   10REM Control a Maplin temperature
   20REM module
   30:
   40pb0=1:REM =show lo point
   50pb1=2:REM =show hi point
   60pb2=4:REM =celcius/fahrenheit
   70pb3=8:REM =sample rate select
   80pb4=16:REM=set hours
   90pb5=32:REM=set mins
  100pb6=64:REM=clock/temperature
  110REM data=CB1 & clock=CB2
  120:
  130DIMserial% 256
  140oscopy=255-pb0-pb1-pb2-pb3-pb6
  150orb=&FE60:ddrb=&FE62
  160?orb=oscopy:?ddrb=127
  170oswc=&FFEE:osby=&FFF4:osnl=&FFE7
  180ifr=&FE6D:ier=&FE6E:pcr=&FE6C
  190:
  200FORX=0 TO2 STEP2
  210P%=serial%
  220[OPTX
  230.change
  240SEI
  250LDX&204:STXoldvec+1
  260LDY&205:STYoldvec+2
  270LDX#irqhandle MOD256:STX&204
  280LDY#irqhandle DIV256:STY&205
  290\IRQ1V changed
  300LDApcr:AND#31:ORA#64+32:STApcr
  310LDAier:ORA#128+8+16:STAier
  320\Enable IRQ when CB1/CB2 change
  330LDA#8+16:STAifr:\Clear any pending IRQs caused by the above
  340CLI:RTS
  350EQUS"(C)1998 SPROW"
  360:
  370.mustbeCB2
  380LDA#8:STAifr:\Clear irq
  390LDAstate:ANDmaskhi:ORAreshi
  400STAreshi
  410LDAstate:ANDmasklo:ORAreslo
  420STAreslo:\Update answer
  430CLC:RORmaskhi:RORmasklo
  440BCSgotall:\Got 13 bits yet?
  450PLA:PLP:LDA&FC:RTI
  460:
  470.irqhandle
  480PHP:PHA
  490LDAifr:AND#16+8:BEQbalance:\User VIA caused the IRQ?
  500AND#8:BNEmustbeCB2:\Otherwise CB1
  510:
  520.mustbeCB1
  530LDAstate:EOR#255:STAstate
  540LDApcr:EOR#16:STApcr:\Toggle edge on which to trigger
  550LDAorb:\Clear the interrupt
  560PLA:PLP:LDA&FC:RTI
  570:
  580.gotall
  590LDA#31:JSRoswc:LDA#14:JSRoswc:LDA#16:JSRoswc:\Move to (14,16)
  600LDAreshi:RORA:RORA:RORA:AND#2\:\Isolate top bit
  610BITstyle:BMIsign
  620:
  630.hundreds
  640RORA:JSRbcd:JMPtens:\If in F its the hundreds column
  650.sign
  660CLC:ADC#ASC"+":JSRoswc:\If in C its the sign
  670:
  680.tens
  690LDAreshi:JSRbcd:\Print tens
  700LDAreslo:RORA:RORA:RORA:RORA:JSRbcd:\Print units
  710LDA#ASC".":JSRoswc:\Decimal dot
  720LDAreslo:JSRbcd:\Tenths
  730LDA#16:STAmaskhi:LDA#0:STAmasklo
  740STAreshi:STAreslo:\Reset masks
  750.balance
  760PLA:PLP
  770.oldvec
  780JMP&9999:\Self modified earlier
  790:
  800.bcd
  810AND#15:CLC:ADC#ASC"0":JMPoswc
  820:
  830.state EQUB0:\Data state (0/255)
  840.style EQUB0:\For dC=255 dF=0
  850.maskhi EQUB16
  860.masklo EQUB0
  870.reshi EQUB0
  880.reslo EQUB0
  890]
  900NEXT
  910:
  920REM Ensure no cursor editing,fast keyboard repeat rate,Fkeys return ASCii values
  930*FX4,1
  940*FX12,2
  950*FX225,150,0
  960MODE7:VDU23,1,0;0;0;0;:PRINT"Temperature module controller"'"Ensure module is plugged in"
  970key=GET:CALLchange:REM Install serial reader
  980VDU11:PRINTSTRING$(39," ")
  990PROCfkey0:PROCfkey1:PROCfkey2
 1000PROCfkey3:PROCfkey4
 1010PRINT'CHR$129"F5"CHR$130''CHR$129"F6"CHR$130''"   "CHR$130"Currently ???.?":REM Draw screen,and leave background handler to fill in the temperature
 1020:
 1030REPEAT
 1040OSCLI"FX15,1":option=GET
 1050IFoption=150 THENPROCfkey0
 1060IFoption=151 THENPROCfkey1
 1070IFoption=152 THENPROCfkey2
 1080IFoption=153 THENPROCfkey3
 1090IFoption=154 THENPROCfkey4
 1100IFoption=155 THENPROCfkey5
 1110IFoption=156 THENPROCfkey6
 1120UNTIL0
 1130END
 1140:
 1150DEFPROCfkey0
 1160IF(oscopy ANDpb1)=0 AND(oscopy ANDpb0)=pb0 THENPROCfkey1:REM Ensure both cant be selected at once
 1170oscopy=oscopy EORpb0:?orb=oscopy
 1180IF(oscopy ANDpb0)=pb0 THENPRINTTAB(0,2);CHR$129"F0"CHR$130"Show lo alarm point" ELSEPRINTTAB(4,2);"Hide"
 1190ENDPROC
 1200:
 1210DEFPROCfkey1
 1220IF(oscopy ANDpb1)=pb1 AND(oscopy ANDpb0)=0 THENPROCfkey0:REM Ensure both cant be selected at once
 1230oscopy=oscopy EORpb1:?orb=oscopy
 1240IF(oscopy ANDpb1)=pb1 THENPRINTTAB(0,4);CHR$129"F1"CHR$130"Show hi alarm point" ELSEPRINTTAB(4,4);"Hide"
 1250ENDPROC
 1260:
 1270DEFPROCfkey2
 1280oscopy=oscopy EORpb2:?orb=oscopy
 1290?style=?style EOR255:REM Toggle flag in the serial reader
 1300IF(oscopy ANDpb2)=pb2 THENPRINTTAB(0,6);CHR$129"F2"CHR$130"Fahrenheit display":PRINTTAB(19,16)"C" ELSEPRINTTAB(4,6)"Celcius display   ":PRINTTAB(19,16)"F"
 1310ENDPROC
 1320:
 1330DEFPROCfkey3
 1340oscopy=oscopy EORpb6:?orb=oscopy
 1350IF(oscopy ANDpb6)=pb6 THENPRINTTAB(0,8);CHR$129"F3"CHR$130"Clock display      ":PRINTTAB(4,12)"Set lo limit":PRINTTAB(4,14)"Set hi limit" ELSEPRINTTAB(4,8)"Temperature readout":PRINTTAB(4,12)"Set hours   ":PRINTTAB(4,14)"Set minutes "
 1360ENDPROC
 1370:
 1380DEFPROCfkey4
 1390oscopy=oscopy EORpb3:?orb=oscopy
 1400IF(oscopy ANDpb3)=pb3 THENPRINTTAB(0,10);CHR$129"F4"CHR$130"Sample rate: 10s" ELSEPRINTTAB(17,10)"1s "
 1410ENDPROC
 1420:
 1430DEFPROCfkey5
 1440IF(oscopy ANDpb6)=pb6 THENPROCsetpoint(pb0):ENDPROC
 1450?orb=oscopy AND(255-pb4)
 1460then%=TIME:REM Simulate press and hold
 1470REPEAT:UNTIL(TIME-then%)>200
 1480?orb=oscopy
 1490REPEAT
 1500key=INKEY(200)
 1510IFkey=155 THEN?orb=oscopy AND(255-pb4):then%=TIME:REPEAT:UNTILTIME>then%+5:?orb=oscopy:REM One switch push
 1520IFkey=156 THEN?orb=oscopy AND(255-pb5):then%=TIME:REPEAT:UNTILTIME>then%+5:?orb=oscopy:REM One switch push
 1530UNTILkey=TRUE
 1540ENDPROC
 1550:
 1560DEFPROCfkey6
 1570IF(oscopy ANDpb6)=pb6 THENPROCsetpoint(pb1):ENDPROC
 1580?orb=oscopy AND(255-pb5)
 1590then%=TIME:REM Simulate press and hold
 1600REPEAT:UNTIL(TIME-then%)>200
 1610?orb=oscopy
 1620REPEAT
 1630key=INKEY(200)
 1640IFkey=156 THEN?orb=oscopy AND(255-pb5):then%=TIME:REPEAT:UNTILTIME>then%+5:?orb=oscopy:REM One switch push
 1650IFkey=155 THEN?orb=oscopy AND(255-pb4):then%=TIME:REPEAT:UNTILTIME>then%+5:?orb=oscopy:REM One switch push
 1660UNTILkey=TRUE
 1670ENDPROC
 1680:
 1690DEFPROCsetpoint(bit)
 1700modify=oscopy AND(255-bit) ORpb3
 1710?orb=modify
 1720PRINTTAB(4,12)"Disable alarm point":PRINTTAB(4,14)"Adjust alarm point"
 1730REPEAT
 1740key=INKEY(200)
 1750IFkey=156 THEN?orb=modify AND(255-pb5):then%=TIME:REPEAT:UNTILTIME>then%+5:?orb=modify
 1760IFkey=155 THEN?orb=modify EORpb4:then%=TIME:REPEAT:UNTILTIME>then%+5:?orb=modify
 1770UNTILkey=TRUE
 1780?orb=oscopy:REM Back to temperature displaying mode and old settings
 1790PRINTTAB(4,12)"Set lo limit       ":PRINTTAB(4,14)"Set hi limit      "
 1800ENDPROC
