File contents
CHKEOF
CHKEOF checks the character in the A register for an end of field marker.
It should be used rather than checking for the character explicitly since it
handles classes of characters rather than single values. Generally, it is
not necessary to detect illegal characters explicitly, it is enough to
detect them as an end of field marker.
On entry: A contains character value to be checked.
On exit: EQ end of field.
CS end of record (EQ also set).
VS illegal character (EQ also set).
A,X,Y preserved.
CHKEOR
CHKEOR checks the character in the A register for an end of record marker.
On entry: A contains character to be checked.
On exit: EQ end of record.
CS end of file (EQ also set).
VS space character (EQ also set).
A,X,Y preserved.
SIZFLD
SIZFLD is provided to allow you to determine the size of a field. First of
all you should locate the field, using one of the field locator routines
such GETFLD, which set up TEMP06. Then call SIZFLD.
On entry: TEMP06 points to the beginning of the
field.
On exit: A,Y have length of field in characters.
EQ zero length field.
X preserved.
TEMP06 preserved.
CMPFLD
CMPFLD compares the values of two fields of the same type, and sets the 6502
flags register like the CMP instruction. TEMP07 points to the first field
(equivalent to the contents of the 6502 A register in the CMP instruction),
and TEMP06 points to the second field. If the two fields being compared are
strings, then wildcards are allowed in the second string.
On entry: A contains the field type: A, N, D or Y; must
be in upper case.
TEMP07 points to field 1.
TEMP06 points to field 2.
On exit: VS error in one of the fields supplied: eg
illegal date; result not valid.
C flag set according to compare.
Z flag set according to compare.
A,X,Y undefined.
SCHFLD
SCHFLD is used to find the number of a field, given its name. It searches
the list of fields in the format file until it finds one that fits the name
given. The name that you specify can obtain wild cards: the single wildcard
"?", and the multiple wildcard "*" are both allowed. SCHFLD will always
return the first field in the format file that fits the name you have given.
You can either continue searching for more fields by using the SCHFLD call
described next.
The name of the field is set up in the 16 byte LWORK area. It should be
terminated by a null, or an end of field marker. It must not be longer then
16 bytes, including the delimiter.
On entry: LWORK contains name to search for; maximum of 16
bytes including delimiter; delimiter null
or end of field marker; wildcards "?" and
"*" valid.
On exit: CS no field found to match the name; A has
error code.
CC field found OK; field number in X.
SCHFLN
After calling SCHFLD, you can search for other fields which also fit the
field specification that you gave given, by making repeated calls to SCHFLN.
Before you call SCHFLN, you must have called SCHFLD first, to start the
sequence, and this call must have successfully found a field.
You can keep calling SCHFLN until the call returns with the Carry flag set
to indicate that it has found no more fields.
On entry: Must have called SCHFLD first, and this must have
returned with the Carry flag clear.
A Contains field number to start searching
from. This should be one more than the last value
that SCHFLD or SCHFLN returned in X.
On exit: CS no more fields found; A has error code (report only
if required).
CC field found; field number in X.
GETWID
GETWID returns the display width of a field, as defined in the format file.
If there is no display width defined, a series of defaults comes into
action.
Display width defined Display width
No display width, Sheet mode 18
No display width, Card mode 0
On entry: X contains number of field for which
width is required.
On exit: CS field doesn't exit.
CC field found; A has display width.
X preserved.
Y undefined.
