              [ BASIC ROM ROUTINES ARTICLE - CONTINUATION ]

4.      Routine: Print A in hex
        Basic 2: &B545
        Basic 4: &BD6C

        Entry: The Accumulator contains the byte to be printed in hex
        Ex.:    LDA #&CD
                JSR &B545

This one can be quickly demonstrated from Basic, if you really want, by
typing A%=&CD:CALL&B545.

5.      Routine: Print 16-bit number in decimal
        Basic 2: &991F
        Basic 4: &A081

        Entry: &2B/&2C (the 2 least significant bytes of the IWA) should
        contain the number to be printed.
        Ex.:    LDA #1023 MOD 256  \put the number 1023
                STA &2B
                LDA #1023 DIV 256  \onto the two lsb's of the IWA
                STA &2C
                JSR &991F

This is the routine which I promised we would discuss at the beginning
of this article, so let's take some time going through it in detail. If
you have a disassembler then you could look at the actual machine code,
which in English goes something like this. You first of all see how many
times 10,000 can be subtracted from the given number before it becomes
negative. For example, you can subtract 10,000 six times from the number
60,000. This is the 10,000s count. Then you see how many times 1,000 can
be subtracted from the remainder, then how many times 100 can be taken
away from the remainder of that, and so on down to the 1s count.
   In order to do this, we need a table of two-byte values: 10,000,
1,000, 100, 10 and 1. There are two tables in Rom; the first table con-
tains the low bytes, and the second table contains the high bytes:

Basic 2 Low bytes:      High bytes
        ----------      ----------
        &996B [&01]     &99B9 [&00]     &0001 = 1
        &996C [&0A]     &99BA [&00]     &000A = 10
        &996D [&64]     &99BB [&00]     &0064 = 100
        &996E [&E8]     &99BC [&03]     &03E8 = 1000
        &996F [&10]     &99BD [&27]     &2710 = 10000

Basic 4 Low bytes       High bytes
        ---------       ----------
        &8026 [&01]     &8021 [&00]     &0001 = 1
        &8027 [&0A]     &8022 [&00]     &000A = 10
        &8028 [&64]     &8023 [&00]     &0064 = 100
        &8029 [&E8]     &8024 [&03]     &03E8 = 1000
        &802A [&10]     &8025 [&27]     &2710 = 10000

If you haven't got a disassembler, then the program below demonstrates
how it works:

       10 FORI%=0TO2STEP2
       20 P%=&900
       30 [OPTI%
       40 LDX #&50  \copy integer from zero page
       50 JSR &AF56  \to IWA
       60
       70 LDX #4
       80 .loop LDA#0
       90 STA &3F,X
      100 SEC
      110 .loop2 LDA&2A
      120 SBC &996B,X  \&8026 for BBC M
      130 TAY
      140 LDA &2B
      150 SBC &99B9,X  \&8021 for Basic 4
      160 BCC skip
      170 STA &2B
      180 STY &2A
      190 INC &3F,X
      200 BNE loop2
      210 .skip DEX
      220 BPL loop
      270
      280 LDX #5  \suppress leading zeroes
      290 .loop3 DEX  \by indexing to first
      300 BEQ print  \non-zero number
      310 LDA &3F,X
      320 BEQ loop3
      330 .print LDA &3F,X
      340 ORA #&30
      350 JSR &FFEE
      360 DEX
      370 BPL print
      380 RTS
      390 ]
      400 NEXT
      410 INPUT !&50
      420 CALL &900

The section of code from line 280 to 320 suppresses leading zeros. This
just means that if you had the number 234, then it will be printed as
234 and not 00234. Sometimes you might not care for leading zero
suppression. In most games, for instance, your score is displayed as
00000 at the start then changes to 00010 when you score some points and
so on. In this case, you can dispense with lines 290-320 in the above
program and replace line 280 with LDX #4.

This article continued in V.+BRR3. First published EUG #55.
