PROGRAMMING TECHNIQUE
by Dominic Ford
Part 2: Graphics
The most important decision which you must make when you are writing
the graphics routines for a program is which graphics mode to use. There
are seven different display types available on the Electron, and an
eighth is available on the BBC. Each display type has its own
characteristics, and you must choose which is most suitable for your
particular program. Some graphics modes, for example, allow you to have
many different colours on screen, but poor detail, while others allow you
to have very great detail but few colours. You select graphics modes by
using the MODE x command. Details of the seven different available modes
are given below:
x Colours Graphics? Res/G Res/T Memory
0 2 Yes 640x256 80x32 20K
1 4 Yes 320x256 40x32 20K
2 16 Yes 160x256 20x32 20K
3 2 No N/A 80x25 16K
4 2 Yes 320x256 40x32 10K
5 4 Yes 160x256 20x32 10K
6 2 No N/A 40x25 8K
7 16 No N/A 40x25 1K <- BBC ONLY!
KEY:
x: MODE number.
Colours: The maximum number of different colours which may be used on
screen at any one time.
Graphics?: Does this graphics mode allow the use of the graphics commands
(ie. MOVE, DRAW, etc.)? Modes 3 & 6 do not allow these commands, as there
are thin horizontal stripes in between the rows of characters, in which
nothing can be displayed. Thus, any graphics drawn in these modes would
have black horizontal stripes across them, and would look rather silly!
To see what I mean, turn on your computer and type:
MODE 6:COLOUR 129:COLOUR 0:CLS
The background should be entirely white, but there are horizontal stripes
where the screen can be no colour except black.
Res/G: The resolution of the screen in this mode (ie. the number of
pixels across and down the screen). Generally, the higher the value, the
smoother your graphics will look. Note that this is not the same as the
parameters taken by the MOVE and DRAW commands - these always scale the
number of pixels across the screen to 1280 and down the screen to 1024,
so that (1280,1024) will always be the top-right corner of the screen,
and (0,0) the bottom left.
Res/T: The number of characters which fit across the screen in this mode
when using text.
Memory: The amount of the computer's 32K of memory which is used by the
graphics mode. If you are writing a long program, this is an important
consideration, as you may not have room for the program after subtracting
20K from the computer's 32K RAM for a MODE 2 screen. If this is the case,
you must use a mode which uses less memory, such as mode 5.
My advice in choosing which mode to use would be to try, if at all
possible, to use one of the 20K modes. The detail of MODE 1, and the
colours of MODE 2, are both far superior to the quality of MODE 5. If you
are an efficient programmer, you should find that it is perfectly
possible to fit a reasonably lengthed program into memory at the same
time as 20K of screen. Shipwrecked, for example, used MODE 2 for its
graphics, as does Shipwrecked II on this issue.
Fitting a program into memory as well as a large screen memory is
fairly easy when you are using a tape or DFS filing system, but this can
prove difficult with ADFS, because 4K of the memory normally used to
store programs is taken away for the ADFS to use, leaving you only a mere
4.5K free for programs. Assuming that once you have loaded the program
you do not intend to use the disk again, there is a way around this. If
you switch over to a tape filing system, the ADFS memory becomes
redundant and can be reclaimed for BASIC use. Once you have done this, of
course, you cannot access disks without resetting the computer, so load
and save options in your program are restricted to tape only. This
technique will be explained in greater depth in a later article on memory
management.
