Filename: PadSrce
Read OK:
File size: 0A98 bytes
Load address: FFFF1A00
Exec address: FFFF8023
Duplicates

There are 3 duplicate copies of this file in the archive:

File contents
   10REM Cumana Touch Pad Utility
   20REM By Carl Dunkley
   30REM (c) The Micro User
   40MODE4
   50VDU23,1,0;0;0;0;0;
   60PROCassemble
   70PROCdemo
   80END
   90:
  100DEFPROCdemo
  110xscale=1280/160
  120PROCreset
  130REPEAT
  140PROCdraw
  150UNTIL0
  160ENDPROC
  170:
  180DEFPROCreset
  190CLS
  200GCOL3,1
  210PLOT69,0,0
  220draw=FALSE
  230A%=0:B%=0
  240ENDPROC
  250:
  260DEFPROCdraw
  270IFINKEY-99PROCreset
  280CALLpad
  290IFU%ORD% draw=TRUE:GCOL0,1
  300IFNOTP% draw=FALSE:GCOL3,1:ENDPROC
  310PLOT69,A%,B%
  320Y%=1024*(999-Y%)/1000
  330X%=1280*X%/1000
  340IFABS(X%-A%)<xscale X%=A%
  350IFABS(Y%-B%)<4 Y%=B%
  360IFdraw DRAWX%,Y% ELSEPLOT69,X%,Y%
  370A%=X%:B%=Y%
  380ENDPROC
  390:
  400DEFPROCassemble
  410osrdch=&FFE0:oswrch=&FFEE
  420osbyte=&FFF4:code=&C00
  430FOR L%=0TO2STEP2
  440P%=code:[OPT L%
  450.pad
  460\clear D%,P%,U%,X% and Y%
  470LDY #&10:JSR clear_var
  480LDY #&40:JSR clear_var
  490LDY #&54:JSR clear_var
  500LDY #&60:JSR clear_var
  510LDY #&64:JSR clear_var
  520\set RS232 input stream
  530LDA #2:LDX #1:LDY #0:JSR osbyte
  540LDA #3:LDX #7:LDY #0:JSR osbyte
  550LDA #27:JSR oswrch
  560LDA #51:JSR oswrch
  570\read unused header bytes
  580JSR osrdch:JSR osrdch
  590\-------------------
  600\read first char
  610JSR read:TAX
  620\read second char
  630JSR read:CMP #12:BEQ set_flags
  640\combine first and second chars
  650CLC
  660.loop0
  670ADC#10:DEX:BNE loop0
  680TAX:JSR osrdch:\ read newline
  690\set P%,U% and D% flags as necessary
  700.set_flags
  710\check pen down?
  720TXA:AND #1:BEQ not_pen
  730LDY #&40:JSR set_var
  740\check for up button pressed
  750.not_pen
  760TXA:AND #8:BEQ not_up
  770LDY #&54:JSR set_var
  780.not_up
  790\check for down button pressed
  800TXA:AND #16:BEQ not_down
  810LDY #&10:JSR set_var
  820.not_down
  830\-------------------
  840\calculate X% and Y%
  850LDX #0:JSR convert
  860LDX #4:JSR convert
  870\re-set input stream
  880LDA #2:LDX #0:LDY #0:JSR osbyte
  890LDA #3:LDX #0:LDY #0:JMP osbyte
  900\-------------------
  910\subroutines
  920\-------------------
  930\convert a 3 char string read from
  940\RS232 port (ie.010,123,999) to a number
  950.convert
  960JSR read:BEQ no_100s
  970TAY:LDA #100:JSR mult
  980.no_100s
  990JSR read:BEQ no_10s
 1000TAY:LDA #10:JSR mult
 1010.no_10s
 1020JSR read:BEQ not_1s
 1030TAY:LDA #1:JSR mult
 1040.not_1s
 1050JMP osrdch:\ read newline + return
 1060\-------------------
 1070\load an integer variable
 1080.clear_var
 1090LDA #0
 1100BEQ load
 1110.set_var
 1120LDA #255
 1130.load
 1140STA&400,Y
 1150STA&401,Y
 1160STA&402,Y
 1170STA&403,Y
 1180RTS
 1190\-------------------
 1200\read RS232 port
 1210.read
 1220JSR osrdch
 1230AND #207
 1240RTS
 1250\-------------------
 1260\multiplication subroutine
 1270.mult
 1280STA&70
 1290.loop1
 1300CLC
 1310LDA &70
 1320ADC &460,X
 1330STA&460,X
 1340BCCno_carry
 1350INC&461,X
 1360.no_carry
 1370DEY:BNEloop1
 1380RTS
 1390\-------------------
 1400]:NEXT
 1410PRINT"Save code? (y/n) ";
 1420REPEAT I%=INSTR("YyNn",GET$)
 1430UNTIL I%:IF I%<3 PROCsave
 1440ENDPROC
 1450:
 1460DEFPROCsave
 1470$&700="SAVE PadCode "+STR$~code+" "+STR$~P%
 1480Y%=7:X%=0:CALL&FFF7:ENDPROC
