USING THE ASSEMBLER 6
~~~~~~~~~~~~~~~~~~~~~
By Richard Dimond
As promised, I now will describe the making of maps for arcade type games
as I wanted to publish my version of Mr Miner which was published as a
hybrid (BASIC plus M/code) program in EU Sep 1987.
This is really the same as in BASIC but the DATA is loaded to an address
within the M/code file.
A map consists of data for the various characters represented by letters
or numbers. In this game the letters A to I are used to represent -
A - Brick wall
B - Rock
C - Diamond
D - Mushroom
E - Earth
F - Space
G - Man
H - Safe (containing a diamond)
I - Flashing key
I have included a program (MAZELD) which LOADs and SAVEs the original
levels. These are SAVEd as MAZE1. The program asks for the suffix number
before the file is SAVEd. The files are saved for loading at &1EE0 as is
needed for the M/code file.
The data lines are arranged in 25 lines of 18 characters, which is the
size of the play area for each level, so that you may be able see how the
map will appear on the screen by comparing the codes used. You can alter
these lines and re-SAVE the file with a different suffix number to see the
effect.
I will now describe how I have made up the M/code for the game and comment
on the routines used.
Due to the length of the assembler listings, the code is assembled in two
parts and then these are LOADed together and SAVEd as one file with the
short program MINERldr. This must be RUN at &E00. Do NOT run this
program without first setting up the code with MINsrc2 as P% will not be
set the end of the code.
In both parts, I found it more convenient to assemble the code below PAGE
and the assembler programs must be RUN with PAGE at &1D00. The code is
then assembled at &E00 but as if assembled at the correct address. This
is done by using OPT 4 - 7 instead of OPT 0 - 3. This assembles at O% but
with addresses as for P%.
PAGE must be initially at &E00 so ADFS users will not be able to use these
programs (unless they use tape?) but can LIST them to see how they are
made up. Also, the length of the second part needs HIMEM to be raised
too. I have included a short program (MINs2rn) which sets PAGE and HIMEM
before CHAINing MINsrc2 for those with 32k Elks who might like to
experiment with these.
Both programs are set to RUN at &1D00 by line 50 in each program.
Program 1 (MINsrc1) is the assembler listing of the original M/code and
DATA though I have altered the addresses so as to combine the code into
one file which is to be loaded to &1D00. This saves the file MIN1
(addresses &1D00 to &2B7C)
Line 60 loads the sprite data to &1D00, DATA lines 140 - 200
Lines 70-90 loads the map data to &1EE0, DATA lines 210 - 320
Line 100 loads the tune data to &27AA, DATA lines 330 - 360
The PROCassem is then called to assemble the code at &2885. I will not
describe this in too much detail, partly because I have not studied it
enough to do so but I want say more about what I have done in the second
part. I hope the following brief notes will be of interest. I will refer
to the lines of the assembler listing which produce the code for each
routine.
Subroutine Z% (lines 450-470) is the code for the tune at &2885. This
loads the value for pitch and duration, depending on the value of the
variable 'p', which are loaded into the sound buffer at &AF0 (line 460).
The value of 'p' decrases by each time the code is called so producing a
different note. Because the event vector is set to Z%, the tune will
start by using *FX14,4 and continue until *FX13,4 is used.
Subroutine S% (480-830) reads the character number from the data and,
after the comparison, loads the address of the character data into &80 and
&81. This is then used by the print subroutine to print the sprite. This
routine was explained in a series of articles in EU (Feb - Sep 1988).
Subroutine R% (840-1060) is concerned with the falling of rocks and
squashing of mushrooms and whether you lose a life.
Subroutine T% (1070-1120) replaces safes with diamonds when the key is
collected.
Program 2 (MINsrc2) is my additional M/code and includes several routines
already described. This creates file MIN2 for loading to &2B7D. It is
arranged in three sections as in the program for the tutorial.
1. Main loop (lines 80 - 470)
2. Subroutines (lines 480 - 1570)
3. Data (lines 1580 - 2090)
I will first write notes on the subroutines.
p (480,490) is the loop given last time for giving the commands in the
data lines as was explained.
dh (500-520) is the double size printing routine as given earlier.
choose (530-670) responds to the key pressed.
P ends the procedure to start the game
L calls the subroutine mload for loading other maze files
S and Q call the subroutines for turning the sound on/off
1, 2 and 3 set the value the variable spd to set the speed of the
game as explained in an earlier article.
I had to experiment with the number of ASL As and also add the SBC in line
630 to get a good choice of speeds. Those who are able to re-assemble the
code may like to experiment with this.
init (680-740) sets the variables. Loads &5300 to &56FF with the brick
character number(224) lines 700,710. This is done so that, when each
level is loaded over this area, there is a border three bricks wide around
the play area. The routine also loads &5700 to &57FF with space
characters(229) and calls the subroutine env for setting up the sound
envelopes.
sdoff and sdon (750,760) are the M/code equivalents of *FX210,1 and
*FX210,0.
sond1 to sond6 (770-820) when called give the sounds needed. The values
of A, X and Y need to be preserved each time and therefore PUSHed and
PULLed from the stack. The sound is given by using osword with register
A loaded with 7 and the address of the data in X and Y registers. The
data needed are the four sound parameters entered as words (EQUW), DATA
lines 1880-1930.
env (830-850) set up the three envelopes. Each is set up with osword in
the same way but with A register loaded with 8 and data lines with the 14
parameters entered as bytes (EQUB), DATA lines 1850-1870.
delsp, dels and dell (860-880) are delay routines and are simply nested
loops as given in an earlier article. dels and dell are short and long
delays and delsp depends on the value of the variable spd which has been
selcted. Again the number NOPs could be varied if anyone wishes to do
this.
