File contents
10MODE 6:HIMEM=&7000:LOMEM=&6400
20VDU 28,0,24,39,16
30OSBYTE=&FFF4:OSWORD=&FFF1:OSASCI=&FFE3:OSWRCH=&FFEE
40OSRDCH=&FFE0:CLI=&FFF7
50OUT=&70:PUT=&71:SP=&72:BPT=&74
60CONBLK=&76:HI=&81:LO=&80:DISP=&82:DH=&83
70UP=&85:STK=&86:ACR=&84
80OLO=&7B:OHI=&7C:OUMB=&88
90HA=&8D:HB=&8E:HC=&8F
100DLINES=&7D:NUMB=&7E:TEMPSTACK=&7F
110FOR OP=0 TO 3 STEP 3
120P%=&5400
450[OPT OP
460TSX:STX TEMPSTACK
480LDA#0:STA CONBLK:LDA#6:STA CONBLK+1
500LDA#ASC("D"):STA DISP
520LDX#(ST1 MOD 256)
530LDY#(ST1 DIV 256)
540JSR OUTPUT
560LDA#4:LDX#1:JSR OSBYTE
590.L5 JSR DISPLAY
610.L7 JSR KEYIN
630CMP#ASC("D"):BNE NOND
650.STD STA DISP:JMP L5
660.NOND CMP#ASC("L"):BEQ STD
690CMP #ASC("H"):BNE NONH
710.HGIN LDX#15:LDY#2:JSR SETAB
730LDA#4:LDX#ASC("0"):LDY#ASC("F"):JSR STRIN
750JSR DHEX:BCCHGIN:LDA DH:STA HI
770LDA&602:STA&600:LDA&603:STA&601:JSR DHEX
790BCC HGIN:LDA DH:STA LO:JMP L5
800.NONH CMP#ASC("F"):BNE NOF
820.FGIN LDX#15:LDY#3:JSR SETAB
830LDA#2:LDX#ASC("0"):LDY#ASC("F"):JSR STRIN
840JSR DHEX:BCC FGIN:LDA DISP:CMP#ASC("L"):BNE OVSWAP
850LDA OLO:SEC:SBC OUMP:STA LO:LDA OHI:SBC#0:STA HI
860.OVSWAP
870LDY#0:LDA DH:.FLOOP INC LO:BNE OVHI:INC HI:.OVHI CMP(LO),Y:BNE FLOOP
880JMP L5
910.NOF LDX DISP:CPX#ASC("L"):BNE NONF:JMP LCOM
950.NONF CMP#&88:BNE NLEFT
970LDA LO:BNE DE1:DEC HI:.DE1 DEC LO:JMP L5
990.NLEFT CMP#&89:BNE NRT
1010INC LO:BNE DE2:INC HI:.DE2 JMP L5
1050LDA LO:CLC:ADC#8:STA LO
1060LDA HI:ADC#0:STA HI:JMP L5
1100LDA LO:SEC:SBC#8:STA LO
1110LDA HI:SBC#0:STA HI:JMP L5
1140.NMOVE CMP#ASC("A"):BNE NONA
1160.AGIN LDY#14
1180LDA ACR:ASL A:CLC:ADC ACR:CLC:ADC#6
1200TAX:JSR SETAB
1220LDA#2:LDX#ASC("0"):LDY#ASC("F"):JSR STRIN
1240JSR DHEX:BCC AGIN:LDA DH:LDY#0:STA (LO),Y
1250JMP L5
1290.DHEX LDA&600:CMP #ASC("9")+1:BCS AL1
1300AND#&0F:BCC TIP
1310.AL1 CMP #ASC("A"):BCC ERHEX:SBC #ASC("A")-10
1330.TIP ASL A:ASL A:ASL A:ASL A:STA DH
1340LDA&601:CMP #ASC("9")+1:BCS AL2
1350AND#&0F:BCC BOT
1360.AL2 CMP #ASC("A"):BCC ERHEX:SBC #ASC("A")-10
1380.BOT ORA DH:STA DH:SEC
1400.ERHEX RTS
1440.NONA CMP #ASC("S")BNE NONS
1460.SGIN LDY#14:LDA ACR:CLC:ADC#30:TAX:JSR SETAB
1480LDA#255:LDX #ASC(" "):LDY #ASC("~"):JSR STRIN
1500LDX#0:LDY#0
1520.LOP LDA&600,X:CMP#&0D:BEQ FINLOP
1530STA (LO),Y:INY:INX:BNE LOP
1540.FINLOP JMP L5
1570.NONS
1580JMP L7
1620.LCOM CMP#&0D:BNE NONCR
1640LDA OLO:STA LO:LDA OHI:STA HI:JMP L5
1660.NONCR CMP#&8B:BNE NONS
1680LDA OLO:INC OUMB:SEC:SBC OUMB:STA LO
1690LDA OHI:SBC#0:STA HI:JMP L5
1720.DIS LDX#(ST2 MOD 256)
1730LDY#(ST2 DIV 256)
1750JSR OUTPUT
1770LDA#16:STA DLINES
1780.LINLOP
1800LDA HI:JSR HEX:LDA LO:JSR HEXSP
1830LDY#0:LDX#3
1840.HALOP LDA(LO),Y:STA HA,Y:INY:DEX:BNE HALOP
1860LDX HA:LDA TYPE,X:TAX:LDA NUM,X
1880STA NUMB:CLC:ADC LO:STA LO:LDA#0:ADC HI:STA HI
1900LDX NUMB:LDY#3:LDA HA:JSR HEXSP:DEY:DEX:BEQ PAD
1910LDA HB:JSR HEXSP:DEY:DEX:BEQ PAD
1920LDA HC:JSR HEXSP:DEX:BEQ MNEM
1940.PAD TYA:PHA
1950LDX#(ST4 MOD 256):LDY#(ST4 DIV 256):JSR OUTPUT
1960PLA:TAY:DEY:BNE PAD
1980.MNEM LDA #ASC(" "):JSR OSASCI
2000LDX HA:LDA HASH,X:ASL A:ASL A:STA OUT
2020LDA#(STRING DIV 256):STA PUT:LDX#4:LDY#0
2040.MNMLOP LDA (OUT),Y:JSR OSASCI:INY:DEX:BNE MNMLOP
2050LDA #ASC(" "):JSR OSASCI
2070LDX HA:LDA TYPE,X:CMP#1:BNE NOD1
2090LDA #ASC("#"):JSR OSASCI:LDA #ASC("&"):JSR OSASCI
2110LDA HB:JSR HEXSP:LDY#5:JMP NDLINE
2130.NOD1 CMP#2:BNE NOD2
2150LDA #ASC("&"):JSR OSASCI:LDA HC:JSR HEX
2160LDA HB:JSR HEXSP:LDY#4:JMP NDLNE
2180.NOD2 CMP#3:BNE NOD3
2200LDA #ASC("&"):JSR OSASCI:LDA HB:JSR HEXSP
2210LDY#6:JMP NDLINE
2230.NOD3 CMP#4:BNE NOD4
2250LDA #ASC("A"):JSR OSASCI:LDY#9:JMP NDLINE
2270.NOD4:CMP#5:BNE NOD5
2290LDY#10:JMP NDLINE
2310.NOD5 CMP#6:BNE NOD6
2330LDA #ASC("("):JSR OSASCI:LDA #ASC("&"):JSR OSASCI
2340LDA HB:JSR HEX:LDA #ASC(","):JSR OSASCI
2350LDA #ASC("X"):JSR OSASCI:LDA #ASC(")"):JSR OSASCI
2360LDY#3:JMP NDLINE
2380.NOD6 CMP#7:BNE NOD7
2400LDA#ASC("("):JSR OSASCI:LDA#ASC("&"):JSR OSASCI
2410LDA HB:JSR HEX:LDA#ASC(")"):JSR OSASCI
2420LDA#ASC(","):JSR OSASCI:LDA#ASC("Y"):JSR OSASCI
2430LDY#3:JMP NDLINE
2450.NOD7 CMP#8:BNE NOD8
2470LDA#ASC("&"):JSR OSASCI:LDA HB:JSR HEX
2480LDA#ASC(","):JSR OSASCI:LDA#ASC("X"):JSR OSASCI
2490LDY#5:JMP NDLINE
2510.NOD8 CMP#9:BNE NOD9
2530LDA#ASC("&"):JSR OSASCI:LDA HC:JSR HEX
2540LDA HB:JSR HEX:LDA#ASC(","):JSR OSASCI
2550LDA#ASC("X"):JSR OSASCI
2560LDY#3:JMP NDLINE
2580.NOD9 CMP#&A:BNE NODA
2600LDA#ASC("&"):JSR OSASCI:LDA HC:JSR HEX
2610LDA HB:JSR HEX:LDA#ASC(","):JSR OSASCI
2620LDA#ASC("Y"):JSR OSASCI
2630LDY#3:JMP NDLINE
2650.NODA CMP#&B:BNE NODB
2670LDA#ASC("&"):JSR OSASCI
2690LDA HB:CMP#&7F:BCS BACK
2710CLC:ADC LO:PHA LDA#0:ADC HI:CLC:BCC REL
2730.BACK EOR#255:ADC#0:STA&70:LDA LO:SEC:SBC&70
2740PHA:LDA HI:SBC#0
2760.REL JSR HEX:PLA:JSR HEXSP
2770LDY#4:JMP NDLINE
2790.NODB CMP#&C:BNE NODC
2810LDA#ASC("("):JSR OSASCI:LDA#ASC("&"):JSR OSASCI
2820LDA HC:JSR HEX:LDA HB:JSR HEX
2830LDA#ASC(")"):JSR OSASCI:LDY#3:JMP NDLINE
2850.NODC CMP#&D:BNE NODD
2870LDA#ASC("&"):JSR OSASCI:LDA HB:JSR HEX
2880LDA#ASC(","):JSR OSASCI:LDA#ASC("Y"):JSR OSASCI
2890LDY#5:JMP NDLINE
2910.NODD LDY#10
2930.NDLINE LDA#ASC(" "):JSR OSASCI:DEY:BPL NDLINE
2950LDX NUMB:LDY#0
2960.DISPLOP LDA HA,Y:JSR CHOUT:INY:DEX:BNE DISPLOP
2980LDA#ASC(" "):.PAD2 JSR OSASCI:INY:CPY#4:BNE PAD2
3000LDX#5:.PAD3 JSR OSASCI:DEX:BNE PAD3
3030LDA DLINES:CMP#16:BNE OVOLD
3050LDA LO:STA OLO:LDA HI:STA OHI
3060LDA NUMB:STA OUMB
3080.OVOLD DEC DLINES:BEQ FINLIN:JMP LINLOP
3090.FINLIN RTS
3130.DISPLAY LDY#2:LDX#15:JSR SETAB
3150LDA HI:JSR HEX:LDA LO:JSR HEXSP:
3170LDA DISP:CMP#ASC("L"):BEQ DDISP
3190JSR SHOW:RTS
3210.DDISP JSR DIS:RTS
3250.SHOW LDX#(ST2 MOD256)
3260LDY#(ST2 DIV256)
3280JSR OUTPUT
3300LDA LO:AND#&F8:SEC:SBC#64:STA UP
3310LDA HI:SBC#0:STA STK
3330LDA LO:AND#7:STA ACR
3350LDX#0:.L4 STX STK+1:LDA#8:CLC:ADC UP:STA UP
3360LDA #0:ADC STK:STA STK
3380JSR HEX:LDA UP:JSR HEXSP:LDA#ASC(" "):JSR OSASCI
3400LDX#0:.L2 STX STK+2:TXA
3410TAY
3430LDA(UP),Y:JSR HEXSP
3450LDX STK+2:INX:CPX#8:BNE L2
3470LDX#0:.L3 STX STK+2:TXA
3490TAY
3500LDA(UP),Y:JSR CHOUT
3520LDX STK+2:INX:CPX#8:BNE L3
3540LDA#ASC(" "):JSR OSASCI:JSR OSASCI
3560LDX STK+1:INX:CPX#16:BNE L4
3580LDY#14:LDA ACR:ASL A:CLC:ADC ACR
3590ADC#5:STA STK+1:TAX:JSR SETAB
3610LDA#ASC("["):JSR OSASCI
3620LDA STK+1:CLC:ADC#3:TAX:LDY#14:JSR SETAB
3640LDA#ASC("]"):JSR OSASCI
3650RTS
3690.CHOUT CMP#ASC(" "):BCC DUF
3710CMP#&7F:BCC OK
3740.DUF LDA#ASC(".")
3750.OK JSR OSASCI:RTS
3790.SETAB STY ST3+2:STX ST3+1
3800LDX#(ST3 MOD256):LDY#(ST3 DIV256)
3810JSR OUTPUT:RTS
3850.KEYIN LDX#0:LDA#21:JSR OSBYTE
3860JSR OSRDCH:BCS KEYERR:RTS
3880.KEYERR STA STK+1
3890LDX#(ST6 MOD256):LDY#(ST6 DIV256):JSR CLI
3900LDA STK+1:CMP#&1B:BNE KERR
3920LDA#&7E:JSR OSBYTE
3930.KERR
3950LDX#0:LDY#22:JSR SETAB:LDX TEMPSTACK:TXS
3980BRK:EQUB99
3990EQUS"END OF DIS"
4010BRK
4050.OUTPUT STX&70:STY&71
4060LDY#0
4070.LOOP LDA(&70),Y:CMP#&FF:BEQ OUTEND
4080JSR OSASCI:INY:BNE LOOP
4090.OUTEND RTS
4130.HEXSP JSR HEX:LDA#&20:JMP OSWRCH
4150.HEX
4170PHA:LSR A:LSR A:LSR A:LSR A
4180JSR HEXDIG:PLA:AND#&F
4190.HEXDIG CMP#&A:BCC HEXDIH:ADC#6
4200.HEXDIH ADC#&30:JMP OSWRCH
4250.STRIN STA CONBLK+2:STX CONBLK+3:STY CONBLK+4
4260LDX#(ST5 MOD256)
4270LDY#(ST5 DIV256):JSR OUTPUT
4280LDA#0:LDX# CONBLK:TAY:JSR OSWORD
4290BCS ESC1:RTS
4300.ESC1 LDA#&1B:JMP KEYERR
4310]
4320ST1=P%+1:!ST1=&0D0C0616:P%=P%+5
4330$P%=" ELECTRON DEBUGGER D DUMP MEMORY "
4340$(P%+40)=" H HEX ADDR. : 0000 L LISTING "
4350$(P%+80)=" F FIND BYTE : 00 A ALTER BYTE "
4360$(P%+120)=" S STRING"
4370P%=P%+LEN($P%):?P%=&FF
4380ST2=P%+1:!ST2=&00000117:ST2!4=0:P%=P%+9
4390!P%=&001F0000:P%=P%+4:!P%=&FF07:P%=P%+2
4400ST3=P%:!P%=&0000001F:P%!4=&FF000000:P%=P%+8
4410ST4=P%:!P%=&FF202020:P%=P%+4
4420ST5=P%:!P%=&00010117:ST5!4=0:P%=P%+8
4430!P%=&FF000000:P%=P%+4
4440ST6=P%:$ST6="FX4,0":P%=P%+6
4450RESTORE
4460NUM=P%:FOR I=0 TO 14:READ N%:P%?I=N%:NEXT I
4470P%=P%+15
4480P%=(P% DIV256)+1:P%=P%*256
4490HASH=P%:TYPE=P%+256:P%=P%+512:STRING=P%
4500NEXT OP
4510FOR I%=0 TO 255 STEP 4:HASH!I%=0:TYPE!I%=0:STRING!I%=0:NEXT I%
4520REPEAT
4530READ A$:IF A$="*" THEN 4570
4540IF ASC(A$)=ASC("-") THEN I=ABS(VAL(A$)):GOTO 4530
4550M=EVAL("&"+LEFT$(A$,1)):MN=EVAL("&"+RIGHT$(A$,2))
4560HASH?MN=I:TYPE?MN=M
4570UNTIL A$="*"
