| Tape/disk: | Home » Personal collection » Acorn DFS disks » dfs_box04_disk09_rgs_robotics_1.scp |
| Filename: | PICKUP |
| Read OK: | ✔ |
| File size: | 13C1 bytes |
| Load address: | FF1900 |
| Exec address: | FF8023 |
File contents
10 REM INTERFACE DRIVER
15 REM FISCHER COMPUTING <--> ACORN BBC COMPUTER
20 REM COPYRIGHT (C) ARTUR FISCHER FORSCHUNG 1984
30 REM Use the following commands to control your FISCHERTECHNIK model with your Acorn Model B
35 REM
40 REM * * COMMANDS * *
45 REM
50 REM - CALL M1,CW%
55 REM Rotates Motor #1 clockwise
60 REM - CALL M1,CCW%
65 REM Rotates Motor #1 counter-clockwise
70 REM - CALL M1,GO%
75 REM Switches device connected to M1 on
80 REM - CALL M1,HALT%
85 REM Switches device connected to M1 off
90 REM Instead of "M1" you may also use M2, M3 or M4
95 REM - FNUSR (E1)
100 REM Returns a '0' or a '1' depending on the current state of the switch
105 REM Instead of 'E1' you may also use any of the keys 'E2' to 'E8'
110 REM - FNUSR (EX)
115 REM Returns a value depending on the current position of the potentiometer
120 REM Instead of 'EX' you can also use 'EY' to obtain a value from potentiometer Y
125 LET drr=&62
130 LET up=&60
135 LET til=&68
140 LET tih=&69
145 LET tic=&6B
150 LET avar=&80
155 LET mask=&81
160 LET buff=&82
165 LET asave=&84
170 LET xsave=&85
175 LET ysave=&86
180 DIM M% 500
185 FOR Z=0 TO 2 STEP 2
190 P%=M%
195[
200 OPT Z
205 \ * * OUTPUT DRIVER * *
210 .init:lda #0:beq stvar:lda #3 :bne bout:lda #12:bne bout:lda #&30:bne bout:lda #&C0
215 .bout :sta mask:lda avar:ora mask:sta avar:jsr check:jmp ok2
220 .check :lda &0600:cmp #1:beq ok
225 .err1:brk:]:PROCequb (&FF):PROCequs ("Use exactly one parameter"):PROCequb (0):[OPT Z
230 .ok:lda&603: cmp #4:beq ok1
235 .err2:brk:]:PROCequb(&FF):PROCequs("Use integer parameters only"):PROCequb(0):[OPT Z
240 .ok1:lda &601:sta buff:lda &602:sta buff+1:ldy #0:lda (buff),Y
245 .back:rts
250 .ok2:and mask:sta mask: lda avar:eor mask
255 .stvar:sta avar: tay
260 .shout:jsr save:ldy #&3F:ldx #drr:jsr write:jsr load:ldx #8
265 .loop: lda #&30:asl avar: bcc null:ora #4
270 .null:jsr save:tay:ldx #up:jsr write:jsr load:ora #8:jsr save:tay:ldx #up
275 jsr write:jsr load:dex:bne loop:jsr save:ldy #&31:ldx #up:jsr write:jsr load:sty avar:rts
280 .E1:ldx #1:jmp test
285 .E2:ldx #2:jmp test
290 .E3:ldx #4:jmp test
295 .E4:ldx #8:jmp test
300 .E5:ldx #16:jmp test
305 .E6:ldx #32:jmp test
310 .E7:ldx #64:jmp test
315 .E8:ldx #128
320 .test:stx mask:lda #&32:jsr save:ldy asave:ldx #up:jsr write:jsr load:ora #8:jsr save:ldy asave:ldx #up:jsr write:jsr load:ldx #8
325 .loop2:asl A:jsr save:ldx #up:jsr read:tya:and #&80:beq nul2:jsr load:ora #1:jmp nul3
330 .nul2:jsr load
335 .nul3:jsr save:ldy #&30:ldx #up:jsr write:jsr load:ldy #&38:ldx #up:jsr write:jsr load:dex:bne loop2:and mask:beq back1:lda #1
340 .back1
345 rts
350 .EX:ldx #&A0:jmp poti
355 .EY:ldx #&90
360 .poti:sei:jsr save:ldy #&20:ldx #tic:jsr write:ldy #&FF:ldx #til:jsr write:ldy #&FF:ldx #tih:jsr write:ldy xsave
365 ldx #up:jsr write:ldy #&38:ldx #up:jsr write:jsr load
370 .tst:jsr save:ldx #til:jsr read:sty ysave:jsr load:tya:ldx #200
375 .delay:dex:bne delay:jsr save:ldx #til:jsr read:sty ysave:jsr load:sec:sbc ysave:bne tst:jsr save:ldx #til:jsr read:sty ysave:jsr load:sec:lda #&FF:sbc ysave:cli:rts
380 .write:lda #&97:jsr &FFF4:clc:rts
385 .read:lda #&96:jsr &FFF4:clc:rts
390 .save:sta asave:stx xsave:sty ysave:rts
395 .load:lda asave:ldx xsave:ldy ysave:rts
400]
405 NEXT Z
410 LET M1=init+4
415 LET M2=init+8
420 LET M3=init+12
425 LET M4=init+16
430 LET INIT=init
435 LET CW%=85
440 LET CCW%=170
445 LET GO%=85
450 LET HALT%=255
455 REM * * * END OF DRIVER * * *
460 DEF FNUSR(A)=USR(A) AND &FF
470 DEFPROCequb(num):?P%=num:P%=P%+1:ENDPROC
480 DEFPROCequs(text$):$P%=text$:P%=P%+LEN text$:ENDPROC
500 CALL INIT
510 REM
520 REM FISCHERTECHNIK COMPUTING
530 REM
540 REM PICK&PLACE
550 REM
560 REM COPYRIGHT (C) ARTUR FISCHER FORSCHUNG 1985
570 REM
580 REM ASSIGNMENTS FOR THE INTERFACE
590 REM
600 REM INPUT
610 REM E1=PHOTO-CELL
620 REM E2=START
630 REM EX=POSITION OF ARM
640 REM EY=POSITION OF ANGLE
650 REM
660 REM OUTPUT
670 REM M1=TURN ROBOT
680 REM M2=UP/DOWN
690 REM M3=MAGNET
700 REM M4=CONVEYOR BELT
750 REM
800 REM FUNCTIONAL DESCRIPTION
810 REM WHEN THE START SWITCH IS PRESSED THE CONVEYOR BELT
820 REM TRANSPORTS THE COIN TO THE ROBOT ARM
830 REM THE ROBOT ARM PICKS THE COIN UP AND TRANSPORTS THE COIN TO THE CHUTE.
900 REM TURN POSITIONS
910 DIM TURN(2),ARM(2)
920 LET TURN(1)=113
930 LET TURN(2)=35
940 LET ARM(1)=120
950 LET ARM(2)=28
1000 MODE6
1010 PRINT"FISCHERTECHNIK"
1020 PRINT"COMPUTING"
1030 PRINT
1040 PRINT"PICK & PLACE"
1050 PRINT
1060 PRINT"PLEASE PRESS THE START SWITCH"
1070 REM START
1080 IF FNUSR(E2)=0 THEN GOTO 1080
1090 CALL M4,CW%
1100 IF FNUSR(E1)=0 THEN GOTO 1100
1110 CALL M4,HALT%
1120 LET NOMINAL_VALUE=TURN(1)
1130 GOSUB 1300
1140 LET NOMINAL_VALUE=ARM(1)
1150 GOSUB 1400
1160 REM MAGNET ON
1170 FORI=0TO100
1180 CALL M3,CW%
1190 NEXTI
1200 LET NOMINAL_VALUE=ARM(2)
1210 GOSUB 1400
1220 LET NOMINAL_VALUE=TURN(2)
1230 GOSUB1300
1240 LET NOMINAL_VALUE=ARM(1)
1250 GOSUB 1400
1260 CALL M3,HALT% :REM MAGNET OFF
1270 LET NOMINAL_VALUE=ARM(2)
1280 GOSUB 1400
1290 GOTO 1060
1300 REM POSITIONAL CONTROL ROUTINE
1310 LET D=FNUSR(EY)-NOMINAL_VALUE
1320 IF D>0 THEN CALL M1,CW%
1330 IF D<0 THEN CALL M1,CCW%
1340 IF D=0 THEN RETURN
1350LET D=ABS(D)
1360 IF D>3 THEN GOTO 1310
1370 CALL M1,HALT%
1380 GOTO 1310
1390 RETURN
1400 REM POSITIONAL CONTROL ROUTINE ARM
1410 LET D=FNUSR(EX)-NOMINAL_VALUE
1420 IF D>0 THEN CALL M2,CW%
1430 IF D<0 THEN CALL M2,CCW%
1440 IF D=0 THEN RETURN
1450 LET D=ABS(D)
1460 IF D>20 THEN GOTO 1400
1470 CALL M2,HALT%
1480 GOTO1400
1490 RETURN
