10 MODE4
20 FOR A=2 TO 6:PRINTTAB(1,A)STRING$(39,"_"):NEXT

That's one staff drawn. The notes need to be defined and for this  we need
to resort to some paper. Or you may have a character defining program. I
have one somewhere, I'll take a look at it and see if it can be published
in EUG.

Draw a grid, 8 x 8 boxes. fill in the boxes which will make the shape you
want. Now working horizontaly, the first box has a value of 128, the 2ed =
64, the 3rd = 32, 4th = 16, 5th = 8, 6th = 4, 7th = 2 and 8th = 1.

Start from the first horizontal row at the top. check which boxes have
been filled in and add those values together.

         ________________________________
        |___|___|___|___|___|___|_ _|___| no boxes = 0
        |___|___|___|_X_|_X_|___|___|___| 4th and 5th = 16+8=24
        |___|___|_X_|___|___|_X_|___|___| 3rd and 6th = 32+4=36
        |___|_X_|___|___|___|___|_X_|___| 2ed and 7th = 64+2=66
        |___|_X_|___|___|___|___|_X_|___| 2ed and 7th = 64+2=66
        |___|___|_X_|___|___|_X_|___|___| 3rd and 6th = 32+4=36
        |___|___|___|_X_|_X_|___|___|___| 4th and 5th = 16+8=36
        |___|___|___|___|___|___|___|___| no boxes = 0
         128  64  32  16  8   4   2   1

Now type in VDU23,224, 0 , 24, 36, 66, 66, 36, 36, 0
                      1st,2ed,3rd,4th,5th,6th,7th,8th

Check the character by typing PRINT CHR$226 <ret>

These numbers are different from those used for this character in the
program, these numbers were used for clarity.

The number after 24 in this case 226 is the ASCII code for the character
just defined. You can use any number between 224 and 255 so the next
character you define might be VDU24,225,ect..

To call this character I used a procedure.

DEF PROCs(h,v):PRINTTAB(h,v)CHR$226:ENDPROC

DEF means define a procedure or function. Immediately following DEF comes
the name of the procedure PROCs. In this case PROCs is followed by two
variables within brackets. When this procedure is called the call will
include definations for these two variables. The procedure itself is
simply a PRINTTAB statement, the parameters for PRINTTAB are the variables
sent by the procedure call. Remenber in a PRINTTAB statement, two numbers
must be included which will dictate the horizontal and vertical position
on the screen of where the character to be printed is to be.

This character is fine for between the lines F, A, C, and E but for the
notes on the lines we need something else. If we define 2 semicircles, one
facing up, the other facing down, then program them to be placed into
position together the effect will be acheved.

This is a lot easier that you might think.

The characters were defined as CHR$224 for the lower half of the circle
and CHR$225 for the upper half.

I'm not going to describe again how a character is defined but for the
lower semicircle the cup side sits on the top row of the grid and the
curve sits 3 rows down. The other semicircle ofcourse is the exact
opposite.

VDU24,224,66,66,60,0,0,0,0,0 and VDU24,225,0,0,0,0,0,60,66,66

The procedure was defined as:

DEF PROCl(h,v,v1):PRINTTAB(h,v)CHR$225:PRINTTAB(h,v1)CHR$224:ENDPROC

Here the procedure name had three variables, h,v  and v1. In the PRINTTAB
statements both shared h which is the horizontal position but one used v
for its vertical while the other used v1.

The a%=INSTR( line which was used above and in the EUG menu is used in
this program. This line has a REPEAT UNTIL loop, the REPEAT is before
a%=INSTR( and UNTIL is at the end. The loop will cycle indefinately so
that when a key is pressed, the relevant action is taken then the cycle
will continue testing for another key press and so on.

The procedures are called by:

IF a%=1PROCl(h%,v%,(v%+1)):c%=88

c% is the value for the pitch in the SOUND command.

Now I said that when the procedure is called it will include values for
the variables defined in the procedure name. What I've done here is to use
other variables to define those variables. The reason is that when this
key is pressed it will place a character (2 in fact, this note sits on a
line) onto the staff in a particular place. But the next note will need to
be further along so the TAB positions will need to be altered each time.
This is done by using some surprisingly simple arithmetic to produce the
values h% and v%. The third value is simply v% with 1 added.

h% is the number of spaces away from the left hand side of the screen. It
must change by 2 each time and also if the right hand side of the screen
is reached it will need to be brought back to the start. h% will take the
printing down to the next staff.

I defined another variable to take care of h% and v%. Surprisingly it's
called b%.

Initially b% was given the value 0 from outside the REPEAT UNTIL loop. It
will keep this value until the end of the loop a line:

b%=b%+2

will add 2 to it. It won't get to the end of the loop until a key has been
pressed. So for the first key press b% will = 0, for the second b% will =
2 and so on.

Back at the start of the loop were 3 lines:

IF b%<38v%=a%:ELSE v%=a%+8
IF b%>75v%=a%+16
IF b%>112END

b% will be less than 38 while printing on the first staff. So here v% will
be equal to a%. So in the example line printed above the second two v%
variables  (h%,v%,(v%+1)) will equal 1 and 2.

If b% was more than 38 v% would be equal to a% plus 8, so in our example
a%=1, a%+8=9. v%=9 v%+1=10. This is to print onto the second staff.

If b% was more than 75 v% would be equal to a%+16

Now there is an important point here. Pressing the first key, a%=1 so the
vertical printing positions will be 1 for the top half and 2 for the
bottom.

Pressing the second key a%=2 so the vertical printing positions will be 2
for the top half anf 3 for the bottom.


00000000  0d 31 30 20 4d 4f 44 45  34 0d 32 30 20 46 4f 52  |.10 MODE4.20 FOR|
00000010  20 41 3d 32 20 54 4f 20  36 3a 50 52 49 4e 54 54  | A=2 TO 6:PRINTT|
00000020  41 42 28 31 2c 41 29 53  54 52 49 4e 47 24 28 33  |AB(1,A)STRING$(3|
00000030  39 2c 22 5f 22 29 3a 4e  45 58 54 0d 0d 54 68 61  |9,"_"):NEXT..Tha|
00000040  74 27 73 20 6f 6e 65 20  73 74 61 66 66 20 64 72  |t's one staff dr|
00000050  61 77 6e 2e 20 54 68 65  20 6e 6f 74 65 73 20 6e  |awn. The notes n|
00000060  65 65 64 20 74 6f 20 62  65 20 64 65 66 69 6e 65  |eed to be define|
00000070  64 20 61 6e 64 20 66 6f  72 20 74 68 69 73 20 20  |d and for this  |
00000080  77 65 20 6e 65 65 64 0d  74 6f 20 72 65 73 6f 72  |we need.to resor|
00000090  74 20 74 6f 20 73 6f 6d  65 20 70 61 70 65 72 2e  |t to some paper.|
000000a0  20 4f 72 20 79 6f 75 20  6d 61 79 20 68 61 76 65  | Or you may have|
000000b0  20 61 20 63 68 61 72 61  63 74 65 72 20 64 65 66  | a character def|
000000c0  69 6e 69 6e 67 20 70 72  6f 67 72 61 6d 2e 20 49  |ining program. I|
000000d0  0d 68 61 76 65 20 6f 6e  65 20 73 6f 6d 65 77 68  |.have one somewh|
000000e0  65 72 65 2c 20 49 27 6c  6c 20 74 61 6b 65 20 61  |ere, I'll take a|
000000f0  20 6c 6f 6f 6b 20 61 74  20 69 74 20 61 6e 64 20  | look at it and |
00000100  73 65 65 20 69 66 20 69  74 20 63 61 6e 20 62 65  |see if it can be|
00000110  20 70 75 62 6c 69 73 68  65 64 0d 69 6e 20 45 55  | published.in EU|
00000120  47 2e 0d 0d 44 72 61 77  20 61 20 67 72 69 64 2c  |G...Draw a grid,|
00000130  20 38 20 78 20 38 20 62  6f 78 65 73 2e 20 66 69  | 8 x 8 boxes. fi|
00000140  6c 6c 20 69 6e 20 74 68  65 20 62 6f 78 65 73 20  |ll in the boxes |
00000150  77 68 69 63 68 20 77 69  6c 6c 20 6d 61 6b 65 20  |which will make |
00000160  74 68 65 20 73 68 61 70  65 20 79 6f 75 0d 77 61  |the shape you.wa|
00000170  6e 74 2e 20 4e 6f 77 20  77 6f 72 6b 69 6e 67 20  |nt. Now working |
00000180  68 6f 72 69 7a 6f 6e 74  61 6c 79 2c 20 74 68 65  |horizontaly, the|
00000190  20 66 69 72 73 74 20 62  6f 78 20 68 61 73 20 61  | first box has a|
000001a0  20 76 61 6c 75 65 20 6f  66 20 31 32 38 2c 20 74  | value of 128, t|
000001b0  68 65 20 32 65 64 20 3d  0d 36 34 2c 20 74 68 65  |he 2ed =.64, the|
000001c0  20 33 72 64 20 3d 20 33  32 2c 20 34 74 68 20 3d  | 3rd = 32, 4th =|
000001d0  20 31 36 2c 20 35 74 68  20 3d 20 38 2c 20 36 74  | 16, 5th = 8, 6t|
000001e0  68 20 3d 20 34 2c 20 37  74 68 20 3d 20 32 20 61  |h = 4, 7th = 2 a|
000001f0  6e 64 20 38 74 68 20 3d  20 31 2e 0d 0d 53 74 61  |nd 8th = 1...Sta|
00000200  72 74 20 66 72 6f 6d 20  74 68 65 20 66 69 72 73  |rt from the firs|
00000210  74 20 68 6f 72 69 7a 6f  6e 74 61 6c 20 72 6f 77  |t horizontal row|
00000220  20 61 74 20 74 68 65 20  74 6f 70 2e 20 63 68 65  | at the top. che|
00000230  63 6b 20 77 68 69 63 68  20 62 6f 78 65 73 20 68  |ck which boxes h|
00000240  61 76 65 0d 62 65 65 6e  20 66 69 6c 6c 65 64 20  |ave.been filled |
00000250  69 6e 20 61 6e 64 20 61  64 64 20 74 68 6f 73 65  |in and add those|
00000260  20 76 61 6c 75 65 73 20  74 6f 67 65 74 68 65 72  | values together|
00000270  2e 20 0d 0d 20 20 20 20  20 20 20 20 20 5f 5f 5f  |. ..         ___|
00000280  5f 5f 5f 5f 5f 5f 5f 5f  5f 5f 5f 5f 5f 5f 5f 5f  |________________|
00000290  5f 5f 5f 5f 5f 5f 5f 5f  5f 5f 5f 5f 5f 0d 20 20  |_____________.  |
000002a0  20 20 20 20 20 20 7c 5f  5f 5f 7c 5f 5f 5f 7c 5f  |      |___|___|_|
000002b0  5f 5f 7c 5f 5f 5f 7c 5f  5f 5f 7c 5f 5f 5f 7c 5f  |__|___|___|___|_|
000002c0  20 5f 7c 5f 5f 5f 7c 20  6e 6f 20 62 6f 78 65 73  | _|___| no boxes|
000002d0  20 3d 20 30 0d 20 20 20  20 20 20 20 20 7c 5f 5f  | = 0.        |__|
000002e0  5f 7c 5f 5f 5f 7c 5f 5f  5f 7c 5f 58 5f 7c 5f 58  |_|___|___|_X_|_X|
000002f0  5f 7c 5f 5f 5f 7c 5f 5f  5f 7c 5f 5f 5f 7c 20 34  |_|___|___|___| 4|
00000300  74 68 20 61 6e 64 20 35  74 68 20 3d 20 31 36 2b  |th and 5th = 16+|
00000310  38 3d 32 34 0d 20 20 20  20 20 20 20 20 7c 5f 5f  |8=24.        |__|
00000320  5f 7c 5f 5f 5f 7c 5f 58  5f 7c 5f 5f 5f 7c 5f 5f  |_|___|_X_|___|__|
00000330  5f 7c 5f 58 5f 7c 5f 5f  5f 7c 5f 5f 5f 7c 20 33  |_|_X_|___|___| 3|
00000340  72 64 20 61 6e 64 20 36  74 68 20 3d 20 33 32 2b  |rd and 6th = 32+|
00000350  34 3d 33 36 0d 20 20 20  20 20 20 20 20 7c 5f 5f  |4=36.        |__|
00000360  5f 7c 5f 58 5f 7c 5f 5f  5f 7c 5f 5f 5f 7c 5f 5f  |_|_X_|___|___|__|
00000370  5f 7c 5f 5f 5f 7c 5f 58  5f 7c 5f 5f 5f 7c 20 32  |_|___|_X_|___| 2|
00000380  65 64 20 61 6e 64 20 37  74 68 20 3d 20 36 34 2b  |ed and 7th = 64+|
00000390  32 3d 36 36 0d 20 20 20  20 20 20 20 20 7c 5f 5f  |2=66.        |__|
000003a0  5f 7c 5f 58 5f 7c 5f 5f  5f 7c 5f 5f 5f 7c 5f 5f  |_|_X_|___|___|__|
000003b0  5f 7c 5f 5f 5f 7c 5f 58  5f 7c 5f 5f 5f 7c 20 32  |_|___|_X_|___| 2|
000003c0  65 64 20 61 6e 64 20 37  74 68 20 3d 20 36 34 2b  |ed and 7th = 64+|
000003d0  32 3d 36 36 0d 20 20 20  20 20 20 20 20 7c 5f 5f  |2=66.        |__|
000003e0  5f 7c 5f 5f 5f 7c 5f 58  5f 7c 5f 5f 5f 7c 5f 5f  |_|___|_X_|___|__|
000003f0  5f 7c 5f 58 5f 7c 5f 5f  5f 7c 5f 5f 5f 7c 20 33  |_|_X_|___|___| 3|
00000400  72 64 20 61 6e 64 20 36  74 68 20 3d 20 33 32 2b  |rd and 6th = 32+|
00000410  34 3d 33 36 0d 20 20 20  20 20 20 20 20 7c 5f 5f  |4=36.        |__|
00000420  5f 7c 5f 5f 5f 7c 5f 5f  5f 7c 5f 58 5f 7c 5f 58  |_|___|___|_X_|_X|
00000430  5f 7c 5f 5f 5f 7c 5f 5f  5f 7c 5f 5f 5f 7c 20 34  |_|___|___|___| 4|
00000440  74 68 20 61 6e 64 20 35  74 68 20 3d 20 31 36 2b  |th and 5th = 16+|
00000450  38 3d 33 36 0d 20 20 20  20 20 20 20 20 7c 5f 5f  |8=36.        |__|
00000460  5f 7c 5f 5f 5f 7c 5f 5f  5f 7c 5f 5f 5f 7c 5f 5f  |_|___|___|___|__|
00000470  5f 7c 5f 5f 5f 7c 5f 5f  5f 7c 5f 5f 5f 7c 20 6e  |_|___|___|___| n|
00000480  6f 20 62 6f 78 65 73 20  3d 20 30 0d 20 20 20 20  |o boxes = 0.    |
00000490  20 20 20 20 20 31 32 38  20 20 36 34 20 20 33 32  |     128  64  32|
000004a0  20 20 31 36 20 20 38 20  20 20 34 20 20 20 32 20  |  16  8   4   2 |
000004b0  20 20 31 0d 0d 4e 6f 77  20 74 79 70 65 20 69 6e  |  1..Now type in|
000004c0  20 56 44 55 32 33 2c 32  32 34 2c 20 30 20 2c 20  | VDU23,224, 0 , |
000004d0  32 34 2c 20 33 36 2c 20  36 36 2c 20 36 36 2c 20  |24, 36, 66, 66, |
000004e0  33 36 2c 20 33 36 2c 20  30 0d 20 20 20 20 20 20  |36, 36, 0.      |
000004f0  20 20 20 20 20 20 20 20  20 20 20 20 20 20 20 20  |                |
00000500  31 73 74 2c 32 65 64 2c  33 72 64 2c 34 74 68 2c  |1st,2ed,3rd,4th,|
00000510  35 74 68 2c 36 74 68 2c  37 74 68 2c 38 74 68 0d  |5th,6th,7th,8th.|
00000520  0d 43 68 65 63 6b 20 74  68 65 20 63 68 61 72 61  |.Check the chara|
00000530  63 74 65 72 20 62 79 20  74 79 70 69 6e 67 20 50  |cter by typing P|
00000540  52 49 4e 54 20 43 48 52  24 32 32 36 20 3c 72 65  |RINT CHR$226 <re|
00000550  74 3e 0d 0d 54 68 65 73  65 20 6e 75 6d 62 65 72  |t>..These number|
00000560  73 20 61 72 65 20 64 69  66 66 65 72 65 6e 74 20  |s are different |
00000570  66 72 6f 6d 20 74 68 6f  73 65 20 75 73 65 64 20  |from those used |
00000580  66 6f 72 20 74 68 69 73  20 63 68 61 72 61 63 74  |for this charact|
00000590  65 72 20 69 6e 20 74 68  65 0d 70 72 6f 67 72 61  |er in the.progra|
000005a0  6d 2c 20 74 68 65 73 65  20 6e 75 6d 62 65 72 73  |m, these numbers|
000005b0  20 77 65 72 65 20 75 73  65 64 20 66 6f 72 20 63  | were used for c|
000005c0  6c 61 72 69 74 79 2e 0d  0d 54 68 65 20 6e 75 6d  |larity...The num|
000005d0  62 65 72 20 61 66 74 65  72 20 32 34 20 69 6e 20  |ber after 24 in |
000005e0  74 68 69 73 20 63 61 73  65 20 32 32 36 20 69 73  |this case 226 is|
000005f0  20 74 68 65 20 41 53 43  49 49 20 63 6f 64 65 20  | the ASCII code |
00000600  66 6f 72 20 74 68 65 20  63 68 61 72 61 63 74 65  |for the characte|
00000610  72 0d 6a 75 73 74 20 64  65 66 69 6e 65 64 2e 20  |r.just defined. |
00000620  59 6f 75 20 63 61 6e 20  75 73 65 20 61 6e 79 20  |You can use any |
00000630  6e 75 6d 62 65 72 20 62  65 74 77 65 65 6e 20 32  |number between 2|
00000640  32 34 20 61 6e 64 20 32  35 35 20 73 6f 20 74 68  |24 and 255 so th|
00000650  65 20 6e 65 78 74 0d 63  68 61 72 61 63 74 65 72  |e next.character|
00000660  20 79 6f 75 20 64 65 66  69 6e 65 20 6d 69 67 68  | you define migh|
00000670  74 20 62 65 20 56 44 55  32 34 2c 32 32 35 2c 65  |t be VDU24,225,e|
00000680  63 74 2e 2e 0d 0d 54 6f  20 63 61 6c 6c 20 74 68  |ct....To call th|
00000690  69 73 20 63 68 61 72 61  63 74 65 72 20 49 20 75  |is character I u|
000006a0  73 65 64 20 61 20 70 72  6f 63 65 64 75 72 65 2e  |sed a procedure.|
000006b0  0d 0d 44 45 46 20 50 52  4f 43 73 28 68 2c 76 29  |..DEF PROCs(h,v)|
000006c0  3a 50 52 49 4e 54 54 41  42 28 68 2c 76 29 43 48  |:PRINTTAB(h,v)CH|
000006d0  52 24 32 32 36 3a 45 4e  44 50 52 4f 43 0d 0d 44  |R$226:ENDPROC..D|
000006e0  45 46 20 6d 65 61 6e 73  20 64 65 66 69 6e 65 20  |EF means define |
000006f0  61 20 70 72 6f 63 65 64  75 72 65 20 6f 72 20 66  |a procedure or f|
00000700  75 6e 63 74 69 6f 6e 2e  20 49 6d 6d 65 64 69 61  |unction. Immedia|
00000710  74 65 6c 79 20 66 6f 6c  6c 6f 77 69 6e 67 20 44  |tely following D|
00000720  45 46 20 63 6f 6d 65 73  0d 74 68 65 20 6e 61 6d  |EF comes.the nam|
00000730  65 20 6f 66 20 74 68 65  20 70 72 6f 63 65 64 75  |e of the procedu|
00000740  72 65 20 50 52 4f 43 73  2e 20 49 6e 20 74 68 69  |re PROCs. In thi|
00000750  73 20 63 61 73 65 20 50  52 4f 43 73 20 69 73 20  |s case PROCs is |
00000760  66 6f 6c 6c 6f 77 65 64  20 62 79 20 74 77 6f 0d  |followed by two.|
00000770  76 61 72 69 61 62 6c 65  73 20 77 69 74 68 69 6e  |variables within|
00000780  20 62 72 61 63 6b 65 74  73 2e 20 57 68 65 6e 20  | brackets. When |
00000790  74 68 69 73 20 70 72 6f  63 65 64 75 72 65 20 69  |this procedure i|
000007a0  73 20 63 61 6c 6c 65 64  20 74 68 65 20 63 61 6c  |s called the cal|
000007b0  6c 20 77 69 6c 6c 0d 69  6e 63 6c 75 64 65 20 64  |l will.include d|
000007c0  65 66 69 6e 61 74 69 6f  6e 73 20 66 6f 72 20 74  |efinations for t|
000007d0  68 65 73 65 20 74 77 6f  20 76 61 72 69 61 62 6c  |hese two variabl|
000007e0  65 73 2e 20 54 68 65 20  70 72 6f 63 65 64 75 72  |es. The procedur|
000007f0  65 20 69 74 73 65 6c 66  20 69 73 0d 73 69 6d 70  |e itself is.simp|
00000800  6c 79 20 61 20 50 52 49  4e 54 54 41 42 20 73 74  |ly a PRINTTAB st|
00000810  61 74 65 6d 65 6e 74 2c  20 74 68 65 20 70 61 72  |atement, the par|
00000820  61 6d 65 74 65 72 73 20  66 6f 72 20 50 52 49 4e  |ameters for PRIN|
00000830  54 54 41 42 20 61 72 65  20 74 68 65 20 76 61 72  |TTAB are the var|
00000840  69 61 62 6c 65 73 0d 73  65 6e 74 20 62 79 20 74  |iables.sent by t|
00000850  68 65 20 70 72 6f 63 65  64 75 72 65 20 63 61 6c  |he procedure cal|
00000860  6c 2e 20 52 65 6d 65 6e  62 65 72 20 69 6e 20 61  |l. Remenber in a|
00000870  20 50 52 49 4e 54 54 41  42 20 73 74 61 74 65 6d  | PRINTTAB statem|
00000880  65 6e 74 2c 20 74 77 6f  20 6e 75 6d 62 65 72 73  |ent, two numbers|
00000890  0d 6d 75 73 74 20 62 65  20 69 6e 63 6c 75 64 65  |.must be include|
000008a0  64 20 77 68 69 63 68 20  77 69 6c 6c 20 64 69 63  |d which will dic|
000008b0  74 61 74 65 20 74 68 65  20 68 6f 72 69 7a 6f 6e  |tate the horizon|
000008c0  74 61 6c 20 61 6e 64 20  76 65 72 74 69 63 61 6c  |tal and vertical|
000008d0  20 70 6f 73 69 74 69 6f  6e 0d 6f 6e 20 74 68 65  | position.on the|
000008e0  20 73 63 72 65 65 6e 20  6f 66 20 77 68 65 72 65  | screen of where|
000008f0  20 74 68 65 20 63 68 61  72 61 63 74 65 72 20 74  | the character t|
00000900  6f 20 62 65 20 70 72 69  6e 74 65 64 20 69 73 20  |o be printed is |
00000910  74 6f 20 62 65 2e 0d 0d  54 68 69 73 20 63 68 61  |to be...This cha|
00000920  72 61 63 74 65 72 20 69  73 20 66 69 6e 65 20 66  |racter is fine f|
00000930  6f 72 20 62 65 74 77 65  65 6e 20 74 68 65 20 6c  |or between the l|
00000940  69 6e 65 73 20 46 2c 20  41 2c 20 43 2c 20 61 6e  |ines F, A, C, an|
00000950  64 20 45 20 62 75 74 20  66 6f 72 20 74 68 65 0d  |d E but for the.|
00000960  6e 6f 74 65 73 20 6f 6e  20 74 68 65 20 6c 69 6e  |notes on the lin|
00000970  65 73 20 77 65 20 6e 65  65 64 20 73 6f 6d 65 74  |es we need somet|
00000980  68 69 6e 67 20 65 6c 73  65 2e 20 49 66 20 77 65  |hing else. If we|
00000990  20 64 65 66 69 6e 65 20  32 20 73 65 6d 69 63 69  | define 2 semici|
000009a0  72 63 6c 65 73 2c 20 6f  6e 65 0d 66 61 63 69 6e  |rcles, one.facin|
000009b0  67 20 75 70 2c 20 74 68  65 20 6f 74 68 65 72 20  |g up, the other |
000009c0  66 61 63 69 6e 67 20 64  6f 77 6e 2c 20 74 68 65  |facing down, the|
000009d0  6e 20 70 72 6f 67 72 61  6d 20 74 68 65 6d 20 74  |n program them t|
000009e0  6f 20 62 65 20 70 6c 61  63 65 64 20 69 6e 74 6f  |o be placed into|
000009f0  0d 70 6f 73 69 74 69 6f  6e 20 74 6f 67 65 74 68  |.position togeth|
00000a00  65 72 20 74 68 65 20 65  66 66 65 63 74 20 77 69  |er the effect wi|
00000a10  6c 6c 20 62 65 20 61 63  68 65 76 65 64 2e 20 0d  |ll be acheved. .|
00000a20  0d 54 68 69 73 20 69 73  20 61 20 6c 6f 74 20 65  |.This is a lot e|
00000a30  61 73 69 65 72 20 74 68  61 74 20 79 6f 75 20 6d  |asier that you m|
00000a40  69 67 68 74 20 74 68 69  6e 6b 2e 0d 0d 54 68 65  |ight think...The|
00000a50  20 63 68 61 72 61 63 74  65 72 73 20 77 65 72 65  | characters were|
00000a60  20 64 65 66 69 6e 65 64  20 61 73 20 43 48 52 24  | defined as CHR$|
00000a70  32 32 34 20 66 6f 72 20  74 68 65 20 6c 6f 77 65  |224 for the lowe|
00000a80  72 20 68 61 6c 66 20 6f  66 20 74 68 65 20 63 69  |r half of the ci|
00000a90  72 63 6c 65 0d 61 6e 64  20 43 48 52 24 32 32 35  |rcle.and CHR$225|
00000aa0  20 66 6f 72 20 74 68 65  20 75 70 70 65 72 20 68  | for the upper h|
00000ab0  61 6c 66 2e 0d 0d 49 27  6d 20 6e 6f 74 20 67 6f  |alf...I'm not go|
00000ac0  69 6e 67 20 74 6f 20 64  65 73 63 72 69 62 65 20  |ing to describe |
00000ad0  61 67 61 69 6e 20 68 6f  77 20 61 20 63 68 61 72  |again how a char|
00000ae0  61 63 74 65 72 20 69 73  20 64 65 66 69 6e 65 64  |acter is defined|
00000af0  20 62 75 74 20 66 6f 72  20 74 68 65 0d 6c 6f 77  | but for the.low|
00000b00  65 72 20 73 65 6d 69 63  69 72 63 6c 65 20 74 68  |er semicircle th|
00000b10  65 20 63 75 70 20 73 69  64 65 20 73 69 74 73 20  |e cup side sits |
00000b20  6f 6e 20 74 68 65 20 74  6f 70 20 72 6f 77 20 6f  |on the top row o|
00000b30  66 20 74 68 65 20 67 72  69 64 20 61 6e 64 20 74  |f the grid and t|
00000b40  68 65 0d 63 75 72 76 65  20 73 69 74 73 20 33 20  |he.curve sits 3 |
00000b50  72 6f 77 73 20 64 6f 77  6e 2e 20 54 68 65 20 6f  |rows down. The o|
00000b60  74 68 65 72 20 73 65 6d  69 63 69 72 63 6c 65 20  |ther semicircle |
00000b70  6f 66 63 6f 75 72 73 65  20 69 73 20 74 68 65 20  |ofcourse is the |
00000b80  65 78 61 63 74 0d 6f 70  70 6f 73 69 74 65 2e 0d  |exact.opposite..|
00000b90  0d 56 44 55 32 34 2c 32  32 34 2c 36 36 2c 36 36  |.VDU24,224,66,66|
00000ba0  2c 36 30 2c 30 2c 30 2c  30 2c 30 2c 30 20 61 6e  |,60,0,0,0,0,0 an|
00000bb0  64 20 56 44 55 32 34 2c  32 32 35 2c 30 2c 30 2c  |d VDU24,225,0,0,|
00000bc0  30 2c 30 2c 30 2c 36 30  2c 36 36 2c 36 36 0d 0d  |0,0,0,60,66,66..|
00000bd0  54 68 65 20 70 72 6f 63  65 64 75 72 65 20 77 61  |The procedure wa|
00000be0  73 20 64 65 66 69 6e 65  64 20 61 73 3a 0d 0d 44  |s defined as:..D|
00000bf0  45 46 20 50 52 4f 43 6c  28 68 2c 76 2c 76 31 29  |EF PROCl(h,v,v1)|
00000c00  3a 50 52 49 4e 54 54 41  42 28 68 2c 76 29 43 48  |:PRINTTAB(h,v)CH|
00000c10  52 24 32 32 35 3a 50 52  49 4e 54 54 41 42 28 68  |R$225:PRINTTAB(h|
00000c20  2c 76 31 29 43 48 52 24  32 32 34 3a 45 4e 44 50  |,v1)CHR$224:ENDP|
00000c30  52 4f 43 0d 0d 48 65 72  65 20 74 68 65 20 70 72  |ROC..Here the pr|
00000c40  6f 63 65 64 75 72 65 20  6e 61 6d 65 20 68 61 64  |ocedure name had|
00000c50  20 74 68 72 65 65 20 76  61 72 69 61 62 6c 65 73  | three variables|
00000c60  2c 20 68 2c 76 20 20 61  6e 64 20 76 31 2e 20 49  |, h,v  and v1. I|
00000c70  6e 20 74 68 65 20 50 52  49 4e 54 54 41 42 0d 73  |n the PRINTTAB.s|
00000c80  74 61 74 65 6d 65 6e 74  73 20 62 6f 74 68 20 73  |tatements both s|
00000c90  68 61 72 65 64 20 68 20  77 68 69 63 68 20 69 73  |hared h which is|
00000ca0  20 74 68 65 20 68 6f 72  69 7a 6f 6e 74 61 6c 20  | the horizontal |
00000cb0  70 6f 73 69 74 69 6f 6e  20 62 75 74 20 6f 6e 65  |position but one|
00000cc0  20 75 73 65 64 20 76 0d  66 6f 72 20 69 74 73 20  | used v.for its |
00000cd0  76 65 72 74 69 63 61 6c  20 77 68 69 6c 65 20 74  |vertical while t|
00000ce0  68 65 20 6f 74 68 65 72  20 75 73 65 64 20 76 31  |he other used v1|
00000cf0  2e 0d 0d 54 68 65 20 61  25 3d 49 4e 53 54 52 28  |...The a%=INSTR(|
00000d00  20 6c 69 6e 65 20 77 68  69 63 68 20 77 61 73 20  | line which was |
00000d10  75 73 65 64 20 61 62 6f  76 65 20 61 6e 64 20 69  |used above and i|
00000d20  6e 20 74 68 65 20 45 55  47 20 6d 65 6e 75 20 69  |n the EUG menu i|
00000d30  73 20 75 73 65 64 20 69  6e 0d 74 68 69 73 20 70  |s used in.this p|
00000d40  72 6f 67 72 61 6d 2e 20  54 68 69 73 20 6c 69 6e  |rogram. This lin|
00000d50  65 20 68 61 73 20 61 20  52 45 50 45 41 54 20 55  |e has a REPEAT U|
00000d60  4e 54 49 4c 20 6c 6f 6f  70 2c 20 74 68 65 20 52  |NTIL loop, the R|
00000d70  45 50 45 41 54 20 69 73  20 62 65 66 6f 72 65 0d  |EPEAT is before.|
00000d80  61 25 3d 49 4e 53 54 52  28 20 61 6e 64 20 55 4e  |a%=INSTR( and UN|
00000d90  54 49 4c 20 69 73 20 61  74 20 74 68 65 20 65 6e  |TIL is at the en|
00000da0  64 2e 20 54 68 65 20 6c  6f 6f 70 20 77 69 6c 6c  |d. The loop will|
00000db0  20 63 79 63 6c 65 20 69  6e 64 65 66 69 6e 61 74  | cycle indefinat|
00000dc0  65 6c 79 20 73 6f 0d 74  68 61 74 20 77 68 65 6e  |ely so.that when|
00000dd0  20 61 20 6b 65 79 20 69  73 20 70 72 65 73 73 65  | a key is presse|
00000de0  64 2c 20 74 68 65 20 72  65 6c 65 76 61 6e 74 20  |d, the relevant |
00000df0  61 63 74 69 6f 6e 20 69  73 20 74 61 6b 65 6e 20  |action is taken |
00000e00  74 68 65 6e 20 74 68 65  20 63 79 63 6c 65 0d 77  |then the cycle.w|
00000e10  69 6c 6c 20 63 6f 6e 74  69 6e 75 65 20 74 65 73  |ill continue tes|
00000e20  74 69 6e 67 20 66 6f 72  20 61 6e 6f 74 68 65 72  |ting for another|
00000e30  20 6b 65 79 20 70 72 65  73 73 20 61 6e 64 20 73  | key press and s|
00000e40  6f 20 6f 6e 2e 0d 0d 54  68 65 20 70 72 6f 63 65  |o on...The proce|
00000e50  64 75 72 65 73 20 61 72  65 20 63 61 6c 6c 65 64  |dures are called|
00000e60  20 62 79 3a 0d 0d 49 46  20 61 25 3d 31 50 52 4f  | by:..IF a%=1PRO|
00000e70  43 6c 28 68 25 2c 76 25  2c 28 76 25 2b 31 29 29  |Cl(h%,v%,(v%+1))|
00000e80  3a 63 25 3d 38 38 0d 0d  63 25 20 69 73 20 74 68  |:c%=88..c% is th|
00000e90  65 20 76 61 6c 75 65 20  66 6f 72 20 74 68 65 20  |e value for the |
00000ea0  70 69 74 63 68 20 69 6e  20 74 68 65 20 53 4f 55  |pitch in the SOU|
00000eb0  4e 44 20 63 6f 6d 6d 61  6e 64 2e 0d 0d 4e 6f 77  |ND command...Now|
00000ec0  20 49 20 73 61 69 64 20  74 68 61 74 20 77 68 65  | I said that whe|
00000ed0  6e 20 74 68 65 20 70 72  6f 63 65 64 75 72 65 20  |n the procedure |
00000ee0  69 73 20 63 61 6c 6c 65  64 20 69 74 20 77 69 6c  |is called it wil|
00000ef0  6c 20 69 6e 63 6c 75 64  65 20 76 61 6c 75 65 73  |l include values|
00000f00  20 66 6f 72 0d 74 68 65  20 76 61 72 69 61 62 6c  | for.the variabl|
00000f10  65 73 20 64 65 66 69 6e  65 64 20 69 6e 20 74 68  |es defined in th|
00000f20  65 20 70 72 6f 63 65 64  75 72 65 20 6e 61 6d 65  |e procedure name|
00000f30  2e 20 57 68 61 74 20 49  27 76 65 20 64 6f 6e 65  |. What I've done|
00000f40  20 68 65 72 65 20 69 73  20 74 6f 20 75 73 65 0d  | here is to use.|
00000f50  6f 74 68 65 72 20 76 61  72 69 61 62 6c 65 73 20  |other variables |
00000f60  74 6f 20 64 65 66 69 6e  65 20 74 68 6f 73 65 20  |to define those |
00000f70  76 61 72 69 61 62 6c 65  73 2e 20 54 68 65 20 72  |variables. The r|
00000f80  65 61 73 6f 6e 20 69 73  20 74 68 61 74 20 77 68  |eason is that wh|
00000f90  65 6e 20 74 68 69 73 0d  6b 65 79 20 69 73 20 70  |en this.key is p|
00000fa0  72 65 73 73 65 64 20 69  74 20 77 69 6c 6c 20 70  |ressed it will p|
00000fb0  6c 61 63 65 20 61 20 63  68 61 72 61 63 74 65 72  |lace a character|
00000fc0  20 28 32 20 69 6e 20 66  61 63 74 2c 20 74 68 69  | (2 in fact, thi|
00000fd0  73 20 6e 6f 74 65 20 73  69 74 73 20 6f 6e 20 61  |s note sits on a|
00000fe0  0d 6c 69 6e 65 29 20 6f  6e 74 6f 20 74 68 65 20  |.line) onto the |
00000ff0  73 74 61 66 66 20 69 6e  20 61 20 70 61 72 74 69  |staff in a parti|
00001000  63 75 6c 61 72 20 70 6c  61 63 65 2e 20 42 75 74  |cular place. But|
00001010  20 74 68 65 20 6e 65 78  74 20 6e 6f 74 65 20 77  | the next note w|
00001020  69 6c 6c 20 6e 65 65 64  20 74 6f 0d 62 65 20 66  |ill need to.be f|
00001030  75 72 74 68 65 72 20 61  6c 6f 6e 67 20 73 6f 20  |urther along so |
00001040  74 68 65 20 54 41 42 20  70 6f 73 69 74 69 6f 6e  |the TAB position|
00001050  73 20 77 69 6c 6c 20 6e  65 65 64 20 74 6f 20 62  |s will need to b|
00001060  65 20 61 6c 74 65 72 65  64 20 65 61 63 68 20 74  |e altered each t|
00001070  69 6d 65 2e 0d 54 68 69  73 20 69 73 20 64 6f 6e  |ime..This is don|
00001080  65 20 62 79 20 75 73 69  6e 67 20 73 6f 6d 65 20  |e by using some |
00001090  73 75 72 70 72 69 73 69  6e 67 6c 79 20 73 69 6d  |surprisingly sim|
000010a0  70 6c 65 20 61 72 69 74  68 6d 65 74 69 63 20 74  |ple arithmetic t|
000010b0  6f 20 70 72 6f 64 75 63  65 20 74 68 65 0d 76 61  |o produce the.va|
000010c0  6c 75 65 73 20 68 25 20  61 6e 64 20 76 25 2e 20  |lues h% and v%. |
000010d0  54 68 65 20 74 68 69 72  64 20 76 61 6c 75 65 20  |The third value |
000010e0  69 73 20 73 69 6d 70 6c  79 20 76 25 20 77 69 74  |is simply v% wit|
000010f0  68 20 31 20 61 64 64 65  64 2e 0d 0d 68 25 20 69  |h 1 added...h% i|
00001100  73 20 74 68 65 20 6e 75  6d 62 65 72 20 6f 66 20  |s the number of |
00001110  73 70 61 63 65 73 20 61  77 61 79 20 66 72 6f 6d  |spaces away from|
00001120  20 74 68 65 20 6c 65 66  74 20 68 61 6e 64 20 73  | the left hand s|
00001130  69 64 65 20 6f 66 20 74  68 65 20 73 63 72 65 65  |ide of the scree|
00001140  6e 2e 20 49 74 0d 6d 75  73 74 20 63 68 61 6e 67  |n. It.must chang|
00001150  65 20 62 79 20 32 20 65  61 63 68 20 74 69 6d 65  |e by 2 each time|
00001160  20 61 6e 64 20 61 6c 73  6f 20 69 66 20 74 68 65  | and also if the|
00001170  20 72 69 67 68 74 20 68  61 6e 64 20 73 69 64 65  | right hand side|
00001180  20 6f 66 20 74 68 65 20  73 63 72 65 65 6e 0d 69  | of the screen.i|
00001190  73 20 72 65 61 63 68 65  64 20 69 74 20 77 69 6c  |s reached it wil|
000011a0  6c 20 6e 65 65 64 20 74  6f 20 62 65 20 62 72 6f  |l need to be bro|
000011b0  75 67 68 74 20 62 61 63  6b 20 74 6f 20 74 68 65  |ught back to the|
000011c0  20 73 74 61 72 74 2e 20  68 25 20 77 69 6c 6c 20  | start. h% will |
000011d0  74 61 6b 65 20 74 68 65  0d 70 72 69 6e 74 69 6e  |take the.printin|
000011e0  67 20 64 6f 77 6e 20 74  6f 20 74 68 65 20 6e 65  |g down to the ne|
000011f0  78 74 20 73 74 61 66 66  2e 0d 0d 49 20 64 65 66  |xt staff...I def|
00001200  69 6e 65 64 20 61 6e 6f  74 68 65 72 20 76 61 72  |ined another var|
00001210  69 61 62 6c 65 20 74 6f  20 74 61 6b 65 20 63 61  |iable to take ca|
00001220  72 65 20 6f 66 20 68 25  20 61 6e 64 20 76 25 2e  |re of h% and v%.|
00001230  20 53 75 72 70 72 69 73  69 6e 67 6c 79 20 69 74  | Surprisingly it|
00001240  27 73 0d 63 61 6c 6c 65  64 20 62 25 2e 0d 0d 49  |'s.called b%...I|
00001250  6e 69 74 69 61 6c 6c 79  20 62 25 20 77 61 73 20  |nitially b% was |
00001260  67 69 76 65 6e 20 74 68  65 20 76 61 6c 75 65 20  |given the value |
00001270  30 20 66 72 6f 6d 20 6f  75 74 73 69 64 65 20 74  |0 from outside t|
00001280  68 65 20 52 45 50 45 41  54 20 55 4e 54 49 4c 20  |he REPEAT UNTIL |
00001290  6c 6f 6f 70 2e 20 49 74  0d 77 69 6c 6c 20 6b 65  |loop. It.will ke|
000012a0  65 70 20 74 68 69 73 20  76 61 6c 75 65 20 75 6e  |ep this value un|
000012b0  74 69 6c 20 74 68 65 20  65 6e 64 20 6f 66 20 74  |til the end of t|
000012c0  68 65 20 6c 6f 6f 70 20  61 20 6c 69 6e 65 3a 0d  |he loop a line:.|
000012d0  0d 62 25 3d 62 25 2b 32  0d 0d 77 69 6c 6c 20 61  |.b%=b%+2..will a|
000012e0  64 64 20 32 20 74 6f 20  69 74 2e 20 49 74 20 77  |dd 2 to it. It w|
000012f0  6f 6e 27 74 20 67 65 74  20 74 6f 20 74 68 65 20  |on't get to the |
00001300  65 6e 64 20 6f 66 20 74  68 65 20 6c 6f 6f 70 20  |end of the loop |
00001310  75 6e 74 69 6c 20 61 20  6b 65 79 20 68 61 73 20  |until a key has |
00001320  62 65 65 6e 0d 70 72 65  73 73 65 64 2e 20 53 6f  |been.pressed. So|
00001330  20 66 6f 72 20 74 68 65  20 66 69 72 73 74 20 6b  | for the first k|
00001340  65 79 20 70 72 65 73 73  20 62 25 20 77 69 6c 6c  |ey press b% will|
00001350  20 3d 20 30 2c 20 66 6f  72 20 74 68 65 20 73 65  | = 0, for the se|
00001360  63 6f 6e 64 20 62 25 20  77 69 6c 6c 20 3d 0d 32  |cond b% will =.2|
00001370  20 61 6e 64 20 73 6f 20  6f 6e 2e 0d 0d 42 61 63  | and so on...Bac|
00001380  6b 20 61 74 20 74 68 65  20 73 74 61 72 74 20 6f  |k at the start o|
00001390  66 20 74 68 65 20 6c 6f  6f 70 20 77 65 72 65 20  |f the loop were |
000013a0  33 20 6c 69 6e 65 73 3a  0d 0d 49 46 20 62 25 3c  |3 lines:..IF b%<|
000013b0  33 38 76 25 3d 61 25 3a  45 4c 53 45 20 76 25 3d  |38v%=a%:ELSE v%=|
000013c0  61 25 2b 38 0d 49 46 20  62 25 3e 37 35 76 25 3d  |a%+8.IF b%>75v%=|
000013d0  61 25 2b 31 36 0d 49 46  20 62 25 3e 31 31 32 45  |a%+16.IF b%>112E|
000013e0  4e 44 0d 0d 62 25 20 77  69 6c 6c 20 62 65 20 6c  |ND..b% will be l|
000013f0  65 73 73 20 74 68 61 6e  20 33 38 20 77 68 69 6c  |ess than 38 whil|
00001400  65 20 70 72 69 6e 74 69  6e 67 20 6f 6e 20 74 68  |e printing on th|
00001410  65 20 66 69 72 73 74 20  73 74 61 66 66 2e 20 53  |e first staff. S|
00001420  6f 20 68 65 72 65 20 76  25 20 77 69 6c 6c 0d 62  |o here v% will.b|
00001430  65 20 65 71 75 61 6c 20  74 6f 20 61 25 2e 20 53  |e equal to a%. S|
00001440  6f 20 69 6e 20 74 68 65  20 65 78 61 6d 70 6c 65  |o in the example|
00001450  20 6c 69 6e 65 20 70 72  69 6e 74 65 64 20 61 62  | line printed ab|
00001460  6f 76 65 20 74 68 65 20  73 65 63 6f 6e 64 20 74  |ove the second t|
00001470  77 6f 20 76 25 0d 76 61  72 69 61 62 6c 65 73 20  |wo v%.variables |
00001480  20 28 68 25 2c 76 25 2c  28 76 25 2b 31 29 29 20  | (h%,v%,(v%+1)) |
00001490  77 69 6c 6c 20 65 71 75  61 6c 20 31 20 61 6e 64  |will equal 1 and|
000014a0  20 32 2e 20 0d 0d 49 66  20 62 25 20 77 61 73 20  | 2. ..If b% was |
000014b0  6d 6f 72 65 20 74 68 61  6e 20 33 38 20 76 25 20  |more than 38 v% |
000014c0  77 6f 75 6c 64 20 62 65  20 65 71 75 61 6c 20 74  |would be equal t|
000014d0  6f 20 61 25 20 70 6c 75  73 20 38 2c 20 73 6f 20  |o a% plus 8, so |
000014e0  69 6e 20 6f 75 72 20 65  78 61 6d 70 6c 65 0d 61  |in our example.a|
000014f0  25 3d 31 2c 20 61 25 2b  38 3d 39 2e 20 76 25 3d  |%=1, a%+8=9. v%=|
00001500  39 20 76 25 2b 31 3d 31  30 2e 20 54 68 69 73 20  |9 v%+1=10. This |
00001510  69 73 20 74 6f 20 70 72  69 6e 74 20 6f 6e 74 6f  |is to print onto|
00001520  20 74 68 65 20 73 65 63  6f 6e 64 20 73 74 61 66  | the second staf|
00001530  66 2e 20 0d 0d 49 66 20  62 25 20 77 61 73 20 6d  |f. ..If b% was m|
00001540  6f 72 65 20 74 68 61 6e  20 37 35 20 76 25 20 77  |ore than 75 v% w|
00001550  6f 75 6c 64 20 62 65 20  65 71 75 61 6c 20 74 6f  |ould be equal to|
00001560  20 61 25 2b 31 36 0d 0d  4e 6f 77 20 74 68 65 72  | a%+16..Now ther|
00001570  65 20 69 73 20 61 6e 20  69 6d 70 6f 72 74 61 6e  |e is an importan|
00001580  74 20 70 6f 69 6e 74 20  68 65 72 65 2e 20 50 72  |t point here. Pr|
00001590  65 73 73 69 6e 67 20 74  68 65 20 66 69 72 73 74  |essing the first|
000015a0  20 6b 65 79 2c 20 61 25  3d 31 20 73 6f 20 74 68  | key, a%=1 so th|
000015b0  65 0d 76 65 72 74 69 63  61 6c 20 70 72 69 6e 74  |e.vertical print|
000015c0  69 6e 67 20 70 6f 73 69  74 69 6f 6e 73 20 77 69  |ing positions wi|
000015d0  6c 6c 20 62 65 20 31 20  66 6f 72 20 74 68 65 20  |ll be 1 for the |
000015e0  74 6f 70 20 68 61 6c 66  20 61 6e 64 20 32 20 66  |top half and 2 f|
000015f0  6f 72 20 74 68 65 0d 62  6f 74 74 6f 6d 2e 0d 0d  |or the.bottom...|
00001600  50 72 65 73 73 69 6e 67  20 74 68 65 20 73 65 63  |Pressing the sec|
00001610  6f 6e 64 20 6b 65 79 20  61 25 3d 32 20 73 6f 20  |ond key a%=2 so |
00001620  74 68 65 20 76 65 72 74  69 63 61 6c 20 70 72 69  |the vertical pri|
00001630  6e 74 69 6e 67 20 70 6f  73 69 74 69 6f 6e 73 20  |nting positions |
00001640  77 69 6c 6c 20 62 65 20  32 0d 66 6f 72 20 74 68  |will be 2.for th|
00001650  65 20 74 6f 70 20 68 61  6c 66 20 61 6e 66 20 33  |e top half anf 3|
00001660  20 66 6f 72 20 74 68 65  20 62 6f 74 74 6f 6d 2e  | for the bottom.|
00001670  0d 0d                                             |..|
00001672
P/+mtext2.m0
P/+mtext2.m1
P/+mtext2.m2
P/+mtext2.m4
P/+mtext2.m5

© Dominic Ford 2021–2024.

Our privacy policy is here.
Last updated: 28 Jul 2024, 23:31 UTC
Website designed by .
