Temperature module instructions =============================== Getting an digital value into your BBC to represent the temperature of some physical object is made simplicity itself by attaching a ready made board to your beeb. Before, the alternative approach would be to use the analogue port to read from a thermistor of similar device - but which would be hard to calibrate. This module allows temperature data to be shifted into the BBC as a background task,while you continue to use the machine for another purpose. This could be of use in (for example) a shop, where the BBC was used for stock taking while also monitoring (and saving...) the temperature of chillers for hygene reasons. Or monitoring the temperature of your greenhouse while typing a letter to your aunt! PARTS...The circuit diagrams shows electrically how to assemble the unit, requiring the following parts: 1x Ready build module (Maplin order code: FE33L9x ZTX300 NPN switching transistors 9x 10k pull up resistors 9x 1.2k base resistors In addition,it may be useful to have a handful of pins, a user port plug anda couple of feet of ribbon cable. BENEFITS...*Software selectable sample rate, mode,and hi/lo point *Runs off a single AA battery *Choice of Celcius or Fahrenheit *Seperate 'hi alarm point reached' and 'lo alarm point reached' pins BUILD...1.Join from the premade module to your board with a short length of 14 way ribbon cable, noting which wire is ground. 2.Attach the resistors and transistors from the output from the BBC user port to the control lines on the m odule.The 'REM' statements at the start of the software and the hints section below tell you which is which.Note PB7 was not needed. 3.Do the same again in the opposite manner for the data and clock inputs from the temperature module back into the BBC's interrup t lines,CB1 and CB2. 4.Ensure that both 0v lines on the BBC and temperature module are joined together. HINTS...*You might want to add a three small (1.5v) piezo buzzers to the alarm point pins,pin 6,7,and 15. Otherwise,just leave them unconnected. Ground is pin 1. * The software can easily be modified if you made a mistake wiring up the pins though I suggest: PB0 = show lo point => module pin 13 PB1 = show hi point => module pin 12 PB2 = celcius/fahrenheit => module pin 14 PB3 = sample rate select => module pin 5 PB4 = set hours => module pin 2 PB5 = set mins => module pin 3 PB6 = clock/temperature => module pin 11 CB1 = data => module pin 9 CB2 = data load clock => module pin 10 FROM...Robert Sprowson. Happy soldering!
00000000 0d 54 65 6d 70 65 72 61 74 75 72 65 20 6d 6f 64 |.Temperature mod| 00000010 75 6c 65 20 69 6e 73 74 72 75 63 74 69 6f 6e 73 |ule instructions| 00000020 0d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d |.===============| 00000030 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d |================| 00000040 0d 47 65 74 74 69 6e 67 20 61 6e 20 64 69 67 69 |.Getting an digi| 00000050 74 61 6c 20 76 61 6c 75 65 20 69 6e 74 6f 20 79 |tal value into y| 00000060 6f 75 72 20 42 42 43 20 74 6f 20 72 65 70 72 65 |our BBC to repre| 00000070 73 65 6e 74 20 74 68 65 20 74 65 6d 70 65 72 61 |sent the tempera| 00000080 74 75 72 65 20 6f 66 0d 73 6f 6d 65 20 70 68 79 |ture of.some phy| 00000090 73 69 63 61 6c 20 6f 62 6a 65 63 74 20 69 73 20 |sical object is | 000000a0 6d 61 64 65 20 73 69 6d 70 6c 69 63 69 74 79 20 |made simplicity | 000000b0 69 74 73 65 6c 66 20 62 79 20 61 74 74 61 63 68 |itself by attach| 000000c0 69 6e 67 20 61 20 72 65 61 64 79 20 6d 61 64 65 |ing a ready made| 000000d0 0d 62 6f 61 72 64 20 74 6f 20 79 6f 75 72 20 62 |.board to your b| 000000e0 65 65 62 2e 20 42 65 66 6f 72 65 2c 20 74 68 65 |eeb. Before, the| 000000f0 20 61 6c 74 65 72 6e 61 74 69 76 65 20 61 70 70 | alternative app| 00000100 72 6f 61 63 68 20 77 6f 75 6c 64 20 62 65 20 20 |roach would be | 00000110 74 6f 20 75 73 65 20 74 68 65 0d 61 6e 61 6c 6f |to use the.analo| 00000120 67 75 65 20 70 6f 72 74 20 74 6f 20 72 65 61 64 |gue port to read| 00000130 20 66 72 6f 6d 20 61 20 74 68 65 72 6d 69 73 74 | from a thermist| 00000140 6f 72 20 6f 66 20 73 69 6d 69 6c 61 72 20 64 65 |or of similar de| 00000150 76 69 63 65 20 2d 20 62 75 74 20 77 68 69 63 68 |vice - but which| 00000160 0d 77 6f 75 6c 64 20 62 65 20 68 61 72 64 20 74 |.would be hard t| 00000170 6f 20 63 61 6c 69 62 72 61 74 65 2e 20 0d 0d 54 |o calibrate. ..T| 00000180 68 69 73 20 6d 6f 64 75 6c 65 20 61 6c 6c 6f 77 |his module allow| 00000190 73 20 74 65 6d 70 65 72 61 74 75 72 65 20 64 61 |s temperature da| 000001a0 74 61 20 74 6f 20 62 65 20 73 68 69 66 74 65 64 |ta to be shifted| 000001b0 20 69 6e 74 6f 20 74 68 65 20 42 42 43 20 61 73 | into the BBC as| 000001c0 20 61 0d 62 61 63 6b 67 72 6f 75 6e 64 20 74 61 | a.background ta| 000001d0 73 6b 2c 77 68 69 6c 65 20 79 6f 75 20 63 6f 6e |sk,while you con| 000001e0 74 69 6e 75 65 20 74 6f 20 75 73 65 20 74 68 65 |tinue to use the| 000001f0 20 6d 61 63 68 69 6e 65 20 66 6f 72 20 61 6e 6f | machine for ano| 00000200 74 68 65 72 20 70 75 72 70 6f 73 65 2e 0d 54 68 |ther purpose..Th| 00000210 69 73 20 63 6f 75 6c 64 20 62 65 20 6f 66 20 75 |is could be of u| 00000220 73 65 20 69 6e 20 28 66 6f 72 20 65 78 61 6d 70 |se in (for examp| 00000230 6c 65 29 20 61 20 73 68 6f 70 2c 20 77 68 65 72 |le) a shop, wher| 00000240 65 20 74 68 65 20 42 42 43 20 77 61 73 20 75 73 |e the BBC was us| 00000250 65 64 20 66 6f 72 0d 73 74 6f 63 6b 20 74 61 6b |ed for.stock tak| 00000260 69 6e 67 20 77 68 69 6c 65 20 61 6c 73 6f 20 6d |ing while also m| 00000270 6f 6e 69 74 6f 72 69 6e 67 20 28 61 6e 64 20 73 |onitoring (and s| 00000280 61 76 69 6e 67 2e 2e 2e 29 20 74 68 65 20 74 65 |aving...) the te| 00000290 6d 70 65 72 61 74 75 72 65 20 6f 66 0d 63 68 69 |mperature of.chi| 000002a0 6c 6c 65 72 73 20 66 6f 72 20 68 79 67 65 6e 65 |llers for hygene| 000002b0 20 72 65 61 73 6f 6e 73 2e 20 4f 72 20 6d 6f 6e | reasons. Or mon| 000002c0 69 74 6f 72 69 6e 67 20 74 68 65 20 74 65 6d 70 |itoring the temp| 000002d0 65 72 61 74 75 72 65 20 6f 66 20 79 6f 75 72 0d |erature of your.| 000002e0 67 72 65 65 6e 68 6f 75 73 65 20 77 68 69 6c 65 |greenhouse while| 000002f0 20 74 79 70 69 6e 67 20 61 20 6c 65 74 74 65 72 | typing a letter| 00000300 20 74 6f 20 79 6f 75 72 20 61 75 6e 74 21 0d 0d | to your aunt!..| 00000310 50 41 52 54 53 2e 2e 2e 54 68 65 20 63 69 72 63 |PARTS...The circ| 00000320 75 69 74 20 64 69 61 67 72 61 6d 73 20 73 68 6f |uit diagrams sho| 00000330 77 73 20 65 6c 65 63 74 72 69 63 61 6c 6c 79 20 |ws electrically | 00000340 68 6f 77 20 74 6f 20 61 73 73 65 6d 62 6c 65 20 |how to assemble | 00000350 74 68 65 0d 75 6e 69 74 2c 20 72 65 71 75 69 72 |the.unit, requir| 00000360 69 6e 67 20 74 68 65 20 66 6f 6c 6c 6f 77 69 6e |ing the followin| 00000370 67 20 70 61 72 74 73 3a 0d 31 78 20 20 52 65 61 |g parts:.1x Rea| 00000380 64 79 20 62 75 69 6c 64 20 6d 6f 64 75 6c 65 20 |dy build module | 00000390 28 4d 61 70 6c 69 6e 20 6f 72 64 65 72 0d 63 6f |(Maplin order.co| 000003a0 64 65 3a 20 46 45 33 33 4c 39 78 20 20 5a 54 58 |de: FE33L9x ZTX| 000003b0 33 30 30 20 20 4e 50 4e 20 73 77 69 74 63 68 69 |300 NPN switchi| 000003c0 6e 67 20 74 72 61 6e 73 69 73 74 6f 72 73 0d 39 |ng transistors.9| 000003d0 78 20 20 31 30 6b 20 70 75 6c 6c 20 75 70 20 72 |x 10k pull up r| 000003e0 65 73 69 73 74 6f 72 73 20 0d 39 78 20 20 31 2e |esistors .9x 1.| 000003f0 32 6b 20 62 61 73 65 20 72 65 73 69 73 74 6f 72 |2k base resistor| 00000400 73 0d 0d 49 6e 20 61 64 64 69 74 69 6f 6e 2c 69 |s..In addition,i| 00000410 74 20 6d 61 79 20 62 65 20 75 73 65 66 75 6c 20 |t may be useful | 00000420 74 6f 20 68 61 76 65 20 61 0d 68 61 6e 64 66 75 |to have a.handfu| 00000430 6c 20 6f 66 20 70 69 6e 73 2c 20 61 20 75 73 65 |l of pins, a use| 00000440 72 20 70 6f 72 74 20 70 6c 75 67 20 61 6e 64 61 |r port plug anda| 00000450 20 63 6f 75 70 6c 65 20 6f 66 20 66 65 65 74 20 | couple of feet | 00000460 6f 66 20 72 69 62 62 6f 6e 0d 63 61 62 6c 65 2e |of ribbon.cable.| 00000470 0d 42 45 4e 45 46 49 54 53 2e 2e 2e 2a 53 6f 66 |.BENEFITS...*Sof| 00000480 74 77 61 72 65 20 73 65 6c 65 63 74 61 62 6c 65 |tware selectable| 00000490 20 73 61 6d 70 6c 65 20 72 61 74 65 2c 20 6d 6f | sample rate, mo| 000004a0 64 65 2c 61 6e 64 20 68 69 2f 6c 6f 20 70 6f 69 |de,and hi/lo poi| 000004b0 6e 74 0d 2a 52 75 6e 73 20 6f 66 66 20 61 20 73 |nt.*Runs off a s| 000004c0 69 6e 67 6c 65 20 41 41 20 62 61 74 74 65 72 79 |ingle AA battery| 000004d0 0d 2a 43 68 6f 69 63 65 20 6f 66 20 43 65 6c 63 |.*Choice of Celc| 000004e0 69 75 73 20 6f 72 20 46 61 68 72 65 6e 68 65 69 |ius or Fahrenhei| 000004f0 74 0d 2a 53 65 70 65 72 61 74 65 20 27 68 69 20 |t.*Seperate 'hi | 00000500 61 6c 61 72 6d 20 70 6f 69 6e 74 20 72 65 61 63 |alarm point reac| 00000510 68 65 64 27 20 61 6e 64 20 27 6c 6f 20 61 6c 61 |hed' and 'lo ala| 00000520 72 6d 20 70 6f 69 6e 74 20 72 65 61 63 68 65 64 |rm point reached| 00000530 27 20 70 69 6e 73 0d 0d 42 55 49 4c 44 2e 2e 2e |' pins..BUILD...| 00000540 31 2e 4a 6f 69 6e 20 66 72 6f 6d 20 74 68 65 20 |1.Join from the | 00000550 70 72 65 6d 61 64 65 20 6d 6f 64 75 6c 65 20 74 |premade module t| 00000560 6f 20 79 6f 75 72 20 62 6f 61 72 64 20 77 69 74 |o your board wit| 00000570 68 20 61 20 73 68 6f 72 74 20 6c 65 6e 67 74 68 |h a short length| 00000580 0d 6f 66 20 31 34 20 77 61 79 20 20 72 69 62 62 |.of 14 way ribb| 00000590 6f 6e 20 63 61 62 6c 65 2c 20 6e 6f 74 69 6e 67 |on cable, noting| 000005a0 20 77 68 69 63 68 20 77 69 72 65 20 69 73 20 67 | which wire is g| 000005b0 72 6f 75 6e 64 2e 0d 32 2e 41 74 74 61 63 68 20 |round..2.Attach | 000005c0 74 68 65 20 72 65 73 69 73 74 6f 72 73 20 61 6e |the resistors an| 000005d0 64 20 74 72 61 6e 73 69 73 74 6f 72 73 20 66 72 |d transistors fr| 000005e0 6f 6d 20 74 68 65 20 6f 75 74 70 75 74 20 66 72 |om the output fr| 000005f0 6f 6d 20 74 68 65 20 42 42 43 20 75 73 65 72 0d |om the BBC user.| 00000600 70 6f 72 74 20 20 74 6f 20 74 68 65 20 63 6f 6e |port to the con| 00000610 74 72 6f 6c 20 6c 69 6e 65 73 20 6f 6e 20 74 68 |trol lines on th| 00000620 65 20 6d 20 6f 64 75 6c 65 2e 54 68 65 20 27 52 |e m odule.The 'R| 00000630 45 4d 27 20 73 74 61 74 65 6d 65 6e 74 73 20 61 |EM' statements a| 00000640 74 20 74 68 65 0d 73 74 61 72 74 20 6f 66 20 74 |t the.start of t| 00000650 68 65 20 20 73 6f 66 74 77 61 72 65 20 61 6e 64 |he software and| 00000660 20 74 68 65 20 68 69 6e 74 73 20 73 65 63 74 69 | the hints secti| 00000670 6f 6e 20 62 65 6c 6f 77 20 74 65 6c 6c 20 79 6f |on below tell yo| 00000680 75 20 77 68 69 63 68 20 69 73 0d 77 68 69 63 68 |u which is.which| 00000690 2e 4e 6f 74 65 20 50 42 37 20 77 61 73 20 20 6e |.Note PB7 was n| 000006a0 6f 74 20 6e 65 65 64 65 64 2e 0d 33 2e 44 6f 20 |ot needed..3.Do | 000006b0 74 68 65 20 73 61 6d 65 20 61 67 61 69 6e 20 69 |the same again i| 000006c0 6e 20 74 68 65 20 6f 70 70 6f 73 69 74 65 20 6d |n the opposite m| 000006d0 61 6e 6e 65 72 20 66 6f 72 20 74 68 65 20 64 61 |anner for the da| 000006e0 74 61 20 61 6e 64 20 63 6c 6f 63 6b 20 69 6e 70 |ta and clock inp| 000006f0 75 74 73 0d 66 72 6f 6d 20 20 74 68 65 20 74 65 |uts.from the te| 00000700 6d 70 65 72 61 74 75 72 65 20 6d 6f 64 75 6c 65 |mperature module| 00000710 20 62 61 63 6b 20 69 6e 74 6f 20 74 68 65 20 42 | back into the B| 00000720 42 43 27 73 20 69 6e 74 65 72 72 75 70 20 74 20 |BC's interrup t | 00000730 6c 69 6e 65 73 2c 43 42 31 20 61 6e 64 0d 43 42 |lines,CB1 and.CB| 00000740 32 2e 0d 34 2e 45 6e 73 75 72 65 20 74 68 61 74 |2..4.Ensure that| 00000750 20 62 6f 74 68 20 30 76 20 6c 69 6e 65 73 20 6f | both 0v lines o| 00000760 6e 20 74 68 65 20 42 42 43 20 61 6e 64 20 74 65 |n the BBC and te| 00000770 6d 70 65 72 61 74 75 72 65 20 6d 6f 64 75 6c 65 |mperature module| 00000780 20 61 72 65 20 6a 6f 69 6e 65 64 20 20 0d 74 6f | are joined .to| 00000790 67 65 74 68 65 72 2e 0d 0d 48 49 4e 54 53 2e 2e |gether...HINTS..| 000007a0 2e 2a 59 6f 75 20 6d 69 67 68 74 20 77 61 6e 74 |.*You might want| 000007b0 20 74 6f 20 61 64 64 20 61 20 74 68 72 65 65 20 | to add a three | 000007c0 73 6d 61 6c 6c 20 28 31 2e 35 76 29 20 70 69 65 |small (1.5v) pie| 000007d0 7a 6f 20 62 75 7a 7a 65 72 73 20 74 6f 20 74 68 |zo buzzers to th| 000007e0 65 0d 61 6c 61 72 6d 20 70 6f 69 6e 74 20 70 69 |e.alarm point pi| 000007f0 6e 73 2c 70 69 6e 20 36 2c 37 2c 61 6e 64 20 31 |ns,pin 6,7,and 1| 00000800 35 2e 20 4f 74 68 65 72 77 69 73 65 2c 6a 75 73 |5. Otherwise,jus| 00000810 74 20 6c 65 61 76 65 20 74 68 65 6d 0d 75 6e 63 |t leave them.unc| 00000820 6f 6e 6e 65 63 74 65 64 2e 20 47 72 6f 75 6e 64 |onnected. Ground| 00000830 20 69 73 20 70 69 6e 20 31 2e 0d 2a 20 54 68 65 | is pin 1..* The| 00000840 20 73 6f 66 74 77 61 72 65 20 63 61 6e 20 65 61 | software can ea| 00000850 73 69 6c 79 20 62 65 20 6d 6f 64 69 66 69 65 64 |sily be modified| 00000860 20 69 66 20 79 6f 75 20 6d 61 64 65 20 61 20 6d | if you made a m| 00000870 69 73 74 61 6b 65 20 77 69 72 69 6e 67 20 75 70 |istake wiring up| 00000880 20 74 68 65 0d 70 69 6e 73 20 74 68 6f 75 67 68 | the.pins though| 00000890 20 49 20 73 75 67 67 65 73 74 3a 20 0d 50 42 30 | I suggest: .PB0| 000008a0 20 3d 20 73 68 6f 77 20 6c 6f 20 70 6f 69 6e 74 | = show lo point| 000008b0 20 20 20 20 20 20 3d 3e 20 6d 6f 64 75 6c 65 20 | => module | 000008c0 70 69 6e 20 31 33 20 20 20 20 20 20 20 20 20 20 |pin 13 | 000008d0 20 20 20 20 20 20 20 20 0d 50 42 31 20 3d 20 73 | .PB1 = s| 000008e0 68 6f 77 20 68 69 20 70 6f 69 6e 74 20 20 20 20 |how hi point | 000008f0 20 20 3d 3e 20 6d 6f 64 75 6c 65 20 70 69 6e 20 | => module pin | 00000900 31 32 0d 50 42 32 20 3d 20 63 65 6c 63 69 75 73 |12.PB2 = celcius| 00000910 2f 66 61 68 72 65 6e 68 65 69 74 20 3d 3e 20 6d |/fahrenheit => m| 00000920 6f 64 75 6c 65 20 70 69 6e 20 31 34 20 20 20 20 |odule pin 14 | 00000930 20 20 20 20 0d 50 42 33 20 3d 20 73 61 6d 70 6c | .PB3 = sampl| 00000940 65 20 72 61 74 65 20 73 65 6c 65 63 74 20 3d 3e |e rate select =>| 00000950 20 6d 6f 64 75 6c 65 20 70 69 6e 20 35 20 0d 50 | module pin 5 .P| 00000960 42 34 20 3d 20 73 65 74 20 68 6f 75 72 73 20 20 |B4 = set hours | 00000970 20 20 20 20 20 20 20 20 3d 3e 20 6d 6f 64 75 6c | => modul| 00000980 65 20 70 69 6e 20 32 20 0d 50 42 35 20 3d 20 73 |e pin 2 .PB5 = s| 00000990 65 74 20 6d 69 6e 73 20 20 20 20 20 20 20 20 20 |et mins | 000009a0 20 20 3d 3e 20 6d 6f 64 75 6c 65 20 70 69 6e 20 | => module pin | 000009b0 33 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 |3 | 000009c0 20 20 20 20 0d 50 42 36 20 3d 20 63 6c 6f 63 6b | .PB6 = clock| 000009d0 2f 74 65 6d 70 65 72 61 74 75 72 65 20 20 3d 3e |/temperature =>| 000009e0 20 6d 6f 64 75 6c 65 20 70 69 6e 20 31 31 0d 43 | module pin 11.C| 000009f0 42 31 20 3d 20 64 61 74 61 20 20 20 20 20 20 20 |B1 = data | 00000a00 20 20 20 20 20 20 20 20 3d 3e 20 6d 6f 64 75 6c | => modul| 00000a10 65 20 70 69 6e 20 39 0d 43 42 32 20 3d 20 64 61 |e pin 9.CB2 = da| 00000a20 74 61 20 6c 6f 61 64 20 63 6c 6f 63 6b 20 20 20 |ta load clock | 00000a30 20 3d 3e 20 6d 6f 64 75 6c 65 20 70 69 6e 20 31 | => module pin 1| 00000a40 30 0d 0d 46 52 4f 4d 2e 2e 2e 52 6f 62 65 72 74 |0..FROM...Robert| 00000a50 20 53 70 72 6f 77 73 6f 6e 2e 0d 48 61 70 70 79 | Sprowson..Happy| 00000a60 20 73 6f 6c 64 65 72 69 6e 67 21 0d | soldering!.| 00000a6c
F/+temp1.m0
