1470DEFPROCup
 1480Y%=Y%-1:PROCupdate:ENDPROC
 1490:
 1500DEFPROCdn
 1510Y%=Y%+1:PROCupdate:ENDPROC
 1520:
 1530DEFPROClt
 1540X%=X%-1:PROCupdate:ENDPROC
 1550:
 1560DEFPROCrt
 1570X%=X%+1:PROCupdate:ENDPROC
 1580:
 1590DEFPROCupdate
 1600PRINTTAB(X%,Y%);
 1610ON M% GOTO 1620,1630,1640
 1620PROCerase:GOTO 1640
 1630PRINTCHR$(233);
 1640ENDPROC
 1650:
 1660DEFPROCerase
 1670PRINTTAB(X%,Y%);
 1680A%=X% MOD 8:B%=Y% MOD 8:F%=0
 1690IF A%=0 AND B%=0 THEN PRINTCHR$(224);:F%=1
 1700IF A%=0 AND B%=7 THEN PRINTCHR$(226);:F%=1
 1710IF A%=7 AND B%=0 THEN PRINTCHR$(225);:F%=1
 1720IF A%=7 AND B%=7 THEN PRINTCHR$(227);:F%=1
 1730IF A%=0 AND B%>0 AND B%<7 THEN PRINTCHR$(230);:F%=1
 1740IF A%=7 AND B%>0 AND B%<7 THEN PRINTCHR$(231);:F%=1
 1750IF A%>0 AND A%<7 AND B%=0 THEN PRINTCHR$(229);:F%=1
 1760IF A%>0 AND A%<7 ANDB%=7 THEN PRINTCHR$(228);:F%=1
 1770IF F%=0 THEN PRINTCHR$(232);
 1780ENDPROC
 1790:
 1800DEFPROCquestions
 1810PRINTTAB(0,15);"No.of chars.across(1-5,default=1)";
 1820REPEAT INPUT W%
 1830UNTIL W%=0 OR W%<5
 1840IF W%=0 THEN W%=1
 1850PRINT'"No.of chars. down (1-3,default=1)";
 1860INPUT H%:IF H%=0 THEN H%=1
 1870IF H%>3 THEN PRINT CHR$(7);:GOTO 1860
 1880PRINT'"ASCII codes for chars.to start at"
 1890PRINTSPC(12);"(224-";256-H%*W%;",default=224)";
 1900INPUT U%:IF U%=0 THEN U%=224
 1910IF U%>256-H%*W% THEN PRINTCHR$(7);:GOTO1900
 1920PRINT'"1st line no.for VDU23 statements"
 1930PRINTSPC(11);"(1-32000,default=1010)";
 1940INPUT LI:IF LI=0 THEN LI=1010
 1950IF LI<=0 OR LI>32000 THEN PRINTCHR$(7);:GOTO1940
 1960ENDPROC
 1970:
 1980DEFPROCtitle
 1990CLS
 2000PRINTTAB(5,2);"* BUDGE ";CHR$(234);" by Brian Lienard."
 2010PRINTTAB(5,4);"B BBC   (& Electron)"
 2020PRINTTAB(5,5);"U  User-"
 2030PRINTTAB(5,6);"D   Defined"
 2040PRINTTAB(5,7);"G    Graphics"
 2050PRINTTAB(5,8);"E     Editor."
 2060ENDPROC
 2070:
 2080DEFPROCview
 2090PRINTTAB(8,31);"Latest  view is:------->";
 2100FOR C%=0 TO H%*W%-1
 2110VDU23,235,val%(C%,1),val%(C%,2),val%(C%,3),val%(C%,4),val%(C%,5),val%(C%,6),val%(C%,7),val%(C%,8)
 2120PRINTTAB(C% MOD W%+33,C% DIV W%+32-H%);CHR$(235);
 2130NEXT
 2140M%=3
 2150ENDPROC
 2160:
 2170DEFPROCload
 2180PROCsave:PROCcls
 2190PRINTTAB(0,25);"LOAD: Which tile across(1-";W%;"/1)";
 2200INPUT P%:IF P%=0 THEN P%=1:GOTO 2220
 2210IF P%<1 OR P%>W% THEN PRINTTAB(31,25);CHR$(7);SPC(4);:GOTO2190
 2220PRINTTAB(0,26);SPC(5);"Which tile  down (1-";H%;"/1)";
 2230INPUT Q%:IF Q%=0 THEN Q%=1:GOTO2250
 2240IF Q%>H% THEN PRINTTAB(31,26);CHR$(7);SPC(4);:GOTO2220
 2250PROCtile((P%-1)*8,(Q%-1)*8)
 2260PRINTTAB(0,28);"Type in values from VDU23 statement:"
 2270FOR I%=1 TO 8
 2280PRINTTAB(0,29);"Dot value for row ";
 2290COLOUR1:PRINT;I%;:COLOUR3
 2300PRINT" (0-255/0)";:INPUTN%
 2310IF N%<0 OR N%>255 THEN PRINTTAB(30,29);CHR$(7);SPC(5);:GOTO2280
 2320V%=128
 2330FOR J%=1 TO 8
 2340IF N% DIV V%=1 THEN PRINTTAB((P%-1)*8+J%-1,(Q%-1)*8+I%-1);CHR$(233);:N%=N%-V%
 2350V%=V%/2:NEXTJ%
 2360PRINTTAB(30,29);SPC(5):NEXT I%
 2370PROCcls: M%=3: PROCcomlist: PROCrestore
 2380ENDPROC
