   10REM $.LETTS1
   20 MODE3:VDU23,1,0;0;0;0;:VDU14:PRINT''"PRESS <SHIFT> TO SCROLL"''
   30PRINT"PLUS-1 CONVERSION"
   40PRINT"*****************"
   50PRINT"I recently bought a second Elk+1 for my son and the February Issue of EUG"
   60PRINT"came with it and I thought it was time to drop you a line."
   70PRINT
   80PRINT"My system is an Elk+1 with Slogger Master RAM Board, PRES PLUS-2, PLUS-6,"
   90PRINT"PLUS-3/4, and at the moment I building Jafa's Systems Mode 7 adaptor. In"
  100PRINT"ROM I have Slogger's T2P4 and Pineapple Software's PCB and Diagram 2. The"
  110PRINT"Pineapple ROMs are for the Beeb, but both work well with the Elk with just"
  120PRINT"a few differences in the keys used. PCB works in normal (a bit on the slow"
  130PRINT"side) and turbo modes, while Diagram 2 is very limited in normal and turbo"
  140PRINT"modes, but okay in 64k."
  150PRINT
  160PRINT"I have modified my PLUS-1 by fitting a 25-way D-type connector in the top"
  170PRINT"half of the box, above the printer socket. By fitting a short length of"
  180PRINT"ribbon cable with an IDC connector to it and plugging this into the"
  190PRINT"printer socket, a standard IBM PC type printer cable can be used to"
  200PRINT"connect direct to any IBM PC compatible printer. I have sent instructions"
  210PRINT"on how to make this modification in case anyone else would like to try it."
  220PRINT"I think it is much neater and more convenient than the Beeb type cables."
  230PRINT
  240PRINT"(1) Connect approx 3 inches of 26-way ribbon cable to a 26-way IDC"
  250  PRINT"connector. Pin 1 is marked by an inverted ""V"" (SEE Fig.1)."
  260PRINT
  270PRINT"(2) Fit the 25-way D-type connector in the top half of the PLUS-1's case"
  280PRINT"having cut a suitable hole."
  290PRINT
  300PRINT"(3) Solder the ribbon cable to the D-type connector as in the following"
  310PRINT"table:-"
  320PRINT
  330PRINT"ELECTRON                         IBM STYLE PLUG"
  340PRINT
  350PRINT"  PIN                                 PIN"
  360PRINT"   1 --------------------------------- 1 "
  370PRINT"   2 --------------------------------- 19"
  380PRINT"   3 --------------------------------- 2 "
  390PRINT"   4 --------------------------------- 19"
  400PRINT"   5 --------------------------------- 3 "
  410PRINT"   6 --------------------------------- 20"
  420PRINT"   7 --------------------------------- 4 "
  430PRINT"   8 --------------------------------- 20"
  440PRINT"   9 --------------------------------- 5 "
  450PRINT"  10 --------------------------------- 21"
  460PRINT"  11 --------------------------------- 6 "
  470PRINT"  12 --------------------------------- 21"
  480PRINT"  13 --------------------------------- 7 "
  490PRINT"  14 --------------------------------- 22"
  500PRINT"  15 --------------------------------- 8 "
  510PRINT"  16 --------------------------------- 22"
  520PRINT"  17 --------------------------------- 9 "
  530PRINT"  18 --------------------------------- 23"
  540PRINT"  19 --------------------------------- 10"
  550PRINT"  20------------------:"
  560PRINT"  21                  :"
  570PRINT"  22                  :"
  580PRINT"  23                  :--- NOT CONNECTED "
  590PRINT"  24                  :"
  600PRINT"  25                  :"
  610PRINT"  26------------------:"
  620PRINT
  630PRINT
  640 PRINT"(4) Connect the IDC connector to the printer port and reassemble the"
  650PRINT"PLUS-1 case"
  660 PRINT''"G. Peake, British Aerospace, Saudi Arabia."
  670 PRINT"******************************************"
  680 VDU3
  690PRINT''"PLEASE PRESS <SPACE> TO VIEW DIAGRAMS"
  700REPEAT:UNTIL GET$=" "
  710MODE4:VDU23,1,0;0;0;0;:GCOL0,129:CLG:GCOL0,0:COLOUR129:COLOUR0:PROCdouble("Fig. 1",16,1):PRINTTAB(8,6)"1             13"TAB(7,9)"14             25"
  720  B=800:FORA=400TO600STEP16:PLOT69,A,B:PLOT69,A,B-4:NEXT:B=775:FORA=408TO590STEP16:PLOT69,A,B:PLOT69,A,B-4:NEXT
  730   B=600:FORA=400TO600STEP16:PLOT69,A,B:PLOT69,A,B-4:NEXT:B=575: FOR A=400TO600STEP16:PLOT69,A,B:PLOT69,A,B-4:NEXT
  740 PROCdiag
  750PRINTTAB(16,20)"REAR VIEW"TAB(16,21)"_________"TAB(1,25)"PLEASE PRESS <SPACE> FOR NEXT DIAGRAM":REPEAT:UNTIL GET$=" "
  760  CLS:PROCdouble("Fig. 2",16,1):PROCdiag2:PRINTTAB(15,11)"Ribbon cable from"TAB(15,12)"Electron printer plug"TAB(15,13)"to IBM style plug":PRINTTAB(16,23)"SIDE VIEW"TAB(16,24)"_________"TAB(10,28)"PLEASE PRESS <SPACE>"
  770REPEAT:UNTIL GET$=" "
  780CLS:PRINT''''"Please press:-"'''"<M> for menu"''"<P> to print text"''"<F> for next file"
  790 REPEAT:A$=GET$:UNTIL A$="M" OR A$="P" OR A$="F"
  800 IF A$="M" THEN CHAIN"$.MENU"
  810 IF A$="F" THEN CHAIN"$.LETTS2"
  820 MODE3:VDU15:VDU2
  830 GOTO30
  840  END
  850   DEF PROCdouble(A$,K,L)
  860  LOCAL N
  870  A%=135
  880  A%=&A:X%=0:Y%=&A
  890  D=&A00
  900  FOR N=1 TO LEN(A$)
  910  B$=MID$(A$,N,1)
  920  ?D=ASC(B$)
  930  CALL (&FFF1)
  940  VDU23,240,D?1,D?1,D?2,D?2,D?3,D?3,D?4,D?4
  950  VDU23,241,D?5,D?5,D?6,D?6,D?7,D?7,D?8,D?8
  960  PRINTTAB(K+N,L);CHR$240;TAB(K+N,L+1);CHR$241
  970  NEXT N
  980  ENDPROC
  990 DEF PROCdiag
 1000 MOVE376,816
 1010 DRAW616,816
 1020 DRAW596,756
 1030 MOVE376,816
 1040 DRAW396,756
 1050 DRAW596,756
 1060 MOVE360,832
 1070 DRAW632,832
 1080 DRAW632,744
 1090 DRAW360,744
 1100 DRAW360,828
 1110 DRAW360,832
 1120 MOVE360,612
 1130 DRAW632,612
 1140 DRAW632,556
 1150 DRAW360,556
 1160 DRAW360,612
 1170 DRAW360,612
 1180 MOVE40,592
 1190 DRAW360,592
 1200 MOVE632,592
 1210 DRAW920,592
 1220 DRAW920,832
 1230 DRAW908,844
 1240 DRAW40,844
 1250 MOVE40,576
 1260 DRAW360,576
 1270 MOVE632,576
 1280 DRAW920,576
 1290 DRAW920,592
 1300 DRAW920,500
 1310 DRAW904,484
 1320 DRAW40,484
 1330 MOVE580,616
 1340 DRAW592,652
 1350 DRAW604,616
 1360 MOVE296,816
 1370 DRAW396,800
 1380 MOVE692,816
 1390 DRAW596,804
 1400 MOVE692,720
 1410 DRAW588,764
 1420 MOVE296,720
 1430 DRAW404,764
 1440 ENDPROC
 1450DEF PROCdiag2
 1460MOVE1024,804
 1470DRAW296,804
 1480DRAW276,792
 1490DRAW272,780
 1500DRAW272,768
 1510DRAW236,768
 1520DRAW236,692
 1530DRAW272,692
 1540DRAW272,512
 1550DRAW236,512
 1560DRAW236,440
 1570DRAW272,440
 1580DRAW272,364
 1590DRAW280,352
 1600DRAW292,348
 1610DRAW1024,348
 1620MOVE272,776
 1630DRAW272,408
 1640MOVE244,440
 1650DRAW244,404
 1660DRAW224,396
 1670DRAW196,520
 1680DRAW304,520
 1690DRAW344,576
 1700DRAW344,700
 1710DRAW272,756
 1720DRAW272,744
 1730DRAW336,696
 1740DRAW336,580
 1750DRAW300,528
 1760DRAW184,528
 1770DRAW216,384
 1780DRAW256,400
 1790DRAW256,440
 1800MOVE384,652
 1810DRAW368,636
 1820DRAW460,636
 1830DRAW368,636
 1840DRAW384,620
 1850ENDPROC
