File contents
CODE5 bites back
================
Back as far as issue 27 Richard Dimond
kindly reproduced the complete source
code to the bare workings behind the
EUG menu system.This however went
unregistered to me.
I then looked at later issues and was
thinking to my self "why not add to
CODE5 support so that Gus doesn't have
to write in capitals?".As you do.
This was prompted by finding some font
definitions in the library directory
of the Master welcome disk.These also
included ones based on a PC character
set (not the usual 8*8 matrix) and
ones for bold etc...
Then I remebered Richard's listing,and
dug it out.Looking closer,infact the
software is already there! All that is
required to change typefaces is to
embed a character &1D for italics or a
&1C for bold.
It would appear therefore that I have
nothing to do,but Gus needs to
remember to use Richard's excellent
routines.
I do however have one suggestion after
reading through,why not reserve 24
bytes (say) for vectors.These would
start in one FIXED place,eg.&900 and
then NEVER move.Then,the menu programs
needn't use CALLs to specific
locations which don't mean anything.
Perhaps an example:
FORX=0TO2STEP2
P%=&900
[OPTX
JMPprint
JMPclear2himem
JMPwordwrap
JMPpressakey
JMP9999 \Reserved
JMP9999 \Reserved
JMP9999 \Reserved
JMP9999 \Reserved
.code5
\Unchanged code as before from here
\on down
]
NEXT
Then in the menu programs:
10REM This is a menu program
20print=&900:clear2himem=&903
30wordwrap=&906:pressakey=&909
40:
50:
60Menu program as per usual
70:
80:
90CALLclear2himem
100CALLprint
110CALLpressakey
120:
130:
140END
The advantage of the method of keeping
the vectors at a FIXED place in memory
is that when a new "code5" program is
written,the benefits of the new
version may be enjoyed on backissues
of EUG by simply copying the new
"code5" module onto the older disks.
At present,doing so would cause menus
to crash as (for example) location
&9AA isn't the start of the print
routine in "code4" !
Food for thought maybe?
Robert Sprowson.
