Ultrasonic Sonar System

By far the largest area of development in BallBot has been the work in
developing the sonar system which the robot uses to navigate. This sonar
system must be able to determine what objects are present around the
robot, how far away they are, and whether they are interesting or not.

The system essentially consists of two units: a transmitter, which is
essentially a loudspeaker, and a reciever, which is a microphone. Both
have a very fine resonant frequency of 40kHz. The system works as follows:

On a regular basis (eight times a second), BallBot emits a loud ultrasonic
pulse from the loudspeaker. As this pulse moves away at the speed of sound
(330m/s), some of this energy is reflected back at the robot in the form
of echoes. If there is an object such as a tennis ball present, the echoes
are much stronger, as shown by the diagram. These strong echoes are
recieved by very sensative microphones on board the robot. The distance of
the object from the robot can be calculated because we know that the time
taken for the sound wave to travel out to the object and then return back
to BallBot is equal to the time delay between the signal being
transmitted, and its echo being recieved. Therefore the following formula
can be applied:

The type of object present can also be determined. Different objects
produce different amplitudes of echo depending upon their size and how
absorbant they are to sound waves. As soon as the first signal from the
object is recieved, BallBot's computer begins sampling the sound being
recieved. The hardware converts the peaks in amplitude of the ultrasound
being recieved into binary 1s, and the troffs into binary 0s. Thus a form
of code is formed which is passed to the computer's input circuitry. The
computer then processes the binary code to search for patterns, which it
recognises as objects such as tennis balls.

Systems such as this are only effective, however, when the echoes are
being reflected off objects which are thicker than the wavelength of the
waves being transmitted. In our case, this can be found to be
approximately 8mm using the formula V=fl. Therefore some objects such as
the net and the fence surrounding the court may not be reliably detected.
Othere objects such as the balls and players will, however, still be
visable when this is allowed for. The pattern recognition system must,
therefore, be programmed to ignore any traces which are recieved from
these items if reliable consistent results are to be obtained, and the AI
code must be programmed to work without traces from these surfaces. It is
important that such traces are either picked up reliably every time, or
ignored completely. If they are necessary for the efficient running of the
AI, infra-red sensory systems may be added to detect the net, the fence,
and anything else of interest.

The Transmitter

The circuitry for this sonar system is still very much under development.
The transmitting system has now been designed, built and tested, and seems
to be working satisfactoraly. This part of the circuitry takes one output
line from the computer, and transmits 40kHz from the speakers when it is
high, and turns off the speaker when it is low. Essentially it consists of
a wave generator circuit, producing 40kHz sine waves, and a transistor to
switch the output to the speaker on and off. The circuit diagram for this
is shown below:

It is at first surprising that this circuit works. The collector ->
emitter connection of a transistor acts as a diode, and yet the voltage
across this negative in the lower half of the 40kHz sine wave. Therefore
we would expect half-wave rectified output from the speaker. I suspect
that the reason why this circuit works is that induction or resonance in
the transmitter fills in the lower-half of the wave.

Having built this circuit, and shown that it worked by monitoring the
output using a microphone and an oscilloscope, I decided to test the
response rate of the circuit to see how long it took the transmitter to
reach maximum amplitude after the output line from the computer goes high,
switching on the transmitter. By programming the computer to switch the
transmitter on and off at high frequency, and monitoring the sound output
on an oscilloscope, I found that it takes about 1ms to reach maximum
amplitude from the "blip" control signal being sent, and 1ms to return to
complete silence after being turned off. Therefore I decided that the
computer should send the "blip" signal to this circuit for a minimum of
1ms for it to be sure to have the effect of producing a sound of maximal
amplitude, but not too long that the recieved waveforms from different
objects become blurred in any way.

The Reciever

The ultrasonic reciever is rather more complicated than the transmitter,
and work is still at a very early stage. Our first objective was to find
out exactly work kind of signal the ultrasonic microphone produces when
exposed to ultrasound. Using an oscilloscope, I found that the signal
produced is an a.c. signal which oscillates at 40kHz, and has an amplitude
which varies with the intensity of the ultrasound to which it is exposed.
I expected the voltage of this signal to be proportional to the inverse
square of the distance. The sound spreads out from the source in the shape
of a sphere (or part of a sphere). Therefore at any one time the sound
energy is spread over the surface area of a sphere of distance d around
the source, where d is the distance between the source and the
transmitter. This would indicate the following formula:

The data actually collected through tests with the ultrasonic equipment is
shown below:

Both tests strongly suggest that the voltage of the signal from the
microphone is inversely proportional to the distance. Therefore, this
suggests that:

As you can see, the product of the voltage recieved and the distance of
the source from the reciever is constant. This could be very useful.
Graphs for Voltage x Distance should, therefore, be a straight horizontal
line. Such graphs of voltage x distance are plotted below:

So far, all studies have been of a system involving transmission in a
straight line, with the reciever facing the transmitter. In BallBot,
however, the transmitter and the reciever will be together, and facing in
the same direction. Therefore some tests have been performed for the input
recieved when an echo is bounced off a surface. Data for such tests are
shown below:

Once again, it appears that voltage is inversely proportional to distance.
This suggests that surfaces reflect a constant proportion of the sound
energy back at the robot. Once again, the product of distance and voltage
should be a constant value. But because we know that the distance of the
object is proportional to the time taken for the echo to be recieved, we
can convert this to saying that the product of the time elapsed since the
ultrasonic blip was transmitted and the input voltage is a constant value
for particular surfaces. This is more useful than distance with regard to
designing the BallBot hardware. Graphs for voltage x distance for echo
tests are plotted below:

The constant value of the product of voltage and distance can be found for
different surfaces for the given speakers and output amplitude. The unit
of this value is the volt-metre (Vm). Work is currently in progress to try
to find actual values of this for the kind of objects which BallBot will
come across (e.g. tennis balls). The value is equal to the voltage
produced across the reciever when an echo is recieved off that type of
surface at a distance of one metre.
