1. After power up the host computer sends a command block to the
controller telling it about the drive connected (this remains in use until
power is lost or the RESET line is pulled low) eg. WD1002.  The problem is
the host computer needs to know when to send the info to the controller
(problem with the BBC as controller reverts to power up default parameters
every time BREAK is pressed).

2. If the controller is microprocessor based then the default parameter
values are stored as part of the program in Eprom on the controller card.
These default parameters can be edited so that they match your drive, eg.
DTC controllers.

3. Truly intelligent controllers are "told" about the drive when it is
formatted, and a special sector is written to the Winchester (on track
0/head 0) automatically containing drive parameter information.  On
subsequent power ups (or after BREAK is pressed on the BBC) the controller
reads the special sector to find out about the drive, eg. Adaptec ACB4000
and Xebec S1410a series controllers.

Interfacing to a host computer

Generally, to interface a controller to a host, a pair of 8 bit parallel
read ports and an 8 bit parallel latched write port are required with some
extra logic to handle the control signals (hand shaking etc.) - all data
into/out of the controller is negative logic, so for the majority of
machines, it has to be inverted.  The interface between a standard SASI
controller and a particular host computer is usually known as a "Host
Interface Adaptor" or "Winchester Host Adaptor", further sections of this
article describe host adaptors for various computers.

Once a host adaptor is implemented a power supply is required for the
drive and controller, typically a Winchester will require +5v at 1A and
+12v at 2.5A when running (peak of 4A at switch on), and the controller
will require around 3A at 5v, these supplies should be "computer grade",
ie. well regulated, probably from a switched mode power supply unit.

Software to "drive" a winchester varies greatly with the host in use, for
the BBC micro the routines required are already inside Acorn's ADFS ROM,
for a Z80 based CP/M machine a driver routine is required for the BIOS
(similar too for IBM PC type machines with MSDOS).  If you cannot find
software to handle a Winchester on your computer you will have to write
routines from scratch - the controller manuals usually give detailed flow
charts to make this easier...

Winchester disk systems  Buying hardware
Buying winchester disk drives/controllers/hardware

Drives

There is a reasonable supply of cheap drive units  available on the second
hand market, but prices and quality vary greatly.  Points of note:

1. All Winchesters (except the very large units with removable media) are
sealed in a clean room, most manufacturers put a seal across the top plate
- don't buy a drive that has the seals broken. (Some drives have been back
to the manufacturer and been re furbished and may have two sets of seals,
this is quite probably okay as long as the top set are not broken).

2. All winchesters have control logic attached to them to operate the
stepper motor, regulate drive speed etc. (should have a 4 pin power
connector, 20 way and 34 way edge connector) - don't but a lump of die
cast aluminium that is no use other than a door stop!

3. Sometimes, if you're lucky, the disk controller is mounted on the
winchester and already (still) connected up (by 20 way and 34 way IDC
ribbon cable) - if the drive looks okay you might have a bargain, it might
even be worth buying the drive just to get the controller board depending
on the price!

4. If possible try out the drive on someone's system before parting with
cash, or at least try the motor, put power on the drive (+5v and +12v) and
watch/listen, most drives (all the ones I have met) are up to speed after
about 30 seconds, the end of a successful power up is indicated by the
drive re calibrating the heads (stepping them out and back to track zero)
- you should hear the stepper motor move the heads.  If, after 30 seconds,
the drive speed has not settled down (motor speed hunting), or nothing is
happened, or if you hear a loud clattering noise, then switch off - choose
another drive!

5. Look on the side of the drive for a sticker called "Bad Block Map",
"Illegal Address Map" or similar, this details any areas on the winchester
that were found to be defective at manufacture - if possible find a drive
that has no map entries (a "physically perfect" disk).  Many disks have
bad blocks, this is not a problem because these can be overcome during
formatting making a "logically perfect" disk.

6. Always get technical information on a drive you are buying, you will
need to know a number of parameters to configure your controller card/host
system.  You will need to know such things as the number of cylinders,
number of heads, head step time, cylinder number after which reduced write
current is used, etc.

There is not too much point in going into who makes what in the way of
drives - basically there are two types: head positioned by stepper motor
or by voice coil, the later is much more expensive and usually reserved
for multi user systems where speed is really critical.

Older 5, 7 and 10Mb drives usually have a fixed head step speed 3mS,
whereas newer drives support buffered seek.  Buffered seek means that the
controller sends all the head step pulses to the drive, which counts them,
and then the drive works out the best way to move the head quickly to the
required cylinder.  Various manufacturers have implemented their own ways
of moving the heads quickly, and may call them such things as "fast step
algorithms" etc. basically it doesn't matter since it is transparent to
the controller.

There is a good chance that you will see more Rodime drives around than
some others as they are a BRITISH (!!!) company (and they are a pretty
good make!).  The RO200 series is most popular and goes something like:
RO201 = 5Mb, RO202 = 10Mb, RO203 = 15Mb, RO204 = 20Mb, RO203E = 30Mb and
RO204E = 40Mb.  The RO200 series are all 5.25" full height, quiet and
reliable.

Controllers

There are a number of different SASI controllers around on the market made
by Shugart, Adaptec, Xebec, DTC, Western Digital, NCL etc., most of these
are software compatible as far as the command structure is concerned
except some of the Western Digital controllers.  The list below is not
complete or exhaustive, there are other makes of controller that may be
suitable.
