     After you have decided which mode to use, and so you know how many
colours are available, you must decide what colours these are going to
be. In MODE 2, where you have 16 colours, you have access to all of the
colours available, and so this choice does not affect you. In 4 colour
modes, on the other hand, you only initially have access to black, red,
yellow and white. These are a warm selection of colours, but you might
want a colder selection in your program, or just simply a set of colours
which go well with your screen design. To do this you use the command:

VDU 19,logical colour number,actual colour number,0,0,0

     The logical colour number is the number that you use with the colour
command to select that particular colour. In a four colour mode this must
be between 0 and 3, and in a two colour mode this must be either 0 or 1.
The actual colour number is the number of the colour which you want to
assign to that logical colour. The actual colour numbers are given below:

0-Black               8-Flashing black/white
1-Red                 9-Flashing red/cyan
2-Green              10-Flashing grenn/magenta
3-Yellow             11-Flashing yellow/blue
4-Blue               12-Flashing blue/yellow
5-Magenta (purple)   13-Flashing magenta/green
6-Cyan (light blue)  14-Flashing cyan/red
7-White              15-Flashing white/black

     Looking at the table above, you might wonder what the difference is
between flashing black/white and flashing white/black. If you look at
them both seperately, there is little difference, but if you look at them
together, you see that when one is black the other is white, and vice
versa. So, for example, if you put a logo on the screen with the logo in
colour 8 and the background in colour 15, the screen flashes between
white on black and black on white. To demonstrate this, turn on your
Electron and type:

MODE 6:VDU 19,1,8,0,0,0:VDU 19,0,15,0,0,0

     You can take this further. Four is the maximum number of colours
allowed on screen at any one time. Therefore for different screens you
can have different selections of colours. The main menu screen might be
in warm colours, and then subsequent menu screens in colder colours. The
changing of these logical colours is called "Palette Switching". You can
go even further and create simple animation using palette switching; an
effect which is called "Colour Cycling". For example, you put a row of
colour 3 above a row of colour 2, with a row of colour 1 below that, and
colour 0 at the base. Initially, you set all logical colours to black.
Then, if you set logical colour 0 to white, the base appears. Now set
logical colour 1 to white as well, the bar moves up the screen. Repeat
this with colours 2 and 3, and you have a simple animation. This is even
more powerful in MODE 2, where you can go through 16 rows up. This is
demonstrated at the end of the tutorial.
     The swirly effect on the title screen of this issue's title screen
was achieved in this way. The colours black, blue, cyan and white are
cycled through a pattern on the screen in order.
     Having decided which graphics mode you are going to use, and which
colours to have on the screen, you must decide how you are going to get
your graphics onto the screen. There are many methods for producing
graphics, and which you choose depends upon what you want the graphics
for, and what you want them to do (and, of course, your programming
ability). The most obvious is the PRINT command. This is a quick, easy
way of putting text onto the screen. When used with the COLOUR command
and the TAB(x,y) function, many interesting effects can be achieved.
These are, however, greatly limited by the fact that only letters can be
displayed on the screen. This limitation may be overcome using user
defined characters (see the Graphics chapter of the User Manual for
details). Even using these characters, however, there are serious
limitations. They can only use one colour per character, and so even if
you make different characters different colours, your screen will still
appear rather dull. Also, they are difficult to use when dealing with
large areas of the screen.
