File contents

GETKYW

This routine finds the key width for a given field.  It uses the value
defined in the format file, if any; otherwise a system of defaults operates:

Key width defined                               Key width
No key width, display width defined             Display width
No key width or display width                   10

On entry:               X       contains number of field for which width is
                                required.

On exit:                CS      field doesn't exist.
                        CC      field found; A has already width.
                        X       preserved.
                        Y       undefined.


GETKYW

This routine finds the key width for a given field.  It uses the value
defined in the format file, if any; otherwise a system of defaults operates:

Key width defined                               Key width
No key width, display width defined             Display width
No key width or display width                   10

On entry:       X               contains the field number for which the key
                                width is required.

On exit:        A               contains key width; if field doesn't exist,
                                a default key width of 10 is returned.
                X               preserved.
                Y               undefined.


CALSBN

This routine is used when displaying numeric fields, to calculate the number
of spaces to be output before the number in order to right justify the
number within its field width.  This also takes into account the decimal
places specified in the format file.

On entry:       X               contains the field number.
                TEMP07          points to the beginning of the field in
                                question.
                TEMP03          contains the field display width, as
                                returned by the GETWID routine.

On exit:        A               gives number of spaces to output, zero if
                                the number is wider than the field, or there
                                are too many decimal places.
                X               undefined.
                Y               undefined.
                TEMP03          preserved.
                TEMP07          preserved.


File Control

File handling in ViewStore is centred around three things: error handling,
FBLOCK and prefixes.  Since the error handling provided by the normal filing
system interface provided is completely unsatisfactory for a program such as
ViewStore, I have developed a system which gives control of what happens
after a disc or filing system error.  For the utility writer, this system is
transparent: you can forget about it as long as you use the calls provided,
and don't call the filing system directly.  If you do this, you can forget
all about BRK errors and handlers.

The system is the same for all file calls: the state of the Overflow (V)
flag indicates after a call whether an error has occurred.  If there has
been an error, then the V flag is set, and the A register contains the error
code.  If you detect an error, you should unravel yourself from any
routines, report the error by calling the REPERL routine, and then close any
files that you have opened yourself, before returning to control of the ROM.
You shouldn't close the intermediate file: this is done automatically when
control is passed back to the ROM.


Filenames

FBLOCK is a small of memory used to store and manipulate filenames.  Several
routines are provided which work on the filename in FBLOCK, altering
directories and prefixes.

A filename in ViewStore is made up of three parts:

        Prefix
        Directory
        Name

ViewStore maintains a list of the current prefixes for each different file
type: data; format; sort and so on.  A routine which adds a specified prefix
to a directory and name stored in FBLOCK is available.  The maximum length
of a prefix is 13 characters, excluding delimiter.  The current prefixes can
only be altered with the PREFIX command in ViewStore's Command Mode.

ViewStore considers directories to be single character; of course the prefix
can include multiple character directories, but the filenames of data and
format files, for example, begin with directories, and these are always
single character directory names, whatever the filing system.  Directories
must be separated from the name itself by a dot, making the total size of
the directory section of a filename 2 characters.

The name part of the filename can be up to 10 characters long.  This does
not include the directory and separator, or the delimiter.  Names are always
delimited with a Carriage Return character.

Part            Max. Size (exc. delimiter)      Example

Prefix          13                              :2.
Director        2                               d.
Name            10                              datafile

MOVFBK          Moves a filename from the store area into FBLOCK.
MOVNAY          Moves a filename out of FBLOCK into the store area.
CHKDIR          Checks for the presence of a directory in a filename in
                FBLOCK, and returns the directory character, if there is
                one.
SETDIR          Sets a directory into a filename in FBLOCK.
STXPRE          Stores the required prefix with a filename in FBLOCK.
OPFILE          Gives access to the filing system OSFIND call.
OSHCAL          Gives access to the filing system OSFILE call.
XOSARG          Vector with error trapping to OSARGS.
XOSBGE          Vector with error trapping to OSBGET.
XOSBPU          Vector with error trapping to OSBPUT.
XOSCLS          Vector  with error trapping to OSFIND with A=0; used to
                close a file.
XOSGBP          Vector with error trapping to OSGBPB.
CALUTI          Loads and runs a utility format file.
