To my mind the two most useful expansions of ADFS are a second drive and ADT. I couldn't manage without either. My second drive is a 5.25 in so that I don't mix up my backups. Remember though when buying a 5.25 drive to ask for a BBC B compatable,double sided double density 80 track. There are a number of PC 5.25 drives comming onto the market now and while these will work they start up as soon as you insert the disk. This can be very annoying. As for a 3.5 in drive try to get a double sided double density one. It is unlikely you will be offered a high density one cheaply as these are still used frequently on PCs but this will be changing soon as PC owners dutyfully obey the latest instructions from the PC press to ditch what they recently spent hundreds on and buy the latest gear if they don't want to look naff. Power supplies for second drives must be used. There are a number of ex-PC switched mode supplies around which will have the connecting plug for 5.25 attached. Make sure it is cased as high voltages are generated inside. Also you will need to put a load resistor across the output since switched modes don't like sitting around doing nothing. I use a 15 ohm 10 watt one which I bought from Maplin. I didn't solder it in, I pushed the wires into the output plug on the supply across the 12 volt line. Most switched modes have a legend on the side givingthe output configuration. A supply for a 3.5 in can be an old PC switched mode but you will need to change the plug or get an adaptor. These do exist but can be tricky to find. Most 3.5 in drives don't need very big supplys. 12 volt 1 amp with 5 volt at .5 amp is usually sufficient. Plugs can be bought quite easily but be careful of the configuration. For both the 3.5 in and the 5.25 in drives the middle two pins are 0 volts. The 5 volt and 12 volt go on the out-side but must not be mixed up. 3.5 in 5.25 in . . . . / . . . . \ ---------- |____________| 12v 0v 0v 5v 5v 0v 0v 12v Supply sockets for 3.5 in and 5.25 in drives looking at the sockets on the drives. Well that's my intro to using ADFS. If there is anything which I have left out, or anything which is not clear then SEND IT IN. I wrote this because members asked for it. If there is some aspect of the Elk which is causing problems, ask for help. That's what a user group is for. SEND IT IN. DONT PRESS 'R', THERE IS NO PROGRAM TO RUN
00000000 54 6f 20 6d 79 20 6d 69 6e 64 20 74 68 65 20 74 |To my mind the t| 00000010 77 6f 20 6d 6f 73 74 20 75 73 65 66 75 6c 20 65 |wo most useful e| 00000020 78 70 61 6e 73 69 6f 6e 73 20 6f 66 20 41 44 46 |xpansions of ADF| 00000030 53 20 61 72 65 20 61 20 73 65 63 6f 6e 64 20 0d |S are a second .| 00000040 64 72 69 76 65 20 61 6e 64 20 41 44 54 2e 20 49 |drive and ADT. I| 00000050 20 63 6f 75 6c 64 6e 27 74 20 6d 61 6e 61 67 65 | couldn't manage| 00000060 20 77 69 74 68 6f 75 74 20 65 69 74 68 65 72 2e | without either.| 00000070 20 4d 79 20 73 65 63 6f 6e 64 20 64 72 69 76 65 | My second drive| 00000080 20 0d 69 73 20 61 20 35 2e 32 35 20 69 6e 20 73 | .is a 5.25 in s| 00000090 6f 20 74 68 61 74 20 49 20 64 6f 6e 27 74 20 6d |o that I don't m| 000000a0 69 78 20 75 70 20 6d 79 20 62 61 63 6b 75 70 73 |ix up my backups| 000000b0 2e 20 52 65 6d 65 6d 62 65 72 20 74 68 6f 75 67 |. Remember thoug| 000000c0 68 20 0d 77 68 65 6e 20 62 75 79 69 6e 67 20 61 |h .when buying a| 000000d0 20 35 2e 32 35 20 64 72 69 76 65 20 74 6f 20 61 | 5.25 drive to a| 000000e0 73 6b 20 66 6f 72 20 61 20 42 42 43 20 42 20 63 |sk for a BBC B c| 000000f0 6f 6d 70 61 74 61 62 6c 65 2c 10 64 6f 75 62 6c |ompatable,.doubl| 00000100 65 20 0d 73 69 64 65 64 20 64 6f 75 62 6c 65 20 |e .sided double | 00000110 64 65 6e 73 69 74 79 20 38 30 20 74 72 61 63 6b |density 80 track| 00000120 2e 20 54 68 65 72 65 20 61 72 65 20 61 20 6e 75 |. There are a nu| 00000130 6d 62 65 72 20 6f 66 20 50 43 20 10 35 2e 32 35 |mber of PC .5.25| 00000140 20 0d 64 72 69 76 65 73 20 63 6f 6d 6d 69 6e 67 | .drives comming| 00000150 20 6f 6e 74 6f 20 74 68 65 20 6d 61 72 6b 65 74 | onto the market| 00000160 20 6e 6f 77 20 61 6e 64 20 77 68 69 6c 65 20 74 | now and while t| 00000170 68 65 73 65 20 77 69 6c 6c 20 10 77 6f 72 6b 20 |hese will .work | 00000180 0d 74 68 65 79 20 73 74 61 72 74 20 75 70 20 61 |.they start up a| 00000190 73 20 73 6f 6f 6e 20 61 73 20 79 6f 75 20 69 6e |s soon as you in| 000001a0 73 65 72 74 20 74 68 65 20 64 69 73 6b 2e 20 54 |sert the disk. T| 000001b0 68 69 73 20 63 61 6e 20 62 65 20 10 76 65 72 79 |his can be .very| 000001c0 20 0d 61 6e 6e 6f 79 69 6e 67 2e 20 0d 0d 41 73 | .annoying. ..As| 000001d0 20 66 6f 72 20 61 20 33 2e 35 20 69 6e 20 64 72 | for a 3.5 in dr| 000001e0 69 76 65 20 74 72 79 20 74 6f 20 10 67 65 74 20 |ive try to .get | 000001f0 61 20 64 6f 75 62 6c 65 20 73 69 64 65 64 20 64 |a double sided d| 00000200 6f 75 62 6c 65 20 64 65 6e 73 69 74 79 20 0d 6f |ouble density .o| 00000210 6e 65 2e 20 49 74 20 69 73 20 75 6e 6c 69 6b 65 |ne. It is unlike| 00000220 6c 79 20 79 6f 75 20 77 69 6c 6c 20 10 62 65 20 |ly you will .be | 00000230 6f 66 66 65 72 65 64 20 61 20 68 69 67 68 20 64 |offered a high d| 00000240 65 6e 73 69 74 79 20 6f 6e 65 20 0d 63 68 65 61 |ensity one .chea| 00000250 70 6c 79 20 61 73 20 74 68 65 73 65 20 61 72 65 |ply as these are| 00000260 20 73 74 69 6c 6c 20 75 73 65 64 20 10 66 72 65 | still used .fre| 00000270 71 75 65 6e 74 6c 79 20 6f 6e 20 50 43 73 20 62 |quently on PCs b| 00000280 75 74 20 74 68 69 73 20 0d 77 69 6c 6c 20 62 65 |ut this .will be| 00000290 20 63 68 61 6e 67 69 6e 67 20 73 6f 6f 6e 20 61 | changing soon a| 000002a0 73 20 50 43 20 6f 77 6e 65 72 73 20 10 64 75 74 |s PC owners .dut| 000002b0 79 66 75 6c 6c 79 20 6f 62 65 79 20 74 68 65 20 |yfully obey the | 000002c0 6c 61 74 65 73 74 20 0d 69 6e 73 74 72 75 63 74 |latest .instruct| 000002d0 69 6f 6e 73 20 66 72 6f 6d 20 74 68 65 20 50 43 |ions from the PC| 000002e0 20 70 72 65 73 73 20 74 6f 20 10 64 69 74 63 68 | press to .ditch| 000002f0 20 77 68 61 74 20 74 68 65 79 20 72 65 63 65 6e | what they recen| 00000300 74 6c 79 20 0d 73 70 65 6e 74 20 68 75 6e 64 72 |tly .spent hundr| 00000310 65 64 73 20 6f 6e 20 61 6e 64 20 62 75 79 20 74 |eds on and buy t| 00000320 68 65 20 6c 61 74 65 73 74 20 10 67 65 61 72 20 |he latest .gear | 00000330 69 66 20 74 68 65 79 20 64 6f 6e 27 74 20 77 61 |if they don't wa| 00000340 6e 74 20 0d 74 6f 20 6c 6f 6f 6b 20 6e 61 66 66 |nt .to look naff| 00000350 2e 20 0d 0d 50 6f 77 65 72 20 73 75 70 70 6c 69 |. ..Power suppli| 00000360 65 73 20 66 6f 72 20 73 65 63 6f 6e 64 20 64 72 |es for second dr| 00000370 69 76 65 73 20 6d 75 73 74 20 62 65 20 75 73 65 |ives must be use| 00000380 64 2e 20 54 68 65 72 65 20 61 72 65 20 61 20 0d |d. There are a .| 00000390 6e 75 6d 62 65 72 20 6f 66 20 65 78 2d 50 43 20 |number of ex-PC | 000003a0 73 77 69 74 63 68 65 64 20 6d 6f 64 65 20 73 75 |switched mode su| 000003b0 70 70 6c 69 65 73 20 61 72 6f 75 6e 64 20 77 68 |pplies around wh| 000003c0 69 63 68 20 77 69 6c 6c 20 68 61 76 65 20 0d 74 |ich will have .t| 000003d0 68 65 20 63 6f 6e 6e 65 63 74 69 6e 67 20 70 6c |he connecting pl| 000003e0 75 67 20 66 6f 72 20 35 2e 32 35 20 61 74 74 61 |ug for 5.25 atta| 000003f0 63 68 65 64 2e 20 4d 61 6b 65 20 73 75 72 65 20 |ched. Make sure | 00000400 69 74 20 69 73 20 63 61 73 65 64 20 61 73 20 0d |it is cased as .| 00000410 68 69 67 68 20 10 76 6f 6c 74 61 67 65 73 20 61 |high .voltages a| 00000420 72 65 20 67 65 6e 65 72 61 74 65 64 20 69 6e 73 |re generated ins| 00000430 69 64 65 2e 20 41 6c 73 6f 20 79 6f 75 20 77 69 |ide. Also you wi| 00000440 6c 6c 20 6e 65 65 64 20 74 6f 20 70 75 74 20 0d |ll need to put .| 00000450 61 20 6c 6f 61 64 20 10 72 65 73 69 73 74 6f 72 |a load .resistor| 00000460 20 61 63 72 6f 73 73 20 74 68 65 20 6f 75 74 70 | across the outp| 00000470 75 74 20 73 69 6e 63 65 20 73 77 69 74 63 68 65 |ut since switche| 00000480 64 20 6d 6f 64 65 73 20 64 6f 6e 27 74 20 0d 6c |d modes don't .l| 00000490 69 6b 65 20 10 73 69 74 74 69 6e 67 20 61 72 6f |ike .sitting aro| 000004a0 75 6e 64 20 64 6f 69 6e 67 20 6e 6f 74 68 69 6e |und doing nothin| 000004b0 67 2e 20 49 20 75 73 65 20 61 20 31 35 20 6f 68 |g. I use a 15 oh| 000004c0 6d 20 31 30 20 77 61 74 74 20 6f 6e 65 20 0d 77 |m 10 watt one .w| 000004d0 68 69 63 68 20 49 20 10 62 6f 75 67 68 74 20 66 |hich I .bought f| 000004e0 72 6f 6d 20 4d 61 70 6c 69 6e 2e 20 49 20 64 69 |rom Maplin. I di| 000004f0 64 6e 27 74 20 73 6f 6c 64 65 72 20 69 74 20 69 |dn't solder it i| 00000500 6e 2c 20 49 20 70 75 73 68 65 64 20 0d 74 68 65 |n, I pushed .the| 00000510 20 77 69 72 65 73 20 69 6e 74 6f 20 74 68 65 20 | wires into the | 00000520 6f 75 74 70 75 74 20 70 6c 75 67 20 6f 6e 20 74 |output plug on t| 00000530 68 65 20 73 75 70 70 6c 79 20 61 63 72 6f 73 73 |he supply across| 00000540 20 74 68 65 20 31 32 20 76 6f 6c 74 20 0d 6c 69 | the 12 volt .li| 00000550 6e 65 2e 20 4d 6f 73 74 20 73 77 69 74 63 68 65 |ne. Most switche| 00000560 64 20 6d 6f 64 65 73 20 68 61 76 65 20 61 20 6c |d modes have a l| 00000570 65 67 65 6e 64 20 6f 6e 20 74 68 65 20 73 69 64 |egend on the sid| 00000580 65 20 67 69 76 69 6e 67 10 74 68 65 20 0d 6f 75 |e giving.the .ou| 00000590 74 70 75 74 20 63 6f 6e 66 69 67 75 72 61 74 69 |tput configurati| 000005a0 6f 6e 2e 0d 0d 41 20 73 75 70 70 6c 79 20 66 6f |on...A supply fo| 000005b0 72 20 61 20 33 2e 35 20 69 6e 20 63 61 6e 20 62 |r a 3.5 in can b| 000005c0 65 20 61 6e 20 6f 6c 64 20 50 43 20 73 77 69 74 |e an old PC swit| 000005d0 63 68 65 64 20 6d 6f 64 65 20 62 75 74 20 79 6f |ched mode but yo| 000005e0 75 20 0d 77 69 6c 6c 20 6e 65 65 64 20 74 6f 20 |u .will need to | 000005f0 63 68 61 6e 67 65 20 74 68 65 20 70 6c 75 67 20 |change the plug | 00000600 6f 72 20 67 65 74 20 61 6e 20 61 64 61 70 74 6f |or get an adapto| 00000610 72 2e 20 54 68 65 73 65 20 64 6f 20 65 78 69 73 |r. These do exis| 00000620 74 20 0d 62 75 74 20 63 61 6e 20 62 65 20 74 72 |t .but can be tr| 00000630 69 63 6b 79 20 74 6f 20 66 69 6e 64 2e 20 4d 6f |icky to find. Mo| 00000640 73 74 20 33 2e 35 20 69 6e 20 64 72 69 76 65 73 |st 3.5 in drives| 00000650 20 64 6f 6e 27 74 20 6e 65 65 64 20 76 65 72 79 | don't need very| 00000660 20 0d 62 69 67 20 73 75 70 70 6c 79 73 2e 20 31 | .big supplys. 1| 00000670 32 20 76 6f 6c 74 20 31 20 61 6d 70 20 77 69 74 |2 volt 1 amp wit| 00000680 68 20 35 20 76 6f 6c 74 20 61 74 20 2e 35 20 61 |h 5 volt at .5 a| 00000690 6d 70 20 69 73 20 75 73 75 61 6c 6c 79 20 0d 73 |mp is usually .s| 000006a0 75 66 66 69 63 69 65 6e 74 2e 20 10 50 6c 75 67 |ufficient. .Plug| 000006b0 73 20 63 61 6e 20 62 65 20 62 6f 75 67 68 74 20 |s can be bought | 000006c0 71 75 69 74 65 20 65 61 73 69 6c 79 20 62 75 74 |quite easily but| 000006d0 20 62 65 20 63 61 72 65 66 75 6c 20 6f 66 20 0d | be careful of .| 000006e0 74 68 65 20 10 63 6f 6e 66 69 67 75 72 61 74 69 |the .configurati| 000006f0 6f 6e 2e 20 46 6f 72 20 62 6f 74 68 20 74 68 65 |on. For both the| 00000700 20 33 2e 35 20 69 6e 20 61 6e 64 20 74 68 65 20 | 3.5 in and the | 00000710 35 2e 32 35 20 69 6e 20 64 72 69 76 65 73 20 0d |5.25 in drives .| 00000720 74 68 65 20 10 6d 69 64 64 6c 65 20 74 77 6f 20 |the .middle two | 00000730 70 69 6e 73 20 61 72 65 20 30 20 76 6f 6c 74 73 |pins are 0 volts| 00000740 2e 20 54 68 65 20 35 20 76 6f 6c 74 20 61 6e 64 |. The 5 volt and| 00000750 20 31 32 20 76 6f 6c 74 20 67 6f 20 6f 6e 20 0d | 12 volt go on .| 00000760 74 68 65 20 10 6f 75 74 2d 73 69 64 65 20 62 75 |the .out-side bu| 00000770 74 20 6d 75 73 74 20 6e 6f 74 20 62 65 20 6d 69 |t must not be mi| 00000780 78 65 64 20 75 70 2e 0d 0d 20 20 20 33 2e 35 20 |xed up... 3.5 | 00000790 69 6e 20 20 20 20 20 20 20 20 20 20 20 35 2e 32 |in 5.2| 000007a0 35 20 69 6e 0d 0d 2e 20 20 2e 20 20 2e 20 20 2e |5 in... . . .| 000007b0 20 20 20 20 20 2f 20 2e 20 20 2e 20 20 2e 20 20 | / . . . | 000007c0 2e 20 5c 0d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 20 20 |. \.---------- | 000007d0 20 20 20 7c 5f 5f 5f 5f 5f 5f 5f 5f 5f 5f 5f 5f | |____________| 000007e0 7c 0d 31 32 76 20 30 76 20 30 76 20 35 76 20 20 ||.12v 0v 0v 5v | 000007f0 20 20 20 35 76 20 30 76 20 30 76 20 31 32 76 0d | 5v 0v 0v 12v.| 00000800 0d 53 75 70 70 6c 79 20 73 6f 63 6b 65 74 73 20 |.Supply sockets | 00000810 66 6f 72 20 33 2e 35 20 69 6e 20 61 6e 64 20 35 |for 3.5 in and 5| 00000820 2e 32 35 20 69 6e 20 64 72 69 76 65 73 20 6c 6f |.25 in drives lo| 00000830 6f 6b 69 6e 67 20 61 74 20 74 68 65 20 0d 73 6f |oking at the .so| 00000840 63 6b 65 74 73 20 6f 6e 20 74 68 65 20 64 72 69 |ckets on the dri| 00000850 76 65 73 2e 0d 0d 57 65 6c 6c 20 74 68 61 74 27 |ves...Well that'| 00000860 73 20 6d 79 20 69 6e 74 72 6f 20 74 6f 20 75 73 |s my intro to us| 00000870 69 6e 67 20 41 44 46 53 2e 20 49 66 20 74 68 65 |ing ADFS. If the| 00000880 72 65 20 69 73 20 61 6e 79 74 68 69 6e 67 20 77 |re is anything w| 00000890 68 69 63 68 20 49 20 0d 68 61 76 65 20 6c 65 66 |hich I .have lef| 000008a0 74 20 6f 75 74 2c 20 6f 72 20 61 6e 79 74 68 69 |t out, or anythi| 000008b0 6e 67 20 77 68 69 63 68 20 69 73 20 6e 6f 74 20 |ng which is not | 000008c0 63 6c 65 61 72 20 74 68 65 6e 20 53 45 4e 44 20 |clear then SEND | 000008d0 49 54 20 49 4e 2e 20 0d 0d 49 20 77 72 6f 74 65 |IT IN. ..I wrote| 000008e0 20 74 68 69 73 20 62 65 63 61 75 73 65 20 6d 65 | this because me| 000008f0 6d 62 65 72 73 20 61 73 6b 65 64 20 66 6f 72 20 |mbers asked for | 00000900 69 74 2e 20 49 66 20 74 68 65 72 65 20 69 73 20 |it. If there is | 00000910 73 6f 6d 65 20 0d 61 73 70 65 63 74 20 6f 66 20 |some .aspect of | 00000920 74 68 65 20 45 6c 6b 20 77 68 69 63 68 20 69 73 |the Elk which is| 00000930 20 63 61 75 73 69 6e 67 20 70 72 6f 62 6c 65 6d | causing problem| 00000940 73 2c 20 61 73 6b 20 66 6f 72 20 68 65 6c 70 2e |s, ask for help.| 00000950 20 0d 54 68 61 74 27 73 20 77 68 61 74 20 61 20 | .That's what a | 00000960 75 73 65 72 20 67 72 6f 75 70 20 69 73 20 66 6f |user group is fo| 00000970 72 2e 20 53 45 4e 44 20 49 54 20 49 4e 2e 0d 0d |r. SEND IT IN...| 00000980 44 4f 4e 54 20 50 52 45 53 53 20 27 52 27 2c 20 |DONT PRESS 'R', | 00000990 54 48 45 52 45 20 49 53 20 4e 4f 20 50 52 4f 47 |THERE IS NO PROG| 000009a0 52 41 4d 20 54 4f 20 52 55 4e 0d |RAM TO RUN.| 000009ab
