								Gareth Babb
								30 Park Drive
								Grimsby
								South Humberside
								DN32 OEG

					Tel: (01472) 878002
					Email: gbabb@hick.feline.conqueror.co.uk

								21.08.95

Dear Gus,

Two issues worth - I forgot I had wrote this, and thus forgot to actually
post it to you last month !

--- John Crane

*BYE closes any open (ADFS) files and parks any Hard Drive heads, whereas
*CLOSE just closes any open files.

--- You

Why not get someone to write a 64k compatible screen loader - you could
even compress the screens at the same time :-)

I usually find the best thing to clean contacts with is a soft rubber.

You forgot the codes which don't change for phONEday, basically all non-
geographic codes (eg. 0800, 0891, 0645 etc.) remain the same, except for
most pager numbers (the oddity is Hutchinson Display Paging which remains
on 0941- 1). Oh yeah, and the change from 010 to 00 for international
access.

Boo ! Down with Anderson Country/Afternoon Shift, get it off, get it off.

--- Derek Walker

Small bit of code to completely compact:

DIM data &100
FOR N=4 TO 7 STEP 3
P%=&C00:O%=data
[OPT N
LDA #218:LDX #0:LDY #0:JSR &FFF4
LDA #3:LDX #20:JSR &FFF4
LDA #23:JSR &FFCB:LDA #1:JSR &FFCB
LDA #0:LDY #8:.curs:JSR &FFCB:DEY:BNE curs
LDA #3:JSR &FFF4

.loop
LDA #0
STA &1D00
STA &1D01:LDA #&20:STA &1D02
LDA #130:JSR &FFF4:STX &1D03:STY &1D04

LDA #8:STA &1D05
LDA #0:STA &1D06:STA &1D07:STA &1D08:STA &1D09:STA &1D0A

STA &1D0B:STA &1D0D:STA &1D0E
LDA #2:STA &1D0C

LDX #0:LDY #&1D:LDA #&72:JSR &FFF1
LDA &1D00:BEQ okay
BRK:BRK:EQUS "Bugger":BRK

.okay
BIT &FF:BMI end_it

LDA &21FE:CMP #3:BNE compact_it

.end_it
LDX #map MOD 256:LDY #map DIV 256:JSR &FFF7

LDA #218:LDX #0:LDY #0:JSR &FFF4
LDA #3:LDX #20:JSR &FFF4
LDA #23:JSR &FFCB
LDA #1:JSR &FFCB:JSR &FFCB
LDA #0:LDY #7:.curs2:JSR &FFCB:DEY:BNE curs2
LDA #3:JMP &FFF4

.compact_it
LDX #map MOD 256:LDY #map DIV 256:JSR &FFF7
LDX #compact MOD 256:LDY #compact DIV 256:JSR &FFF7
JMP loop

.map:EQUS "Map":EQUB 13
.compact:EQUS "Compact 1D 63":EQUB 13
]
NEXT
OSCLI "Save EFC "+STR$~data+" "+STR$~O%+" C00 C00"


Erm, ADFS doesn't use NMIs - though it does claim NMI workspace - or IRQs
for ANYTHING. For both floppy and HD it polls (which is why for Floppy it
will disable IRQs and change screen mode - disabling the palette at the
same time - otherwise the 177x will flag overruns). The normal ST506/SASI
HD interface will wait for the computer to take data as fast as it can,
which is why ADFS doesn't have to change screen mode, or bother with
disabling IRQs.

On the beeb, NMIs are only used for Floppy, and even then all code is run
from &D00, the place specifically reserved for NMI code. A loop in (A)DFS
itself just keeps check on a flag byte, which the NMI routine updates to
flag when data transfer from the 177x has finished.

I presume Acron didn't use NMIs on the Elk due to the problems with
claiming and releasing memory from the ULA - on the Plus 3, bit 4 of the
ctrl reg is connected straight to the NMI line, except that it isn't
because Link 1 is not made by default, so a NMI can be forced. ADI from
Pres requires the enabling of this Link on the Plus 3, as that does use
NMIs (I presume mainly to keep the mode 0 display - though it does break
up a bit as the ULA is forced to release memory in the middle of screen
refreshes).

--- You

Re Internet. 386 and a Fax Modem ? No neddy, you can get away with
anything you want for normal email access, I use a 286 for email (about
the only thing I use it for). Even KA9Q (a well known PD TCPIP program)
will run happily on a 286 to give you telnet, ftp, email etc. It's only
when you start going for WWW (over rated) and need the graphics that
Windows (and thus processing power needed) come into play.

Alternatively get a descent computer, I do believe a company called Acorn
produce some ...

Look out for local BBs' which will provide email/newsgroup access for
nothing/small fee. Otherwise full internet operators (ie. provide direct
access to things like WWW, telnet, ftp ...) are providing quite extensive
local coverage now-a-days. Enc. pile of text files.

--- Gerry Emson

What you have there is a standard PC serial mouse. No good for the Elk
unless you find a serial port and write your own software - no existing
software will support it. Sell it and hunt out an old user port (eg. AMX)
mouse.

I've run an Elk from a 12v power supply no probs, a car battery shouldn't
be much different. This was going through the normal power circuity stage
- it copes, so no need to produce -5v yourself (what use is that anyway, I
think it just goes to the edge connector).


			Yours sincerely,

				Gareth Babb

I LIKED ANDERSON COUNTRY.
