   10 REM BallBot V4.0
   20 REM Real-Time Version with Continuous Testing Option
   30 REM New mechanical robot design changes (two motor drive)
   40 REM (C) Dominic Ford 1997
   50 :
   60 REM Welcome screen
   70 MODE6:@%=&905:PRINT" BallBot Artificial Intelligence Module"'"Simulation Tester V4.0 Real Time Version"''"Programmed and Designed by Dominic Ford"''SPC(16);"(C) 1997"
   80 PRINT'''"1. Real-Time Simulation"''"2. Logged Continuous Runs"''"3. Do specific run"
   90 REPEAT type$=GET$:UNTIL type$="1" OR type$="2" OR type$="3"
  100 :
  110 REM Setup variables
  120 ON ERROR OSCLI"CLOSE":REPORT:PRINT" at line ";ERL:END
  130 VOICE 1,"StringLib-Soft":*STEREO 1 0
  140 VOICE 2,"StringLib-Soft":*STEREO 2 -127
  150 VOICE 3,"StringLib-Soft":*STEREO 3 127
  160 current=0:DIMball(4,1):bbx=640:bby=950:dir=270:PROCsetupbb
  170 MODE12:IF type$="1" THEN MOUSE ON:PROCdrawfull
  180 IF type$="2" THEN start=TIME:stage=0:idle=FALSE:INPUT"Filename";f$:OSCLI"SPOOL "+f$
  190 IF type$="3" THEN PRINT"Enter Data:"':FORb=0TO4:PRINT"Ball ";b+1;:INPUTball(b,0),ball(b,1):NEXT:type$="1":MOUSE ON:PROCdrawfull
  200 :
  210 REM Start main loop
  220 REPEAT:T=TIME
  230 IF type$="1" THEN PROCuser ELSE PROCcompmon
  240 IF idle THEN UNTIL FALSE
  250 PROCsense
  260 mov=FNai(freqa,freqb,freqc)
  270 left=(mov AND 1)<>0
  280 right=(mov AND 2)<>0
  290 turbo=(mov AND 4)<>0
  300 on=(mov AND 8)<>0
  310 PROCmoveit
  320 PRINTTAB(0,2)TIME-T
  330 REPEAT UNTIL TIME>(T+15)
  340 UNTIL FALSE
  350 :
  360 REM Graphic interface
  370 DEFPROCdrawfull
  380 REM Set up constants
  390 LOCALsx,sy,width
  400 sx=1:sy=2:width=10
  410 REM Setup Colours
  420 COLOUR0,0,64,0:COLOUR1,255,0,0:COLOUR2,255,255,255:COLOUR3,255,0,0:COLOUR4,255,255,0:COLOUR5,0,0,0:COLOUR6,255,255,0
  430 :
  440 REM Draw green court area
  450 CLS:GCOL0,0:RECTANGLE FILL 0,0,1279,1023
  460 REM Mark out white lines onto court
  470 GCOL0,2:RECTANGLE FILL sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:RECTANGLE FILL sx/(23.77+2*sx)*1280,(1.37+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
  480 RECTANGLE FILL sx/(23.77+2*sx)*1280,(9.6+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:RECTANGLE FILL sx/(23.77+2*sx)*1280,(10.97+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
  490 RECTANGLE FILL (sx+5.47)/(23.77+2*sx)*1280,(sy+5.49)/(10.97+2*sy)*1024,12.8/(23.77+2*sx)*1280,width
  500 RECTANGLE FILL sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024:RECTANGLE FILL (sx+23.77)/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024+width
  510 RECTANGLE FILL (sx+5.47)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024:RECTANGLE FILL (sx+18.3)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024
  520 :
  530 REM Draw net
  540 GCOL0,5:FORl=100TO924STEP10:MOVE 640,l:DRAW 680,l+50:NEXT:FORl=0TO40STEP10:MOVE 640+l,100+l:DRAW640+l,924+l:NEXT:FORl=0TO5:MOVE637+l,100:DRAW677+l,150:MOVE637+l,924:DRAW677+l,974:NEXT
  550 GCOL0,2:MOVE 682,142:DRAW682,966
  560 PROCdrawmini
  570 ENDPROC
  580 :
  590 REM Draw ballbot and balls
  600 DEFPROCdrawmini
  610 IF type$="2" THEN ENDPROC
  620 GCOL3,4:FORb=0TO4
  630 IF ball(b,0)<>0 OR ball(b,1)<>0 THEN RECTANGLE FILL ball(b,0),ball(b,1),5,5
  640 NEXT
  650 GCOL3,3:RECTANGLE FILL bbx,bby,5,5
  660 ENDPROC
  670 :
  680 REM User interface (putting balls down)
  690 DEFPROCuser
  700 MOUSE x,y,c
  710 IF c=0 THEN ENDPROC
  720 IF (c AND 4)<>0 THEN PROCdrawmini:ball(current,0)=x:ball(current,1)=y:current=(current+1)MOD5:PROCdrawmini
  730 IF (c AND 2)<>0 THEN idle=FALSE:stage=0:start=TIME
  740 REPEAT
  750 MOUSE x,y,c
  760 UNTIL c=0
  770 ENDPROC
  780 :
  790 REM Calculate ballbot's new position
  800 DEFPROCmoveit
  810 LOCAL speed
  820 IF left AND (NOT right) THEN dir=dir-2.5*(1-3*turbo):speed=0.1
  830 IF right AND (NOT left) THEN dir=dir+2.5*(1-3*turbo):speed=0.1
  840 IF left AND right THEN speed=1
  850 :
  860 REM Get direction in range 0<theta<360
  870 REPEAT IF dir<0 THEN dir=dir+360
  880 IF dir>=360 THEN dir=dir-360
  890 UNTIL dir>=0 AND dir<360
  900 :
  910 PROCdrawmini:bbx=bbx+15*SIN(PI*dir/180)*speed*(.75*-turbo+.25)
  920 bby=bby+20*COS(PI*dir/180)*speed*(.75*-turbo+.25)
  930 FORball=0TO4:IF ABS(bbx-ball(ball,0))<10 AND ABS(bby-ball(ball,1))<10 THEN ball(ball,0)=0
  940 NEXT:PROCdrawmini
  950 ENDPROC
  960 :
  970 REM Calculate ballbot's background echo reading (-balls)
  980 DEFFNback(freq,min,max)
  990 REM Get angular range in form 0<theta<360
 1000 REM Set up initial outside range settings
 1010 hit=0:dist=0:dista=9999:hita=0:REM LOCAL hit,dist,hita,dista
 1020 REM If straight at net is in range, will be shortest.
 1030 IF(bbx<640ANDmin<=90ANDmax>=90)OR(bbx>640ANDmin<=270ANDmax>=270) AND (bby>100 AND bby<923) THEN hit=bby:dist=ABS(bbx-640):min=0:max=0
 1040 REM Otherwise find shortest extreme of range
 1050 IF SIN(PI*min/180)<>0 THEN dist=(640-bbx)/SIN(PI*min/180):hit=bby+(640-bbx)/TAN(PI*min/180)
 1060 IF SIN(PI*max/180)<>0 THEN dista=(640-bbx)/SIN(PI*max/180):hita=bby+(640-bbx)/TAN(PI*max/180)
 1070 REM Just check if post in middle of range
 1080 IF bbx<640 AND hit>100 AND (hita<100 OR dista<0) AND dist>0 THEN hita=100:dista=SQR((bbx-640)^2+(bby-100)^2)
 1090 IF bbx<640 AND hita<923 AND (hit>923 OR dist<0) AND dista>0 THEN hit=923:dist=SQR((bbx-640)^2+(bby-923)^2)
 1100 IF bbx>640 AND hita>100 AND (hit<100 OR dist<0) AND dista>0 THEN hit=100:dist=SQR((bbx-640)^2+(bby-100)^2)
 1110 IF bbx>640 AND hit<923 AND (hita>923 OR dista<0) AND dist>0 THEN hita=923:dista=SQR((bbx-640)^2+(bby-923)^2)
 1120 REM Pick best to send off!
 1130 IF dist<0 OR (dista<dist AND hita>100 AND hita<923) THEN dist=dista:hit=hita
 1140 IF hit>923 OR hit<100 OR dist<0 THEN ftype$="U":=freq+RND(6)-3
 1150 IF hit>900 OR hit<123 THEN ftype$="P":=dist
 1160 ftype$="N"
 1170 =dist
 1180 :
 1190 REM Calculate Ballbot's readings (MAIN ROUTINE)
 1200 :
 1210 DEFPROCsense
 1220 REM Get background readings from FNback
 1230 freq=RND(250)+1500
 1240 freqa=FNback(freq,dir-15,dir+15):fa$=ftype$
 1250 freqb=FNback(freq,dir-45,dir-15):fb$=ftype$
 1260 freqc=FNback(freq,dir+15,dir+45):fc$=ftype$
 1270 :
 1280 REM Add any relevant balls to readings (using hairy trigonometry)
 1290 :
 1300 FORball=0TO4
 1310 d%=SQR((ball(ball,0)-bbx)^2+(ball(ball,1)-bby)^2)
 1320 IF ball(ball,0)=0 THEN d%=9999
 1330 a=FNangle(ball(ball,0),ball(ball,1),bbx,bby)-dir:IFa>180 THEN a=a-360
 1340 IF ABS(a)<15 AND freqa>d% THEN freqa=d%:fa$="B"
 1350 IF a>-46 AND a<=-15 AND freqb>d% THEN freqb=d%:fb$="B"
 1360 IF a>=15 AND a<46 AND freqc>d% THEN freqc=d%:fc$="B"
 1370 NEXT
 1380 :
 1390 REM Update user displays
 1400 :
 1410 IF type$="2" THEN ENDPROC
 1420 PRINTTAB(0,0)INT((TIME-start)/6000);":";(INT((TIME-start)/100)MOD60);" "
 1430 PRINTTAB(0,31)fb$,fa$,fc$,stage,INT(searching),left,right,dir;
 1440 SOUND 1,-1,freqa/4,5:SOUND 2,-1,freqb/4,5:SOUND 3,-1,freqc/4,5
 1450 ENDPROC
 1460:
 1470 REM Calculate bearing of B from A
 1480 DEFFNangle(x1,y1,x2,y2)
 1490 IF y2=y1 THEN ang=90 ELSE ang=180*ATN((x2-x1)/(y2-y1))/PI
 1500 IF (y2>y1) THEN ang=ang+180
 1510 IF ang<0 THEN ang=ang+360
 1520 =ang MOD 360
 1530 :
 1540 REM Computer Monitor of BallBot's progress
 1550 DEFPROCcompmon
 1560 IF idle AND (ball(0,0)<>0 OR ball(1,0)<>0 OR ball(2,0)<>0 OR ball(3,0)<>0 OR ball(4,0)<>0) THEN st$="Fail" ELSE st$="Pass"
 1570 IF idle THEN PRINTst$,INT((TIME-start)/6000);":";(INT((TIME-start)/100)MOD60)
 1580 IF TIME>start+36000 THEN idle=TRUE:PRINT"Time","****"
 1590 IFbbx>630ANDbbx<650ANDbby>100ANDbby<923THENidle=TRUE:PRINT"Crash","****"
 1600 IF idle THEN bbx=640:bby=950:dir=270:stage=0:PROCsetupbb:start=TIME:FORb=0TO4:ball(b,0)=RND(1280):ball(b,1)=RND(1024):NEXT
 1610 IF idle THEN PRINT"[";ball(0,0);",";ball(0,1);"] [";ball(1,0);",";ball(1,1);"] [";ball(2,0);",";ball(2,1);"] [";ball(3,0);",";ball(3,1);"] [";ball(4,0);",";ball(4,1);"]",;:idle=FALSE
 1620 ENDPROC
 1630 :
 1640 REM BALLBOT ROBOTIC INTELLIGENCE MODULE
 1650 :
 1660 DEFFNai(freqa,freqb,freqc)
 1670 REM Artificial intelligence routines (ie. What Next??)
 1680 LOCALleft,right,turbo
 1690 left=FALSE:right=FALSE:turbo=FALSE
 1700 :
 1710 REM What stage are we in? Hunt for balls or move to new area?
 1720 IF near<>0 AND stage<8 THEN PROCdonearstuff
 1730 IF near=0 AND (stage=0 OR stage=2) THEN PROChunt
 1740 IF near=0 AND (stage=1 OR stage=3) THEN PROCmoveout
 1750 IF stage=4 THEN PROCreleaseb
 1760 :
 1770 REM Prepare output into binary for transmission
 1780 feed=0:IF left THEN feed=feed+1
 1790 IF right THEN feed=feed+2
 1800 IF turbo THEN feed=feed+4
 1810 IF idle THEN feed=feed+8
 1820 =feed
 1830 :
 1840 REM Perform a sweep to find any balls
 1850 DEFPROChunt
 1860 REM Watch out if too near to net
 1870 REMIF(freqa<20AND fa$<>"B")OR(freqb<20AND fb$<>"B")OR(freqc<20AND fc$<>"B")ANDfa$="B"THEN:ENDPROC
 1880 :
 1890 REM Rotate to face ball
 1900 REM Where search after this ball?
 1910 IF (fb$="B" AND freqb>150) THEN tending=0
 1920 IF fc$="B" AND freqc>150 THEN tending=1
 1930 REM Pick best ball to aim at
 1940 dist=freqa*0.75:IF dist>freqb AND fb$="B" AND (freqb<freqc OR fc$<>"B") THEN steer=-1:left=TRUE:ENDPROC
 1950 IF dist>freqc AND fc$="B" THEN steer=1:right=TRUE:ENDPROC
 1960 IF fa$="B" THEN left=(steer<>1):right=(steer<>-1):steer=0:searching=searching/2:turbo=freqa>100:ENDPROC
 1970 IF fb$="B" THEN steer=-1:left=TRUE:ENDPROC
 1980 IF fc$="B" THEN steer=1:right=TRUE:ENDPROC
 1990 :
 2000 REM If no ball in sight, continue rotation...
 2010 searching=searching+1:turbo=(searching>5):steer=0
 2020 IF (tending AND 1)<>0 THEN right=TRUE ELSE left=TRUE
 2030 IF searching=5 THEN tending=(tending EOR 1)
 2040 IF searching>50 THEN stage=stage+1
 2050 ENDPROC
 2060 :
 2070 REM Find edge of net and aim for it to move to other side
 2080 DEFPROCmoveout
 2090 REM Watch out if too near to net
 2100 IF (freqa<30 OR freqb<30 OR freqc<30) OR (reving>0 AND (freqa<250 OR freqb<250 OR freqc<250)) THEN reving=5:right=TRUE:left=FALSE:ENDPROC
 2110 IF reving>0 THEN turbo=TRUE:left=TRUE:right=TRUE:reving=reving-1:ENDPROC
 2120 REM Align ballbot to face the net post...
 2130 IF fa$="N" OR fa$="P" THEN right=TRUE:ENDPROC
 2140 IF fb$<>"N" AND fb$<>"P" THEN left=TRUE:steer=6:ENDPROC
 2150 IF fb$="P" AND freqb<100 AND fa$<>"P" AND fa$<>"N" THEN near=1:ENDPROC
 2160 IF steer>0 THEN steer=steer-1:left=TRUE:ENDPROC
 2170 turbo=TRUE:left=TRUE:right=TRUE
 2180 ENDPROC
 2190 :
 2200 REM Nearly there... Just need a little nudge in the right direction.
 2210 DEFPROCdonearstuff
 2220 REM Watch out if too near to net
 2230 IF near<6 THEN right=TRUE:left=FALSE:near=near-(fa$="U")
 2240 IF near<10 THEN left=TRUE:turbo=TRUE:right=TRUE:near=near+1:ENDPROC
 2250 IF near<15 THEN left=TRUE:turbo=TRUE:right=FALSE:near=near+1:ENDPROC
 2260 left=TRUE:turbo=TRUE:right=TRUE:near=near+1
 2270 IF near>18 THEN near=0:stage=stage+1:searching=0:tending=1
 2280 ENDPROC
 2290 :
 2300 REM Initialise BallBot variables at the beginning of a run
 2310 DEFPROCsetupbb
 2320 reving=FALSE:left=FALSE:right=FALSE:searching=0:idle=TRUE
 2330 near=FALSE:tending=1:steer=0
 2340 ENDPROC
 2350 :
 2360 DEFPROCreleaseb
 2370 REM Got all the balls, now just dump them!
 2380 near=near+1
 2390 IF near>9 THEN idle=TRUE:near=FALSE
 2400 ENDPROC


 � BallBot V4.0
7 � Real-Time Version with Continuous Testing Option
< � New mechanical robot design changes (two motor drive)
( � (C) Dominic Ford 1997
2 :
< � Welcome screen
F� �6:@%=&905:�" BallBot Artificial Intelligence Module"'"Simulation Tester V4.0 Real Time Version"''"Programmed and Designed by Dominic Ford"''�(16);"(C) 1997"
PU �'''"1. Real-Time Simulation"''"2. Logged Continuous Runs"''"3. Do specific run"
Z2 � type$=�:� type$="1" � type$="2" � type$="3"
d :
n � Setup variables
x$ � � �"CLOSE":�:�" at line ";�:�
�& ȡ 1,"StringLib-Soft":*STEREO 1 0
�) ȡ 2,"StringLib-Soft":*STEREO 2 -127
�( ȡ 3,"StringLib-Soft":*STEREO 3 127
�: current=0:�ball(4,1):bbx=640:bby=950:dir=270:�setupbb
�% �12:� type$="1" � ȗ �:�drawfull
�E � type$="2" � start=�:stage=0:idle=�:�"Filename";f$:�"SPOOL "+f$
�g � type$="3" � �"Enter Data:"':�b=0�4:�"Ball ";b+1;:�ball(b,0),ball(b,1):�:type$="1":ȗ �:�drawfull
� :
� � Start main loop
�
 �:T=�
�# � type$="1" � �user � �compmon
� � idle � � �
� �sense
 mov=�ai(freqa,freqb,freqc)
 left=(mov � 1)<>0
 right=(mov � 2)<>0
" turbo=(mov � 4)<>0
, on=(mov � 8)<>0
6 �moveit
@ �0,2)�-T
J � � �>(T+15)
T � �
^ :
h � Graphic interface
r ��drawfull
| � Set up constants
� �sx,sy,width
� sx=1:sy=2:width=10
� � Setup Colours
�V �0,0,64,0:�1,255,0,0:�2,255,255,255:�3,255,0,0:�4,255,255,0:�5,0,0,0:�6,255,255,0
� :
� � Draw green court area
� �:�0,0:ȓ Ȑ 0,0,1279,1023
�& � Mark out white lines onto court
֬ �0,2:ȓ Ȑ sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:ȓ Ȑ sx/(23.77+2*sx)*1280,(1.37+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
� ȓ Ȑ sx/(23.77+2*sx)*1280,(9.6+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:ȓ Ȑ sx/(23.77+2*sx)*1280,(10.97+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
�_ ȓ Ȑ (sx+5.47)/(23.77+2*sx)*1280,(sy+5.49)/(10.97+2*sy)*1024,12.8/(23.77+2*sx)*1280,width
� ȓ Ȑ sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024:ȓ Ȑ (sx+23.77)/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024+width
�� ȓ Ȑ (sx+5.47)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024:ȓ Ȑ (sx+18.3)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024
 :
 � Draw net
� �0,5:�l=100�924�10:� 640,l:� 680,l+50:�:�l=0�40�10:� 640+l,100+l:�640+l,924+l:�:�l=0�5:�637+l,100:�677+l,150:�637+l,924:�677+l,974:�
& �0,2:� 682,142:�682,966
0 �drawmini
: �
D :
N � Draw ballbot and balls
X ��drawmini
b � type$="2" � �
l �3,4:�b=0�4
vB � ball(b,0)<>0 � ball(b,1)<>0 � ȓ Ȑ ball(b,0),ball(b,1),5,5
� �
� �3,3:ȓ Ȑ bbx,bby,5,5
� �
� :
�* � User interface (putting balls down)
� ��user
�
 ȗ x,y,c
� � c=0 � �
�a � (c � 4)<>0 � �drawmini:ball(current,0)=x:ball(current,1)=y:current=(current+1)�5:�drawmini
�* � (c � 2)<>0 � idle=�:stage=0:start=�
� �
�
 ȗ x,y,c
�
 � c=0
 �
 :
' � Calculate ballbot's new position

 ��moveit
* � speed
4; � left � (� right) � dir=dir-2.5*(1-3*turbo):speed=0.1
>; � right � (� left) � dir=dir+2.5*(1-3*turbo):speed=0.1
H � left � right � speed=1
R :
\) � Get direction in range 0<theta<360
f � � dir<0 � dir=dir+360
p � dir>=360 � dir=dir-360
z � dir>=0 � dir<360
� :
�= �drawmini:bbx=bbx+15*�(�*dir/180)*speed*(.75*-turbo+.25)
�3 bby=bby+20*�(�*dir/180)*speed*(.75*-turbo+.25)
�Q �ball=0�4:� �(bbx-ball(ball,0))<10 � �(bby-ball(ball,1))<10 � ball(ball,0)=0
� �:�drawmini
� �
� :
�; � Calculate ballbot's background echo reading (-balls)
� ݤback(freq,min,max)
�, � Get angular range in form 0<theta<360
�, � Set up initial outside range settings
�? hit=0:dist=0:dista=9999:hita=0:� LOCAL hit,dist,hita,dista
�8 � If straight at net is in range, will be shortest.
w �(bbx<640�min<=90�max>=90)�(bbx>640�min<=270�max>=270) � (bby>100 � bby<923) � hit=bby:dist=�(bbx-640):min=0:max=0
/ � Otherwise find shortest extreme of range
S � �(�*min/180)<>0 � dist=(640-bbx)/�(�*min/180):hit=bby+(640-bbx)/�(�*min/180)
$U � �(�*max/180)<>0 � dista=(640-bbx)/�(�*max/180):hita=bby+(640-bbx)/�(�*max/180)
., � Just check if post in middle of range
8d � bbx<640 � hit>100 � (hita<100 � dista<0) � dist>0 � hita=100:dista=�((bbx-640)^2+(bby-100)^2)
Bb � bbx<640 � hita<923 � (hit>923 � dist<0) � dista>0 � hit=923:dist=�((bbx-640)^2+(bby-923)^2)
Lb � bbx>640 � hita>100 � (hit<100 � dist<0) � dista>0 � hit=100:dist=�((bbx-640)^2+(bby-100)^2)
Vd � bbx>640 � hit<923 � (hita>923 � dista<0) � dist>0 � hita=923:dista=�((bbx-640)^2+(bby-923)^2)
` � Pick best to send off!
jH � dist<0 � (dista<dist � hita>100 � hita<923) � dist=dista:hit=hita
t; � hit>923 � hit<100 � dist<0 � ftype$="U":=freq+�(6)-3
~+ � hit>900 � hit<123 � ftype$="P":=dist
� ftype$="N"
�
 =dist
� :
�2 � Calculate Ballbot's readings (MAIN ROUTINE)
� :
� ��sense
�* � Get background readings from FNback
� freq=�(250)+1500
�/ freqa=�back(freq,dir-15,dir+15):fa$=ftype$
�/ freqb=�back(freq,dir-45,dir-15):fb$=ftype$
�/ freqc=�back(freq,dir+15,dir+45):fc$=ftype$
� :
D � Add any relevant balls to readings (using hairy trigonometry)

 :
 �ball=0�4
4 d%=�((ball(ball,0)-bbx)^2+(ball(ball,1)-bby)^2)
( � ball(ball,0)=0 � d%=9999
2E a=�angle(ball(ball,0),ball(ball,1),bbx,bby)-dir:�a>180 � a=a-360
<, � �(a)<15 � freqa>d% � freqa=d%:fa$="B"
F3 � a>-46 � a<=-15 � freqb>d% � freqb=d%:fb$="B"
P1 � a>=15 � a<46 � freqc>d% � freqc=d%:fc$="B"
Z �
d :
n � Update user displays
x :
� � type$="2" � �
�: �0,0)�((�-start)/6000);":";(�((�-start)/100)�60);" "
�: �0,31)fb$,fa$,fc$,stage,�(searching),left,right,dir;
�7 � 1,-1,freqa/4,5:� 2,-1,freqb/4,5:� 3,-1,freqc/4,5
� �
�:
�$ � Calculate bearing of B from A
� ݤangle(x1,y1,x2,y2)
�4 � y2=y1 � ang=90 � ang=180*�((x2-x1)/(y2-y1))/�
� � (y2>y1) � ang=ang+180
� � ang<0 � ang=ang+360
� =ang � 360
� :
- � Computer Monitor of BallBot's progress
 ��compmon
r � idle � (ball(0,0)<>0 � ball(1,0)<>0 � ball(2,0)<>0 � ball(3,0)<>0 � ball(4,0)<>0) � st$="Fail" � st$="Pass"
"> � idle � �st$,�((�-start)/6000);":";(�((�-start)/100)�60)
,, � �>start+36000 � idle=�:�"Time","****"
6< �bbx>630�bbx<650�bby>100�bby<923�idle=�:�"Crash","****"
@k � idle � bbx=640:bby=950:dir=270:stage=0:�setupbb:start=�:�b=0�4:ball(b,0)=�(1280):ball(b,1)=�(1024):�
J� � idle � �"[";ball(0,0);",";ball(0,1);"] [";ball(1,0);",";ball(1,1);"] [";ball(2,0);",";ball(2,1);"] [";ball(3,0);",";ball(3,1);"] [";ball(4,0);",";ball(4,1);"]",;:idle=�
T �
^ :
h* � BALLBOT ROBOTIC INTELLIGENCE MODULE
r :
| ݤai(freqa,freqb,freqc)
�9 � Artificial intelligence routines (ie. What Next??)
� �left,right,turbo
� left=�:right=�:turbo=�
� :
�@ � What stage are we in? Hunt for balls or move to new area?
�' � near<>0 � stage<8 � �donearstuff
�+ � near=0 � (stage=0 � stage=2) � �hunt
�. � near=0 � (stage=1 � stage=3) � �moveout
� � stage=4 � �releaseb
� :
�2 � Prepare output into binary for transmission
�  feed=0:� left � feed=feed+1
� � right � feed=feed+2
 � turbo � feed=feed+4
 � idle � feed=feed+8

 =feed
& :
0( � Perform a sweep to find any balls
: ��hunt
D# � Watch out if too near to net
Nd �IF(freqa<20AND fa$<>"B")OR(freqb<20AND fb$<>"B")OR(freqc<20AND fc$<>"B")ANDfa$="B"THEN:ENDPROC
X :
b � Rotate to face ball
l$ � Where search after this ball?
v( � (fb$="B" � freqb>150) � tending=0
�& � fc$="B" � freqc>150 � tending=1
� � Pick best ball to aim at
�Z dist=freqa*0.75:� dist>freqb � fb$="B" � (freqb<freqc � fc$<>"B") � steer=-1:left=�:�
�/ � dist>freqc � fc$="B" � steer=1:right=�:�
�b � fa$="B" � left=(steer<>1):right=(steer<>-1):steer=0:searching=searching/2:turbo=freqa>100:�
�" � fb$="B" � steer=-1:left=�:�
�" � fc$="B" � steer=1:right=�:�
� :
�0 � If no ball in sight, continue rotation...
�6 searching=searching+1:turbo=(searching>5):steer=0
�* � (tending � 1)<>0 � right=� � left=�
�* � searching=5 � tending=(tending � 1)
�# � searching>50 � stage=stage+1
 �
 :
< � Find edge of net and aim for it to move to other side
  ��moveout
*# � Watch out if too near to net
4v � (freqa<30 � freqb<30 � freqc<30) � (reving>0 � (freqa<250 � freqb<250 � freqc<250)) � reving=5:right=�:left=�:�
>: � reving>0 � turbo=�:left=�:right=�:reving=reving-1:�
H, � Align ballbot to face the net post...
R$ � fa$="N" � fa$="P" � right=�:�
\- � fb$<>"N" � fb$<>"P" � left=�:steer=6:�
f; � fb$="P" � freqb<100 � fa$<>"P" � fa$<>"N" � near=1:�
p' � steer>0 � steer=steer-1:left=�:�
z turbo=�:left=�:right=�
� �
� :
�G � Nearly there... Just need a little nudge in the right direction.
� ��donearstuff
�# � Watch out if too near to net
�2 � near<6 � right=�:left=�:near=near-(fa$="U")
�5 � near<10 � left=�:turbo=�:right=�:near=near+1:�
�5 � near<15 � left=�:turbo=�:right=�:near=near+1:�
�' left=�:turbo=�:right=�:near=near+1
�; � near>18 � near=0:stage=stage+1:searching=0:tending=1
� �
� :
�= � Initialise BallBot variables at the beginning of a run
	 ��setupbb
	/ reving=�:left=�:right=�:searching=0:idle=�
	 near=�:tending=1:steer=0
	$ �
	. :
	8 ��releaseb
	B- � Got all the balls, now just dump them!
	L near=near+1
	V � near>9 � idle=�:near=�
	` �
�
00000000  0d 00 0a 13 20 f4 20 42  61 6c 6c 42 6f 74 20 56  |.... . BallBot V|
00000010  34 2e 30 0d 00 14 37 20  f4 20 52 65 61 6c 2d 54  |4.0...7 . Real-T|
00000020  69 6d 65 20 56 65 72 73  69 6f 6e 20 77 69 74 68  |ime Version with|
00000030  20 43 6f 6e 74 69 6e 75  6f 75 73 20 54 65 73 74  | Continuous Test|
00000040  69 6e 67 20 4f 70 74 69  6f 6e 0d 00 1e 3c 20 f4  |ing Option...< .|
00000050  20 4e 65 77 20 6d 65 63  68 61 6e 69 63 61 6c 20  | New mechanical |
00000060  72 6f 62 6f 74 20 64 65  73 69 67 6e 20 63 68 61  |robot design cha|
00000070  6e 67 65 73 20 28 74 77  6f 20 6d 6f 74 6f 72 20  |nges (two motor |
00000080  64 72 69 76 65 29 0d 00  28 1c 20 f4 20 28 43 29  |drive)..(. . (C)|
00000090  20 44 6f 6d 69 6e 69 63  20 46 6f 72 64 20 31 39  | Dominic Ford 19|
000000a0  39 37 0d 00 32 06 20 3a  0d 00 3c 15 20 f4 20 57  |97..2. :..<. . W|
000000b0  65 6c 63 6f 6d 65 20 73  63 72 65 65 6e 0d 00 46  |elcome screen..F|
000000c0  a2 20 eb 36 3a 40 25 3d  26 39 30 35 3a f1 22 20  |. .6:@%=&905:." |
000000d0  42 61 6c 6c 42 6f 74 20  41 72 74 69 66 69 63 69  |BallBot Artifici|
000000e0  61 6c 20 49 6e 74 65 6c  6c 69 67 65 6e 63 65 20  |al Intelligence |
000000f0  4d 6f 64 75 6c 65 22 27  22 53 69 6d 75 6c 61 74  |Module"'"Simulat|
00000100  69 6f 6e 20 54 65 73 74  65 72 20 56 34 2e 30 20  |ion Tester V4.0 |
00000110  52 65 61 6c 20 54 69 6d  65 20 56 65 72 73 69 6f  |Real Time Versio|
00000120  6e 22 27 27 22 50 72 6f  67 72 61 6d 6d 65 64 20  |n"''"Programmed |
00000130  61 6e 64 20 44 65 73 69  67 6e 65 64 20 62 79 20  |and Designed by |
00000140  44 6f 6d 69 6e 69 63 20  46 6f 72 64 22 27 27 89  |Dominic Ford"''.|
00000150  28 31 36 29 3b 22 28 43  29 20 31 39 39 37 22 0d  |(16);"(C) 1997".|
00000160  00 50 55 20 f1 27 27 27  22 31 2e 20 52 65 61 6c  |.PU .'''"1. Real|
00000170  2d 54 69 6d 65 20 53 69  6d 75 6c 61 74 69 6f 6e  |-Time Simulation|
00000180  22 27 27 22 32 2e 20 4c  6f 67 67 65 64 20 43 6f  |"''"2. Logged Co|
00000190  6e 74 69 6e 75 6f 75 73  20 52 75 6e 73 22 27 27  |ntinuous Runs"''|
000001a0  22 33 2e 20 44 6f 20 73  70 65 63 69 66 69 63 20  |"3. Do specific |
000001b0  72 75 6e 22 0d 00 5a 32  20 f5 20 74 79 70 65 24  |run"..Z2 . type$|
000001c0  3d be 3a fd 20 74 79 70  65 24 3d 22 31 22 20 84  |=.:. type$="1" .|
000001d0  20 74 79 70 65 24 3d 22  32 22 20 84 20 74 79 70  | type$="2" . typ|
000001e0  65 24 3d 22 33 22 0d 00  64 06 20 3a 0d 00 6e 16  |e$="3"..d. :..n.|
000001f0  20 f4 20 53 65 74 75 70  20 76 61 72 69 61 62 6c  | . Setup variabl|
00000200  65 73 0d 00 78 24 20 ee  20 85 20 ff 22 43 4c 4f  |es..x$ . . ."CLO|
00000210  53 45 22 3a f6 3a f1 22  20 61 74 20 6c 69 6e 65  |SE":.:." at line|
00000220  20 22 3b 9e 3a e0 0d 00  82 26 20 c8 a1 20 31 2c  | ";.:....& .. 1,|
00000230  22 53 74 72 69 6e 67 4c  69 62 2d 53 6f 66 74 22  |"StringLib-Soft"|
00000240  3a 2a 53 54 45 52 45 4f  20 31 20 30 0d 00 8c 29  |:*STEREO 1 0...)|
00000250  20 c8 a1 20 32 2c 22 53  74 72 69 6e 67 4c 69 62  | .. 2,"StringLib|
00000260  2d 53 6f 66 74 22 3a 2a  53 54 45 52 45 4f 20 32  |-Soft":*STEREO 2|
00000270  20 2d 31 32 37 0d 00 96  28 20 c8 a1 20 33 2c 22  | -127...( .. 3,"|
00000280  53 74 72 69 6e 67 4c 69  62 2d 53 6f 66 74 22 3a  |StringLib-Soft":|
00000290  2a 53 54 45 52 45 4f 20  33 20 31 32 37 0d 00 a0  |*STEREO 3 127...|
000002a0  3a 20 63 75 72 72 65 6e  74 3d 30 3a de 62 61 6c  |: current=0:.bal|
000002b0  6c 28 34 2c 31 29 3a 62  62 78 3d 36 34 30 3a 62  |l(4,1):bbx=640:b|
000002c0  62 79 3d 39 35 30 3a 64  69 72 3d 32 37 30 3a f2  |by=950:dir=270:.|
000002d0  73 65 74 75 70 62 62 0d  00 aa 25 20 eb 31 32 3a  |setupbb...% .12:|
000002e0  e7 20 74 79 70 65 24 3d  22 31 22 20 8c 20 c8 97  |. type$="1" . ..|
000002f0  20 ee 3a f2 64 72 61 77  66 75 6c 6c 0d 00 b4 45  | .:.drawfull...E|
00000300  20 e7 20 74 79 70 65 24  3d 22 32 22 20 8c 20 73  | . type$="2" . s|
00000310  74 61 72 74 3d 91 3a 73  74 61 67 65 3d 30 3a 69  |tart=.:stage=0:i|
00000320  64 6c 65 3d a3 3a e8 22  46 69 6c 65 6e 61 6d 65  |dle=.:."Filename|
00000330  22 3b 66 24 3a ff 22 53  50 4f 4f 4c 20 22 2b 66  |";f$:."SPOOL "+f|
00000340  24 0d 00 be 67 20 e7 20  74 79 70 65 24 3d 22 33  |$...g . type$="3|
00000350  22 20 8c 20 f1 22 45 6e  74 65 72 20 44 61 74 61  |" . ."Enter Data|
00000360  3a 22 27 3a e3 62 3d 30  b8 34 3a f1 22 42 61 6c  |:"':.b=0.4:."Bal|
00000370  6c 20 22 3b 62 2b 31 3b  3a e8 62 61 6c 6c 28 62  |l ";b+1;:.ball(b|
00000380  2c 30 29 2c 62 61 6c 6c  28 62 2c 31 29 3a ed 3a  |,0),ball(b,1):.:|
00000390  74 79 70 65 24 3d 22 31  22 3a c8 97 20 ee 3a f2  |type$="1":.. .:.|
000003a0  64 72 61 77 66 75 6c 6c  0d 00 c8 06 20 3a 0d 00  |drawfull.... :..|
000003b0  d2 16 20 f4 20 53 74 61  72 74 20 6d 61 69 6e 20  |.. . Start main |
000003c0  6c 6f 6f 70 0d 00 dc 0a  20 f5 3a 54 3d 91 0d 00  |loop.... .:T=...|
000003d0  e6 23 20 e7 20 74 79 70  65 24 3d 22 31 22 20 8c  |.# . type$="1" .|
000003e0  20 f2 75 73 65 72 20 8b  20 f2 63 6f 6d 70 6d 6f  | .user . .compmo|
000003f0  6e 0d 00 f0 11 20 e7 20  69 64 6c 65 20 8c 20 fd  |n.... . idle . .|
00000400  20 a3 0d 00 fa 0b 20 f2  73 65 6e 73 65 0d 01 04  | ..... .sense...|
00000410  1f 20 6d 6f 76 3d a4 61  69 28 66 72 65 71 61 2c  |. mov=.ai(freqa,|
00000420  66 72 65 71 62 2c 66 72  65 71 63 29 0d 01 0e 16  |freqb,freqc)....|
00000430  20 6c 65 66 74 3d 28 6d  6f 76 20 80 20 31 29 3c  | left=(mov . 1)<|
00000440  3e 30 0d 01 18 17 20 72  69 67 68 74 3d 28 6d 6f  |>0.... right=(mo|
00000450  76 20 80 20 32 29 3c 3e  30 0d 01 22 17 20 74 75  |v . 2)<>0..". tu|
00000460  72 62 6f 3d 28 6d 6f 76  20 80 20 34 29 3c 3e 30  |rbo=(mov . 4)<>0|
00000470  0d 01 2c 14 20 6f 6e 3d  28 6d 6f 76 20 80 20 38  |..,. on=(mov . 8|
00000480  29 3c 3e 30 0d 01 36 0c  20 f2 6d 6f 76 65 69 74  |)<>0..6. .moveit|
00000490  0d 01 40 0e 20 f1 8a 30  2c 32 29 91 2d 54 0d 01  |..@. ..0,2).-T..|
000004a0  4a 11 20 f5 20 fd 20 91  3e 28 54 2b 31 35 29 0d  |J. . . .>(T+15).|
000004b0  01 54 08 20 fd 20 a3 0d  01 5e 06 20 3a 0d 01 68  |.T. . ...^. :..h|
000004c0  18 20 f4 20 47 72 61 70  68 69 63 20 69 6e 74 65  |. . Graphic inte|
000004d0  72 66 61 63 65 0d 01 72  0f 20 dd f2 64 72 61 77  |rface..r. ..draw|
000004e0  66 75 6c 6c 0d 01 7c 17  20 f4 20 53 65 74 20 75  |full..|. . Set u|
000004f0  70 20 63 6f 6e 73 74 61  6e 74 73 0d 01 86 11 20  |p constants.... |
00000500  ea 73 78 2c 73 79 2c 77  69 64 74 68 0d 01 90 17  |.sx,sy,width....|
00000510  20 73 78 3d 31 3a 73 79  3d 32 3a 77 69 64 74 68  | sx=1:sy=2:width|
00000520  3d 31 30 0d 01 9a 14 20  f4 20 53 65 74 75 70 20  |=10.... . Setup |
00000530  43 6f 6c 6f 75 72 73 0d  01 a4 56 20 fb 30 2c 30  |Colours...V .0,0|
00000540  2c 36 34 2c 30 3a fb 31  2c 32 35 35 2c 30 2c 30  |,64,0:.1,255,0,0|
00000550  3a fb 32 2c 32 35 35 2c  32 35 35 2c 32 35 35 3a  |:.2,255,255,255:|
00000560  fb 33 2c 32 35 35 2c 30  2c 30 3a fb 34 2c 32 35  |.3,255,0,0:.4,25|
00000570  35 2c 32 35 35 2c 30 3a  fb 35 2c 30 2c 30 2c 30  |5,255,0:.5,0,0,0|
00000580  3a fb 36 2c 32 35 35 2c  32 35 35 2c 30 0d 01 ae  |:.6,255,255,0...|
00000590  06 20 3a 0d 01 b8 1c 20  f4 20 44 72 61 77 20 67  |. :.... . Draw g|
000005a0  72 65 65 6e 20 63 6f 75  72 74 20 61 72 65 61 0d  |reen court area.|
000005b0  01 c2 1f 20 db 3a e6 30  2c 30 3a c8 93 20 c8 90  |... .:.0,0:.. ..|
000005c0  20 30 2c 30 2c 31 32 37  39 2c 31 30 32 33 0d 01  | 0,0,1279,1023..|
000005d0  cc 26 20 f4 20 4d 61 72  6b 20 6f 75 74 20 77 68  |.& . Mark out wh|
000005e0  69 74 65 20 6c 69 6e 65  73 20 6f 6e 74 6f 20 63  |ite lines onto c|
000005f0  6f 75 72 74 0d 01 d6 ac  20 e6 30 2c 32 3a c8 93  |ourt.... .0,2:..|
00000600  20 c8 90 20 73 78 2f 28  32 33 2e 37 37 2b 32 2a  | .. sx/(23.77+2*|
00000610  73 78 29 2a 31 32 38 30  2c 73 79 2f 28 31 30 2e  |sx)*1280,sy/(10.|
00000620  39 37 2b 32 2a 73 79 29  2a 31 30 32 34 2c 32 33  |97+2*sy)*1024,23|
00000630  2e 37 37 2f 28 32 33 2e  37 37 2b 32 2a 73 78 29  |.77/(23.77+2*sx)|
00000640  2a 31 32 38 30 2c 77 69  64 74 68 3a c8 93 20 c8  |*1280,width:.. .|
00000650  90 20 73 78 2f 28 32 33  2e 37 37 2b 32 2a 73 78  |. sx/(23.77+2*sx|
00000660  29 2a 31 32 38 30 2c 28  31 2e 33 37 2b 73 79 29  |)*1280,(1.37+sy)|
00000670  2f 28 31 30 2e 39 37 2b  32 2a 73 79 29 2a 31 30  |/(10.97+2*sy)*10|
00000680  32 34 2c 32 33 2e 37 37  2f 28 32 33 2e 37 37 2b  |24,23.77/(23.77+|
00000690  32 2a 73 78 29 2a 31 32  38 30 2c 77 69 64 74 68  |2*sx)*1280,width|
000006a0  0d 01 e0 ae 20 c8 93 20  c8 90 20 73 78 2f 28 32  |.... .. .. sx/(2|
000006b0  33 2e 37 37 2b 32 2a 73  78 29 2a 31 32 38 30 2c  |3.77+2*sx)*1280,|
000006c0  28 39 2e 36 2b 73 79 29  2f 28 31 30 2e 39 37 2b  |(9.6+sy)/(10.97+|
000006d0  32 2a 73 79 29 2a 31 30  32 34 2c 32 33 2e 37 37  |2*sy)*1024,23.77|
000006e0  2f 28 32 33 2e 37 37 2b  32 2a 73 78 29 2a 31 32  |/(23.77+2*sx)*12|
000006f0  38 30 2c 77 69 64 74 68  3a c8 93 20 c8 90 20 73  |80,width:.. .. s|
00000700  78 2f 28 32 33 2e 37 37  2b 32 2a 73 78 29 2a 31  |x/(23.77+2*sx)*1|
00000710  32 38 30 2c 28 31 30 2e  39 37 2b 73 79 29 2f 28  |280,(10.97+sy)/(|
00000720  31 30 2e 39 37 2b 32 2a  73 79 29 2a 31 30 32 34  |10.97+2*sy)*1024|
00000730  2c 32 33 2e 37 37 2f 28  32 33 2e 37 37 2b 32 2a  |,23.77/(23.77+2*|
00000740  73 78 29 2a 31 32 38 30  2c 77 69 64 74 68 0d 01  |sx)*1280,width..|
00000750  ea 5f 20 c8 93 20 c8 90  20 28 73 78 2b 35 2e 34  |._ .. .. (sx+5.4|
00000760  37 29 2f 28 32 33 2e 37  37 2b 32 2a 73 78 29 2a  |7)/(23.77+2*sx)*|
00000770  31 32 38 30 2c 28 73 79  2b 35 2e 34 39 29 2f 28  |1280,(sy+5.49)/(|
00000780  31 30 2e 39 37 2b 32 2a  73 79 29 2a 31 30 32 34  |10.97+2*sy)*1024|
00000790  2c 31 32 2e 38 2f 28 32  33 2e 37 37 2b 32 2a 73  |,12.8/(23.77+2*s|
000007a0  78 29 2a 31 32 38 30 2c  77 69 64 74 68 0d 01 f4  |x)*1280,width...|
000007b0  ae 20 c8 93 20 c8 90 20  73 78 2f 28 32 33 2e 37  |. .. .. sx/(23.7|
000007c0  37 2b 32 2a 73 78 29 2a  31 32 38 30 2c 73 79 2f  |7+2*sx)*1280,sy/|
000007d0  28 31 30 2e 39 37 2b 32  2a 73 79 29 2a 31 30 32  |(10.97+2*sy)*102|
000007e0  34 2c 77 69 64 74 68 2c  31 30 2e 39 37 2f 28 31  |4,width,10.97/(1|
000007f0  30 2e 39 37 2b 32 2a 73  79 29 2a 31 30 32 34 3a  |0.97+2*sy)*1024:|
00000800  c8 93 20 c8 90 20 28 73  78 2b 32 33 2e 37 37 29  |.. .. (sx+23.77)|
00000810  2f 28 32 33 2e 37 37 2b  32 2a 73 78 29 2a 31 32  |/(23.77+2*sx)*12|
00000820  38 30 2c 73 79 2f 28 31  30 2e 39 37 2b 32 2a 73  |80,sy/(10.97+2*s|
00000830  79 29 2a 31 30 32 34 2c  77 69 64 74 68 2c 31 30  |y)*1024,width,10|
00000840  2e 39 37 2f 28 31 30 2e  39 37 2b 32 2a 73 79 29  |.97/(10.97+2*sy)|
00000850  2a 31 30 32 34 2b 77 69  64 74 68 0d 01 fe ba 20  |*1024+width.... |
00000860  c8 93 20 c8 90 20 28 73  78 2b 35 2e 34 37 29 2f  |.. .. (sx+5.47)/|
00000870  28 32 33 2e 37 37 2b 32  2a 73 78 29 2a 31 32 38  |(23.77+2*sx)*128|
00000880  30 2c 28 73 79 2b 31 2e  33 37 29 2f 28 31 30 2e  |0,(sy+1.37)/(10.|
00000890  39 37 2b 32 2a 73 79 29  2a 31 30 32 34 2c 77 69  |97+2*sy)*1024,wi|
000008a0  64 74 68 2c 38 2e 32 33  2f 28 31 30 2e 39 37 2b  |dth,8.23/(10.97+|
000008b0  32 2a 73 79 29 2a 31 30  32 34 3a c8 93 20 c8 90  |2*sy)*1024:.. ..|
000008c0  20 28 73 78 2b 31 38 2e  33 29 2f 28 32 33 2e 37  | (sx+18.3)/(23.7|
000008d0  37 2b 32 2a 73 78 29 2a  31 32 38 30 2c 28 73 79  |7+2*sx)*1280,(sy|
000008e0  2b 31 2e 33 37 29 2f 28  31 30 2e 39 37 2b 32 2a  |+1.37)/(10.97+2*|
000008f0  73 79 29 2a 31 30 32 34  2c 77 69 64 74 68 2c 38  |sy)*1024,width,8|
00000900  2e 32 33 2f 28 31 30 2e  39 37 2b 32 2a 73 79 29  |.23/(10.97+2*sy)|
00000910  2a 31 30 32 34 0d 02 08  06 20 3a 0d 02 12 0f 20  |*1024.... :.... |
00000920  f4 20 44 72 61 77 20 6e  65 74 0d 02 1c 89 20 e6  |. Draw net.... .|
00000930  30 2c 35 3a e3 6c 3d 31  30 30 b8 39 32 34 88 31  |0,5:.l=100.924.1|
00000940  30 3a ec 20 36 34 30 2c  6c 3a df 20 36 38 30 2c  |0:. 640,l:. 680,|
00000950  6c 2b 35 30 3a ed 3a e3  6c 3d 30 b8 34 30 88 31  |l+50:.:.l=0.40.1|
00000960  30 3a ec 20 36 34 30 2b  6c 2c 31 30 30 2b 6c 3a  |0:. 640+l,100+l:|
00000970  df 36 34 30 2b 6c 2c 39  32 34 2b 6c 3a ed 3a e3  |.640+l,924+l:.:.|
00000980  6c 3d 30 b8 35 3a ec 36  33 37 2b 6c 2c 31 30 30  |l=0.5:.637+l,100|
00000990  3a df 36 37 37 2b 6c 2c  31 35 30 3a ec 36 33 37  |:.677+l,150:.637|
000009a0  2b 6c 2c 39 32 34 3a df  36 37 37 2b 6c 2c 39 37  |+l,924:.677+l,97|
000009b0  34 3a ed 0d 02 26 1c 20  e6 30 2c 32 3a ec 20 36  |4:...&. .0,2:. 6|
000009c0  38 32 2c 31 34 32 3a df  36 38 32 2c 39 36 36 0d  |82,142:.682,966.|
000009d0  02 30 0e 20 f2 64 72 61  77 6d 69 6e 69 0d 02 3a  |.0. .drawmini..:|
000009e0  06 20 e1 0d 02 44 06 20  3a 0d 02 4e 1d 20 f4 20  |. ...D. :..N. . |
000009f0  44 72 61 77 20 62 61 6c  6c 62 6f 74 20 61 6e 64  |Draw ballbot and|
00000a00  20 62 61 6c 6c 73 0d 02  58 0f 20 dd f2 64 72 61  | balls..X. ..dra|
00000a10  77 6d 69 6e 69 0d 02 62  14 20 e7 20 74 79 70 65  |wmini..b. . type|
00000a20  24 3d 22 32 22 20 8c 20  e1 0d 02 6c 10 20 e6 33  |$="2" . ...l. .3|
00000a30  2c 34 3a e3 62 3d 30 b8  34 0d 02 76 42 20 e7 20  |,4:.b=0.4..vB . |
00000a40  62 61 6c 6c 28 62 2c 30  29 3c 3e 30 20 84 20 62  |ball(b,0)<>0 . b|
00000a50  61 6c 6c 28 62 2c 31 29  3c 3e 30 20 8c 20 c8 93  |all(b,1)<>0 . ..|
00000a60  20 c8 90 20 62 61 6c 6c  28 62 2c 30 29 2c 62 61  | .. ball(b,0),ba|
00000a70  6c 6c 28 62 2c 31 29 2c  35 2c 35 0d 02 80 06 20  |ll(b,1),5,5.... |
00000a80  ed 0d 02 8a 1b 20 e6 33  2c 33 3a c8 93 20 c8 90  |..... .3,3:.. ..|
00000a90  20 62 62 78 2c 62 62 79  2c 35 2c 35 0d 02 94 06  | bbx,bby,5,5....|
00000aa0  20 e1 0d 02 9e 06 20 3a  0d 02 a8 2a 20 f4 20 55  | ..... :...* . U|
00000ab0  73 65 72 20 69 6e 74 65  72 66 61 63 65 20 28 70  |ser interface (p|
00000ac0  75 74 74 69 6e 67 20 62  61 6c 6c 73 20 64 6f 77  |utting balls dow|
00000ad0  6e 29 0d 02 b2 0b 20 dd  f2 75 73 65 72 0d 02 bc  |n).... ..user...|
00000ae0  0d 20 c8 97 20 78 2c 79  2c 63 0d 02 c6 0e 20 e7  |. .. x,y,c.... .|
00000af0  20 63 3d 30 20 8c 20 e1  0d 02 d0 61 20 e7 20 28  | c=0 . ....a . (|
00000b00  63 20 80 20 34 29 3c 3e  30 20 8c 20 f2 64 72 61  |c . 4)<>0 . .dra|
00000b10  77 6d 69 6e 69 3a 62 61  6c 6c 28 63 75 72 72 65  |wmini:ball(curre|
00000b20  6e 74 2c 30 29 3d 78 3a  62 61 6c 6c 28 63 75 72  |nt,0)=x:ball(cur|
00000b30  72 65 6e 74 2c 31 29 3d  79 3a 63 75 72 72 65 6e  |rent,1)=y:curren|
00000b40  74 3d 28 63 75 72 72 65  6e 74 2b 31 29 83 35 3a  |t=(current+1).5:|
00000b50  f2 64 72 61 77 6d 69 6e  69 0d 02 da 2a 20 e7 20  |.drawmini...* . |
00000b60  28 63 20 80 20 32 29 3c  3e 30 20 8c 20 69 64 6c  |(c . 2)<>0 . idl|
00000b70  65 3d a3 3a 73 74 61 67  65 3d 30 3a 73 74 61 72  |e=.:stage=0:star|
00000b80  74 3d 91 0d 02 e4 06 20  f5 0d 02 ee 0d 20 c8 97  |t=..... ..... ..|
00000b90  20 78 2c 79 2c 63 0d 02  f8 0a 20 fd 20 63 3d 30  | x,y,c.... . c=0|
00000ba0  0d 03 02 06 20 e1 0d 03  0c 06 20 3a 0d 03 16 27  |.... ..... :...'|
00000bb0  20 f4 20 43 61 6c 63 75  6c 61 74 65 20 62 61 6c  | . Calculate bal|
00000bc0  6c 62 6f 74 27 73 20 6e  65 77 20 70 6f 73 69 74  |lbot's new posit|
00000bd0  69 6f 6e 0d 03 20 0d 20  dd f2 6d 6f 76 65 69 74  |ion.. . ..moveit|
00000be0  0d 03 2a 0c 20 ea 20 73  70 65 65 64 0d 03 34 3b  |..*. . speed..4;|
00000bf0  20 e7 20 6c 65 66 74 20  80 20 28 ac 20 72 69 67  | . left . (. rig|
00000c00  68 74 29 20 8c 20 64 69  72 3d 64 69 72 2d 32 2e  |ht) . dir=dir-2.|
00000c10  35 2a 28 31 2d 33 2a 74  75 72 62 6f 29 3a 73 70  |5*(1-3*turbo):sp|
00000c20  65 65 64 3d 30 2e 31 0d  03 3e 3b 20 e7 20 72 69  |eed=0.1..>; . ri|
00000c30  67 68 74 20 80 20 28 ac  20 6c 65 66 74 29 20 8c  |ght . (. left) .|
00000c40  20 64 69 72 3d 64 69 72  2b 32 2e 35 2a 28 31 2d  | dir=dir+2.5*(1-|
00000c50  33 2a 74 75 72 62 6f 29  3a 73 70 65 65 64 3d 30  |3*turbo):speed=0|
00000c60  2e 31 0d 03 48 1d 20 e7  20 6c 65 66 74 20 80 20  |.1..H. . left . |
00000c70  72 69 67 68 74 20 8c 20  73 70 65 65 64 3d 31 0d  |right . speed=1.|
00000c80  03 52 06 20 3a 0d 03 5c  29 20 f4 20 47 65 74 20  |.R. :..\) . Get |
00000c90  64 69 72 65 63 74 69 6f  6e 20 69 6e 20 72 61 6e  |direction in ran|
00000ca0  67 65 20 30 3c 74 68 65  74 61 3c 33 36 30 0d 03  |ge 0<theta<360..|
00000cb0  66 1c 20 f5 20 e7 20 64  69 72 3c 30 20 8c 20 64  |f. . . dir<0 . d|
00000cc0  69 72 3d 64 69 72 2b 33  36 30 0d 03 70 1d 20 e7  |ir=dir+360..p. .|
00000cd0  20 64 69 72 3e 3d 33 36  30 20 8c 20 64 69 72 3d  | dir>=360 . dir=|
00000ce0  64 69 72 2d 33 36 30 0d  03 7a 17 20 fd 20 64 69  |dir-360..z. . di|
00000cf0  72 3e 3d 30 20 80 20 64  69 72 3c 33 36 30 0d 03  |r>=0 . dir<360..|
00000d00  84 06 20 3a 0d 03 8e 3d  20 f2 64 72 61 77 6d 69  |.. :...= .drawmi|
00000d10  6e 69 3a 62 62 78 3d 62  62 78 2b 31 35 2a b5 28  |ni:bbx=bbx+15*.(|
00000d20  af 2a 64 69 72 2f 31 38  30 29 2a 73 70 65 65 64  |.*dir/180)*speed|
00000d30  2a 28 2e 37 35 2a 2d 74  75 72 62 6f 2b 2e 32 35  |*(.75*-turbo+.25|
00000d40  29 0d 03 98 33 20 62 62  79 3d 62 62 79 2b 32 30  |)...3 bby=bby+20|
00000d50  2a 9b 28 af 2a 64 69 72  2f 31 38 30 29 2a 73 70  |*.(.*dir/180)*sp|
00000d60  65 65 64 2a 28 2e 37 35  2a 2d 74 75 72 62 6f 2b  |eed*(.75*-turbo+|
00000d70  2e 32 35 29 0d 03 a2 51  20 e3 62 61 6c 6c 3d 30  |.25)...Q .ball=0|
00000d80  b8 34 3a e7 20 94 28 62  62 78 2d 62 61 6c 6c 28  |.4:. .(bbx-ball(|
00000d90  62 61 6c 6c 2c 30 29 29  3c 31 30 20 80 20 94 28  |ball,0))<10 . .(|
00000da0  62 62 79 2d 62 61 6c 6c  28 62 61 6c 6c 2c 31 29  |bby-ball(ball,1)|
00000db0  29 3c 31 30 20 8c 20 62  61 6c 6c 28 62 61 6c 6c  |)<10 . ball(ball|
00000dc0  2c 30 29 3d 30 0d 03 ac  10 20 ed 3a f2 64 72 61  |,0)=0.... .:.dra|
00000dd0  77 6d 69 6e 69 0d 03 b6  06 20 e1 0d 03 c0 06 20  |wmini.... ..... |
00000de0  3a 0d 03 ca 3b 20 f4 20  43 61 6c 63 75 6c 61 74  |:...; . Calculat|
00000df0  65 20 62 61 6c 6c 62 6f  74 27 73 20 62 61 63 6b  |e ballbot's back|
00000e00  67 72 6f 75 6e 64 20 65  63 68 6f 20 72 65 61 64  |ground echo read|
00000e10  69 6e 67 20 28 2d 62 61  6c 6c 73 29 0d 03 d4 19  |ing (-balls)....|
00000e20  20 dd a4 62 61 63 6b 28  66 72 65 71 2c 6d 69 6e  | ..back(freq,min|
00000e30  2c 6d 61 78 29 0d 03 de  2c 20 f4 20 47 65 74 20  |,max)..., . Get |
00000e40  61 6e 67 75 6c 61 72 20  72 61 6e 67 65 20 69 6e  |angular range in|
00000e50  20 66 6f 72 6d 20 30 3c  74 68 65 74 61 3c 33 36  | form 0<theta<36|
00000e60  30 0d 03 e8 2c 20 f4 20  53 65 74 20 75 70 20 69  |0..., . Set up i|
00000e70  6e 69 74 69 61 6c 20 6f  75 74 73 69 64 65 20 72  |nitial outside r|
00000e80  61 6e 67 65 20 73 65 74  74 69 6e 67 73 0d 03 f2  |ange settings...|
00000e90  3f 20 68 69 74 3d 30 3a  64 69 73 74 3d 30 3a 64  |? hit=0:dist=0:d|
00000ea0  69 73 74 61 3d 39 39 39  39 3a 68 69 74 61 3d 30  |ista=9999:hita=0|
00000eb0  3a f4 20 4c 4f 43 41 4c  20 68 69 74 2c 64 69 73  |:. LOCAL hit,dis|
00000ec0  74 2c 68 69 74 61 2c 64  69 73 74 61 0d 03 fc 38  |t,hita,dista...8|
00000ed0  20 f4 20 49 66 20 73 74  72 61 69 67 68 74 20 61  | . If straight a|
00000ee0  74 20 6e 65 74 20 69 73  20 69 6e 20 72 61 6e 67  |t net is in rang|
00000ef0  65 2c 20 77 69 6c 6c 20  62 65 20 73 68 6f 72 74  |e, will be short|
00000f00  65 73 74 2e 0d 04 06 77  20 e7 28 62 62 78 3c 36  |est....w .(bbx<6|
00000f10  34 30 80 6d 69 6e 3c 3d  39 30 80 6d 61 78 3e 3d  |40.min<=90.max>=|
00000f20  39 30 29 84 28 62 62 78  3e 36 34 30 80 6d 69 6e  |90).(bbx>640.min|
00000f30  3c 3d 32 37 30 80 6d 61  78 3e 3d 32 37 30 29 20  |<=270.max>=270) |
00000f40  80 20 28 62 62 79 3e 31  30 30 20 80 20 62 62 79  |. (bby>100 . bby|
00000f50  3c 39 32 33 29 20 8c 20  68 69 74 3d 62 62 79 3a  |<923) . hit=bby:|
00000f60  64 69 73 74 3d 94 28 62  62 78 2d 36 34 30 29 3a  |dist=.(bbx-640):|
00000f70  6d 69 6e 3d 30 3a 6d 61  78 3d 30 0d 04 10 2f 20  |min=0:max=0.../ |
00000f80  f4 20 4f 74 68 65 72 77  69 73 65 20 66 69 6e 64  |. Otherwise find|
00000f90  20 73 68 6f 72 74 65 73  74 20 65 78 74 72 65 6d  | shortest extrem|
00000fa0  65 20 6f 66 20 72 61 6e  67 65 0d 04 1a 53 20 e7  |e of range...S .|
00000fb0  20 b5 28 af 2a 6d 69 6e  2f 31 38 30 29 3c 3e 30  | .(.*min/180)<>0|
00000fc0  20 8c 20 64 69 73 74 3d  28 36 34 30 2d 62 62 78  | . dist=(640-bbx|
00000fd0  29 2f b5 28 af 2a 6d 69  6e 2f 31 38 30 29 3a 68  |)/.(.*min/180):h|
00000fe0  69 74 3d 62 62 79 2b 28  36 34 30 2d 62 62 78 29  |it=bby+(640-bbx)|
00000ff0  2f b7 28 af 2a 6d 69 6e  2f 31 38 30 29 0d 04 24  |/.(.*min/180)..$|
00001000  55 20 e7 20 b5 28 af 2a  6d 61 78 2f 31 38 30 29  |U . .(.*max/180)|
00001010  3c 3e 30 20 8c 20 64 69  73 74 61 3d 28 36 34 30  |<>0 . dista=(640|
00001020  2d 62 62 78 29 2f b5 28  af 2a 6d 61 78 2f 31 38  |-bbx)/.(.*max/18|
00001030  30 29 3a 68 69 74 61 3d  62 62 79 2b 28 36 34 30  |0):hita=bby+(640|
00001040  2d 62 62 78 29 2f b7 28  af 2a 6d 61 78 2f 31 38  |-bbx)/.(.*max/18|
00001050  30 29 0d 04 2e 2c 20 f4  20 4a 75 73 74 20 63 68  |0)..., . Just ch|
00001060  65 63 6b 20 69 66 20 70  6f 73 74 20 69 6e 20 6d  |eck if post in m|
00001070  69 64 64 6c 65 20 6f 66  20 72 61 6e 67 65 0d 04  |iddle of range..|
00001080  38 64 20 e7 20 62 62 78  3c 36 34 30 20 80 20 68  |8d . bbx<640 . h|
00001090  69 74 3e 31 30 30 20 80  20 28 68 69 74 61 3c 31  |it>100 . (hita<1|
000010a0  30 30 20 84 20 64 69 73  74 61 3c 30 29 20 80 20  |00 . dista<0) . |
000010b0  64 69 73 74 3e 30 20 8c  20 68 69 74 61 3d 31 30  |dist>0 . hita=10|
000010c0  30 3a 64 69 73 74 61 3d  b6 28 28 62 62 78 2d 36  |0:dista=.((bbx-6|
000010d0  34 30 29 5e 32 2b 28 62  62 79 2d 31 30 30 29 5e  |40)^2+(bby-100)^|
000010e0  32 29 0d 04 42 62 20 e7  20 62 62 78 3c 36 34 30  |2)..Bb . bbx<640|
000010f0  20 80 20 68 69 74 61 3c  39 32 33 20 80 20 28 68  | . hita<923 . (h|
00001100  69 74 3e 39 32 33 20 84  20 64 69 73 74 3c 30 29  |it>923 . dist<0)|
00001110  20 80 20 64 69 73 74 61  3e 30 20 8c 20 68 69 74  | . dista>0 . hit|
00001120  3d 39 32 33 3a 64 69 73  74 3d b6 28 28 62 62 78  |=923:dist=.((bbx|
00001130  2d 36 34 30 29 5e 32 2b  28 62 62 79 2d 39 32 33  |-640)^2+(bby-923|
00001140  29 5e 32 29 0d 04 4c 62  20 e7 20 62 62 78 3e 36  |)^2)..Lb . bbx>6|
00001150  34 30 20 80 20 68 69 74  61 3e 31 30 30 20 80 20  |40 . hita>100 . |
00001160  28 68 69 74 3c 31 30 30  20 84 20 64 69 73 74 3c  |(hit<100 . dist<|
00001170  30 29 20 80 20 64 69 73  74 61 3e 30 20 8c 20 68  |0) . dista>0 . h|
00001180  69 74 3d 31 30 30 3a 64  69 73 74 3d b6 28 28 62  |it=100:dist=.((b|
00001190  62 78 2d 36 34 30 29 5e  32 2b 28 62 62 79 2d 31  |bx-640)^2+(bby-1|
000011a0  30 30 29 5e 32 29 0d 04  56 64 20 e7 20 62 62 78  |00)^2)..Vd . bbx|
000011b0  3e 36 34 30 20 80 20 68  69 74 3c 39 32 33 20 80  |>640 . hit<923 .|
000011c0  20 28 68 69 74 61 3e 39  32 33 20 84 20 64 69 73  | (hita>923 . dis|
000011d0  74 61 3c 30 29 20 80 20  64 69 73 74 3e 30 20 8c  |ta<0) . dist>0 .|
000011e0  20 68 69 74 61 3d 39 32  33 3a 64 69 73 74 61 3d  | hita=923:dista=|
000011f0  b6 28 28 62 62 78 2d 36  34 30 29 5e 32 2b 28 62  |.((bbx-640)^2+(b|
00001200  62 79 2d 39 32 33 29 5e  32 29 0d 04 60 1d 20 f4  |by-923)^2)..`. .|
00001210  20 50 69 63 6b 20 62 65  73 74 20 74 6f 20 73 65  | Pick best to se|
00001220  6e 64 20 6f 66 66 21 0d  04 6a 48 20 e7 20 64 69  |nd off!..jH . di|
00001230  73 74 3c 30 20 84 20 28  64 69 73 74 61 3c 64 69  |st<0 . (dista<di|
00001240  73 74 20 80 20 68 69 74  61 3e 31 30 30 20 80 20  |st . hita>100 . |
00001250  68 69 74 61 3c 39 32 33  29 20 8c 20 64 69 73 74  |hita<923) . dist|
00001260  3d 64 69 73 74 61 3a 68  69 74 3d 68 69 74 61 0d  |=dista:hit=hita.|
00001270  04 74 3b 20 e7 20 68 69  74 3e 39 32 33 20 84 20  |.t; . hit>923 . |
00001280  68 69 74 3c 31 30 30 20  84 20 64 69 73 74 3c 30  |hit<100 . dist<0|
00001290  20 8c 20 66 74 79 70 65  24 3d 22 55 22 3a 3d 66  | . ftype$="U":=f|
000012a0  72 65 71 2b b3 28 36 29  2d 33 0d 04 7e 2b 20 e7  |req+.(6)-3..~+ .|
000012b0  20 68 69 74 3e 39 30 30  20 84 20 68 69 74 3c 31  | hit>900 . hit<1|
000012c0  32 33 20 8c 20 66 74 79  70 65 24 3d 22 50 22 3a  |23 . ftype$="P":|
000012d0  3d 64 69 73 74 0d 04 88  0f 20 66 74 79 70 65 24  |=dist.... ftype$|
000012e0  3d 22 4e 22 0d 04 92 0a  20 3d 64 69 73 74 0d 04  |="N".... =dist..|
000012f0  9c 06 20 3a 0d 04 a6 32  20 f4 20 43 61 6c 63 75  |.. :...2 . Calcu|
00001300  6c 61 74 65 20 42 61 6c  6c 62 6f 74 27 73 20 72  |late Ballbot's r|
00001310  65 61 64 69 6e 67 73 20  28 4d 41 49 4e 20 52 4f  |eadings (MAIN RO|
00001320  55 54 49 4e 45 29 0d 04  b0 06 20 3a 0d 04 ba 0c  |UTINE).... :....|
00001330  20 dd f2 73 65 6e 73 65  0d 04 c4 2a 20 f4 20 47  | ..sense...* . G|
00001340  65 74 20 62 61 63 6b 67  72 6f 75 6e 64 20 72 65  |et background re|
00001350  61 64 69 6e 67 73 20 66  72 6f 6d 20 46 4e 62 61  |adings from FNba|
00001360  63 6b 0d 04 ce 15 20 66  72 65 71 3d b3 28 32 35  |ck.... freq=.(25|
00001370  30 29 2b 31 35 30 30 0d  04 d8 2f 20 66 72 65 71  |0)+1500.../ freq|
00001380  61 3d a4 62 61 63 6b 28  66 72 65 71 2c 64 69 72  |a=.back(freq,dir|
00001390  2d 31 35 2c 64 69 72 2b  31 35 29 3a 66 61 24 3d  |-15,dir+15):fa$=|
000013a0  66 74 79 70 65 24 0d 04  e2 2f 20 66 72 65 71 62  |ftype$.../ freqb|
000013b0  3d a4 62 61 63 6b 28 66  72 65 71 2c 64 69 72 2d  |=.back(freq,dir-|
000013c0  34 35 2c 64 69 72 2d 31  35 29 3a 66 62 24 3d 66  |45,dir-15):fb$=f|
000013d0  74 79 70 65 24 0d 04 ec  2f 20 66 72 65 71 63 3d  |type$.../ freqc=|
000013e0  a4 62 61 63 6b 28 66 72  65 71 2c 64 69 72 2b 31  |.back(freq,dir+1|
000013f0  35 2c 64 69 72 2b 34 35  29 3a 66 63 24 3d 66 74  |5,dir+45):fc$=ft|
00001400  79 70 65 24 0d 04 f6 06  20 3a 0d 05 00 44 20 f4  |ype$.... :...D .|
00001410  20 41 64 64 20 61 6e 79  20 72 65 6c 65 76 61 6e  | Add any relevan|
00001420  74 20 62 61 6c 6c 73 20  74 6f 20 72 65 61 64 69  |t balls to readi|
00001430  6e 67 73 20 28 75 73 69  6e 67 20 68 61 69 72 79  |ngs (using hairy|
00001440  20 74 72 69 67 6f 6e 6f  6d 65 74 72 79 29 0d 05  | trigonometry)..|
00001450  0a 06 20 3a 0d 05 14 0e  20 e3 62 61 6c 6c 3d 30  |.. :.... .ball=0|
00001460  b8 34 0d 05 1e 34 20 64  25 3d b6 28 28 62 61 6c  |.4...4 d%=.((bal|
00001470  6c 28 62 61 6c 6c 2c 30  29 2d 62 62 78 29 5e 32  |l(ball,0)-bbx)^2|
00001480  2b 28 62 61 6c 6c 28 62  61 6c 6c 2c 31 29 2d 62  |+(ball(ball,1)-b|
00001490  62 79 29 5e 32 29 0d 05  28 1f 20 e7 20 62 61 6c  |by)^2)..(. . bal|
000014a0  6c 28 62 61 6c 6c 2c 30  29 3d 30 20 8c 20 64 25  |l(ball,0)=0 . d%|
000014b0  3d 39 39 39 39 0d 05 32  45 20 61 3d a4 61 6e 67  |=9999..2E a=.ang|
000014c0  6c 65 28 62 61 6c 6c 28  62 61 6c 6c 2c 30 29 2c  |le(ball(ball,0),|
000014d0  62 61 6c 6c 28 62 61 6c  6c 2c 31 29 2c 62 62 78  |ball(ball,1),bbx|
000014e0  2c 62 62 79 29 2d 64 69  72 3a e7 61 3e 31 38 30  |,bby)-dir:.a>180|
000014f0  20 8c 20 61 3d 61 2d 33  36 30 0d 05 3c 2c 20 e7  | . a=a-360..<, .|
00001500  20 94 28 61 29 3c 31 35  20 80 20 66 72 65 71 61  | .(a)<15 . freqa|
00001510  3e 64 25 20 8c 20 66 72  65 71 61 3d 64 25 3a 66  |>d% . freqa=d%:f|
00001520  61 24 3d 22 42 22 0d 05  46 33 20 e7 20 61 3e 2d  |a$="B"..F3 . a>-|
00001530  34 36 20 80 20 61 3c 3d  2d 31 35 20 80 20 66 72  |46 . a<=-15 . fr|
00001540  65 71 62 3e 64 25 20 8c  20 66 72 65 71 62 3d 64  |eqb>d% . freqb=d|
00001550  25 3a 66 62 24 3d 22 42  22 0d 05 50 31 20 e7 20  |%:fb$="B"..P1 . |
00001560  61 3e 3d 31 35 20 80 20  61 3c 34 36 20 80 20 66  |a>=15 . a<46 . f|
00001570  72 65 71 63 3e 64 25 20  8c 20 66 72 65 71 63 3d  |reqc>d% . freqc=|
00001580  64 25 3a 66 63 24 3d 22  42 22 0d 05 5a 06 20 ed  |d%:fc$="B"..Z. .|
00001590  0d 05 64 06 20 3a 0d 05  6e 1b 20 f4 20 55 70 64  |..d. :..n. . Upd|
000015a0  61 74 65 20 75 73 65 72  20 64 69 73 70 6c 61 79  |ate user display|
000015b0  73 0d 05 78 06 20 3a 0d  05 82 14 20 e7 20 74 79  |s..x. :.... . ty|
000015c0  70 65 24 3d 22 32 22 20  8c 20 e1 0d 05 8c 3a 20  |pe$="2" . ....: |
000015d0  f1 8a 30 2c 30 29 a8 28  28 91 2d 73 74 61 72 74  |..0,0).((.-start|
000015e0  29 2f 36 30 30 30 29 3b  22 3a 22 3b 28 a8 28 28  |)/6000);":";(.((|
000015f0  91 2d 73 74 61 72 74 29  2f 31 30 30 29 83 36 30  |.-start)/100).60|
00001600  29 3b 22 20 22 0d 05 96  3a 20 f1 8a 30 2c 33 31  |);" "...: ..0,31|
00001610  29 66 62 24 2c 66 61 24  2c 66 63 24 2c 73 74 61  |)fb$,fa$,fc$,sta|
00001620  67 65 2c a8 28 73 65 61  72 63 68 69 6e 67 29 2c  |ge,.(searching),|
00001630  6c 65 66 74 2c 72 69 67  68 74 2c 64 69 72 3b 0d  |left,right,dir;.|
00001640  05 a0 37 20 d4 20 31 2c  2d 31 2c 66 72 65 71 61  |..7 . 1,-1,freqa|
00001650  2f 34 2c 35 3a d4 20 32  2c 2d 31 2c 66 72 65 71  |/4,5:. 2,-1,freq|
00001660  62 2f 34 2c 35 3a d4 20  33 2c 2d 31 2c 66 72 65  |b/4,5:. 3,-1,fre|
00001670  71 63 2f 34 2c 35 0d 05  aa 06 20 e1 0d 05 b4 05  |qc/4,5.... .....|
00001680  3a 0d 05 be 24 20 f4 20  43 61 6c 63 75 6c 61 74  |:...$ . Calculat|
00001690  65 20 62 65 61 72 69 6e  67 20 6f 66 20 42 20 66  |e bearing of B f|
000016a0  72 6f 6d 20 41 0d 05 c8  19 20 dd a4 61 6e 67 6c  |rom A.... ..angl|
000016b0  65 28 78 31 2c 79 31 2c  78 32 2c 79 32 29 0d 05  |e(x1,y1,x2,y2)..|
000016c0  d2 34 20 e7 20 79 32 3d  79 31 20 8c 20 61 6e 67  |.4 . y2=y1 . ang|
000016d0  3d 39 30 20 8b 20 61 6e  67 3d 31 38 30 2a 99 28  |=90 . ang=180*.(|
000016e0  28 78 32 2d 78 31 29 2f  28 79 32 2d 79 31 29 29  |(x2-x1)/(y2-y1))|
000016f0  2f af 0d 05 dc 1c 20 e7  20 28 79 32 3e 79 31 29  |/..... . (y2>y1)|
00001700  20 8c 20 61 6e 67 3d 61  6e 67 2b 31 38 30 0d 05  | . ang=ang+180..|
00001710  e6 1a 20 e7 20 61 6e 67  3c 30 20 8c 20 61 6e 67  |.. . ang<0 . ang|
00001720  3d 61 6e 67 2b 33 36 30  0d 05 f0 0f 20 3d 61 6e  |=ang+360.... =an|
00001730  67 20 83 20 33 36 30 0d  05 fa 06 20 3a 0d 06 04  |g . 360.... :...|
00001740  2d 20 f4 20 43 6f 6d 70  75 74 65 72 20 4d 6f 6e  |- . Computer Mon|
00001750  69 74 6f 72 20 6f 66 20  42 61 6c 6c 42 6f 74 27  |itor of BallBot'|
00001760  73 20 70 72 6f 67 72 65  73 73 0d 06 0e 0e 20 dd  |s progress.... .|
00001770  f2 63 6f 6d 70 6d 6f 6e  0d 06 18 72 20 e7 20 69  |.compmon...r . i|
00001780  64 6c 65 20 80 20 28 62  61 6c 6c 28 30 2c 30 29  |dle . (ball(0,0)|
00001790  3c 3e 30 20 84 20 62 61  6c 6c 28 31 2c 30 29 3c  |<>0 . ball(1,0)<|
000017a0  3e 30 20 84 20 62 61 6c  6c 28 32 2c 30 29 3c 3e  |>0 . ball(2,0)<>|
000017b0  30 20 84 20 62 61 6c 6c  28 33 2c 30 29 3c 3e 30  |0 . ball(3,0)<>0|
000017c0  20 84 20 62 61 6c 6c 28  34 2c 30 29 3c 3e 30 29  | . ball(4,0)<>0)|
000017d0  20 8c 20 73 74 24 3d 22  46 61 69 6c 22 20 8b 20  | . st$="Fail" . |
000017e0  73 74 24 3d 22 50 61 73  73 22 0d 06 22 3e 20 e7  |st$="Pass".."> .|
000017f0  20 69 64 6c 65 20 8c 20  f1 73 74 24 2c a8 28 28  | idle . .st$,.((|
00001800  91 2d 73 74 61 72 74 29  2f 36 30 30 30 29 3b 22  |.-start)/6000);"|
00001810  3a 22 3b 28 a8 28 28 91  2d 73 74 61 72 74 29 2f  |:";(.((.-start)/|
00001820  31 30 30 29 83 36 30 29  0d 06 2c 2c 20 e7 20 91  |100).60)..,, . .|
00001830  3e 73 74 61 72 74 2b 33  36 30 30 30 20 8c 20 69  |>start+36000 . i|
00001840  64 6c 65 3d b9 3a f1 22  54 69 6d 65 22 2c 22 2a  |dle=.:."Time","*|
00001850  2a 2a 2a 22 0d 06 36 3c  20 e7 62 62 78 3e 36 33  |***"..6< .bbx>63|
00001860  30 80 62 62 78 3c 36 35  30 80 62 62 79 3e 31 30  |0.bbx<650.bby>10|
00001870  30 80 62 62 79 3c 39 32  33 8c 69 64 6c 65 3d b9  |0.bby<923.idle=.|
00001880  3a f1 22 43 72 61 73 68  22 2c 22 2a 2a 2a 2a 22  |:."Crash","****"|
00001890  0d 06 40 6b 20 e7 20 69  64 6c 65 20 8c 20 62 62  |..@k . idle . bb|
000018a0  78 3d 36 34 30 3a 62 62  79 3d 39 35 30 3a 64 69  |x=640:bby=950:di|
000018b0  72 3d 32 37 30 3a 73 74  61 67 65 3d 30 3a f2 73  |r=270:stage=0:.s|
000018c0  65 74 75 70 62 62 3a 73  74 61 72 74 3d 91 3a e3  |etupbb:start=.:.|
000018d0  62 3d 30 b8 34 3a 62 61  6c 6c 28 62 2c 30 29 3d  |b=0.4:ball(b,0)=|
000018e0  b3 28 31 32 38 30 29 3a  62 61 6c 6c 28 62 2c 31  |.(1280):ball(b,1|
000018f0  29 3d b3 28 31 30 32 34  29 3a ed 0d 06 4a af 20  |)=.(1024):...J. |
00001900  e7 20 69 64 6c 65 20 8c  20 f1 22 5b 22 3b 62 61  |. idle . ."[";ba|
00001910  6c 6c 28 30 2c 30 29 3b  22 2c 22 3b 62 61 6c 6c  |ll(0,0);",";ball|
00001920  28 30 2c 31 29 3b 22 5d  20 5b 22 3b 62 61 6c 6c  |(0,1);"] [";ball|
00001930  28 31 2c 30 29 3b 22 2c  22 3b 62 61 6c 6c 28 31  |(1,0);",";ball(1|
00001940  2c 31 29 3b 22 5d 20 5b  22 3b 62 61 6c 6c 28 32  |,1);"] [";ball(2|
00001950  2c 30 29 3b 22 2c 22 3b  62 61 6c 6c 28 32 2c 31  |,0);",";ball(2,1|
00001960  29 3b 22 5d 20 5b 22 3b  62 61 6c 6c 28 33 2c 30  |);"] [";ball(3,0|
00001970  29 3b 22 2c 22 3b 62 61  6c 6c 28 33 2c 31 29 3b  |);",";ball(3,1);|
00001980  22 5d 20 5b 22 3b 62 61  6c 6c 28 34 2c 30 29 3b  |"] [";ball(4,0);|
00001990  22 2c 22 3b 62 61 6c 6c  28 34 2c 31 29 3b 22 5d  |",";ball(4,1);"]|
000019a0  22 2c 3b 3a 69 64 6c 65  3d a3 0d 06 54 06 20 e1  |",;:idle=...T. .|
000019b0  0d 06 5e 06 20 3a 0d 06  68 2a 20 f4 20 42 41 4c  |..^. :..h* . BAL|
000019c0  4c 42 4f 54 20 52 4f 42  4f 54 49 43 20 49 4e 54  |LBOT ROBOTIC INT|
000019d0  45 4c 4c 49 47 45 4e 43  45 20 4d 4f 44 55 4c 45  |ELLIGENCE MODULE|
000019e0  0d 06 72 06 20 3a 0d 06  7c 1c 20 dd a4 61 69 28  |..r. :..|. ..ai(|
000019f0  66 72 65 71 61 2c 66 72  65 71 62 2c 66 72 65 71  |freqa,freqb,freq|
00001a00  63 29 0d 06 86 39 20 f4  20 41 72 74 69 66 69 63  |c)...9 . Artific|
00001a10  69 61 6c 20 69 6e 74 65  6c 6c 69 67 65 6e 63 65  |ial intelligence|
00001a20  20 72 6f 75 74 69 6e 65  73 20 28 69 65 2e 20 57  | routines (ie. W|
00001a30  68 61 74 20 4e 65 78 74  3f 3f 29 0d 06 90 16 20  |hat Next??).... |
00001a40  ea 6c 65 66 74 2c 72 69  67 68 74 2c 74 75 72 62  |.left,right,turb|
00001a50  6f 0d 06 9a 1b 20 6c 65  66 74 3d a3 3a 72 69 67  |o.... left=.:rig|
00001a60  68 74 3d a3 3a 74 75 72  62 6f 3d a3 0d 06 a4 06  |ht=.:turbo=.....|
00001a70  20 3a 0d 06 ae 40 20 f4  20 57 68 61 74 20 73 74  | :...@ . What st|
00001a80  61 67 65 20 61 72 65 20  77 65 20 69 6e 3f 20 48  |age are we in? H|
00001a90  75 6e 74 20 66 6f 72 20  62 61 6c 6c 73 20 6f 72  |unt for balls or|
00001aa0  20 6d 6f 76 65 20 74 6f  20 6e 65 77 20 61 72 65  | move to new are|
00001ab0  61 3f 0d 06 b8 27 20 e7  20 6e 65 61 72 3c 3e 30  |a?...' . near<>0|
00001ac0  20 80 20 73 74 61 67 65  3c 38 20 8c 20 f2 64 6f  | . stage<8 . .do|
00001ad0  6e 65 61 72 73 74 75 66  66 0d 06 c2 2b 20 e7 20  |nearstuff...+ . |
00001ae0  6e 65 61 72 3d 30 20 80  20 28 73 74 61 67 65 3d  |near=0 . (stage=|
00001af0  30 20 84 20 73 74 61 67  65 3d 32 29 20 8c 20 f2  |0 . stage=2) . .|
00001b00  68 75 6e 74 0d 06 cc 2e  20 e7 20 6e 65 61 72 3d  |hunt.... . near=|
00001b10  30 20 80 20 28 73 74 61  67 65 3d 31 20 84 20 73  |0 . (stage=1 . s|
00001b20  74 61 67 65 3d 33 29 20  8c 20 f2 6d 6f 76 65 6f  |tage=3) . .moveo|
00001b30  75 74 0d 06 d6 1a 20 e7  20 73 74 61 67 65 3d 34  |ut.... . stage=4|
00001b40  20 8c 20 f2 72 65 6c 65  61 73 65 62 0d 06 e0 06  | . .releaseb....|
00001b50  20 3a 0d 06 ea 32 20 f4  20 50 72 65 70 61 72 65  | :...2 . Prepare|
00001b60  20 6f 75 74 70 75 74 20  69 6e 74 6f 20 62 69 6e  | output into bin|
00001b70  61 72 79 20 66 6f 72 20  74 72 61 6e 73 6d 69 73  |ary for transmis|
00001b80  73 69 6f 6e 0d 06 f4 20  20 66 65 65 64 3d 30 3a  |sion...  feed=0:|
00001b90  e7 20 6c 65 66 74 20 8c  20 66 65 65 64 3d 66 65  |. left . feed=fe|
00001ba0  65 64 2b 31 0d 06 fe 1a  20 e7 20 72 69 67 68 74  |ed+1.... . right|
00001bb0  20 8c 20 66 65 65 64 3d  66 65 65 64 2b 32 0d 07  | . feed=feed+2..|
00001bc0  08 1a 20 e7 20 74 75 72  62 6f 20 8c 20 66 65 65  |.. . turbo . fee|
00001bd0  64 3d 66 65 65 64 2b 34  0d 07 12 19 20 e7 20 69  |d=feed+4.... . i|
00001be0  64 6c 65 20 8c 20 66 65  65 64 3d 66 65 65 64 2b  |dle . feed=feed+|
00001bf0  38 0d 07 1c 0a 20 3d 66  65 65 64 0d 07 26 06 20  |8.... =feed..&. |
00001c00  3a 0d 07 30 28 20 f4 20  50 65 72 66 6f 72 6d 20  |:..0( . Perform |
00001c10  61 20 73 77 65 65 70 20  74 6f 20 66 69 6e 64 20  |a sweep to find |
00001c20  61 6e 79 20 62 61 6c 6c  73 0d 07 3a 0b 20 dd f2  |any balls..:. ..|
00001c30  68 75 6e 74 0d 07 44 23  20 f4 20 57 61 74 63 68  |hunt..D# . Watch|
00001c40  20 6f 75 74 20 69 66 20  74 6f 6f 20 6e 65 61 72  | out if too near|
00001c50  20 74 6f 20 6e 65 74 0d  07 4e 64 20 f4 49 46 28  | to net..Nd .IF(|
00001c60  66 72 65 71 61 3c 32 30  41 4e 44 20 66 61 24 3c  |freqa<20AND fa$<|
00001c70  3e 22 42 22 29 4f 52 28  66 72 65 71 62 3c 32 30  |>"B")OR(freqb<20|
00001c80  41 4e 44 20 66 62 24 3c  3e 22 42 22 29 4f 52 28  |AND fb$<>"B")OR(|
00001c90  66 72 65 71 63 3c 32 30  41 4e 44 20 66 63 24 3c  |freqc<20AND fc$<|
00001ca0  3e 22 42 22 29 41 4e 44  66 61 24 3d 22 42 22 54  |>"B")ANDfa$="B"T|
00001cb0  48 45 4e 3a 45 4e 44 50  52 4f 43 0d 07 58 06 20  |HEN:ENDPROC..X. |
00001cc0  3a 0d 07 62 1a 20 f4 20  52 6f 74 61 74 65 20 74  |:..b. . Rotate t|
00001cd0  6f 20 66 61 63 65 20 62  61 6c 6c 0d 07 6c 24 20  |o face ball..l$ |
00001ce0  f4 20 57 68 65 72 65 20  73 65 61 72 63 68 20 61  |. Where search a|
00001cf0  66 74 65 72 20 74 68 69  73 20 62 61 6c 6c 3f 0d  |fter this ball?.|
00001d00  07 76 28 20 e7 20 28 66  62 24 3d 22 42 22 20 80  |.v( . (fb$="B" .|
00001d10  20 66 72 65 71 62 3e 31  35 30 29 20 8c 20 74 65  | freqb>150) . te|
00001d20  6e 64 69 6e 67 3d 30 0d  07 80 26 20 e7 20 66 63  |nding=0...& . fc|
00001d30  24 3d 22 42 22 20 80 20  66 72 65 71 63 3e 31 35  |$="B" . freqc>15|
00001d40  30 20 8c 20 74 65 6e 64  69 6e 67 3d 31 0d 07 8a  |0 . tending=1...|
00001d50  1f 20 f4 20 50 69 63 6b  20 62 65 73 74 20 62 61  |. . Pick best ba|
00001d60  6c 6c 20 74 6f 20 61 69  6d 20 61 74 0d 07 94 5a  |ll to aim at...Z|
00001d70  20 64 69 73 74 3d 66 72  65 71 61 2a 30 2e 37 35  | dist=freqa*0.75|
00001d80  3a e7 20 64 69 73 74 3e  66 72 65 71 62 20 80 20  |:. dist>freqb . |
00001d90  66 62 24 3d 22 42 22 20  80 20 28 66 72 65 71 62  |fb$="B" . (freqb|
00001da0  3c 66 72 65 71 63 20 84  20 66 63 24 3c 3e 22 42  |<freqc . fc$<>"B|
00001db0  22 29 20 8c 20 73 74 65  65 72 3d 2d 31 3a 6c 65  |") . steer=-1:le|
00001dc0  66 74 3d b9 3a e1 0d 07  9e 2f 20 e7 20 64 69 73  |ft=.:..../ . dis|
00001dd0  74 3e 66 72 65 71 63 20  80 20 66 63 24 3d 22 42  |t>freqc . fc$="B|
00001de0  22 20 8c 20 73 74 65 65  72 3d 31 3a 72 69 67 68  |" . steer=1:righ|
00001df0  74 3d b9 3a e1 0d 07 a8  62 20 e7 20 66 61 24 3d  |t=.:....b . fa$=|
00001e00  22 42 22 20 8c 20 6c 65  66 74 3d 28 73 74 65 65  |"B" . left=(stee|
00001e10  72 3c 3e 31 29 3a 72 69  67 68 74 3d 28 73 74 65  |r<>1):right=(ste|
00001e20  65 72 3c 3e 2d 31 29 3a  73 74 65 65 72 3d 30 3a  |er<>-1):steer=0:|
00001e30  73 65 61 72 63 68 69 6e  67 3d 73 65 61 72 63 68  |searching=search|
00001e40  69 6e 67 2f 32 3a 74 75  72 62 6f 3d 66 72 65 71  |ing/2:turbo=freq|
00001e50  61 3e 31 30 30 3a e1 0d  07 b2 22 20 e7 20 66 62  |a>100:...." . fb|
00001e60  24 3d 22 42 22 20 8c 20  73 74 65 65 72 3d 2d 31  |$="B" . steer=-1|
00001e70  3a 6c 65 66 74 3d b9 3a  e1 0d 07 bc 22 20 e7 20  |:left=.:...." . |
00001e80  66 63 24 3d 22 42 22 20  8c 20 73 74 65 65 72 3d  |fc$="B" . steer=|
00001e90  31 3a 72 69 67 68 74 3d  b9 3a e1 0d 07 c6 06 20  |1:right=.:..... |
00001ea0  3a 0d 07 d0 30 20 f4 20  49 66 20 6e 6f 20 62 61  |:...0 . If no ba|
00001eb0  6c 6c 20 69 6e 20 73 69  67 68 74 2c 20 63 6f 6e  |ll in sight, con|
00001ec0  74 69 6e 75 65 20 72 6f  74 61 74 69 6f 6e 2e 2e  |tinue rotation..|
00001ed0  2e 0d 07 da 36 20 73 65  61 72 63 68 69 6e 67 3d  |....6 searching=|
00001ee0  73 65 61 72 63 68 69 6e  67 2b 31 3a 74 75 72 62  |searching+1:turb|
00001ef0  6f 3d 28 73 65 61 72 63  68 69 6e 67 3e 35 29 3a  |o=(searching>5):|
00001f00  73 74 65 65 72 3d 30 0d  07 e4 2a 20 e7 20 28 74  |steer=0...* . (t|
00001f10  65 6e 64 69 6e 67 20 80  20 31 29 3c 3e 30 20 8c  |ending . 1)<>0 .|
00001f20  20 72 69 67 68 74 3d b9  20 8b 20 6c 65 66 74 3d  | right=. . left=|
00001f30  b9 0d 07 ee 2a 20 e7 20  73 65 61 72 63 68 69 6e  |....* . searchin|
00001f40  67 3d 35 20 8c 20 74 65  6e 64 69 6e 67 3d 28 74  |g=5 . tending=(t|
00001f50  65 6e 64 69 6e 67 20 82  20 31 29 0d 07 f8 23 20  |ending . 1)...# |
00001f60  e7 20 73 65 61 72 63 68  69 6e 67 3e 35 30 20 8c  |. searching>50 .|
00001f70  20 73 74 61 67 65 3d 73  74 61 67 65 2b 31 0d 08  | stage=stage+1..|
00001f80  02 06 20 e1 0d 08 0c 06  20 3a 0d 08 16 3c 20 f4  |.. ..... :...< .|
00001f90  20 46 69 6e 64 20 65 64  67 65 20 6f 66 20 6e 65  | Find edge of ne|
00001fa0  74 20 61 6e 64 20 61 69  6d 20 66 6f 72 20 69 74  |t and aim for it|
00001fb0  20 74 6f 20 6d 6f 76 65  20 74 6f 20 6f 74 68 65  | to move to othe|
00001fc0  72 20 73 69 64 65 0d 08  20 0e 20 dd f2 6d 6f 76  |r side.. . ..mov|
00001fd0  65 6f 75 74 0d 08 2a 23  20 f4 20 57 61 74 63 68  |eout..*# . Watch|
00001fe0  20 6f 75 74 20 69 66 20  74 6f 6f 20 6e 65 61 72  | out if too near|
00001ff0  20 74 6f 20 6e 65 74 0d  08 34 76 20 e7 20 28 66  | to net..4v . (f|
00002000  72 65 71 61 3c 33 30 20  84 20 66 72 65 71 62 3c  |reqa<30 . freqb<|
00002010  33 30 20 84 20 66 72 65  71 63 3c 33 30 29 20 84  |30 . freqc<30) .|
00002020  20 28 72 65 76 69 6e 67  3e 30 20 80 20 28 66 72  | (reving>0 . (fr|
00002030  65 71 61 3c 32 35 30 20  84 20 66 72 65 71 62 3c  |eqa<250 . freqb<|
00002040  32 35 30 20 84 20 66 72  65 71 63 3c 32 35 30 29  |250 . freqc<250)|
00002050  29 20 8c 20 72 65 76 69  6e 67 3d 35 3a 72 69 67  |) . reving=5:rig|
00002060  68 74 3d b9 3a 6c 65 66  74 3d a3 3a e1 0d 08 3e  |ht=.:left=.:...>|
00002070  3a 20 e7 20 72 65 76 69  6e 67 3e 30 20 8c 20 74  |: . reving>0 . t|
00002080  75 72 62 6f 3d b9 3a 6c  65 66 74 3d b9 3a 72 69  |urbo=.:left=.:ri|
00002090  67 68 74 3d b9 3a 72 65  76 69 6e 67 3d 72 65 76  |ght=.:reving=rev|
000020a0  69 6e 67 2d 31 3a e1 0d  08 48 2c 20 f4 20 41 6c  |ing-1:...H, . Al|
000020b0  69 67 6e 20 62 61 6c 6c  62 6f 74 20 74 6f 20 66  |ign ballbot to f|
000020c0  61 63 65 20 74 68 65 20  6e 65 74 20 70 6f 73 74  |ace the net post|
000020d0  2e 2e 2e 0d 08 52 24 20  e7 20 66 61 24 3d 22 4e  |.....R$ . fa$="N|
000020e0  22 20 84 20 66 61 24 3d  22 50 22 20 8c 20 72 69  |" . fa$="P" . ri|
000020f0  67 68 74 3d b9 3a e1 0d  08 5c 2d 20 e7 20 66 62  |ght=.:...\- . fb|
00002100  24 3c 3e 22 4e 22 20 80  20 66 62 24 3c 3e 22 50  |$<>"N" . fb$<>"P|
00002110  22 20 8c 20 6c 65 66 74  3d b9 3a 73 74 65 65 72  |" . left=.:steer|
00002120  3d 36 3a e1 0d 08 66 3b  20 e7 20 66 62 24 3d 22  |=6:...f; . fb$="|
00002130  50 22 20 80 20 66 72 65  71 62 3c 31 30 30 20 80  |P" . freqb<100 .|
00002140  20 66 61 24 3c 3e 22 50  22 20 80 20 66 61 24 3c  | fa$<>"P" . fa$<|
00002150  3e 22 4e 22 20 8c 20 6e  65 61 72 3d 31 3a e1 0d  |>"N" . near=1:..|
00002160  08 70 27 20 e7 20 73 74  65 65 72 3e 30 20 8c 20  |.p' . steer>0 . |
00002170  73 74 65 65 72 3d 73 74  65 65 72 2d 31 3a 6c 65  |steer=steer-1:le|
00002180  66 74 3d b9 3a e1 0d 08  7a 1b 20 74 75 72 62 6f  |ft=.:...z. turbo|
00002190  3d b9 3a 6c 65 66 74 3d  b9 3a 72 69 67 68 74 3d  |=.:left=.:right=|
000021a0  b9 0d 08 84 06 20 e1 0d  08 8e 06 20 3a 0d 08 98  |..... ..... :...|
000021b0  47 20 f4 20 4e 65 61 72  6c 79 20 74 68 65 72 65  |G . Nearly there|
000021c0  2e 2e 2e 20 4a 75 73 74  20 6e 65 65 64 20 61 20  |... Just need a |
000021d0  6c 69 74 74 6c 65 20 6e  75 64 67 65 20 69 6e 20  |little nudge in |
000021e0  74 68 65 20 72 69 67 68  74 20 64 69 72 65 63 74  |the right direct|
000021f0  69 6f 6e 2e 0d 08 a2 12  20 dd f2 64 6f 6e 65 61  |ion..... ..donea|
00002200  72 73 74 75 66 66 0d 08  ac 23 20 f4 20 57 61 74  |rstuff...# . Wat|
00002210  63 68 20 6f 75 74 20 69  66 20 74 6f 6f 20 6e 65  |ch out if too ne|
00002220  61 72 20 74 6f 20 6e 65  74 0d 08 b6 32 20 e7 20  |ar to net...2 . |
00002230  6e 65 61 72 3c 36 20 8c  20 72 69 67 68 74 3d b9  |near<6 . right=.|
00002240  3a 6c 65 66 74 3d a3 3a  6e 65 61 72 3d 6e 65 61  |:left=.:near=nea|
00002250  72 2d 28 66 61 24 3d 22  55 22 29 0d 08 c0 35 20  |r-(fa$="U")...5 |
00002260  e7 20 6e 65 61 72 3c 31  30 20 8c 20 6c 65 66 74  |. near<10 . left|
00002270  3d b9 3a 74 75 72 62 6f  3d b9 3a 72 69 67 68 74  |=.:turbo=.:right|
00002280  3d b9 3a 6e 65 61 72 3d  6e 65 61 72 2b 31 3a e1  |=.:near=near+1:.|
00002290  0d 08 ca 35 20 e7 20 6e  65 61 72 3c 31 35 20 8c  |...5 . near<15 .|
000022a0  20 6c 65 66 74 3d b9 3a  74 75 72 62 6f 3d b9 3a  | left=.:turbo=.:|
000022b0  72 69 67 68 74 3d a3 3a  6e 65 61 72 3d 6e 65 61  |right=.:near=nea|
000022c0  72 2b 31 3a e1 0d 08 d4  27 20 6c 65 66 74 3d b9  |r+1:....' left=.|
000022d0  3a 74 75 72 62 6f 3d b9  3a 72 69 67 68 74 3d b9  |:turbo=.:right=.|
000022e0  3a 6e 65 61 72 3d 6e 65  61 72 2b 31 0d 08 de 3b  |:near=near+1...;|
000022f0  20 e7 20 6e 65 61 72 3e  31 38 20 8c 20 6e 65 61  | . near>18 . nea|
00002300  72 3d 30 3a 73 74 61 67  65 3d 73 74 61 67 65 2b  |r=0:stage=stage+|
00002310  31 3a 73 65 61 72 63 68  69 6e 67 3d 30 3a 74 65  |1:searching=0:te|
00002320  6e 64 69 6e 67 3d 31 0d  08 e8 06 20 e1 0d 08 f2  |nding=1.... ....|
00002330  06 20 3a 0d 08 fc 3d 20  f4 20 49 6e 69 74 69 61  |. :...= . Initia|
00002340  6c 69 73 65 20 42 61 6c  6c 42 6f 74 20 76 61 72  |lise BallBot var|
00002350  69 61 62 6c 65 73 20 61  74 20 74 68 65 20 62 65  |iables at the be|
00002360  67 69 6e 6e 69 6e 67 20  6f 66 20 61 20 72 75 6e  |ginning of a run|
00002370  0d 09 06 0e 20 dd f2 73  65 74 75 70 62 62 0d 09  |.... ..setupbb..|
00002380  10 2f 20 72 65 76 69 6e  67 3d a3 3a 6c 65 66 74  |./ reving=.:left|
00002390  3d a3 3a 72 69 67 68 74  3d a3 3a 73 65 61 72 63  |=.:right=.:searc|
000023a0  68 69 6e 67 3d 30 3a 69  64 6c 65 3d b9 0d 09 1a  |hing=0:idle=....|
000023b0  1d 20 6e 65 61 72 3d a3  3a 74 65 6e 64 69 6e 67  |. near=.:tending|
000023c0  3d 31 3a 73 74 65 65 72  3d 30 0d 09 24 06 20 e1  |=1:steer=0..$. .|
000023d0  0d 09 2e 06 20 3a 0d 09  38 0f 20 dd f2 72 65 6c  |.... :..8. ..rel|
000023e0  65 61 73 65 62 0d 09 42  2d 20 f4 20 47 6f 74 20  |easeb..B- . Got |
000023f0  61 6c 6c 20 74 68 65 20  62 61 6c 6c 73 2c 20 6e  |all the balls, n|
00002400  6f 77 20 6a 75 73 74 20  64 75 6d 70 20 74 68 65  |ow just dump the|
00002410  6d 21 0d 09 4c 10 20 6e  65 61 72 3d 6e 65 61 72  |m!..L. near=near|
00002420  2b 31 0d 09 56 1d 20 e7  20 6e 65 61 72 3e 39 20  |+1..V. . near>9 |
00002430  8c 20 69 64 6c 65 3d b9  3a 6e 65 61 72 3d a3 0d  |. idle=.:near=..|
00002440  09 60 06 20 e1 0d ff                              |.`. ...|
00002447
BioBot/BBMotor.m0
BioBot/BBMotor.m1
BioBot/BBMotor.m2
BioBot/BBMotor.m4
BioBot/BBMotor.m5

© Dominic Ford 2021–2024.

Our privacy policy is here.
Last updated: 28 Jul 2024, 23:31 UTC
Website designed by .
