80 column text only file

Eprom Emulator Instructions
===========================
If you don't have access to a ROM  board  with  sideways  RAM socket(s)
but,like me,have access to an Eprom programmer then you could build this
little device.

It need not only be restricted to storing sideways ROM images,but may be
used with other Eprom based devices that need to be continu ally
redeveloped - for example it can also be used with Maplin's UM5100 speech
programmer replay only board,which accepts Eproms onl y.

PARTS...
The circuit diagram shows electrically how to assemble the unit,requiring
the following parts:

1x  62256 SRAM (28 pin)
1x  28 pin DIL socket
1x  SPDT switch
1x  Battery box to hold 3xAA batteries
2x  IN4001 diodes

In addition,it may be useful to have a ZIF socket mounted on the outside
of your case,to reduce the stress on,levering the device in and out.

BENEFITS...
*Switches automatically between battery backup and system powersupply
*Can emulate chips 27128/27256
*Low power CMOS static RAM lasts for weeks on a set of batteries
*Cheaper than EEPROM (around `22)
*Hardware selection of write enable/write protect - gets around protected
 ROM images

BUILD...
1.As the pin outs on a 62256 and 27128 (or 27256) are virtually identical
all but print 1,27,28 can be direct one to one connections .
2.Pin 1,27,28 can be bent out of shape carefully with a pair of pliers -
being carefully not to stress the metal.
3.Solder a small wire to pin 1 and run this under the chip and plug it
into pin 27 of the socket.This becomes address 14.
4.Not CS and Not OE are handled by the Eprom programmer or microprocessor
so can be left aline.
5.Having bent pin 27 out of the way of the small wire you just soldered on
attach this to the centre pole of the switch.The other tw o terminals of
the switch go to pin 14 (GND) and 28 (VCC).
6.Pin 28 also must be split.The two diodes prevent the microprocessor's
power supply from trying to recharge the batteries,and vice  versa.
7.The battery clip and switch should be wire ended and insulated to
prevent shorts in confined spaces and to allow the device to fit
 under the keyboard on a BBC B.

HINTS...
*Below around 2.5v the contents of SRAM may become corrupted or lost
*I found this very useful to test out the suitability of ROM images before
 committing them to EPROM
*I also fitted a ZIF socket to the ashtray (the punch out section on the
 left of the B's keyboard where the speech sockets would go)
 to save having to keep levering the pack in and out
*If you do make a ZIF socket,there may be timing problems with piggy back
 ROMs such as Mega 3.Try connecting a 100nF capacitor from  pin 28 to pin
 14.
*The auto power switching only works if there is a difference of around
 0.6v between the main power supply and the battery pack - he nce the use
 of 4.5v of cells in the battery

FROM...
Robert Sprowson.
(01625) 431067.
Happy soldering!
