File contents
   10MODE3:VDU23,1,0;0;0;0;:VDU14:PRINT''"PRESS <SHIFT> TO SCROLL"'':PROCtext
   20REPEAT:PRINT''"PLEASE PRESS <P> TO PRINT TEXT, <D> TO VIEW DIAGRAM, <M> FOR MAIN MENU"
   30REPEAT:A%=INSTR("DMP",GET$):UNTILA%
   40IFA%=1 THEN Z%=0
   50IFA%=1 THENCHAIN"$.DLOAD"
   60IFA%=2 THENCHAIN"$.MENU"
   70IFA%=3 THENVDU15:VDU2:PROCtext:VDU3
   80UNTIL FALSE
   90END
  100DEF PROCtext
  110PRINT"Once you've got your new drive connected up you can test it by formatting"
  120PRINT"a disc  and saving a file onto it. Re-load the program and attempt to run"
  130PRINT"it. The drive head may be a fraction off alignment however, in which case"
  140PRINT"it may work ok, but all your discs will be useless on anyone elses' drive"
  150PRINT"and their discs won't run on yours."
  160PRINT
  170PRINT"FRC ELECTRONICS (disc drive specialists) will do a complete re-align and"
  180PRINT"fault diagnosis for a total of #31.14 (including VAT and return P&P), plus"
  190PRINT"whatever it costs you to post the drive to them. But if you're going to do"
  200PRINT"this you may as well buy a refurb Beeb drive instead. Thus, if you're"
  210PRINT"fairly handy with a screwdriver and feeling brave you can attempt the"
  220PRINT"following:-"
  230PRINT
  240PRINT"(1) ALL - Obtain a formatted disc from someone with a drive which is known"
  250PRINT"to be ok and obviously formatted to whichever system you have (DFS or"
  260PRINT"ADFS)."
  270PRINT
  280PRINT"(2) DFS - (for ADFS go to 3) Assuming you have set your ""new"" drive as"
  290PRINT"drive 1 (DS1) put the disc you've  obtained from the good drive in and"
  300PRINT"type *CAT 1. If your drive's ok you should get the disc details and a"
  310PRINT"catalogue of programs (if any) on screen. I recommend you use a disc"
  320PRINT"without any programs on in case it gets damaged. If your drive is out of"
  330PRINT"alignment you will get, after what seems like eternity, DISC ERROR 18"
  340PRINT"1:00/00 or something similar. (GO TO 4)"
  350PRINT
  360PRINT"(3) ADFS - Assuming you have your ""new"" drive set as drive 1 (DS1),"
  370PRINT"put the disc you've obtained from the good drive in and type *MOUNT 1.If"
  380PRINT"your drive's ok you will get the prompt > on screen. If your drive is out"
  390PRINT"of alignment you will get (after what seems like after eternity), the"
  400PRINT"on-screen message DISC ERROR 50 1:00/00 or something similar.(GO TO 4)"
  410PRINT
  420PRINT"(4) ALL - At  the rear of the disc drive circuit board (the side with all"
  430PRINT"the links on) you will find a small white plug with multi-coloured wires"
  440PRINT"attached. This comes from the stepper motor. Carefully unplug this plug."
  450PRINT"When you now come to activate the drive (as in 2 or 3) the disc will"
  460PRINT"rotate but the head will not move."
  470PRINT
  480PRINT"(5) ALL - Activate the disc (as in 2 or 3) and carefully move the head (it"
  490PRINT"moves quite freely on its runners with the motor disconnected) until you"
  500PRINT"get the appropriate display on screen.You may have to have a few goes as"
  510PRINT"if you're not quick enough the DISC ERROR message will appear before"
  520PRINT"you've located the head correctly."
  530PRINT
  540PRINT"(6) ALL - There is a stop with a screw in it which stops the head going"
  550PRINT"too far back. Slacken the screw and adjust the stop so that it touches the"
  560PRINT"back of the head at the point you've just found. Check by running the"
  570PRINT"drive that you've not inadvertently moved the head a fraction. Adjust as"
  580PRINT"necessary and when you're happy tighten the screw as much as possible."
  590PRINT
  600PRINT"(7) ALL - Reconnect the little white plug. If the head now moves away from"
  610PRINT"the stop i.e to the right (as in my case), slacken the two screws holding"
  620PRINT"the  stepper motor in place and carefully slide the motor left or right"
  630PRINT"(with the power still connected) until the head comes to rest on the stop."
  640PRINT"Tighten the two screws as much as possible."
  650PRINT
  660PRINT"Your drive should now be re-aligned and all discs previously produced on"
  670PRINT"it will be unreadable. All you need do now is reformat them and as a"
  680PRINT"double check run them on the drive you get the reference discs from."
  690PRINT
  700PRINT"                            SUPPLY ADDRESSES"
  710PRINT"                            ~~~~~~~~~~~~~~~~"
  720PRINT"DISPLAY ELECTRONICS                            GREENWELD ELECTRONICS"
  730PRINT"32 BIGGIN WAY                                  27 PARK ROAD         "
  740PRINT"UPPER NORWOOD                                  SOUTHAMPTON          "
  750PRINT"LONDON                                         SO1 3TB              "
  760PRINT"SE19 3XF                                       (0703 236363)        "
  770PRINT"(081 679 4414)                                                      "
  780PRINT
  790PRINT"FRC ELECTRONICS                                P R E S"
  800PRINT"52 QUEENSWAY                                   PO BOX 319"
  810PRINT"CAVERSHAM PARK VILLAGE                         LIGHTWATER "
  820PRINT"READING                                        SURREY      "
  830PRINT"BERKSHIRE                                      GU18 5PW     "
  840PRINT"RG4 0SJ                                        (0276 472046) "
  850PRINT"(0734 479550)                                                 "
  860PRINT
  870PRINT"MAPLIN ELECTRONICS                                              "
  880PRINT"PO BOX 3                                                         "
  890PRINT"RAYLEIGH                                                          "
  900PRINT"ESSEX                                                              "
  910PRINT"SS6 8LR                                                             "
  920PRINT
  930PRINT"If you would like further help, please contact:-                      "
  940PRINT
  950PRINT"JOHN CRANE, 34 ST ANDREWS WALK, HARROGATE, NORTH YORKSHIRE, HG2 7RL. "
  960PRINT"**************************************************************************"
  970ENDPROC
