The second method used by Thomson to obtain values for m/e involved
the newly discovered phenomenon of the deflection of cathode rays by an
electric field. This was probably the most famous experiment he ever
devised. The trick was to apply both electric and magnetic fields at the
same time, in such a way that the two forces on the rays would exactly
balance each other. In this situation the deflection of the rays woud be
zero. This is a common technique of measurement in physics, since it is
much easier to determine when a deflection or velocity is exactly zero,
than to measure a finite quantity.
When a particle with charge e moves at speed v perpendicular to a
magnetic field B, the magnetic force acting on it has a magnitude of
F = Bev
m
and is directed perpendicular to both the field and the direction of
motion. When the same particle travels perpendicular to an electric field
E, the electric force has a magnitude of
F = Ee
e
and is directed parallel to the electric field. For these two forces to
balance, the electric and magnetic fields must be perpendicular to each
other, and we must have:
Bev = Ee
E
Hence, v = -
B
Again, he already knew the value mv/e from the magnetic deflection,
so he could use the measured value of v to find the mass:charge ratio m/e.
The results from this measurement are also tabulated in the Philosophical
Magazine. These values for m/e are consistent with those from the previous
experiment, and have much smaller random errors than the latter.
It seemed that there were two possible explanations for the
mass:charge ratio of these particles being so much smaller than that of
any known particle. Either their charge was very much graeter than that of
the hydrogen ion, or their mass was very much less. The hydrogen ion was
thought to be a good reference point, since it had the smallest
mass:charge ratio previously encountered and was known to be a charge
carrier in liquid electrolytes. Thomson guessed immediately that the
main reason for the low m/e must be the small mass of the particles, since
they were known to pass through solid aluminium quite easily.
This led him to the uncomfortable conclusion that these particles
must be many times lighter than the smallest known atom. Schuster had once
come to a similar answer and abandoned his reasoning immediately, but
Thomson was willing to consider the idea seriously. He had shown from his
measurements that the mass:charge ratio of the particles was always the
same regardless of the gas in the discharge tube, and the material of the
cathode. This suggested that the new particles were present in all matter,
regardless of chemical composition. It had previously been assumed that
each chemical element is composed of its own type of atoms, which are
completely indivisible. Hence the gases nitrogen and oxygen were believed
to contain no particles in common, even at the deepest level of the atom.
This theory was no longer tenable in view of Thomson's discovery, so he
wasted no time in suggesting that the new particles, or "corpuscles" as he
called them, were a universal constituent of all atoms. In the intense
electric field around a cathode, the corpuscles in some of the gas
molecules or metal atoms would break free and be accelerated away in the
form of cathode rays. Some chemists had previously suggested the existence
of such a building block inside the atom, but they always had larger
particles such as hydrogen atoms in mind, and never found any supporting
evidence for their theories.
(explanation of Lenard's attenuation expt?)
At first, Thomson thought that the negative charge of the electron
was greater than the positive charge of the hydrogen ion. Although this
would help to explain the low m/e ratio, it seems odd to suggest that
the charge of the negative corpuscle should be larger than that of its
undiscoverred positive counterpart. This would place severe restrictions
on their arrangement in atoms, since the total charge of the positive and
negative components must always be zero. He explains his reasoning in the
Philosophical Magazine:
"In the molecule of HCl, for example, I picture the components of
the hydrogen atoms as held together by a great number of tubes of
electrostatic force; the components of the chlorine atom are similarly
held together, while only one stray tube bind the hydrogen atom to the
chlorine atom."
This may have been an attempt to explain why it is so much easier
to split an HCl molecule into two ions than to break an atom into
individual corpuscles. If this were not the case, then atoms of one
element would break apart and reform to make another. Nowadays we explain
this in terms of the strong nuclear force, which does effectively form one
stable corpuscle (the nucleus) with a high charge.
Soon afterwards Thomson abandoned this idea, realising that the
negative charge of a corpuscle is equal to the positive charge of a
hydrogen ion.
