MEGA BYTES ON A KILO BYTE MACHINE
*********************************
By D. Walker
************
My project for this summer was to attach a Winchester Drive (Hard Disc
(HD)) to my Electron. Over the last year or so I have been collecting
the hardware and software required and a couple of weeks ago I found
the last piece in the jigsaw.
The major components involved in the project were:
The Hard Disc Drive - I used a Maxtor 15 head/1023 cylinder drive with
a ST506 interface. The format used by ADFS is that each cylinder has
32 sectors each containing 256 bytes: 256 x 32 x 1023 x 15 =
125,706,240 bytes.
The Hard Disc Controller - I used a OMT5200 controller. This card
carries out all the disc housekeeping and has two interfaces - a SCSI
(Small Computer Systems Interface - pronounced skuzzy) and a ST412/506
interface. The block diagram shows how everything is linked together.
The Host Adaptor - This part I had to build myself. I had obtained a
copy of the Acorn Host Adaptor circuit diagram and had started to
build the circuit on Vero board but it turned out to great a task. I
eventually contacted a member of a BBC user group who helped me obtain
a circuit board, this made life a lot easier.
The 1MHz bus - I used the low cost bus from Pres, this had to be
modified by removing the data buffer chip and wiring through the NPGFC
signal from the cartridge slot connector to the 1Mhz bus connector.
Pres Plus 3 ADFS - I have Pres's Plus 3 cartridge disc interface which
uses their own version of Acorns ADFS - v1.10, this software doesn't
have the necessary patches to talk to the HD so I had to obtain a copy
of Acorns original Electron ADFS ROM v1.0. The AFDS ROM has to be
fitted to the highest priority socket available.
Extra cartridge slot - My plus 1 cartridge slots are full with the
Disc Interface and Slogger "Click" cartridge so I had to wire up a
third slot to the Plus 1 for the 1MHz bus. Luckily the 1MHz bus
doesn't involve any ROM decoding so it was a simple case of
paralleling up to one of the existing slots.
WARNING - The Acorn Plus 1 expansion ROM socket is wired for a MAXIMUM
ROM size of 8K - this is fine if you are using the original ROM or
Sloggers Expansion ROM but the Pres AP2 is a 16K ROM and fails to be
recognised in the Plus 1 - The modification to make the socket 16K is
fairly simple but involves a lot of soldering. The Socket has to be
removed, then the 5V tracks have to be cut on both sides of pin 26, a
wire link has to inserted to loop round the cut tracks at pin 26,
re-solder the socket in place and finally link address "A13" from the
underside of the cartridge slot to pin 26.
And lastly a Power supply - I used on old IBM supply. They come with
Page 1
built in off/on switch and all the connectors to connect to the drive,
the controller card and the host adaptor.
A heck of a lot of interfaces isn't it? but it isn't as complicated
as it sounds. Of course if you can pick up a BBC hard drive then all
that is needed is the 1MHz bus which would make life a bit easier.
The connecting together of all the interfaces is by the use ribbon
cable and press connectors (IDC) all available from Maplin
Electronics.
