P/ADEXsrc

This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.

Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.

Tape/disk:	Home » Personal collection » Acorn ADFS disks » Electron_User_Group » EUG_27.ADF
Filename:	P/ADEXsrc
Read OK:	✔
File size:	1FD6 bytes
Load address:	FFFF0E00
Exec address:	FFFF802B

Duplicates

There is 1 duplicate copy of this file in the archive:

AEW website » eug » eug_5_25_discs_Eug-27_D-EUG27.dsd » U.ADEXSrc
Personal collection » Acorn ADFS disks » Electron_User_Group » EUG_27.ADF » P/ADEXsrc

File contents

   10REM ****************************
   20REM ADFS Exposed
   30REM Original BASIC program from
   40REM Electron User, November 1987
   50REM M/coded by Richard Dimond
   60REM (c) July 1996
   70REM ****************************
   80REM
   90DIM Q% &1000
  100PROCass
  110OSCLI"SAVE ADFSEX "+STR$~Q%+" "+STR$~O%+" 2000 2000"
  120END
  130DEFPROCass
  140os=&FFEE:osb=&FFF4:osw=&FFF1
  150addr=&70:plot=&74:X=&7A:Y=&7C:C1=&7E:C2=&7F
  160hex=&80:work=&82:decimal=&84
  170dad=&82:dsp=&84:T=&86:S=&88:count=&8A:diff=&8E:trkno=&8F
  180W%=&2D00:X%=W%+&100
  190FORI%=4TO6STEP2
  200P%=&2000:O%=Q%
  210[OPTI%
  220.start
  230LDA#15:LDX#d1 MOD256:LDY#d1 DIV256:JSRp
  240LDX#title MOD256:LDY#title DIV256:JSRdh
  250LDA#47:LDX#d2 MOD256:LDY#d2 DIV256:JSRp
  260.pause JSR&FFE0
  270BCCnoesc:RTS:.noesc
  280CMP#13:BNEpause
  290JSRreaddisc
  300LDA#16:LDX#d3 MOD256:LDY#d3 DIV256:JSRp
  310JSRvars
  320JSRgrid
  330JSRinfo
  340JSRkey
  350JSRfsmap
  360JSRcat
  370JSRfdfsecs
  380LDA#45:LDX#run MOD256:LDY#run DIV256:JSRp
  390JSR&FFE0
  400AND#&DF:CMP#82:BEQst
  410LDA#22:JSRos:LDA#6:JSRos
  420RTS
  430.st LDA#21:JSRosb:JMPstart
  440.p STXaddr:STYaddr+1:TAX:LDY#0
  450.lp LDA(addr),Y:JSRos:INY:DEX:BNElp:RTS
  460.dh STXaddr:STYaddr+1:LDY#0
  470.dlop LDA(addr),Y:STYcount:CMP#&0D:BNEcont:RTS:.cont STA&56:LDA#10:LDX#&56:LDY#0:JSRosw
  480LDA#23:JSRos:LDA#255:JSRos
  490LDA&57:JSRos:JSRos
  500LDA&58:JSRos:JSRos
  510LDA&59:JSRos:JSRos
  520LDA&5A:JSRos:JSRos
  530LDA#255:JSRos:LDA#8:JSRos:LDA#10:JSRos
  540LDA#23:JSRos:LDA#255:JSRos
  550LDA&5B:JSRos:JSRos
  560LDA&5C:JSRos:JSRos
  570LDA&5D:JSRos:JSRos
  580LDA&5E:JSRos:JSRos
  590LDA#255:JSRos:LDA#11:JSRos
  600LDYcount:INY:JMPdlop
  610.readdisc
  620LDX#comm MOD256:LDY#comm DIV256:JSR&FFF7
  630LDA#&72:LDX#blk MOD256:LDY#blk DIV256
  640JMPosw
  650 .prtdec   \ reset
  660 LDA #0
  670 STA decimal+0:STA decimal+1
  680 STA decimal+2:STA decimal+3
  690 STA decimal+4:STA decimal+5
  700 .convert
  710 LDA #0
  720 STA work:STA work+1
  730 CLC:LDX #16
  740 .loop
  750 ROL hex:ROL hex+1
  760 ROL work:ROL work+1
  770 SEC:LDA work
  780 SBC #10:TAY
  790 LDA work+1
  800 SBC #0:BCC less
  810 STY work:STA work+1
  820 .less
  830 DEX:BNE loop
  840 ROL hex:ROL hex+1
  850 CLC:LDA work
  860 ADC #48
  870 JSR concatenate
  880 LDA hex:ORA hex+1
  890 BNE convert
  900 LDX decimal
  910 LDY #1
  920 .print
  930 LDA decimal,Y
  940 JSR os
  950 INY:DEX
  960 BNE print
  970 RTS
  980 .concatenate
  990 PHA:LDY decimal
 1000 BEQ zero
 1010 .move
 1020 LDA decimal,Y
 1030 STA decimal+1,Y
 1040 DEY:BNE move
 1050 .zero
 1060 PLA
 1070 STA decimal+1
 1080 INC decimal
 1090 RTS
 1100.vars
 1110LDY#&FE:LDA X%,Y:STAsize
 1120LDY#&FC:LDA W%,Y:STAsectors
 1130INY:LDA W%,Y:STAsectors+1
 1140LDAsectors:STAtracks
 1150LDAsectors+1:STAtracks+1
 1160LSRtracks+1:RORtracks
 1170LSRtracks+1:RORtracks
 1180LSRtracks+1:RORtracks
 1190LSRtracks+1:RORtracks
 1200LDAtracks:CMP#160:BNEone
 1210LDA#2:JMPtwo
 1220.one LDA#1:.two STAsides
 1230LDAsectors:STAdiscsize+1
 1240LDAsectors+1:STAdiscsize+2
 1250LDAsides:CMP#1:BNEdd:LDA#224:JMPch:.dd:LDA#192:.ch TAX:LDA#23:JSRos:LDA#224:JSRos:TXA:LDX#8:.ll JSRos:DEX:BNEll
 1260RTS
 1270.plotpt
 1280LDA#25:JSRos
 1290LDA#5:LDX#plot MOD256:LDY#plot DIV256:JMPp
 1300.grid
 1310LDA#20:LDX#d4 MOD256:LDY#d4 DIV256:JSRp
 1320.g LDA#80:STAcount:LDA#0:STAplot+1:STAplot+2:STAplot+3:STAplot+4
 1330.vlp
 1340LDA#4:STAplot:LDA#1:STAplot+4
 1350JSRplotpt
 1360LDA#29:STAplot:LDA#3:STAplot+4
 1370JSRplotpt
 1380CLC:LDAplot+1:ADC#16:STAplot+1
 1390LDAplot+2:ADC#0:STAplot+2
 1400DECcount:BNEvlp
 1410LDA#16:STAcount:LDA#0:STAplot+3:LDA#1:STAplot+4
 1420.vlp1
 1430LDA#4:STAplot:LDA#0:STAplot+1:STAplot+2
 1440JSRplotpt
 1450LDA#29:STAplot:LDA#5:STAplot+2
 1460JSRplotpt
 1470CLC:LDAplot+3:ADC#32:STAplot+3
 1480LDAplot+4:ADC#0:STAplot+4
 1490DECcount:BNEvlp1
 1500LDA#8:STAcount:LDA#4:STAplot+1:LDA#0:STAplot+2:STAhex:STAhex+1:STAtrkno
 1510LDAsides:CMP#2:BNEnd:LDA#20:STAdiff:JMPd:.nd LDA#10:STAdiff:.d
 1520.vlp2 LDA#4:STAplot:LDA#0:STAplot+3:LDA#3:STAplot+4
 1530JSRplotpt
 1540LDA#5:STAplot:LDA#32:STAplot+3
 1550JSRplotpt
 1560LDA#5:JSRos
 1570LDAtrkno:BNEnz:LDA#4:STAplot:STAplot+1:LDA#64:STAplot+3
 1580JSRplotpt
 1590LDA#48:JSRos
 1600.nz SEC:LDAplot+1:SBC#32:STAplot+1
 1610LDAplot+2:SBC#0:STAplot+2
 1620LDA#4:STAplot:LDA#64:STAplot+3
 1630JSRplotpt
 1640LDAtrkno:CMPtracks:BCSnp:JSRprtdec:.np
 1650CLC:LDAtrkno:ADCdiff:STAtrkno:STAhex
 1660.fin CLC:LDAplot+1:ADC#192:STAplot+1
 1670LDAplot+2:ADC#0:STAplot+2
 1680DECcount:BEQrts:JMPvlp2
 1690.rts LDA#4:JSRos:RTS
 1700.info
 1710LDA#43:LDX#tks MOD256:LDY#tks DIV256:JSRp
 1720LDA#10:LDX#tk MOD256:LDY#tk DIV256:JSRp
 1730LDAtracks:STAhex:LDAtracks+1:STAhex+1:JSRprtdec
 1740LDA#11:LDX#secs MOD256:LDY#secs DIV256:JSRp
 1750LDAsectors:STAhex:LDAsectors+1:STAhex+1:JSRprtdec
 1760LDA#9:LDX#sds MOD256:LDY#sds DIV256:JSRp
 1770LDAsides:STAhex:LDAsides+1:STAhex+1:JSRprtdec
 1780RTS
 1790.key
 1800LDA#32:STA X:LDA#0:STA X+1:STA Y:STA Y+1:LDA#1:STA C1:LDA#3:STA C2:JSRsqr
 1810LDA#18:LDX#sused MOD256:LDY#sused DIV256:JSRp
 1820LDA#32:STA X:LDA#100:STA Y:LDA#0:STA C1:LDA#2:STA C2:JSRsqr
 1830LDA#17:LDX#sfree MOD256:LDY#sfree DIV256:JSRp
 1840LDA#78:STA X:LDA#2:STA X+1:LDA#2:STA C1:LDA#0:STA C2:JSRsqr
 1850LDA#17:LDX#root MOD256:LDY#root DIV256:JSRp
 1860LDA#0:STA Y:LDA#3:STA C1:LDA#1:STA C2:JSRsqr
 1870LDA#17:LDX#map MOD256:LDY#map DIV256:JSRp
 1880RTS
 1890.sqr
 1900LDA#18:JSRos:LDA#0:JSRos:LDA C1:JSRos
 1910LDA#4:STAplot:LDA X:STAplot+1:LDA X+1:STAplot+2:LDA Y:STAplot+3:LDA Y+1:STAplot+4
 1920JSRplotpt
 1930CLC:LDAplot+3:ADC#38:STAplot+3
 1940LDAplot+4:ADC#0:STAplot+4
 1950JSRplotpt
 1960LDA#85:STAplot:LDA Y:STAplot+3:LDA Y+1:STAplot+4
 1970CLC:LDAplot+1:ADC#30:STAplot+1
 1980LDAplot+2:ADC#0:STAplot+2
 1990JSRplotpt
 2000LDA#4:STAplot
 2010CLC:LDAplot+3:ADC#38:STAplot+3
 2020LDAplot+4:ADC#0:STAplot+4
 2030JSRplotpt
 2040LDA#85:STAplot
 2050LDA X:STAplot+1:LDA X+1:STAplot+2
 2060JSRplotpt
 2070LDA#18:JSRos:LDA#0:JSRos:LDA C2:JSRos
 2080LDA#4:STAplot:LDA X:STAplot+1:LDA X+1:STAplot+2:LDA Y:STAplot+3:LDA Y+1:STAplot+4
 2090JSRplotpt
 2100LDA#29:STAplot
 2110CLC:LDAplot+1:ADC#30:STAplot+1
 2120LDAplot+2:ADC#0:STAplot+2
 2130JSRplotpt
 2140CLC:LDAplot+3:ADC#38:STAplot+3
 2150LDAplot+4:ADC#0:STAplot+4
 2160JSRplotpt
 2170LDA X:STAplot+1:LDA X+1:STAplot+2
 2180JSRplotpt
 2190LDA Y:STAplot+3:LDA Y+1:STAplot+4
 2200JSRplotpt
 2210RTS
 2220.sfreesecs
 2230LDA#5:JSRos
 2240CLC:LDAdsp:ADCdad:STAdsp
 2250LDAdsp+1:ADCdad+1:STAdsp+1
 2260.fslp LDAdad:STA T
 2270LDAdad+1:STA T+1
 2280LDX#4:.dlp LSR T+1:ROR T:ROR S:DEX:BNEdlp
 2290LDX#4:.dlp2 LSR S:DEX:BNEdlp2
 2300LDAsides:CMP#2:BEQds:LDX#4:JMPmul:.ds LDX#3
 2310.mul ASL T:ROL T+1:DEX:BNEmul
 2320LDA T:STA X:LDA T+1:STA X+1
 2330LDA#0:STA S+1
 2340LDX#5:.slp ASL S:ROL S+1:DEX:BNEslp
 2350SEC:LDA#0:SBC S:STA Y
 2360LDA#3:SBC S+1:STA Y+1
 2370LDA#4:STAplot:LDA X:STAplot+1:LDA X+1:STAplot+2:LDA Y:STAplot+3:LDA Y+1:STAplot+4
 2380JSRplotpt
 2390LDA#224:JSRos
 2400CLC:LDAdad:ADC#1:STAdad
 2410LDAdad+1:ADC#0:STAdad+1
 2420LDAdad:CMPdsp:BEQc:JMPfslp
 2430.c LDAdad+1:CMPdsp+1:BEQcon:JMPfslp:.con
 2440.rts1 LDA#4:JSRos:RTS
 2450.fsmap
 2460LDA#0:STAdad:STAdad+1
 2470LDA#2:STAdsp:LDA#0:STAdsp+1
 2480LDA#18:JSRos:LDA#3:JSRos:LDA#2:JSRos
 2490JSRsfreesecs
 2500RTS
 2510.cat
 2520LDA#2:STAdad:LDA#0:STAdad+1
 2530LDA#5:STAdsp:LDA#0:STAdsp+1
 2540LDA#18:JSRos:LDA#3:JSRos:LDA#3:JSRos
 2550JSRsfreesecs
 2560RTS
 2570.fdfsecs
 2580LDA#18:JSRos:LDA#3:JSRos:LDA#1:JSRos
 2590LDY#0:STYcount
 2600.sflp
 2610LDYcount
 2620LDA W%,Y:STAdad
 2630LDA X%,Y:STAdsp
 2640INY
 2650LDA W%,Y:STAdad+1
 2660LDA X%,Y:STAdsp+1
 2670INY:INY:STYcount
 2680JSRsfreesecs
 2690LDAsize:CMPcount:BEQend
 2700JMPsflp
 2710.end RTS
 2720:
 2730RTS
 2740.d1 EQUB22:EQUB1:EQUB31:EQUB10:EQUB1:EQUB23:EQUB1:EQUD0:EQUD0
 2750.title EQUS"ADFS Free Space Map"+CHR$13
 2760.d2 EQUB31:EQUB0:EQUB9
 2770EQUS"Please insert disc"
 2780EQUB31:EQUB0:EQUB11
 2790EQUS"Press RETURN when ready"
 2800.blk EQUB0:EQUW W%:EQUW&FFFF:EQUW8:EQUW0:EQUW2
 2810.comm EQUS"*MOUNT"+CHR$13
 2820.d3 EQUB19:EQUB2:EQUB4:EQUB0:EQUW0:EQUB23:EQUB1:EQUD0:EQUD0
 2830.size EQUW0:.sectors EQUW0:.tracks EQUW0:.sides EQUW0:.discsize EQUD0
 2840.d4 EQUB18:EQUB0:EQUB129:EQUB24:EQUW0:EQUW256:EQUW1276:EQUW768:EQUB16:EQUB26:EQUB18:EQUB0:EQUB128:EQUB18:EQUB0:EQUB3
 2850.tks EQUB31:EQUB0:EQUB4:EQUS"<"+STRING$(15,"-")+" Tracks "+STRING$(15,"-")+">"
 2860.tk  EQUB31:EQUB0:EQUB25:EQUS"Tracks:":.secs EQUB31:EQUB14:EQUB25:EQUS"Sectors:":.sds EQUB31:EQUB32:EQUB25:EQUS"Sides:"
 2870.run EQUB17:EQUB1:EQUB31:EQUB4:EQUB27:EQUS "Press R to RUN   SPACE to Exit":EQUB23:EQUB1:EQUD0:EQUD0
 2880.sused EQUB31:EQUB3:EQUB31:EQUS"Sectors in use "
 2890.sfree EQUB31:EQUB3:EQUB28:EQUS"Free sector(s) "
 2900.root EQUB31:EQUB22:EQUB28:EQUS"Root directory"
 2910.map EQUB31:EQUB22:EQUB31:EQUS"Free space map"
 2920]
 2930NEXT:ENDPROC


"� ****************************
