The routine 'sfreesecs' is rather complex for calculating the values of T and S for the co-ords X and Y in order to print the character number 224. Line 2220 gives the command VDU5 to join the cursors. Next the disc space (dsp) is added to the disc address (dad) and stored in 'dsp' to give the end address. The disc address is stored in T, the bits then shifted right four times to to divide by 16. The four low bits of T are rotated into S. These are then shifted four times to the right so that S has the value of T MOD 16. The bits in T are then shifted left three or four times to multiply by 8 or 16 depending on the value of sides to give the X co-ord. The value of S is multiplied by 32 by shifting left 5 times and then this value is subtracted from 768 (&300) to give the value of the Yco-ord. The routine 'plotpt' is then used to set the print postion for the character 224 and then it is printed. The disc address is then increased and compared with the end address and if not equal the progran returns to calculate for the next sector. When the end address has been reached and comparison is equal, the cursors are returned to normal by the command VDU4 and the routine ends. The fs map is shown by the next routine lines 2450 - 2500 by loading 'dad' with zero and 'dsp' with two and changing the colour to white. The root directory is shown ina similar way with routine 'cat'. The routine 'fdfsecs' (lines 2570 - 2710) first sets the colour with VDU18,3,1 and sets the index Y to zero and stores this in 'count'. In the loop 'sflp' the index value in 'count' is loaded into Y register so that the disc address info is read from W%,Y and the disc space info from X%,Y. Each time that this is done, the routine to print the free sectors is called and when the value of count equals that of size, the routine ends. The program then returns to print the final cue at line 380 and pauses at line 390. If the key R is pressed (the AND#&DF gives the same value if the lower case r is uesd) the program goes to 'st', this gives the command *FX21 to clear the buffers before a jump is made to 'start'. If any other key is pressed, MODE 6 is selected and the program returns to BASIC. **************************************************************************
00000000 0d 54 68 65 1a 20 72 6f 75 74 69 6e 65 20 27 73 |.The. routine 's| 00000010 66 72 65 65 73 65 63 73 27 20 69 73 20 72 61 74 |freesecs' is rat| 00000020 68 65 72 20 63 6f 6d 70 6c 65 78 20 66 6f 72 20 |her complex for | 00000030 63 61 6c 63 75 6c 61 74 69 6e 67 20 74 68 65 20 |calculating the | 00000040 76 61 6c 75 65 73 20 6f 66 20 54 0d 61 6e 64 20 |values of T.and | 00000050 53 1a 20 66 6f 72 20 74 68 65 20 63 6f 2d 6f 72 |S. for the co-or| 00000060 64 73 20 58 20 61 6e 64 20 59 20 69 6e 20 6f 72 |ds X and Y in or| 00000070 64 65 72 20 74 6f 20 70 72 69 6e 74 20 74 68 65 |der to print the| 00000080 20 63 68 61 72 61 63 74 65 72 20 6e 75 6d 62 65 | character numbe| 00000090 72 20 32 32 34 2e 20 0d 4c 69 6e 65 20 32 32 32 |r 224. .Line 222| 000000a0 30 20 67 69 76 65 73 20 74 68 65 20 63 6f 6d 6d |0 gives the comm| 000000b0 61 6e 64 20 56 44 55 35 20 74 6f 20 6a 6f 69 6e |and VDU5 to join| 000000c0 20 74 68 65 20 63 75 72 73 6f 72 73 2e 20 20 4e | the cursors. N| 000000d0 65 78 74 20 74 68 65 20 64 69 73 63 20 73 70 61 |ext the disc spa| 000000e0 63 65 0d 28 64 73 70 29 20 69 73 20 61 64 64 65 |ce.(dsp) is adde| 000000f0 64 1a 20 74 6f 1a 20 74 68 65 20 64 69 73 63 20 |d. to. the disc | 00000100 61 64 64 72 65 73 73 20 28 64 61 64 29 20 61 6e |address (dad) an| 00000110 64 20 73 74 6f 72 65 64 20 69 6e 20 27 64 73 70 |d stored in 'dsp| 00000120 27 20 74 6f 20 67 69 76 65 20 74 68 65 0d 65 6e |' to give the.en| 00000130 64 20 61 64 64 72 65 73 73 2e 20 20 0d 0d 54 68 |d address. ..Th| 00000140 65 20 64 69 73 63 20 61 64 64 72 65 73 73 20 69 |e disc address i| 00000150 73 20 73 74 6f 72 65 64 20 69 6e 20 54 2c 20 74 |s stored in T, t| 00000160 68 65 20 62 69 74 73 20 74 68 65 6e 20 73 68 69 |he bits then shi| 00000170 66 74 65 64 20 72 69 67 68 74 20 66 6f 75 72 20 |fted right four | 00000180 74 69 6d 65 73 20 74 6f 0d 74 6f 20 64 69 76 69 |times to.to divi| 00000190 64 65 20 62 79 20 31 36 2e 20 20 54 68 65 1a 20 |de by 16. The. | 000001a0 66 6f 75 72 1a 20 6c 6f 77 1a 20 62 69 74 73 20 |four. low. bits | 000001b0 6f 66 20 54 20 61 72 65 20 72 6f 74 61 74 65 64 |of T are rotated| 000001c0 20 69 6e 74 6f 20 53 2e 20 20 54 68 65 73 65 20 | into S. These | 000001d0 61 72 65 0d 74 68 65 6e 20 73 68 69 66 74 65 64 |are.then shifted| 000001e0 20 66 6f 75 72 20 74 69 6d 65 73 20 74 6f 20 74 | four times to t| 000001f0 68 65 20 72 69 67 68 74 20 73 6f 20 74 68 61 74 |he right so that| 00000200 20 53 20 68 61 73 20 74 68 65 20 76 61 6c 75 65 | S has the value| 00000210 20 6f 66 20 54 20 4d 4f 44 20 31 36 2e 0d 0d 54 | of T MOD 16...T| 00000220 68 65 20 62 69 74 73 1a 20 69 6e 1a 20 54 20 61 |he bits. in. T a| 00000230 72 65 20 74 68 65 6e 20 73 68 69 66 74 65 64 20 |re then shifted | 00000240 6c 65 66 74 20 74 68 72 65 65 20 6f 72 20 66 6f |left three or fo| 00000250 75 72 20 74 69 6d 65 73 20 74 6f 20 6d 75 6c 74 |ur times to mult| 00000260 69 70 6c 79 20 62 79 20 38 0d 6f 72 20 31 36 20 |iply by 8.or 16 | 00000270 64 65 70 65 6e 64 69 6e 67 20 6f 6e 1a 20 74 68 |depending on. th| 00000280 65 20 76 61 6c 75 65 20 6f 66 20 73 69 64 65 73 |e value of sides| 00000290 20 74 6f 20 67 69 76 65 20 74 68 65 20 58 20 63 | to give the X c| 000002a0 6f 2d 6f 72 64 2e 20 20 54 68 65 20 76 61 6c 75 |o-ord. The valu| 000002b0 65 20 6f 66 0d 53 20 69 73 20 6d 75 6c 74 69 70 |e of.S is multip| 000002c0 6c 69 65 64 20 62 79 20 33 32 1a 20 62 79 1a 20 |lied by 32. by. | 000002d0 73 68 69 66 74 69 6e 67 1a 20 6c 65 66 74 1a 20 |shifting. left. | 000002e0 35 1a 20 74 69 6d 65 73 20 61 6e 64 20 74 68 65 |5. times and the| 000002f0 6e 20 74 68 69 73 20 76 61 6c 75 65 20 69 73 0d |n this value is.| 00000300 73 75 62 74 72 61 63 74 65 64 20 66 72 6f 6d 20 |subtracted from | 00000310 37 36 38 20 28 26 33 30 30 29 20 74 6f 20 67 69 |768 (&300) to gi| 00000320 76 65 20 74 68 65 20 76 61 6c 75 65 20 6f 66 20 |ve the value of | 00000330 74 68 65 1a 20 59 63 6f 2d 6f 72 64 2e 20 20 54 |the. Yco-ord. T| 00000340 68 65 20 72 6f 75 74 69 6e 65 0d 27 70 6c 6f 74 |he routine.'plot| 00000350 70 74 27 20 69 73 20 74 68 65 6e 20 75 73 65 64 |pt' is then used| 00000360 20 74 6f 20 73 65 74 20 74 68 65 20 70 72 69 6e | to set the prin| 00000370 74 20 70 6f 73 74 69 6f 6e 20 66 6f 72 20 74 68 |t postion for th| 00000380 65 1a 20 63 68 61 72 61 63 74 65 72 1a 20 32 32 |e. character. 22| 00000390 34 20 61 6e 64 0d 74 68 65 6e 1a 20 69 74 20 69 |4 and.then. it i| 000003a0 73 20 70 72 69 6e 74 65 64 2e 20 20 0d 0d 54 68 |s printed. ..Th| 000003b0 65 20 64 69 73 63 20 61 64 64 72 65 73 73 20 69 |e disc address i| 000003c0 73 20 74 68 65 6e 1a 20 69 6e 63 72 65 61 73 65 |s then. increase| 000003d0 64 1a 20 61 6e 64 20 63 6f 6d 70 61 72 65 64 20 |d. and compared | 000003e0 77 69 74 68 20 74 68 65 20 65 6e 64 20 61 64 64 |with the end add| 000003f0 72 65 73 73 20 61 6e 64 0d 69 66 20 6e 6f 74 20 |ress and.if not | 00000400 65 71 75 61 6c 20 74 68 65 20 70 72 6f 67 72 61 |equal the progra| 00000410 6e 20 72 65 74 75 72 6e 73 20 74 6f 1a 20 63 61 |n returns to. ca| 00000420 6c 63 75 6c 61 74 65 1a 20 66 6f 72 20 74 68 65 |lculate. for the| 00000430 20 6e 65 78 74 20 73 65 63 74 6f 72 2e 20 20 57 | next sector. W| 00000440 68 65 6e 0d 74 68 65 20 65 6e 64 20 61 64 64 72 |hen.the end addr| 00000450 65 73 73 20 68 61 73 20 62 65 65 6e 20 72 65 61 |ess has been rea| 00000460 63 68 65 64 20 61 6e 64 20 63 6f 6d 70 61 72 69 |ched and compari| 00000470 73 6f 6e 20 69 73 1a 20 65 71 75 61 6c 2c 20 74 |son is. equal, t| 00000480 68 65 20 63 75 72 73 6f 72 73 20 61 72 65 0d 72 |he cursors are.r| 00000490 65 74 75 72 6e 65 64 20 74 6f 20 6e 6f 72 6d 61 |eturned to norma| 000004a0 6c 20 62 79 20 74 68 65 20 63 6f 6d 6d 61 6e 64 |l by the command| 000004b0 20 56 44 55 34 20 61 6e 64 20 74 68 65 20 72 6f | VDU4 and the ro| 000004c0 75 74 69 6e 65 20 65 6e 64 73 2e 0d 0d 54 68 65 |utine ends...The| 000004d0 20 66 73 20 6d 61 70 20 69 73 20 73 68 6f 77 6e | fs map is shown| 000004e0 20 62 79 20 74 68 65 20 6e 65 78 74 20 72 6f 75 | by the next rou| 000004f0 74 69 6e 65 20 6c 69 6e 65 73 20 32 34 35 30 20 |tine lines 2450 | 00000500 2d 20 32 35 30 30 20 62 79 20 6c 6f 61 64 69 6e |- 2500 by loadin| 00000510 67 20 27 64 61 64 27 0d 77 69 74 68 20 7a 65 72 |g 'dad'.with zer| 00000520 6f 20 61 6e 64 20 27 64 73 70 27 20 77 69 74 68 |o and 'dsp' with| 00000530 20 74 77 6f 20 61 6e 64 20 63 68 61 6e 67 69 6e | two and changin| 00000540 67 20 74 68 65 20 63 6f 6c 6f 75 72 20 74 6f 20 |g the colour to | 00000550 77 68 69 74 65 2e 0d 0d 54 68 65 20 72 6f 6f 74 |white...The root| 00000560 20 64 69 72 65 63 74 6f 72 79 20 69 73 20 73 68 | directory is sh| 00000570 6f 77 6e 20 69 6e 61 20 73 69 6d 69 6c 61 72 20 |own ina similar | 00000580 77 61 79 20 77 69 74 68 20 72 6f 75 74 69 6e 65 |way with routine| 00000590 20 27 63 61 74 27 2e 0d 0d 54 68 65 1a 20 72 6f | 'cat'...The. ro| 000005a0 75 74 69 6e 65 1a 20 27 66 64 66 73 65 63 73 27 |utine. 'fdfsecs'| 000005b0 1a 20 28 6c 69 6e 65 73 1a 20 32 35 37 30 1a 20 |. (lines. 2570. | 000005c0 2d 1a 20 32 37 31 30 29 20 66 69 72 73 74 20 73 |-. 2710) first s| 000005d0 65 74 73 20 74 68 65 20 63 6f 6c 6f 75 72 20 77 |ets the colour w| 000005e0 69 74 68 0d 56 44 55 31 38 2c 33 2c 31 20 61 6e |ith.VDU18,3,1 an| 000005f0 64 20 73 65 74 73 20 74 68 65 20 69 6e 64 65 78 |d sets the index| 00000600 20 59 20 74 6f 20 7a 65 72 6f 20 61 6e 64 20 73 | Y to zero and s| 00000610 74 6f 72 65 73 20 74 68 69 73 20 69 6e 20 27 63 |tores this in 'c| 00000620 6f 75 6e 74 27 2e 20 0d 0d 49 6e 20 74 68 65 20 |ount'. ..In the | 00000630 6c 6f 6f 70 20 27 73 66 6c 70 27 20 74 68 65 20 |loop 'sflp' the | 00000640 69 6e 64 65 78 20 76 61 6c 75 65 20 69 6e 20 27 |index value in '| 00000650 63 6f 75 6e 74 27 20 69 73 20 6c 6f 61 64 65 64 |count' is loaded| 00000660 20 69 6e 74 6f 20 59 20 72 65 67 69 73 74 65 72 | into Y register| 00000670 20 73 6f 0d 74 68 61 74 20 74 68 65 20 64 69 73 | so.that the dis| 00000680 63 20 61 64 64 72 65 73 73 20 69 6e 66 6f 20 69 |c address info i| 00000690 73 20 72 65 61 64 1a 20 66 72 6f 6d 20 57 25 2c |s read. from W%,| 000006a0 59 20 61 6e 64 20 74 68 65 20 64 69 73 63 20 73 |Y and the disc s| 000006b0 70 61 63 65 20 69 6e 66 6f 20 66 72 6f 6d 0d 58 |pace info from.X| 000006c0 25 2c 59 2e 20 20 45 61 63 68 20 74 69 6d 65 20 |%,Y. Each time | 000006d0 74 68 61 74 20 74 68 69 73 20 69 73 20 64 6f 6e |that this is don| 000006e0 65 2c 20 74 68 65 1a 20 72 6f 75 74 69 6e 65 20 |e, the. routine | 000006f0 74 6f 20 70 72 69 6e 74 20 74 68 65 20 66 72 65 |to print the fre| 00000700 65 20 73 65 63 74 6f 72 73 0d 69 73 20 63 61 6c |e sectors.is cal| 00000710 6c 65 64 20 61 6e 64 20 77 68 65 6e 20 74 68 65 |led and when the| 00000720 20 76 61 6c 75 65 20 6f 66 20 63 6f 75 6e 74 20 | value of count | 00000730 65 71 75 61 6c 73 20 74 68 61 74 1a 20 6f 66 1a |equals that. of.| 00000740 20 73 69 7a 65 2c 1a 20 74 68 65 1a 20 72 6f 75 | size,. the. rou| 00000750 74 69 6e 65 0d 65 6e 64 73 2e 0d 0d 54 68 65 20 |tine.ends...The | 00000760 70 72 6f 67 72 61 6d 20 74 68 65 6e 20 72 65 74 |program then ret| 00000770 75 72 6e 73 20 74 6f 20 70 72 69 6e 74 20 74 68 |urns to print th| 00000780 65 20 66 69 6e 61 6c 20 63 75 65 20 61 74 20 6c |e final cue at l| 00000790 69 6e 65 20 33 38 30 1a 20 61 6e 64 20 70 61 75 |ine 380. and pau| 000007a0 73 65 73 20 61 74 0d 6c 69 6e 65 1a 20 33 39 30 |ses at.line. 390| 000007b0 2e 20 20 49 66 20 74 68 65 20 6b 65 79 20 52 20 |. If the key R | 000007c0 69 73 20 70 72 65 73 73 65 64 20 28 74 68 65 20 |is pressed (the | 000007d0 41 4e 44 23 26 44 46 20 67 69 76 65 73 20 74 68 |AND#&DF gives th| 000007e0 65 20 73 61 6d 65 20 76 61 6c 75 65 1a 20 69 66 |e same value. if| 000007f0 0d 74 68 65 20 6c 6f 77 65 72 20 63 61 73 65 20 |.the lower case | 00000800 72 20 69 73 20 75 65 73 64 29 20 74 68 65 20 70 |r is uesd) the p| 00000810 72 6f 67 72 61 6d 20 67 6f 65 73 20 74 6f 20 27 |rogram goes to '| 00000820 73 74 27 2c 20 74 68 69 73 20 67 69 76 65 73 20 |st', this gives | 00000830 74 68 65 20 63 6f 6d 6d 61 6e 64 0d 2a 46 58 32 |the command.*FX2| 00000840 31 20 74 6f 20 63 6c 65 61 72 20 74 68 65 20 62 |1 to clear the b| 00000850 75 66 66 65 72 73 20 62 65 66 6f 72 65 20 61 20 |uffers before a | 00000860 6a 75 6d 70 20 69 73 20 6d 61 64 65 20 74 6f 20 |jump is made to | 00000870 27 73 74 61 72 74 27 2e 20 20 49 66 20 61 6e 79 |'start'. If any| 00000880 20 6f 74 68 65 72 0d 6b 65 79 20 69 73 20 70 72 | other.key is pr| 00000890 65 73 73 65 64 2c 20 4d 4f 44 45 20 36 20 69 73 |essed, MODE 6 is| 000008a0 20 73 65 6c 65 63 74 65 64 20 61 6e 64 20 74 68 | selected and th| 000008b0 65 20 70 72 6f 67 72 61 6d 20 72 65 74 75 72 6e |e program return| 000008c0 73 20 74 6f 20 42 41 53 49 43 2e 0d 0d 2a 2a 2a |s to BASIC...***| 000008d0 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a |****************| * 00000910 2a 2a 2a 2a 2a 2a 2a 0d 0d |*******..| 00000919
