                       P i x e l   M a p p e r

       Anyone who continued their Micro User subscription long enough to
see the change of name to "Acorn Computing" might have noticed that
"Pixel Mapper", a program published for the BBC Micro in October/November
1992 did not work on the Electron. This was a shame, as it was actually a
very clever program to distort pictures into virtually any shape you
wanted. I have now found, and sorted out, the problem (a minor difference
in the address of a look-up table in the OS ROM). I have also added a few
new facilities, including a simple menu.
       The program is in two main parts, a Shaper and a Mapper. The first
is basically a simple art program. Using this, you design the shape you
want to fit your picture into. Then the Mapper will convert your picture
(which can be a screen file of any size in any graphics mode) line-by-line
to fit the shape you designed.
       The Shaper is different from most art programs, as it is
object-orientated. This means that its files are stored as a series of
shapes in the order you drew them, rather than an ordinary pixel-based
screen file. This has the advantage that the files are very small, and
also they can be re-drawn in any screen mode. However, it does mean that
mistakes can be difficult to correct. For this reason, the original
version had no facility to re-load a saved shape file, or to delete a
shape drawn in the wrong place (it was assumed that the shapes used for
the Pixel Mapper would be very simple, so there would be nothing to lose
by clearing the screen and starting again if the result was not
satisfactory). I have added these two facilities, but unfortunately the
program would not run with the ADFS in Mode 1 as it was supposed to (most
BBC Micro owners use the DFS, which has PAGE set at &1900, not &1D00). To
get round this, I have provided the option of running it in either Mode 4
or 5 (with obvious advantages/drawbacks).
       The controls for the shaper are as follows:
     G: Lock cursor to grid     } you are given the option to choose the
                                 } size of  the grid, and  whether or not
     N : Unlock cursor from grid } to display it, when the program is run.
     O : Return cursor to origin
     F : Select foreground colour
     B : Select background colour (erase)
     T : Draw triangle (use space bar to fix other two points)
     R : Draw rectangle (use space bar to fix opposite point)
     C : Make n-sided polygon (use a large value to draw a circle)
 Space : Fix corner of object
Arrow keys : Move cursor
    +Shift : Move cursor faster       } not if cursor is
  +Control : Move cursor faster still } locked to grid.
     Q : Quit the program (return to menu)
Func/, : Load shape file
Func/. : Save shape file
Shift/D: Delete last object drawn (or cancel current one)
Escape : Cancel current operation
     L : Display number of objects left (this was included because memory
          was very tight in the original Mode 1 version, so only 15
          objects were allowed. Now there is room for about 300, so you
          shouldn't need to use this option)

        The operation of the Mapper program is fairly self-explanatory.
You are first asked to enter the Mode of the screen file you want to
distort. In some cases, you can also select the destination mode. You are
then asked for the vertical height of the picture - this enables you to
enlarge a small picture to fill the whole screen.
        I have also included a new option - to select between a shape file
(designed using the Shaper) and an ordinary screen file. If you choose to
map on to a screen designed using an art program (such as the Electron
User's Elkpaint), then all colours except Colour 0 will be treated as
foreground. However, bear in mind that a screen file will only work in its
original Mode, and will use up a lot of disc space. It can be possible,
using the mapper to change the Mode of a  screen file, by simply mapping
it on to a large box filling the whole screen.
        Again memory is very tight if you are running the Mapper from
ADFS, so you may have to cut down on the REM statements at the start if
you make any changes. I have unfortunately had to join many of the lines
together to make it run.
        Acorn Computing published four sample shape files. These are saved
in a directory called "S", under the filenames "Distanc", "Hrglass",
"Wobble", and "Wrap". You might like to try them out using the title
screens from a few games - most Superior Software title screens are in
Mode 5, and have a vertical length of 208 pixels. Best results are usually
achieved using Mode 1 as a destination mode (though this does take
considerably longer than Mode 5). Acorn Computing illustrated their
article by mapping the title screen from Barbarian on to the shape of a
Polo mint!
                                                     Matthew Ford

00000000  81 2e 2e 2e 2e 2e 2e 2e  2e 2e 2a 2e 2e 2e 2e 2e  |..........*.....|
00000010  2e 2e 2a 2e 2e 2e 2e 2e  2e 2e 2a 2e 2e 2e 2e 2e  |..*.......*.....|
*
00000040  2e 2e 2a 2e 2e 2e 2e 2e  2e 2e 2a 2e 3c 0d 20 20  |..*.......*.<.  |
00000050  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00000060  20 20 20 20 20 50 20 69  20 78 20 65 20 6c 20 20  |     P i x e l  |
00000070  20 4d 20 61 20 70 20 70  20 65 20 72 0d 0d 20 20  | M a p p e r..  |
00000080  20 20 20 20 20 41 6e 79  6f 6e 65 20 77 68 6f 20  |     Anyone who |
00000090  63 6f 6e 74 69 6e 75 65  64 20 74 68 65 69 72 20  |continued their |
000000a0  4d 69 63 72 6f 1a 20 55  73 65 72 1a 20 73 75 62  |Micro. User. sub|
000000b0  73 63 72 69 70 74 69 6f  6e 20 6c 6f 6e 67 20 65  |scription long e|
000000c0  6e 6f 75 67 68 20 74 6f  0d 73 65 65 1a 20 74 68  |nough to.see. th|
000000d0  65 1a 20 63 68 61 6e 67  65 20 6f 66 20 6e 61 6d  |e. change of nam|
000000e0  65 20 74 6f 20 22 41 63  6f 72 6e 1a 20 43 6f 6d  |e to "Acorn. Com|
000000f0  70 75 74 69 6e 67 22 1a  20 6d 69 67 68 74 1a 20  |puting". might. |
00000100  68 61 76 65 1a 20 6e 6f  74 69 63 65 64 1a 20 74  |have. noticed. t|
00000110  68 61 74 20 0d 22 50 69  78 65 6c 20 4d 61 70 70  |hat ."Pixel Mapp|
00000120  65 72 22 2c 20 61 1a 20  70 72 6f 67 72 61 6d 20  |er", a. program |
00000130  70 75 62 6c 69 73 68 65  64 20 66 6f 72 20 74 68  |published for th|
00000140  65 20 42 42 43 20 4d 69  63 72 6f 20 69 6e 20 4f  |e BBC Micro in O|
00000150  63 74 6f 62 65 72 2f 4e  6f 76 65 6d 62 65 72 0d  |ctober/November.|
00000160  31 39 39 32 20 64 69 64  20 6e 6f 74 20 77 6f 72  |1992 did not wor|
00000170  6b 1a 20 6f 6e 20 74 68  65 20 45 6c 65 63 74 72  |k. on the Electr|
00000180  6f 6e 2e 20 54 68 69 73  20 77 61 73 20 61 20 73  |on. This was a s|
00000190  68 61 6d 65 2c 20 61 73  20 69 74 20 77 61 73 20  |hame, as it was |
000001a0  61 63 74 75 61 6c 6c 79  20 61 0d 76 65 72 79 20  |actually a.very |
000001b0  63 6c 65 76 65 72 20 70  72 6f 67 72 61 6d 20 74  |clever program t|
000001c0  6f 20 64 69 73 74 6f 72  74 1a 20 70 69 63 74 75  |o distort. pictu|
000001d0  72 65 73 1a 20 69 6e 74  6f 1a 20 76 69 72 74 75  |res. into. virtu|
000001e0  61 6c 6c 79 1a 20 61 6e  79 1a 20 73 68 61 70 65  |ally. any. shape|
000001f0  1a 20 79 6f 75 0d 77 61  6e 74 65 64 2e 20 49 20  |. you.wanted. I |
00000200  68 61 76 65 20 6e 6f 77  20 66 6f 75 6e 64 2c 1a  |have now found,.|
00000210  20 61 6e 64 20 73 6f 72  74 65 64 20 6f 75 74 2c  | and sorted out,|
00000220  20 74 68 65 20 70 72 6f  62 6c 65 6d 20 28 61 20  | the problem (a |
00000230  6d 69 6e 6f 72 20 64 69  66 66 65 72 65 6e 63 65  |minor difference|
00000240  0d 69 6e 20 74 68 65 20  61 64 64 72 65 73 73 20  |.in the address |
00000250  6f 66 20 61 20 6c 6f 6f  6b 2d 75 70 1a 20 74 61  |of a look-up. ta|
00000260  62 6c 65 20 69 6e 20 74  68 65 20 4f 53 20 52 4f  |ble in the OS RO|
00000270  4d 29 2e 20 49 20 68 61  76 65 20 61 6c 73 6f 20  |M). I have also |
00000280  61 64 64 65 64 20 61 20  66 65 77 0d 6e 65 77 20  |added a few.new |
00000290  66 61 63 69 6c 69 74 69  65 73 2c 20 69 6e 63 6c  |facilities, incl|
000002a0  75 64 69 6e 67 20 61 20  73 69 6d 70 6c 65 20 6d  |uding a simple m|
000002b0  65 6e 75 2e 0d 20 20 20  20 20 20 20 54 68 65 20  |enu..       The |
000002c0  70 72 6f 67 72 61 6d 20  69 73 20 69 6e 20 74 77  |program is in tw|
000002d0  6f 1a 20 6d 61 69 6e 20  70 61 72 74 73 2c 20 61  |o. main parts, a|
000002e0  20 53 68 61 70 65 72 20  61 6e 64 20 61 20 4d 61  | Shaper and a Ma|
000002f0  70 70 65 72 2e 20 54 68  65 20 66 69 72 73 74 0d  |pper. The first.|
00000300  69 73 20 62 61 73 69 63  61 6c 6c 79 20 61 20 73  |is basically a s|
00000310  69 6d 70 6c 65 20 61 72  74 20 70 72 6f 67 72 61  |imple art progra|
00000320  6d 2e 1a 20 55 73 69 6e  67 1a 20 74 68 69 73 2c  |m.. Using. this,|
00000330  1a 20 79 6f 75 20 64 65  73 69 67 6e 20 74 68 65  |. you design the|
00000340  20 73 68 61 70 65 20 79  6f 75 0d 77 61 6e 74 20  | shape you.want |
00000350  74 6f 20 66 69 74 20 79  6f 75 72 20 70 69 63 74  |to fit your pict|
00000360  75 72 65 20 69 6e 74 6f  2e 20 54 68 65 6e 20 74  |ure into. Then t|
00000370  68 65 20 4d 61 70 70 65  72 1a 20 77 69 6c 6c 1a  |he Mapper. will.|
00000380  20 63 6f 6e 76 65 72 74  20 79 6f 75 72 20 70 69  | convert your pi|
00000390  63 74 75 72 65 0d 28 77  68 69 63 68 20 63 61 6e  |cture.(which can|
000003a0  20 62 65 20 61 20 73 63  72 65 65 6e 20 66 69 6c  | be a screen fil|
000003b0  65 20 6f 66 20 61 6e 79  20 73 69 7a 65 20 69 6e  |e of any size in|
000003c0  20 61 6e 79 20 67 72 61  70 68 69 63 73 20 6d 6f  | any graphics mo|
000003d0  64 65 29 20 6c 69 6e 65  2d 62 79 2d 6c 69 6e 65  |de) line-by-line|
000003e0  0d 74 6f 20 66 69 74 20  74 68 65 20 73 68 61 70  |.to fit the shap|
000003f0  65 20 79 6f 75 20 64 65  73 69 67 6e 65 64 2e 0d  |e you designed..|
00000400  20 20 20 20 20 20 20 54  68 65 1a 20 53 68 61 70  |       The. Shap|
00000410  65 72 1a 20 69 73 1a 20  64 69 66 66 65 72 65 6e  |er. is. differen|
00000420  74 1a 20 66 72 6f 6d 1a  1a 20 6d 6f 73 74 1a 20  |t. from.. most. |
00000430  61 72 74 1a 20 70 72 6f  67 72 61 6d 73 2c 1a 20  |art. programs,. |
00000440  61 73 1a 20 69 74 1a 20  69 73 0d 6f 62 6a 65 63  |as. it. is.objec|
00000450  74 2d 6f 72 69 65 6e 74  61 74 65 64 2e 20 54 68  |t-orientated. Th|
00000460  69 73 20 6d 65 61 6e 73  20 74 68 61 74 20 69 74  |is means that it|
00000470  73 1a 20 66 69 6c 65 73  1a 20 61 72 65 1a 20 73  |s. files. are. s|
00000480  74 6f 72 65 64 1a 20 61  73 20 61 20 73 65 72 69  |tored. as a seri|
00000490  65 73 20 6f 66 0d 73 68  61 70 65 73 1a 20 69 6e  |es of.shapes. in|
000004a0  20 74 68 65 20 6f 72 64  65 72 20 79 6f 75 20 64  | the order you d|
000004b0  72 65 77 20 74 68 65 6d  2c 20 72 61 74 68 65 72  |rew them, rather|
000004c0  20 74 68 61 6e 1a 20 61  6e 1a 20 6f 72 64 69 6e  | than. an. ordin|
000004d0  61 72 79 1a 20 70 69 78  65 6c 2d 62 61 73 65 64  |ary. pixel-based|
000004e0  0d 73 63 72 65 65 6e 20  66 69 6c 65 2e 1a 20 54  |.screen file.. T|
000004f0  68 69 73 1a 20 68 61 73  1a 20 74 68 65 1a 20 61  |his. has. the. a|
00000500  64 76 61 6e 74 61 67 65  20 74 68 61 74 20 74 68  |dvantage that th|
00000510  65 20 66 69 6c 65 73 20  61 72 65 20 76 65 72 79  |e files are very|
00000520  20 73 6d 61 6c 6c 2c 20  61 6e 64 0d 61 6c 73 6f  | small, and.also|
00000530  20 74 68 65 79 20 63 61  6e 20 62 65 20 72 65 2d  | they can be re-|
00000540  64 72 61 77 6e 20 69 6e  1a 20 61 6e 79 1a 20 73  |drawn in. any. s|
00000550  63 72 65 65 6e 20 6d 6f  64 65 2e 20 48 6f 77 65  |creen mode. Howe|
00000560  76 65 72 2c 20 69 74 20  64 6f 65 73 20 6d 65 61  |ver, it does mea|
00000570  6e 20 74 68 61 74 0d 6d  69 73 74 61 6b 65 73 1a  |n that.mistakes.|
00000580  20 63 61 6e 1a 20 62 65  1a 20 64 69 66 66 69 63  | can. be. diffic|
00000590  75 6c 74 1a 20 74 6f 20  63 6f 72 72 65 63 74 2e  |ult. to correct.|
000005a0  20 46 6f 72 20 74 68 69  73 1a 20 72 65 61 73 6f  | For this. reaso|
000005b0  6e 2c 1a 20 74 68 65 1a  20 6f 72 69 67 69 6e 61  |n,. the. origina|
000005c0  6c 0d 76 65 72 73 69 6f  6e 20 68 61 64 20 6e 6f  |l.version had no|
000005d0  20 66 61 63 69 6c 69 74  79 20 74 6f 1a 20 72 65  | facility to. re|
000005e0  2d 6c 6f 61 64 1a 20 61  1a 20 73 61 76 65 64 1a  |-load. a. saved.|
000005f0  20 73 68 61 70 65 1a 20  66 69 6c 65 2c 20 6f 72  | shape. file, or|
00000600  20 74 6f 20 64 65 6c 65  74 65 20 61 0d 73 68 61  | to delete a.sha|
00000610  70 65 20 64 72 61 77 6e  20 69 6e 20 74 68 65 20  |pe drawn in the |
00000620  77 72 6f 6e 67 20 70 6c  61 63 65 20 28 69 74 20  |wrong place (it |
00000630  77 61 73 20 61 73 73 75  6d 65 64 20 74 68 61 74  |was assumed that|
00000640  1a 20 74 68 65 1a 20 73  68 61 70 65 73 1a 20 75  |. the. shapes. u|
00000650  73 65 64 20 66 6f 72 0d  74 68 65 1a 20 50 69 78  |sed for.the. Pix|
00000660  65 6c 1a 20 4d 61 70 70  65 72 20 77 6f 75 6c 64  |el. Mapper would|
00000670  20 62 65 20 76 65 72 79  20 73 69 6d 70 6c 65 2c  | be very simple,|
00000680  20 73 6f 20 74 68 65 72  65 20 77 6f 75 6c 64 20  | so there would |
00000690  62 65 20 6e 6f 74 68 69  6e 67 20 74 6f 20 6c 6f  |be nothing to lo|
000006a0  73 65 0d 62 79 1a 20 63  6c 65 61 72 69 6e 67 1a  |se.by. clearing.|
000006b0  20 74 68 65 1a 20 73 63  72 65 65 6e 1a 20 61 6e  | the. screen. an|
000006c0  64 1a 20 73 74 61 72 74  69 6e 67 1a 20 61 67 61  |d. starting. aga|
000006d0  69 6e 1a 20 69 66 1a 20  74 68 65 1a 20 72 65 73  |in. if. the. res|
000006e0  75 6c 74 1a 20 77 61 73  1a 20 6e 6f 74 0d 73 61  |ult. was. not.sa|
000006f0  74 69 73 66 61 63 74 6f  72 79 29 2e 20 49 20 68  |tisfactory). I h|
00000700  61 76 65 1a 20 61 64 64  65 64 1a 20 74 68 65 73  |ave. added. thes|
00000710  65 1a 20 74 77 6f 20 66  61 63 69 6c 69 74 69 65  |e. two facilitie|
00000720  73 2c 20 62 75 74 20 75  6e 66 6f 72 74 75 6e 61  |s, but unfortuna|
00000730  74 65 6c 79 20 74 68 65  0d 70 72 6f 67 72 61 6d  |tely the.program|
00000740  20 77 6f 75 6c 64 20 6e  6f 74 20 72 75 6e 20 77  | would not run w|
00000750  69 74 68 20 74 68 65 1a  20 41 44 46 53 20 69 6e  |ith the. ADFS in|
00000760  20 4d 6f 64 65 20 31 20  61 73 20 69 74 20 77 61  | Mode 1 as it wa|
00000770  73 20 73 75 70 70 6f 73  65 64 20 74 6f 20 28 6d  |s supposed to (m|
00000780  6f 73 74 0d 42 42 43 20  4d 69 63 72 6f 20 6f 77  |ost.BBC Micro ow|
00000790  6e 65 72 73 20 75 73 65  20 74 68 65 20 44 46 53  |ners use the DFS|
000007a0  2c 20 77 68 69 63 68 1a  20 68 61 73 20 50 41 47  |, which. has PAG|
000007b0  45 20 73 65 74 20 61 74  20 26 31 39 30 30 2c 20  |E set at &1900, |
000007c0  6e 6f 74 20 26 31 44 30  30 29 2e 20 54 6f 0d 67  |not &1D00). To.g|
000007d0  65 74 20 72 6f 75 6e 64  20 74 68 69 73 2c 20 49  |et round this, I|
000007e0  20 68 61 76 65 20 70 72  6f 76 69 64 65 64 20 74  | have provided t|
000007f0  68 65 20 6f 70 74 69 6f  6e 1a 20 6f 66 20 72 75  |he option. of ru|
00000800  6e 6e 69 6e 67 20 69 74  20 69 6e 20 65 69 74 68  |nning it in eith|
00000810  65 72 20 4d 6f 64 65 20  34 0d 6f 72 20 35 20 28  |er Mode 4.or 5 (|
00000820  77 69 74 68 20 6f 62 76  69 6f 75 73 20 61 64 76  |with obvious adv|
00000830  61 6e 74 61 67 65 73 2f  64 72 61 77 62 61 63 6b  |antages/drawback|
00000840  73 29 2e 20 0d 20 20 20  20 20 20 20 54 68 65 20  |s). .       The |
00000850  63 6f 6e 74 72 6f 6c 73  20 66 6f 72 20 74 68 65  |controls for the|
00000860  20 73 68 61 70 65 72 20  61 72 65 20 61 73 20 66  | shaper are as f|
00000870  6f 6c 6c 6f 77 73 3a 0d  20 20 20 20 20 47 1a 3a  |ollows:.     G.:|
00000880  20 4c 6f 63 6b 20 63 75  72 73 6f 72 20 74 6f 20  | Lock cursor to |
00000890  67 72 69 64 20 20 20 20  20 7d 20 79 6f 75 20 61  |grid     } you a|
000008a0  72 65 20 67 69 76 65 6e  20 74 68 65 20 6f 70 74  |re given the opt|
000008b0  69 6f 6e 20 74 6f 20 63  68 6f 6f 73 65 20 74 68  |ion to choose th|
000008c0  65 0d 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |e.              |
000008d0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
000008e0  20 20 20 7d 20 73 69 7a  65 20 6f 66 20 20 74 68  |   } size of  th|
000008f0  65 20 67 72 69 64 2c 20  61 6e 64 20 20 77 68 65  |e grid, and  whe|
00000900  74 68 65 72 20 6f 72 20  6e 6f 74 20 0d 20 20 20  |ther or not .   |
00000910  20 20 4e 20 3a 20 55 6e  6c 6f 63 6b 20 63 75 72  |  N : Unlock cur|
00000920  73 6f 72 20 66 72 6f 6d  20 67 72 69 64 20 7d 20  |sor from grid } |
00000930  74 6f 20 64 69 73 70 6c  61 79 20 69 74 2c 20 77  |to display it, w|
00000940  68 65 6e 20 74 68 65 20  70 72 6f 67 72 61 6d 20  |hen the program |
00000950  69 73 20 72 75 6e 2e 0d  20 20 20 20 20 4f 20 3a  |is run..     O :|
00000960  20 52 65 74 75 72 6e 20  63 75 72 73 6f 72 20 74  | Return cursor t|
00000970  6f 20 6f 72 69 67 69 6e  0d 20 20 20 20 20 46 20  |o origin.     F |
00000980  3a 20 53 65 6c 65 63 74  20 66 6f 72 65 67 72 6f  |: Select foregro|
00000990  75 6e 64 20 63 6f 6c 6f  75 72 0d 20 20 20 20 20  |und colour.     |
000009a0  42 20 3a 20 53 65 6c 65  63 74 20 62 61 63 6b 67  |B : Select backg|
000009b0  72 6f 75 6e 64 20 63 6f  6c 6f 75 72 20 28 65 72  |round colour (er|
000009c0  61 73 65 29 0d 20 20 20  20 20 54 20 3a 20 44 72  |ase).     T : Dr|
000009d0  61 77 20 74 72 69 61 6e  67 6c 65 20 28 75 73 65  |aw triangle (use|
000009e0  20 73 70 61 63 65 20 62  61 72 20 74 6f 20 66 69  | space bar to fi|
000009f0  78 20 6f 74 68 65 72 20  74 77 6f 20 70 6f 69 6e  |x other two poin|
00000a00  74 73 29 0d 20 20 20 20  20 52 20 3a 20 44 72 61  |ts).     R : Dra|
00000a10  77 20 72 65 63 74 61 6e  67 6c 65 20 28 75 73 65  |w rectangle (use|
00000a20  20 73 70 61 63 65 20 62  61 72 20 74 6f 20 66 69  | space bar to fi|
00000a30  78 20 6f 70 70 6f 73 69  74 65 20 70 6f 69 6e 74  |x opposite point|
00000a40  29 0d 20 20 20 20 20 43  20 3a 20 4d 61 6b 65 20  |).     C : Make |
00000a50  6e 2d 73 69 64 65 64 20  70 6f 6c 79 67 6f 6e 20  |n-sided polygon |
00000a60  28 75 73 65 20 61 20 6c  61 72 67 65 20 76 61 6c  |(use a large val|
00000a70  75 65 20 74 6f 20 64 72  61 77 20 61 20 63 69 72  |ue to draw a cir|
00000a80  63 6c 65 29 0d 20 53 70  61 63 65 20 3a 20 46 69  |cle). Space : Fi|
00000a90  78 20 63 6f 72 6e 65 72  20 6f 66 20 6f 62 6a 65  |x corner of obje|
00000aa0  63 74 0d 41 72 72 6f 77  20 6b 65 79 73 20 3a 20  |ct.Arrow keys : |
00000ab0  4d 6f 76 65 20 63 75 72  73 6f 72 0d 20 20 20 20  |Move cursor.    |
00000ac0  2b 53 68 69 66 74 20 3a  20 4d 6f 76 65 20 63 75  |+Shift : Move cu|
00000ad0  72 73 6f 72 20 66 61 73  74 65 72 20 20 20 20 20  |rsor faster     |
00000ae0  20 20 7d 20 6e 6f 74 20  69 66 20 63 75 72 73 6f  |  } not if curso|
00000af0  72 20 69 73 0d 20 20 2b  43 6f 6e 74 72 6f 6c 20  |r is.  +Control |
00000b00  3a 20 4d 6f 76 65 20 63  75 72 73 6f 72 20 66 61  |: Move cursor fa|
00000b10  73 74 65 72 20 73 74 69  6c 6c 20 7d 20 6c 6f 63  |ster still } loc|
00000b20  6b 65 64 20 74 6f 20 67  72 69 64 2e 0d 20 20 20  |ked to grid..   |
00000b30  20 20 51 20 3a 20 51 75  69 74 20 74 68 65 20 70  |  Q : Quit the p|
00000b40  72 6f 67 72 61 6d 20 28  72 65 74 75 72 6e 20 74  |rogram (return t|
00000b50  6f 20 6d 65 6e 75 29 0d  46 75 6e 63 2f 2c 20 3a  |o menu).Func/, :|
00000b60  20 4c 6f 61 64 20 73 68  61 70 65 20 66 69 6c 65  | Load shape file|
00000b70  0d 46 75 6e 63 2f 2e 20  3a 20 53 61 76 65 20 73  |.Func/. : Save s|
00000b80  68 61 70 65 20 66 69 6c  65 0d 53 68 69 66 74 2f  |hape file.Shift/|
00000b90  44 3a 20 44 65 6c 65 74  65 20 6c 61 73 74 20 6f  |D: Delete last o|
00000ba0  62 6a 65 63 74 20 64 72  61 77 6e 20 28 6f 72 20  |bject drawn (or |
00000bb0  63 61 6e 63 65 6c 20 63  75 72 72 65 6e 74 20 6f  |cancel current o|
00000bc0  6e 65 29 0d 45 73 63 61  70 65 20 3a 20 43 61 6e  |ne).Escape : Can|
00000bd0  63 65 6c 20 63 75 72 72  65 6e 74 20 6f 70 65 72  |cel current oper|
00000be0  61 74 69 6f 6e 0d 20 20  20 20 20 4c 20 3a 20 44  |ation.     L : D|
00000bf0  69 73 70 6c 61 79 20 6e  75 6d 62 65 72 20 6f 66  |isplay number of|
00000c00  20 6f 62 6a 65 63 74 73  20 6c 65 66 74 1a 20 28  | objects left. (|
00000c10  74 68 69 73 20 77 61 73  20 69 6e 63 6c 75 64 65  |this was include|
00000c20  64 20 62 65 63 61 75 73  65 20 6d 65 6d 6f 72 79  |d because memory|
00000c30  0d 20 20 20 20 20 20 20  20 20 20 77 61 73 1a 20  |.          was. |
00000c40  76 65 72 79 1a 20 74 69  67 68 74 1a 20 69 6e 20  |very. tight. in |
00000c50  74 68 65 20 6f 72 69 67  69 6e 61 6c 20 4d 6f 64  |the original Mod|
00000c60  65 20 31 1a 20 76 65 72  73 69 6f 6e 2c 1a 20 73  |e 1. version,. s|
00000c70  6f 1a 20 6f 6e 6c 79 1a  20 31 35 0d 20 20 20 20  |o. only. 15.    |
00000c80  20 20 20 20 20 20 6f 62  6a 65 63 74 73 1a 20 77  |      objects. w|
00000c90  65 72 65 1a 20 61 6c 6c  6f 77 65 64 2e 1a 20 4e  |ere. allowed.. N|
00000ca0  6f 77 20 74 68 65 72 65  20 69 73 20 72 6f 6f 6d  |ow there is room|
00000cb0  20 66 6f 72 20 61 62 6f  75 74 20 33 30 30 2c 20  | for about 300, |
00000cc0  73 6f 20 79 6f 75 0d 20  20 20 20 20 20 20 20 20  |so you.         |
00000cd0  20 73 68 6f 75 6c 64 6e  27 74 20 6e 65 65 64 20  | shouldn't need |
00000ce0  74 6f 20 75 73 65 20 74  68 69 73 20 6f 70 74 69  |to use this opti|
00000cf0  6f 6e 29 0d 0d 20 20 20  20 20 20 20 20 54 68 65  |on)..        The|
00000d00  1a 20 6f 70 65 72 61 74  69 6f 6e 1a 20 6f 66 1a  |. operation. of.|
00000d10  20 74 68 65 20 4d 61 70  70 65 72 20 70 72 6f 67  | the Mapper prog|
00000d20  72 61 6d 20 69 73 20 66  61 69 72 6c 79 20 73 65  |ram is fairly se|
00000d30  6c 66 2d 65 78 70 6c 61  6e 61 74 6f 72 79 2e 0d  |lf-explanatory..|
00000d40  59 6f 75 20 61 72 65 20  66 69 72 73 74 20 61 73  |You are first as|
00000d50  6b 65 64 1a 20 74 6f 1a  20 65 6e 74 65 72 1a 20  |ked. to. enter. |
00000d60  74 68 65 1a 20 4d 6f 64  65 1a 20 6f 66 1a 20 74  |the. Mode. of. t|
00000d70  68 65 20 73 63 72 65 65  6e 20 66 69 6c 65 20 79  |he screen file y|
00000d80  6f 75 20 77 61 6e 74 20  74 6f 0d 64 69 73 74 6f  |ou want to.disto|
00000d90  72 74 2e 20 49 6e 20 73  6f 6d 65 20 63 61 73 65  |rt. In some case|
00000da0  73 2c 20 79 6f 75 20 63  61 6e 20 61 6c 73 6f 20  |s, you can also |
00000db0  73 65 6c 65 63 74 20 74  68 65 20 64 65 73 74 69  |select the desti|
00000dc0  6e 61 74 69 6f 6e 1a 20  6d 6f 64 65 2e 20 59 6f  |nation. mode. Yo|
00000dd0  75 20 61 72 65 0d 74 68  65 6e 20 61 73 6b 65 64  |u are.then asked|
00000de0  20 66 6f 72 20 74 68 65  20 76 65 72 74 69 63 61  | for the vertica|
00000df0  6c 20 68 65 69 67 68 74  20 6f 66 20 74 68 65 20  |l height of the |
00000e00  70 69 63 74 75 72 65 20  2d 20 74 68 69 73 1a 20  |picture - this. |
00000e10  65 6e 61 62 6c 65 73 1a  20 79 6f 75 1a 20 74 6f  |enables. you. to|
00000e20  0d 65 6e 6c 61 72 67 65  20 61 20 73 6d 61 6c 6c  |.enlarge a small|
00000e30  20 70 69 63 74 75 72 65  20 74 6f 20 66 69 6c 6c  | picture to fill|
00000e40  20 74 68 65 20 77 68 6f  6c 65 20 73 63 72 65 65  | the whole scree|
00000e50  6e 2e 20 0d 20 20 20 20  20 20 20 20 49 20 68 61  |n. .        I ha|
00000e60  76 65 20 61 6c 73 6f 20  69 6e 63 6c 75 64 65 64  |ve also included|
00000e70  20 61 20 6e 65 77 20 6f  70 74 69 6f 6e 20 2d 20  | a new option - |
00000e80  74 6f 20 73 65 6c 65 63  74 20 62 65 74 77 65 65  |to select betwee|
00000e90  6e 20 61 20 73 68 61 70  65 20 66 69 6c 65 0d 28  |n a shape file.(|
00000ea0  64 65 73 69 67 6e 65 64  20 75 73 69 6e 67 20 74  |designed using t|
00000eb0  68 65 20 53 68 61 70 65  72 29 20 61 6e 64 1a 20  |he Shaper) and. |
00000ec0  61 6e 20 6f 72 64 69 6e  61 72 79 20 73 63 72 65  |an ordinary scre|
00000ed0  65 6e 20 66 69 6c 65 2e  20 49 66 20 79 6f 75 20  |en file. If you |
00000ee0  63 68 6f 6f 73 65 20 74  6f 0d 6d 61 70 20 6f 6e  |choose to.map on|
00000ef0  20 74 6f 20 61 20 73 63  72 65 65 6e 20 64 65 73  | to a screen des|
00000f00  69 67 6e 65 64 1a 20 75  73 69 6e 67 1a 20 61 6e  |igned. using. an|
00000f10  1a 20 61 72 74 1a 20 70  72 6f 67 72 61 6d 20 28  |. art. program (|
00000f20  73 75 63 68 20 61 73 20  74 68 65 20 45 6c 65 63  |such as the Elec|
00000f30  74 72 6f 6e 0d 55 73 65  72 27 73 1a 20 45 6c 6b  |tron.User's. Elk|
00000f40  70 61 69 6e 74 29 2c 1a  20 74 68 65 6e 1a 20 61  |paint),. then. a|
00000f50  6c 6c 20 63 6f 6c 6f 75  72 73 20 65 78 63 65 70  |ll colours excep|
00000f60  74 20 43 6f 6c 6f 75 72  20 30 20 77 69 6c 6c 20  |t Colour 0 will |
00000f70  62 65 1a 20 74 72 65 61  74 65 64 1a 20 61 73 0d  |be. treated. as.|
00000f80  66 6f 72 65 67 72 6f 75  6e 64 2e 20 48 6f 77 65  |foreground. Howe|
00000f90  76 65 72 2c 20 62 65 61  72 20 69 6e 20 6d 69 6e  |ver, bear in min|
00000fa0  64 20 74 68 61 74 20 61  20 73 63 72 65 65 6e 20  |d that a screen |
00000fb0  66 69 6c 65 20 77 69 6c  6c 20 6f 6e 6c 79 20 77  |file will only w|
00000fc0  6f 72 6b 20 69 6e 20 69  74 73 0d 6f 72 69 67 69  |ork in its.origi|
00000fd0  6e 61 6c 20 4d 6f 64 65  2c 20 61 6e 64 20 77 69  |nal Mode, and wi|
00000fe0  6c 6c 1a 20 75 73 65 1a  20 75 70 1a 20 61 20 6c  |ll. use. up. a l|
00000ff0  6f 74 20 6f 66 20 64 69  73 63 20 73 70 61 63 65  |ot of disc space|
00001000  2e 20 49 74 20 63 61 6e  20 62 65 20 70 6f 73 73  |. It can be poss|
00001010  69 62 6c 65 2c 0d 75 73  69 6e 67 20 74 68 65 20  |ible,.using the |
00001020  6d 61 70 70 65 72 20 74  6f 20 63 68 61 6e 67 65  |mapper to change|
00001030  20 74 68 65 20 4d 6f 64  65 1a 20 6f 66 1a 20 61  | the Mode. of. a|
00001040  20 20 73 63 72 65 65 6e  20 66 69 6c 65 2c 20 62  |  screen file, b|
00001050  79 20 73 69 6d 70 6c 79  20 6d 61 70 70 69 6e 67  |y simply mapping|
00001060  0d 69 74 20 6f 6e 20 74  6f 20 61 20 6c 61 72 67  |.it on to a larg|
00001070  65 20 62 6f 78 20 66 69  6c 6c 69 6e 67 20 74 68  |e box filling th|
00001080  65 20 77 68 6f 6c 65 20  73 63 72 65 65 6e 2e 0d  |e whole screen..|
00001090  20 20 20 20 20 20 20 20  41 67 61 69 6e 1a 20 6d  |        Again. m|
000010a0  65 6d 6f 72 79 1a 20 69  73 1a 20 76 65 72 79 1a  |emory. is. very.|
000010b0  20 74 69 67 68 74 1a 20  69 66 20 79 6f 75 20 61  | tight. if you a|
000010c0  72 65 20 72 75 6e 6e 69  6e 67 20 74 68 65 20 4d  |re running the M|
000010d0  61 70 70 65 72 20 66 72  6f 6d 0d 41 44 46 53 2c  |apper from.ADFS,|
000010e0  20 73 6f 20 79 6f 75 20  6d 61 79 20 68 61 76 65  | so you may have|
000010f0  20 74 6f 1a 20 63 75 74  1a 20 64 6f 77 6e 1a 20  | to. cut. down. |
00001100  6f 6e 20 74 68 65 20 52  45 4d 20 73 74 61 74 65  |on the REM state|
00001110  6d 65 6e 74 73 20 61 74  20 74 68 65 20 73 74 61  |ments at the sta|
00001120  72 74 20 69 66 0d 79 6f  75 20 6d 61 6b 65 20 61  |rt if.you make a|
00001130  6e 79 20 63 68 61 6e 67  65 73 2e 20 49 20 68 61  |ny changes. I ha|
00001140  76 65 20 75 6e 66 6f 72  74 75 6e 61 74 65 6c 79  |ve unfortunately|
00001150  20 68 61 64 20 74 6f 1a  20 6a 6f 69 6e 1a 20 6d  | had to. join. m|
00001160  61 6e 79 20 6f 66 20 74  68 65 20 6c 69 6e 65 73  |any of the lines|
00001170  0d 74 6f 67 65 74 68 65  72 20 74 6f 20 6d 61 6b  |.together to mak|
00001180  65 20 69 74 20 72 75 6e  2e 0d 20 20 20 20 20 20  |e it run..      |
00001190  20 20 41 63 6f 72 6e 20  43 6f 6d 70 75 74 69 6e  |  Acorn Computin|
000011a0  67 20 70 75 62 6c 69 73  68 65 64 20 66 6f 75 72  |g published four|
000011b0  20 73 61 6d 70 6c 65 20  73 68 61 70 65 20 66 69  | sample shape fi|
000011c0  6c 65 73 2e 20 54 68 65  73 65 20 61 72 65 20 73  |les. These are s|
000011d0  61 76 65 64 0d 69 6e 1a  20 61 20 64 69 72 65 63  |aved.in. a direc|
000011e0  74 6f 72 79 20 63 61 6c  6c 65 64 20 22 53 22 2c  |tory called "S",|
000011f0  1a 20 75 6e 64 65 72 1a  20 74 68 65 1a 20 66 69  |. under. the. fi|
00001200  6c 65 6e 61 6d 65 73 1a  20 22 44 69 73 74 61 6e  |lenames. "Distan|
00001210  63 22 2c 1a 20 22 48 72  67 6c 61 73 73 22 2c 0d  |c",. "Hrglass",.|
00001220  22 57 6f 62 62 6c 65 22  2c 20 61 6e 64 1a 20 22  |"Wobble", and. "|
00001230  57 72 61 70 22 2e 1a 20  59 6f 75 1a 20 6d 69 67  |Wrap".. You. mig|
00001240  68 74 1a 20 6c 69 6b 65  1a 20 74 6f 1a 20 74 72  |ht. like. to. tr|
00001250  79 20 74 68 65 6d 20 6f  75 74 20 75 73 69 6e 67  |y them out using|
00001260  20 74 68 65 20 74 69 74  6c 65 0d 73 63 72 65 65  | the title.scree|
00001270  6e 73 20 66 72 6f 6d 20  61 20 66 65 77 20 67 61  |ns from a few ga|
00001280  6d 65 73 20 2d 20 6d 6f  73 74 20 53 75 70 65 72  |mes - most Super|
00001290  69 6f 72 1a 20 53 6f 66  74 77 61 72 65 1a 20 74  |ior. Software. t|
000012a0  69 74 6c 65 1a 20 73 63  72 65 65 6e 73 1a 20 61  |itle. screens. a|
000012b0  72 65 20 69 6e 0d 4d 6f  64 65 20 35 2c 20 61 6e  |re in.Mode 5, an|
000012c0  64 20 68 61 76 65 20 61  20 76 65 72 74 69 63 61  |d have a vertica|
000012d0  6c 20 6c 65 6e 67 74 68  20 6f 66 20 32 30 38 20  |l length of 208 |
000012e0  70 69 78 65 6c 73 2e 20  42 65 73 74 20 72 65 73  |pixels. Best res|
000012f0  75 6c 74 73 20 61 72 65  20 75 73 75 61 6c 6c 79  |ults are usually|
00001300  0d 61 63 68 69 65 76 65  64 1a 20 75 73 69 6e 67  |.achieved. using|
00001310  1a 20 4d 6f 64 65 1a 20  31 1a 20 61 73 1a 20 61  |. Mode. 1. as. a|
00001320  1a 20 64 65 73 74 69 6e  61 74 69 6f 6e 1a 20 6d  |. destination. m|
00001330  6f 64 65 1a 20 28 74 68  6f 75 67 68 20 74 68 69  |ode. (though thi|
00001340  73 20 64 6f 65 73 20 74  61 6b 65 0d 63 6f 6e 73  |s does take.cons|
00001350  69 64 65 72 61 62 6c 79  1a 20 6c 6f 6e 67 65 72  |iderably. longer|
00001360  1a 20 74 68 61 6e 1a 20  4d 6f 64 65 1a 20 35 29  |. than. Mode. 5)|
00001370  2e 1a 20 41 63 6f 72 6e  1a 20 43 6f 6d 70 75 74  |.. Acorn. Comput|
00001380  69 6e 67 1a 20 69 6c 6c  75 73 74 72 61 74 65 64  |ing. illustrated|
00001390  20 74 68 65 69 72 0d 61  72 74 69 63 6c 65 20 62  | their.article b|
000013a0  79 20 6d 61 70 70 69 6e  67 20 74 68 65 20 74 69  |y mapping the ti|
000013b0  74 6c 65 20 73 63 72 65  65 6e 20 66 72 6f 6d 20  |tle screen from |
000013c0  42 61 72 62 61 72 69 61  6e 1a 20 6f 6e 1a 20 74  |Barbarian. on. t|
000013d0  6f 1a 20 74 68 65 20 73  68 61 70 65 20 6f 66 20  |o. the shape of |
000013e0  61 0d 50 6f 6c 6f 20 6d  69 6e 74 21 20 0d 20 20  |a.Polo mint! .  |
000013f0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
*
00001420  20 20 20 4d 61 74 74 68  65 77 20 46 6f 72 64 0d  |   Matthew Ford.|
00001430

PixMap/Text.m0

PixMap/Text.m1

PixMap/Text.m2

PixMap/Text.m4

PixMap/Text.m5

Our privacy policy is here.
Last updated: 28 Jul 2024, 23:31 UTC
Website designed by .
