USING THE ASSEMBLER 7
~~~~~~~~~~~~~~~~~~~~~
By Richard Dimond
I hope that my last contribution was reasonably understandable and not too
overwhelming!! Like most of my programs, it just grew and grew!! I have
a program that grew too big for 32k and hope to shorten it by M/coding it.
Having said that, before I describe the promised adventure program, I want
to comment on two routines which were used in the programs given last time
as these will be often used in M/code.
In the Miner program, when you move around, the play area is re-drawn each
time from the data starting at a different address. This address is
calculated by adding or subtracting an amount depending on which way you
move.
For addition, the carry flag must be cleared first then the low byte
values added followed by the high byte values. Thus -
CLC:LDAaddr:ADC#xlow:STAaddr
LDAaddr+1:ADC#xhigh:STAaddr
adds the two byte value 'x' to the address held at 'addr' and stores it at
this address.
For subtraction, the routine is the same except the carry flag must be set
first.
In the MINsrc1 program line 650, the value to be added is first stored in
&90. This is then added after loading the value from 'data' and stored
again. As there is no high byte value to add, the ADC#0 in the line adds
1 to the high byte if the carry flag is set by the addition of the low
byte. Lines 660 and 670 are similar for changing the address held in
'addr'.
The other routine is for transferring blocks of data from one memory area
to another. This is done with a loop similar to those I have already
given. In line 680 of the program referred to, data from the address in
&80 is loaded into A register and stored into the address in'addr' with
the commands - LDA(&80),Y:STA(addr),Y. As Y register is loaded with 17 at
the start, this is added to the addresses and each time round the loop Y
is decreased until the value goes negative when the value in Y falls below
zero. In this way 18 bytes are transferred.
Another loop often used is this -
LDY#0
.loop
<transfer commands>
INY:BNEloop
RTS
This transfers 256 bytes, ie a page of data and can be extended to
transfer several pages by increasing the high bytes of the addresses each
time the loop is completed and either counting the number of pages using X
register as a counter or comparing the high byte of one of the addresses.
Now for the game such as it is!! It was based on a series of articles in
'Let's Compute' - remember the kid's magazine? It is far from complete as
the series was unfinished when the magazine stopped publication. It was
also written in rather peculiar Basic as it was to be adapted for other
machines and I thoght it a challenge to rewrite in M/code. I thoght also
that there was sufficient to give you some ideas on writing an adventure
program in M/code and also to show some further routines. If anyone has
ideas on how to complete the game or to write another, I would be glad to
help.
First I will give a breakdown of the program referring to the lines of the
assembler which produce the code as I did last time.
Lines 120 - 1090 are the subroutines
2000 - 2240 are the main loop
5000 - the buffer for osword (&FFF1) for the input.
5010 - title data
5020 - 5030 data for printing the directions
5040 - 5240 message data
5250 - 5280 table of message addresses
5290 - flag for the messages
5300 - 5550 words for COMMANDS
5310 directions - single letters
5320 directions - words
5340 actions
5400 useful objects to take
5470 other objects
5550 inventory
5570 - stores the current lacation number
5580 - 5780 locations
5790 - 5820 table of location addresses
5830 - 6030 movement data
6040 - 6180 object descriptions
6190 - 6210 table of addresses for these
6220 - data for object positions
6230 - data for objects held
6240 - two bytes for holding the action numbers
I will describe the working of the program from the start (line 2000) and
explain the subroutines as they are used again referring to the lines in
the assembler listing.
At the start you are in location 1 - The Control Room as the value in
'loc' (line 5570) is 1.
Line 2010 selects MODE 6 followed by two OSNEWLs.
2020 uses routine 'rep' to print 12 spaces <TAB(12)>, and prints the
title using routine 'prt' and an OSNEWL.
2030 prints the underline
The main loop starts at line 2040.
The messages are printed by loading A register with the number of the
message and then calling the routine 'prtmess'. The value in A is doubled
by ASL A, 2 subtracted and the value transferred to Y register. Thus Y is
loaded with 0, 2, 4,... according to which message is to be printed. This
is then used as an index to the two bytes or the address of the message.
These two values are then loaded into X and Y registers before calling the
routine 'prt'.
The routine 'prtloc' works in the same way except that A register is
loaded with the value of the current location held in 'loc' so that you
are told where you are.
This method of referring to an address in a table is often used in M/code.
In this program it is used to set up the printing of the data and what you
can do according to the location you are since the value in 'loc' is used
for the index.
Line 2080 prints message 2 and the routine 'ldobs' is called. This
routine searches the data 'obsdat' (line 6220) - note that each four bytes
are in reverse order as they are entered using EQUD.
The data is compared with the location number and, if they are equal, the
object number, which is the value in Y register, is printed with the
routine 'prtob' (line 440). The 'obflag' (&75) is set to -1 (&FF) to show
that an object has be found.
On completion of the search, the program jumps to 'ret' and the obflag is
compared with &FF. If this is equal the routine ends. If no object is
found then the obflag is zero and message 15 is printed (line 580).
