Filename: PrinterDMs/!PrinterDM/Library
Read OK:
File size: 234C bytes
Load address: FFFFFB41
Exec address: 5897BD65
Duplicates

There are 3 duplicate copies of this file in the archive:

File contents
   10REM >Library V.0.80 for dot matrix printer driver
   20REM Purpose: printer-specific parts of the printer application
   30REM Authors: A.Thompson, NReeves
   40REM *******************************************************
   50REM initialise the dot matrix printer driver specific parts
   60REM *******************************************************
   70:
   80DEFPROCPrinter_initialise
   90LOCAL P%
  100PrinterClass$="PrinterDM"
  110FullPrinterClass$="dot matrix"
  120OutputType%=&FF4
  130REM define printer class dependent fields in printer data area
  140    dump_depth_field% = FNp_field(1)
  150     interlace_field% = FNp_field(3)
  160 line_prologue_field% = FNp_field(20)
  170 line_epilogue_field% = FNp_field(20)
  180line_interlace_field% = FNp_field(20)
  190  job_epilogue_field% = FNp_field(20)
  200  job_prologue_field% = FNp_field(20)
  210   printer_data_size% = FNp_field(0)
  220REM define class dependent icons in main window
  230main_line%=2
  240printer_data_list% = 0:P%=0
  250PROCPrinter_read_config_file
  260REM now convert to circular list
  270P%!list_pointer_field%=printer_data_list%
  280ENDPROC
  290:
  300REM *****************
  310REM set initial state
  320REM *****************
  330DEFPROCPrinter_set_initial_state
  340LOCAL D%
  350REM set default state
  360D%=printer_data_list%
  370WHILE D%!list_pointer_field%<>printer_data_list% AND D%!printer_number_field%<>printer_config%
  380 D%=D%!list_pointer_field%
  390ENDWHILE
  400IF D%!printer_number_field%=printer_config% THEN printer_data_list%=D%
  410PROCPrinter_set_description
  420PROCPrinter_set_module_data
  430ENDPROC
  440:
  450REM ********
  460REM shutdown
  470REM ********
  480DEFPROCPrinter_terminate
  490*if "<Printer$Scrap>" = "<PDriver$Dir>.DM!Scrap" then unset Printer$Scrap
  500*if "<Printer$Temp>" = "<PDriver$Dir>.DM!Temp" then unset Printer$Temp
  510ENDPROC
  520:
  530REM **************************************
  540REM the printer-specific template loading
  550REM **************************************
  560DEFPROCPrinter_load_templates
  570PROCset_icon_state(main%, main_line%, line_new% << 21, 1<<21)
  580ENDPROC
  590:
  600REM ***********************************
  610REM the printer-specific event handler
  620REM ***********************************
  630DEFFNPrinter_process_event(action%, E%)
  640LOCAL res%
  650res%=FALSE
  660CASE action% OF
  670 WHEN 17,18:
  680  CASE E%!16 OF
  690   WHEN &502:
  700    IF E%!32 = main% AND E%!36 >= -1 THEN PROChelpreply("Printer setup.|MClick SELECT or ADJUST to alter the settings.",E%!8,E%!4):res% = TRUE
  710  ENDCASE
  720 WHEN 6
  730  IF E%!12=main% AND NOT print_on% THEN
  740   CASE TRUE OF
  750    WHEN (E%!8 AND %101)<>0:
  760     CASE E%!16 OF
  770      WHEN main_description%:
  780       IF E%!8 AND 1 THEN
  790        res% = printer_data_list%
  800        REPEAT printer_data_list% = printer_data_list%!list_pointer_field%
  810        UNTIL printer_data_list%!list_pointer_field% = res%
  820       ELSE
  830        printer_data_list% = printer_data_list%!list_pointer_field%
  840       ENDIF
  850       PROCPrinter_set_description
  860       PROCPrinter_set_module_data
  870       printer_new% = printer_data_list%!printer_number_field%
  880       res%=TRUE
  890      WHEN main_line%
  900       !q%=main%
  910       q%!4=main_line%
  920       SYS "Wimp_GetIconState",,q%
  930       line_new% = (q%!24 >> 21) AND 1
  940     ENDCASE
  950   ENDCASE
  960  ENDIF
  970ENDCASE
  980=res%
  990:
 1000REM *****************************************************************
 1010REM read the configuration file with all the individual printer info
 1020REM *****************************************************************
 1030DEFPROCPrinter_read_config_file
 1040LOCAL H%,ptr%
 1050DIM defaults% printer_data_size%
 1060FOR H%=0 TO printer_data_size%-4 STEP 4:defaults%!H%=0:NEXT
 1070printer_data% = defaults%
 1080H%=OPENIN"<PDriver$dir>.PrData"
 1090IF H%=0 ERROR 100,"Can't read printer data file"
 1100REPEAT
 1110 ptr% = PTR#H%
 1120 PROCPrinter_process_line(H%)
 1130UNTIL EOF#H%
 1140CLOSE#H%
 1150ENDPROC
 1160:
 1170REM *********************************************
 1180REM process one line from the configuration file
 1190REM *********************************************
 1200DEFPROCPrinter_process_line(H%)
 1210LOCAL I%,J%,tag$
 1220$buf%=GET$#H%
 1230I%=0
 1240WHILE FNtagchar(buf%?I%): I% += 1:ENDWHILE
 1250IF buf%?I% = ASC":" THEN
 1260 REM got a tag
 1270 tag$=FNlowercase(LEFT$($buf%,I%))
 1280 I% += 1
 1290 WHILE buf%?I%=ASC" ": I% += 1:ENDWHILE
 1300 CASE tag$ OF
 1310  WHEN "printer_name"
 1320   REM build a name
 1330   DIM description% LEN$buf% -I% +1
 1340   $description% = RIGHT$($buf%,LEN$buf%-I%)
 1350   REM now add a block to our list of printer data blocks
 1360   DIM printer_data% printer_data_size%
 1370   FOR I%=0 TO printer_data_size%-4 STEP 4
 1380     printer_data%!I% = defaults%!I%
 1390   NEXT
 1400   printer_data%!description_field% = description%
 1410   IF P%=0 THEN
 1420    printer_data_list% = printer_data%
 1430   ELSE
 1440    P%!list_pointer_field% = printer_data%
 1450   ENDIF
 1460   P% = printer_data%
 1470  WHEN "pxres","pyres","features","pxres_halftone","pyres_halftone","printer_number","page_width","page_height","page_bottom","page_top","page_left","page_right"
 1480   REM note that all tags are the same as their respective field names
 1490   printer_data%!EVAL(tag$+"_field%") = FNread_integer_expression(RIGHT$($buf%,LEN$buf%-I%))
 1500  WHEN "dump_depth","interlace"
 1510   printer_data%?EVAL(tag$+"_field%") = FNread_integer_expression(RIGHT$($buf%,LEN$buf%-I%))
 1520  WHEN "line_prologue","line_epilogue","line_interlace","job_prologue","job_epilogue"
 1530   WHILE buf%?I%=ASC" ":I%+=1:ENDWHILE
 1540   J% = EVAL(tag$+"_field%")
 1550   SYS "OS_GSTrans",buf%+I%,printer_data%+1+J%,20 TO ,,I%
 1560   printer_data%?J% = I%
 1570  WHEN "server"
 1580   J% = I%
 1590   WHILE buf%?J%>=ASC" " AND buf%?J%<>ASC";"
 1600    J% += 1
 1610   ENDWHILE
 1620   REM from I% to J% is the string
 1630   server_ptr% = ptr% + I%
 1640   server_config$ = MID$($buf%, I%+1, J%-I%)
 1650  WHEN "printer"
 1660   printer_config% = FNread
 1670   printer_new% = printer_config%
 1680   printer_ptr% = ptr% + I%
 1690  WHEN "location"
 1700   location_config% = FNread
 1710   location_ptr% = ptr% + I%
 1720  WHEN "baud"
 1730   baud_config% = FNread
 1740   baud_ptr% = ptr% + I%
 1750  WHEN "data"
 1760   data_config% = FNread
 1770   data_ptr% = ptr% + I%
 1780  WHEN "xon"
 1790   XON_config% = FNread
 1800   XON_new% = XON_config%
 1810   XON_ptr% = ptr% + I%
 1820  WHEN "line"
 1830   line_config% = FNread
 1840   line_new% = line_config%
 1850   line_ptr% = ptr% + I%
 1860 ENDCASE
 1870ENDIF
 1880ENDPROC
 1890:
 1900DEFFNread=FNread_integer_expression(RIGHT$($buf%,LEN$buf%-I%))
 1910:
 1920REM ***************************************
 1930REM convert a string to an integer
 1940REM ***************************************
 1950DEFFNread_integer_expression(S$)
 1960LOCAL R%, T%, E$, P%
 1970E$=""
 1980REM get rid of any comment
 1990WHILE LEFT$(S$,1) <> ";" AND LENS$ <> 0
 2000 E$ += LEFT$(S$,1)
 2010 S$ = RIGHT$(S$,LENS$-1)
 2020ENDWHILE
 2030SYS"XOS_EvaluateExpression",E$,buf%,256 TO ,T%,R%;P%
 2040IF T% <> 0 OR (P% AND 1) ERROR 100, "Integer value needed for "+tag$
 2050=R%
 2060:
 2070REM ***************************************
 2080REM allow only alphanumerics in tag fields
 2090REM ***************************************
 2100DEFFNtagchar(C%)
 2110IF (C% >= ASC"A" AND C% <= ASC"Z") THEN =TRUE
 2120IF (C% >= ASC"a" AND C% <= ASC"z") THEN =TRUE
 2130=  (C% >= ASC"0" AND C% <= ASC"9") OR C% = ASC"_"
 2140:
 2150REM *********************************************************************
 2160REM set the printer driver module's state to reflect the current settings
 2170REM *********************************************************************
 2180DEFPROCPrinter_set_module_data
 2190LOCAL A%,B%,C%,D%,E%,F%
 2200A%=defaults%!pxres_field%
 2210B%=defaults%!pyres_field%
 2220C%=defaults%!features_field%
 2230D%=defaults%!pxres_halftone_field%
 2240E%=defaults%!pyres_halftone_field%
 2250F%=defaults%!printer_number_field%
 2260SYS "PDriver_SetInfo",,A%,B%,C%,,D%,E%,F%
 2270msg%!0=20
 2280msg%!12=0
 2290msg%!16=Message_SetPrinter%
 2300SYS "Wimp_SendMessage", 18, msg%, 0
 2310A%=defaults%!page_width_field%
 2320B%=defaults%!page_height_field%
 2330C%=defaults%!page_left_field%
 2340D%=defaults%!page_bottom_field%
 2350E%=defaults%!page_right_field%
 2360F%=defaults%!page_top_field%
 2370SYS "PDriver_SetPageSize",,A%,B%,C%,D%,E%,F%
 2380SYS "PDriver_SetPrinter",defaults%+dump_depth_field%
 2390ENDPROC
 2400:
 2410REM ***************************************
 2420REM set the description field in our window
 2430REM ***************************************
 2440DEFPROCPrinter_set_description
 2450LOCAL S%, S$
 2460FOR S% = 0 TO printer_data_size%-4 STEP 4
 2470defaults%!S% = printer_data_list%!S%
 2480NEXT
 2490PROCPrinter_set_icon(main_description%,$(defaults%!description_field%))
 2500SYS "XOS_CLI","SET Printer$"+" """+$(defaults%!description_field%)+""""
 2510ENDPROC
 2520:
 2530DEFPROCPrinter_set_numeric_icon(I%,F%,S%, RETURN S$)
 2540S$ = STR$(defaults%!F%/S%)
 2550PROCPrinter_set_icon(I%,S$)
 2560ENDPROC
 2570:
 2580DEFPROCPrinter_set_icon(I%,S$)
 2590LOCAL S%
 2600S%=FNiconaddr(main%,I%)
 2610$S% = S$
 2620PROCzero_terminate(S%)
 2630PROCset_icon_state(main%,I%,0,0): REM force redraw
 2640ENDPROC
 2650:
 2660DEF PROCPrinter_AmendConfig
 2670IF line_config% <> line_new% THEN
 2680 PTR#out_file%=line_ptr%
 2690 BPUT#out_file%,STR$line_new%;
 2700 line_config% = line_new%
 2710ENDIF
 2720ENDPROC
 2730:
 2740DEF PROCPrinter_Ignore
 2750ENDPROC
 2760:
 2770DEF PROCPrinter_XonXoff(flag%)
 2780IF flag% THEN
 2790 *fx 2,2
 2800ELSE
 2810 *fx 2,0
 2820ENDIF
 2830ENDPROC
 2840:
 2850DEF PROCPrinter_Header
 2860`ext%=EXT#in_file%
 2870`last%=-1
 2880ENDPROC
 2890:
 2900DEF PROCPrinter_Footer
 2910ENDPROC
 2920:
 2930DEF FNPrinter_Send(len%)
 2940PROCEscOn
 2950LOCAL L%,I%,C%
 2960L%=`ext% - PTR#in_file%
 2970IF len%>=L% len%=L%
 2980IF line_new% THEN
 2990 I%=len%
 3000 WHILE I%>0
 3010  C%=BGET#in_file%
 3020  IF C%=10 BPUT#out_file%,13:I%-=1
 3030  BPUT#out_file%,C%
 3040  IF C%=13 BPUT#out_file%,10:I%-=1
 3050  I%-=1
 3060  `last%=C%
 3070 ENDWHILE
 3080ELSE
 3090 SYS "OS_GBPB", 4, in_file%, buf%, len%
 3100 SYS "OS_GBPB", 2, out_file%, buf%, len%
 3110ENDIF
 3120PROCEscOff
 3130=(len%>=L%)

3� >Library V.0.80 for dot matrix printer driver
@� Purpose: printer-specific parts of the printer application
"� Authors: A.Thompson, NReeves
(=� *******************************************************
2=� initialise the dot matrix printer driver specific parts
<=� *******************************************************
F:
P��Printer_initialise
Z� P%
dPrinterClass$="PrinterDM"
n"FullPrinterClass$="dot matrix"
xOutputType%=&FF4
�@� define printer class dependent fields in printer data area
�'    dump_depth_field% = �p_field(1)
�'     interlace_field% = �p_field(3)
�( line_prologue_field% = �p_field(20)
�( line_epilogue_field% = �p_field(20)
�(line_interlace_field% = �p_field(20)
�(  job_epilogue_field% = �p_field(20)
�(  job_prologue_field% = �p_field(20)
�'   printer_data_size% = �p_field(0)
�1� define class dependent icons in main window
�main_line%=2
�printer_data_list% = 0:P%=0
��Printer_read_config_file
"� now convert to circular list
-P%!list_pointer_field%=printer_data_list%
�
":
,� *****************
6� set initial state
@� *****************
J��Printer_set_initial_state
T� D%
^� set default state
hD%=printer_data_list%
r]ȕ D%!list_pointer_field%<>printer_data_list% � D%!printer_number_field%<>printer_config%
| D%=D%!list_pointer_field%
��
�F� D%!printer_number_field%=printer_config% � printer_data_list%=D%
��Printer_set_description
��Printer_set_module_data
��
�:
�� ********
�� shutdown
�� ********
���Printer_terminate
�M*if "<Printer$Scrap>" = "<PDriver$Dir>.DM!Scrap" then unset Printer$Scrap
�J*if "<Printer$Temp>" = "<PDriver$Dir>.DM!Temp" then unset Printer$Temp
��
:
,� **************************************
+� the printer-specific template loading
&,� **************************************
0��Printer_load_templates
:>�set_icon_state(main%, main_line%, line_new% << 21, 1<<21)
D�
N:
X)� ***********************************
b(� the printer-specific event handler
l)� ***********************************
v(ݤPrinter_process_event(action%, E%)
�
� res%
�
res%=�
�Ȏ action% �
�
 � 17,18:
�  Ȏ E%!16 �
�   � &502:
��    � E%!32 = main% � E%!36 >= -1 � �helpreply("Printer setup.|MClick SELECT or ADJUST to alter the settings.",E%!8,E%!4):res% = �
�  �
� � 6
�#  � E%!12=main% � � print_on% �
�
   Ȏ � �
�    � (E%!8 � %101)<>0:
�     Ȏ E%!16 �
      � main_description%:
       � E%!8 � 1 �
%        res% = printer_data_list%
 I        � printer_data_list% = printer_data_list%!list_pointer_field%
*;        � printer_data_list%!list_pointer_field% = res%
4       �
>G        printer_data_list% = printer_data_list%!list_pointer_field%
H       �
R#       �Printer_set_description
\#       �Printer_set_module_data
fB       printer_new% = printer_data_list%!printer_number_field%
p       res%=�
z      � main_line%
�       !q%=main%
�       q%!4=main_line%
�%       ș "Wimp_GetIconState",,q%
�(       line_new% = (q%!24 >> 21) � 1
�
     �
�   �
�  �
��
�	=res%
�:
�G� *****************************************************************
�F� read the configuration file with all the individual printer info
�G� *****************************************************************
��Printer_read_config_file

� H%,ptr%
"� defaults% printer_data_size%
$6� H%=0 � printer_data_size%-4 � 4:defaults%!H%=0:�
.printer_data% = defaults%
8H%=�"<PDriver$dir>.PrData"
B/� H%=0 � 100,"Can't read printer data file"
L�
V ptr% = �#H%
` �Printer_process_line(H%)
j
� �#H%
t�#H%
~�
�:
�3� *********************************************
�2� process one line from the configuration file
�3� *********************************************
���Printer_process_line(H%)
�� I%,J%,tag$
�$buf%=�#H%
�I%=0
�#ȕ �tagchar(buf%?I%): I% += 1:�
�� buf%?I% = �":" �
� � got a tag
�  tag$=�lowercase(�$buf%,I%))
 I% += 1

 ȕ buf%?I%=�" ": I% += 1:�
 Ȏ tag$ �
  � "printer_name"
(   � build a name
2#   � description% �$buf% -I% +1
<(   $description% = �$buf%,�$buf%-I%)
F;   � now add a block to our list of printer data blocks
P)   � printer_data% printer_data_size%
Z(   � I%=0 � printer_data_size%-4 � 4
d(     printer_data%!I% = defaults%!I%
n   �
x6   printer_data%!description_field% = description%
�   � P%=0 �
�*    printer_data_list% = printer_data%
�   �
�.    P%!list_pointer_field% = printer_data%
�   �
�   P% = printer_data%
��  � "pxres","pyres","features","pxres_halftone","pyres_halftone","printer_number","page_width","page_height","page_bottom","page_top","page_left","page_right"
�H   � note that all tags are the same as their respective field names
�T   printer_data%!�(tag$+"_field%") = �read_integer_expression(�$buf%,�$buf%-I%))
�   � "dump_depth","interlace"
�T   printer_data%?�(tag$+"_field%") = �read_integer_expression(�$buf%,�$buf%-I%))
�V  � "line_prologue","line_epilogue","line_interlace","job_prologue","job_epilogue"
�   ȕ buf%?I%=�" ":I%+=1:�
   J% = �(tag$+"_field%")
;   ș "OS_GSTrans",buf%+I%,printer_data%+1+J%,20 � ,,I%
   printer_data%?J% = I%
"  � "server"
,   J% = I%
6'   ȕ buf%?J%>=�" " � buf%?J%<>�";"
@    J% += 1
J   �
T$   � from I% to J% is the string
^   server_ptr% = ptr% + I%
h,   server_config$ = �$buf%, I%+1, J%-I%)
r  � "printer"
|   printer_config% = �read
�%   printer_new% = printer_config%
�   printer_ptr% = ptr% + I%
�  � "location"
�   location_config% = �read
�    location_ptr% = ptr% + I%
�  � "baud"
�   baud_config% = �read
�   baud_ptr% = ptr% + I%
�  � "data"
�   data_config% = �read
�   data_ptr% = ptr% + I%
�
  � "xon"
�   XON_config% = �read
   XON_new% = XON_config%
   XON_ptr% = ptr% + I%
  � "line"
&   line_config% = �read
0   line_new% = line_config%
:   line_ptr% = ptr% + I%
D �
N�
X�
b:
l6ݤread=�read_integer_expression(�$buf%,�$buf%-I%))
v:
�-� ***************************************
�$� convert a string to an integer
�-� ***************************************
�!ݤread_integer_expression(S$)
�� R%, T%, E$, P%
�	E$=""
�� get rid of any comment
�ȕ �S$,1) <> ";" � �S$ <> 0
� E$ += �S$,1)
� S$ = �S$,�S$-1)
��
�6ș"XOS_EvaluateExpression",E$,buf%,256 � ,T%,R%;P%
�@� T% <> 0 � (P% � 1) � 100, "Integer value needed for "+tag$
=R%
:
-� ***************************************
 ,� allow only alphanumerics in tag fields
*-� ***************************************
4ݤtagchar(C%)
>$� (C% >= �"A" � C% <= �"Z") � =�
H$� (C% >= �"a" � C% <= �"z") � =�
R,=  (C% >= �"0" � C% <= �"9") � C% = �"_"
\:
fK� *********************************************************************
pK� set the printer driver module's state to reflect the current settings
zK� *********************************************************************
���Printer_set_module_data
�� A%,B%,C%,D%,E%,F%
�A%=defaults%!pxres_field%
�B%=defaults%!pyres_field%
� C%=defaults%!features_field%
�&D%=defaults%!pxres_halftone_field%
�&E%=defaults%!pyres_halftone_field%
�&F%=defaults%!printer_number_field%
�,ș "PDriver_SetInfo",,A%,B%,C%,,D%,E%,F%
�
msg%!0=20
�
msg%!12=0
�msg%!16=Message_SetPrinter%
�&ș "Wimp_SendMessage", 18, msg%, 0
	"A%=defaults%!page_width_field%
	#B%=defaults%!page_height_field%
	!C%=defaults%!page_left_field%
	$#D%=defaults%!page_bottom_field%
	."E%=defaults%!page_right_field%
	8 F%=defaults%!page_top_field%
	B/ș "PDriver_SetPageSize",,A%,B%,C%,D%,E%,F%
	L7ș "PDriver_SetPrinter",defaults%+dump_depth_field%
	V�
	`:
	j-� ***************************************
	t-� set the description field in our window
	~-� ***************************************
	���Printer_set_description
	�� S%, S$
	�'� S% = 0 � printer_data_size%-4 � 4
	�(defaults%!S% = printer_data_list%!S%
	��
	�H�Printer_set_icon(main_description%,$(defaults%!description_field%))
	�Jș "XOS_CLI","SET Printer$"+" """+$(defaults%!description_field%)+""""
	��
	�:
	�.��Printer_set_numeric_icon(I%,F%,S%, � S$)
	�S$ = �(defaults%!F%/S%)
	��Printer_set_icon(I%,S$)
�

:
��Printer_set_icon(I%,S$)
� S%
(S%=�iconaddr(main%,I%)
2$S% = S$
<�zero_terminate(S%)
F1�set_icon_state(main%,I%,0,0): � force redraw
P�
Z:
d� �Printer_AmendConfig
n!� line_config% <> line_new% �
x �#out_file%=line_ptr%
� �#out_file%,�line_new%;
� line_config% = line_new%
��
��
�:
�� �Printer_Ignore
��
�:
�� �Printer_XonXoff(flag%)
�
� flag% �
� *fx 2,2
��
� *fx 2,0
�
�
:
"� �Printer_Header
,`ext%=�#in_file%
6
`last%=-1
@�
J:
T� �Printer_Footer
^�
h:
r� �Printer_Send(len%)
|
�EscOn
�� L%,I%,C%
�L%=`ext% - �#in_file%
�� len%>=L% len%=L%
�� line_new% �
� I%=len%
� ȕ I%>0
�  C%=�#in_file%
�"  � C%=10 �#out_file%,13:I%-=1
�  �#out_file%,C%
�"  � C%=13 �#out_file%,10:I%-=1
�  I%-=1
�  `last%=C%
� �
�
* ș "OS_GBPB", 4, in_file%, buf%, len%
+ ș "OS_GBPB", 2, out_file%, buf%, len%
&�
0�EscOff
:=(len%>=L%)
�
00000000  0d 00 0a 33 f4 20 3e 4c  69 62 72 61 72 79 20 56  |...3. >Library V|
00000010  2e 30 2e 38 30 20 66 6f  72 20 64 6f 74 20 6d 61  |.0.80 for dot ma|
00000020  74 72 69 78 20 70 72 69  6e 74 65 72 20 64 72 69  |trix printer dri|
00000030  76 65 72 0d 00 14 40 f4  20 50 75 72 70 6f 73 65  |ver...@. Purpose|
00000040  3a 20 70 72 69 6e 74 65  72 2d 73 70 65 63 69 66  |: printer-specif|
00000050  69 63 20 70 61 72 74 73  20 6f 66 20 74 68 65 20  |ic parts of the |
00000060  70 72 69 6e 74 65 72 20  61 70 70 6c 69 63 61 74  |printer applicat|
00000070  69 6f 6e 0d 00 1e 22 f4  20 41 75 74 68 6f 72 73  |ion...". Authors|
00000080  3a 20 41 2e 54 68 6f 6d  70 73 6f 6e 2c 20 4e 52  |: A.Thompson, NR|
00000090  65 65 76 65 73 0d 00 28  3d f4 20 2a 2a 2a 2a 2a  |eeves..(=. *****|
000000a0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
000000d0  2a 2a 0d 00 32 3d f4 20  69 6e 69 74 69 61 6c 69  |**..2=. initiali|
000000e0  73 65 20 74 68 65 20 64  6f 74 20 6d 61 74 72 69  |se the dot matri|
000000f0  78 20 70 72 69 6e 74 65  72 20 64 72 69 76 65 72  |x printer driver|
00000100  20 73 70 65 63 69 66 69  63 20 70 61 72 74 73 0d  | specific parts.|
00000110  00 3c 3d f4 20 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |.<=. ***********|
00000120  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00000140  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 0d 00 46 05  |************..F.|
00000150  3a 0d 00 50 18 dd f2 50  72 69 6e 74 65 72 5f 69  |:..P...Printer_i|
00000160  6e 69 74 69 61 6c 69 73  65 0d 00 5a 08 ea 20 50  |nitialise..Z.. P|
00000170  25 0d 00 64 1d 50 72 69  6e 74 65 72 43 6c 61 73  |%..d.PrinterClas|
00000180  73 24 3d 22 50 72 69 6e  74 65 72 44 4d 22 0d 00  |s$="PrinterDM"..|
00000190  6e 22 46 75 6c 6c 50 72  69 6e 74 65 72 43 6c 61  |n"FullPrinterCla|
000001a0  73 73 24 3d 22 64 6f 74  20 6d 61 74 72 69 78 22  |ss$="dot matrix"|
000001b0  0d 00 78 14 4f 75 74 70  75 74 54 79 70 65 25 3d  |..x.OutputType%=|
000001c0  26 46 46 34 0d 00 82 40  f4 20 64 65 66 69 6e 65  |&FF4...@. define|
000001d0  20 70 72 69 6e 74 65 72  20 63 6c 61 73 73 20 64  | printer class d|
000001e0  65 70 65 6e 64 65 6e 74  20 66 69 65 6c 64 73 20  |ependent fields |
000001f0  69 6e 20 70 72 69 6e 74  65 72 20 64 61 74 61 20  |in printer data |
00000200  61 72 65 61 0d 00 8c 27  20 20 20 20 64 75 6d 70  |area...'    dump|
00000210  5f 64 65 70 74 68 5f 66  69 65 6c 64 25 20 3d 20  |_depth_field% = |
00000220  a4 70 5f 66 69 65 6c 64  28 31 29 0d 00 96 27 20  |.p_field(1)...' |
00000230  20 20 20 20 69 6e 74 65  72 6c 61 63 65 5f 66 69  |    interlace_fi|
00000240  65 6c 64 25 20 3d 20 a4  70 5f 66 69 65 6c 64 28  |eld% = .p_field(|
00000250  33 29 0d 00 a0 28 20 6c  69 6e 65 5f 70 72 6f 6c  |3)...( line_prol|
00000260  6f 67 75 65 5f 66 69 65  6c 64 25 20 3d 20 a4 70  |ogue_field% = .p|
00000270  5f 66 69 65 6c 64 28 32  30 29 0d 00 aa 28 20 6c  |_field(20)...( l|
00000280  69 6e 65 5f 65 70 69 6c  6f 67 75 65 5f 66 69 65  |ine_epilogue_fie|
00000290  6c 64 25 20 3d 20 a4 70  5f 66 69 65 6c 64 28 32  |ld% = .p_field(2|
000002a0  30 29 0d 00 b4 28 6c 69  6e 65 5f 69 6e 74 65 72  |0)...(line_inter|
000002b0  6c 61 63 65 5f 66 69 65  6c 64 25 20 3d 20 a4 70  |lace_field% = .p|
000002c0  5f 66 69 65 6c 64 28 32  30 29 0d 00 be 28 20 20  |_field(20)...(  |
000002d0  6a 6f 62 5f 65 70 69 6c  6f 67 75 65 5f 66 69 65  |job_epilogue_fie|
000002e0  6c 64 25 20 3d 20 a4 70  5f 66 69 65 6c 64 28 32  |ld% = .p_field(2|
000002f0  30 29 0d 00 c8 28 20 20  6a 6f 62 5f 70 72 6f 6c  |0)...(  job_prol|
00000300  6f 67 75 65 5f 66 69 65  6c 64 25 20 3d 20 a4 70  |ogue_field% = .p|
00000310  5f 66 69 65 6c 64 28 32  30 29 0d 00 d2 27 20 20  |_field(20)...'  |
00000320  20 70 72 69 6e 74 65 72  5f 64 61 74 61 5f 73 69  | printer_data_si|
00000330  7a 65 25 20 3d 20 a4 70  5f 66 69 65 6c 64 28 30  |ze% = .p_field(0|
00000340  29 0d 00 dc 31 f4 20 64  65 66 69 6e 65 20 63 6c  |)...1. define cl|
00000350  61 73 73 20 64 65 70 65  6e 64 65 6e 74 20 69 63  |ass dependent ic|
00000360  6f 6e 73 20 69 6e 20 6d  61 69 6e 20 77 69 6e 64  |ons in main wind|
00000370  6f 77 0d 00 e6 10 6d 61  69 6e 5f 6c 69 6e 65 25  |ow....main_line%|
00000380  3d 32 0d 00 f0 1f 70 72  69 6e 74 65 72 5f 64 61  |=2....printer_da|
00000390  74 61 5f 6c 69 73 74 25  20 3d 20 30 3a 50 25 3d  |ta_list% = 0:P%=|
000003a0  30 0d 00 fa 1d f2 50 72  69 6e 74 65 72 5f 72 65  |0.....Printer_re|
000003b0  61 64 5f 63 6f 6e 66 69  67 5f 66 69 6c 65 0d 01  |ad_config_file..|
000003c0  04 22 f4 20 6e 6f 77 20  63 6f 6e 76 65 72 74 20  |.". now convert |
000003d0  74 6f 20 63 69 72 63 75  6c 61 72 20 6c 69 73 74  |to circular list|
000003e0  0d 01 0e 2d 50 25 21 6c  69 73 74 5f 70 6f 69 6e  |...-P%!list_poin|
000003f0  74 65 72 5f 66 69 65 6c  64 25 3d 70 72 69 6e 74  |ter_field%=print|
00000400  65 72 5f 64 61 74 61 5f  6c 69 73 74 25 0d 01 18  |er_data_list%...|
00000410  05 e1 0d 01 22 05 3a 0d  01 2c 17 f4 20 2a 2a 2a  |....".:..,.. ***|
00000420  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 0d 01  |**************..|
00000430  36 17 f4 20 73 65 74 20  69 6e 69 74 69 61 6c 20  |6.. set initial |
00000440  73 74 61 74 65 0d 01 40  17 f4 20 2a 2a 2a 2a 2a  |state..@.. *****|
00000450  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 0d 01 4a 1f  |************..J.|
00000460  dd f2 50 72 69 6e 74 65  72 5f 73 65 74 5f 69 6e  |..Printer_set_in|
00000470  69 74 69 61 6c 5f 73 74  61 74 65 0d 01 54 08 ea  |itial_state..T..|
00000480  20 44 25 0d 01 5e 17 f4  20 73 65 74 20 64 65 66  | D%..^.. set def|
00000490  61 75 6c 74 20 73 74 61  74 65 0d 01 68 19 44 25  |ault state..h.D%|
000004a0  3d 70 72 69 6e 74 65 72  5f 64 61 74 61 5f 6c 69  |=printer_data_li|
000004b0  73 74 25 0d 01 72 5d c8  95 20 44 25 21 6c 69 73  |st%..r].. D%!lis|
000004c0  74 5f 70 6f 69 6e 74 65  72 5f 66 69 65 6c 64 25  |t_pointer_field%|
000004d0  3c 3e 70 72 69 6e 74 65  72 5f 64 61 74 61 5f 6c  |<>printer_data_l|
000004e0  69 73 74 25 20 80 20 44  25 21 70 72 69 6e 74 65  |ist% . D%!printe|
000004f0  72 5f 6e 75 6d 62 65 72  5f 66 69 65 6c 64 25 3c  |r_number_field%<|
00000500  3e 70 72 69 6e 74 65 72  5f 63 6f 6e 66 69 67 25  |>printer_config%|
00000510  0d 01 7c 1e 20 44 25 3d  44 25 21 6c 69 73 74 5f  |..|. D%=D%!list_|
00000520  70 6f 69 6e 74 65 72 5f  66 69 65 6c 64 25 0d 01  |pointer_field%..|
00000530  86 05 ce 0d 01 90 46 e7  20 44 25 21 70 72 69 6e  |......F. D%!prin|
00000540  74 65 72 5f 6e 75 6d 62  65 72 5f 66 69 65 6c 64  |ter_number_field|
00000550  25 3d 70 72 69 6e 74 65  72 5f 63 6f 6e 66 69 67  |%=printer_config|
00000560  25 20 8c 20 70 72 69 6e  74 65 72 5f 64 61 74 61  |% . printer_data|
00000570  5f 6c 69 73 74 25 3d 44  25 0d 01 9a 1c f2 50 72  |_list%=D%.....Pr|
00000580  69 6e 74 65 72 5f 73 65  74 5f 64 65 73 63 72 69  |inter_set_descri|
00000590  70 74 69 6f 6e 0d 01 a4  1c f2 50 72 69 6e 74 65  |ption.....Printe|
000005a0  72 5f 73 65 74 5f 6d 6f  64 75 6c 65 5f 64 61 74  |r_set_module_dat|
000005b0  61 0d 01 ae 05 e1 0d 01  b8 05 3a 0d 01 c2 0e f4  |a.........:.....|
000005c0  20 2a 2a 2a 2a 2a 2a 2a  2a 0d 01 cc 0e f4 20 73  | ********..... s|
000005d0  68 75 74 64 6f 77 6e 0d  01 d6 0e f4 20 2a 2a 2a  |hutdown..... ***|
000005e0  2a 2a 2a 2a 2a 0d 01 e0  17 dd f2 50 72 69 6e 74  |*****......Print|
000005f0  65 72 5f 74 65 72 6d 69  6e 61 74 65 0d 01 ea 4d  |er_terminate...M|
00000600  2a 69 66 20 22 3c 50 72  69 6e 74 65 72 24 53 63  |*if "<Printer$Sc|
00000610  72 61 70 3e 22 20 3d 20  22 3c 50 44 72 69 76 65  |rap>" = "<PDrive|
00000620  72 24 44 69 72 3e 2e 44  4d 21 53 63 72 61 70 22  |r$Dir>.DM!Scrap"|
00000630  20 74 68 65 6e 20 75 6e  73 65 74 20 50 72 69 6e  | then unset Prin|
00000640  74 65 72 24 53 63 72 61  70 0d 01 f4 4a 2a 69 66  |ter$Scrap...J*if|
00000650  20 22 3c 50 72 69 6e 74  65 72 24 54 65 6d 70 3e  | "<Printer$Temp>|
00000660  22 20 3d 20 22 3c 50 44  72 69 76 65 72 24 44 69  |" = "<PDriver$Di|
00000670  72 3e 2e 44 4d 21 54 65  6d 70 22 20 74 68 65 6e  |r>.DM!Temp" then|
00000680  20 75 6e 73 65 74 20 50  72 69 6e 74 65 72 24 54  | unset Printer$T|
00000690  65 6d 70 0d 01 fe 05 e1  0d 02 08 05 3a 0d 02 12  |emp.........:...|
000006a0  2c f4 20 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |,. *************|
000006b0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
000006c0  2a 2a 2a 2a 2a 2a 2a 2a  2a 0d 02 1c 2b f4 20 74  |*********...+. t|
000006d0  68 65 20 70 72 69 6e 74  65 72 2d 73 70 65 63 69  |he printer-speci|
000006e0  66 69 63 20 74 65 6d 70  6c 61 74 65 20 6c 6f 61  |fic template loa|
000006f0  64 69 6e 67 0d 02 26 2c  f4 20 2a 2a 2a 2a 2a 2a  |ding..&,. ******|
00000700  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00000720  0d 02 30 1c dd f2 50 72  69 6e 74 65 72 5f 6c 6f  |..0...Printer_lo|
00000730  61 64 5f 74 65 6d 70 6c  61 74 65 73 0d 02 3a 3e  |ad_templates..:>|
00000740  f2 73 65 74 5f 69 63 6f  6e 5f 73 74 61 74 65 28  |.set_icon_state(|
00000750  6d 61 69 6e 25 2c 20 6d  61 69 6e 5f 6c 69 6e 65  |main%, main_line|
00000760  25 2c 20 6c 69 6e 65 5f  6e 65 77 25 20 3c 3c 20  |%, line_new% << |
00000770  32 31 2c 20 31 3c 3c 32  31 29 0d 02 44 05 e1 0d  |21, 1<<21)..D...|
00000780  02 4e 05 3a 0d 02 58 29  f4 20 2a 2a 2a 2a 2a 2a  |.N.:..X). ******|
00000790  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
000007a0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 0d 02 62  |*************..b|
000007b0  28 f4 20 74 68 65 20 70  72 69 6e 74 65 72 2d 73  |(. the printer-s|
000007c0  70 65 63 69 66 69 63 20  65 76 65 6e 74 20 68 61  |pecific event ha|
000007d0  6e 64 6c 65 72 0d 02 6c  29 f4 20 2a 2a 2a 2a 2a  |ndler..l). *****|
000007e0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
000007f0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 0d 02  |**************..|
00000800  76 28 dd a4 50 72 69 6e  74 65 72 5f 70 72 6f 63  |v(..Printer_proc|
00000810  65 73 73 5f 65 76 65 6e  74 28 61 63 74 69 6f 6e  |ess_event(action|
00000820  25 2c 20 45 25 29 0d 02  80 0a ea 20 72 65 73 25  |%, E%)..... res%|
00000830  0d 02 8a 0a 72 65 73 25  3d a3 0d 02 94 10 c8 8e  |....res%=.......|
00000840  20 61 63 74 69 6f 6e 25  20 ca 0d 02 9e 0d 20 c9  | action% ..... .|
00000850  20 31 37 2c 31 38 3a 0d  02 a8 10 20 20 c8 8e 20  | 17,18:....  .. |
00000860  45 25 21 31 36 20 ca 0d  02 b2 0e 20 20 20 c9 20  |E%!16 .....   . |
00000870  26 35 30 32 3a 0d 02 bc  86 20 20 20 20 e7 20 45  |&502:....    . E|
00000880  25 21 33 32 20 3d 20 6d  61 69 6e 25 20 80 20 45  |%!32 = main% . E|
00000890  25 21 33 36 20 3e 3d 20  2d 31 20 8c 20 f2 68 65  |%!36 >= -1 . .he|
000008a0  6c 70 72 65 70 6c 79 28  22 50 72 69 6e 74 65 72  |lpreply("Printer|
000008b0  20 73 65 74 75 70 2e 7c  4d 43 6c 69 63 6b 20 53  | setup.|MClick S|
000008c0  45 4c 45 43 54 20 6f 72  20 41 44 4a 55 53 54 20  |ELECT or ADJUST |
000008d0  74 6f 20 61 6c 74 65 72  20 74 68 65 20 73 65 74  |to alter the set|
000008e0  74 69 6e 67 73 2e 22 2c  45 25 21 38 2c 45 25 21  |tings.",E%!8,E%!|
000008f0  34 29 3a 72 65 73 25 20  3d 20 b9 0d 02 c6 07 20  |4):res% = ..... |
00000900  20 cb 0d 02 d0 08 20 c9  20 36 0d 02 da 23 20 20  | ..... . 6...#  |
00000910  e7 20 45 25 21 31 32 3d  6d 61 69 6e 25 20 80 20  |. E%!12=main% . |
00000920  ac 20 70 72 69 6e 74 5f  6f 6e 25 20 8c 0d 02 e4  |. print_on% ....|
00000930  0d 20 20 20 c8 8e 20 b9  20 ca 0d 02 ee 1b 20 20  |.   .. . .....  |
00000940  20 20 c9 20 28 45 25 21  38 20 80 20 25 31 30 31  |  . (E%!8 . %101|
00000950  29 3c 3e 30 3a 0d 02 f8  13 20 20 20 20 20 c8 8e  |)<>0:....     ..|
00000960  20 45 25 21 31 36 20 ca  0d 03 02 1e 20 20 20 20  | E%!16 .....    |
00000970  20 20 c9 20 6d 61 69 6e  5f 64 65 73 63 72 69 70  |  . main_descrip|
00000980  74 69 6f 6e 25 3a 0d 03  0c 17 20 20 20 20 20 20  |tion%:....      |
00000990  20 e7 20 45 25 21 38 20  80 20 31 20 8c 0d 03 16  | . E%!8 . 1 ....|
000009a0  25 20 20 20 20 20 20 20  20 72 65 73 25 20 3d 20  |%        res% = |
000009b0  70 72 69 6e 74 65 72 5f  64 61 74 61 5f 6c 69 73  |printer_data_lis|
000009c0  74 25 0d 03 20 49 20 20  20 20 20 20 20 20 f5 20  |t%.. I        . |
000009d0  70 72 69 6e 74 65 72 5f  64 61 74 61 5f 6c 69 73  |printer_data_lis|
000009e0  74 25 20 3d 20 70 72 69  6e 74 65 72 5f 64 61 74  |t% = printer_dat|
000009f0  61 5f 6c 69 73 74 25 21  6c 69 73 74 5f 70 6f 69  |a_list%!list_poi|
00000a00  6e 74 65 72 5f 66 69 65  6c 64 25 0d 03 2a 3b 20  |nter_field%..*; |
00000a10  20 20 20 20 20 20 20 fd  20 70 72 69 6e 74 65 72  |       . printer|
00000a20  5f 64 61 74 61 5f 6c 69  73 74 25 21 6c 69 73 74  |_data_list%!list|
00000a30  5f 70 6f 69 6e 74 65 72  5f 66 69 65 6c 64 25 20  |_pointer_field% |
00000a40  3d 20 72 65 73 25 0d 03  34 0c 20 20 20 20 20 20  |= res%..4.      |
00000a50  20 cc 0d 03 3e 47 20 20  20 20 20 20 20 20 70 72  | ...>G        pr|
00000a60  69 6e 74 65 72 5f 64 61  74 61 5f 6c 69 73 74 25  |inter_data_list%|
00000a70  20 3d 20 70 72 69 6e 74  65 72 5f 64 61 74 61 5f  | = printer_data_|
00000a80  6c 69 73 74 25 21 6c 69  73 74 5f 70 6f 69 6e 74  |list%!list_point|
00000a90  65 72 5f 66 69 65 6c 64  25 0d 03 48 0c 20 20 20  |er_field%..H.   |
00000aa0  20 20 20 20 cd 0d 03 52  23 20 20 20 20 20 20 20  |    ...R#       |
00000ab0  f2 50 72 69 6e 74 65 72  5f 73 65 74 5f 64 65 73  |.Printer_set_des|
00000ac0  63 72 69 70 74 69 6f 6e  0d 03 5c 23 20 20 20 20  |cription..\#    |
00000ad0  20 20 20 f2 50 72 69 6e  74 65 72 5f 73 65 74 5f  |   .Printer_set_|
00000ae0  6d 6f 64 75 6c 65 5f 64  61 74 61 0d 03 66 42 20  |module_data..fB |
00000af0  20 20 20 20 20 20 70 72  69 6e 74 65 72 5f 6e 65  |      printer_ne|
00000b00  77 25 20 3d 20 70 72 69  6e 74 65 72 5f 64 61 74  |w% = printer_dat|
00000b10  61 5f 6c 69 73 74 25 21  70 72 69 6e 74 65 72 5f  |a_list%!printer_|
00000b20  6e 75 6d 62 65 72 5f 66  69 65 6c 64 25 0d 03 70  |number_field%..p|
00000b30  11 20 20 20 20 20 20 20  72 65 73 25 3d b9 0d 03  |.       res%=...|
00000b40  7a 16 20 20 20 20 20 20  c9 20 6d 61 69 6e 5f 6c  |z.      . main_l|
00000b50  69 6e 65 25 0d 03 84 14  20 20 20 20 20 20 20 21  |ine%....       !|
00000b60  71 25 3d 6d 61 69 6e 25  0d 03 8e 1a 20 20 20 20  |q%=main%....    |
00000b70  20 20 20 71 25 21 34 3d  6d 61 69 6e 5f 6c 69 6e  |   q%!4=main_lin|
00000b80  65 25 0d 03 98 25 20 20  20 20 20 20 20 c8 99 20  |e%...%       .. |
00000b90  22 57 69 6d 70 5f 47 65  74 49 63 6f 6e 53 74 61  |"Wimp_GetIconSta|
00000ba0  74 65 22 2c 2c 71 25 0d  03 a2 28 20 20 20 20 20  |te",,q%...(     |
00000bb0  20 20 6c 69 6e 65 5f 6e  65 77 25 20 3d 20 28 71  |  line_new% = (q|
00000bc0  25 21 32 34 20 3e 3e 20  32 31 29 20 80 20 31 0d  |%!24 >> 21) . 1.|
00000bd0  03 ac 0a 20 20 20 20 20  cb 0d 03 b6 08 20 20 20  |...     .....   |
00000be0  cb 0d 03 c0 07 20 20 cd  0d 03 ca 05 cb 0d 03 d4  |.....  .........|
00000bf0  09 3d 72 65 73 25 0d 03  de 05 3a 0d 03 e8 47 f4  |.=res%....:...G.|
00000c00  20 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  | ***************|
00000c10  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00000c40  2a 2a 0d 03 f2 46 f4 20  72 65 61 64 20 74 68 65  |**...F. read the|
00000c50  20 63 6f 6e 66 69 67 75  72 61 74 69 6f 6e 20 66  | configuration f|
00000c60  69 6c 65 20 77 69 74 68  20 61 6c 6c 20 74 68 65  |ile with all the|
00000c70  20 69 6e 64 69 76 69 64  75 61 6c 20 70 72 69 6e  | individual prin|
00000c80  74 65 72 20 69 6e 66 6f  0d 03 fc 47 f4 20 2a 2a  |ter info...G. **|
00000c90  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00000cc0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 0d  |***************.|
00000cd0  04 06 1e dd f2 50 72 69  6e 74 65 72 5f 72 65 61  |.....Printer_rea|
00000ce0  64 5f 63 6f 6e 66 69 67  5f 66 69 6c 65 0d 04 10  |d_config_file...|
00000cf0  0d ea 20 48 25 2c 70 74  72 25 0d 04 1a 22 de 20  |.. H%,ptr%...". |
00000d00  64 65 66 61 75 6c 74 73  25 20 70 72 69 6e 74 65  |defaults% printe|
00000d10  72 5f 64 61 74 61 5f 73  69 7a 65 25 0d 04 24 36  |r_data_size%..$6|
00000d20  e3 20 48 25 3d 30 20 b8  20 70 72 69 6e 74 65 72  |. H%=0 . printer|
00000d30  5f 64 61 74 61 5f 73 69  7a 65 25 2d 34 20 88 20  |_data_size%-4 . |
00000d40  34 3a 64 65 66 61 75 6c  74 73 25 21 48 25 3d 30  |4:defaults%!H%=0|
00000d50  3a ed 0d 04 2e 1d 70 72  69 6e 74 65 72 5f 64 61  |:.....printer_da|
00000d60  74 61 25 20 3d 20 64 65  66 61 75 6c 74 73 25 0d  |ta% = defaults%.|
00000d70  04 38 1e 48 25 3d 8e 22  3c 50 44 72 69 76 65 72  |.8.H%=."<PDriver|
00000d80  24 64 69 72 3e 2e 50 72  44 61 74 61 22 0d 04 42  |$dir>.PrData"..B|
00000d90  2f e7 20 48 25 3d 30 20  85 20 31 30 30 2c 22 43  |/. H%=0 . 100,"C|
00000da0  61 6e 27 74 20 72 65 61  64 20 70 72 69 6e 74 65  |an't read printe|
00000db0  72 20 64 61 74 61 20 66  69 6c 65 22 0d 04 4c 05  |r data file"..L.|
00000dc0  f5 0d 04 56 10 20 70 74  72 25 20 3d 20 8f 23 48  |...V. ptr% = .#H|
00000dd0  25 0d 04 60 1e 20 f2 50  72 69 6e 74 65 72 5f 70  |%..`. .Printer_p|
00000de0  72 6f 63 65 73 73 5f 6c  69 6e 65 28 48 25 29 0d  |rocess_line(H%).|
00000df0  04 6a 0a fd 20 c5 23 48  25 0d 04 74 08 d9 23 48  |.j.. .#H%..t..#H|
00000e00  25 0d 04 7e 05 e1 0d 04  88 05 3a 0d 04 92 33 f4  |%..~......:...3.|
00000e10  20 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  | ***************|
00000e20  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
00000e30  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 0d 04  |**************..|
00000e40  9c 32 f4 20 70 72 6f 63  65 73 73 20 6f 6e 65 20  |.2. process one |
00000e50  6c 69 6e 65 20 66 72 6f  6d 20 74 68 65 20 63 6f  |line from the co|
00000e60  6e 66 69 67 75 72 61 74  69 6f 6e 20 66 69 6c 65  |nfiguration file|
00000e70  0d 04 a6 33 f4 20 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |...3. **********|
00000e80  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00000ea0  2a 2a 2a 0d 04 b0 1e dd  f2 50 72 69 6e 74 65 72  |***......Printer|
00000eb0  5f 70 72 6f 63 65 73 73  5f 6c 69 6e 65 28 48 25  |_process_line(H%|
00000ec0  29 0d 04 ba 10 ea 20 49  25 2c 4a 25 2c 74 61 67  |)..... I%,J%,tag|
00000ed0  24 0d 04 c4 0e 24 62 75  66 25 3d be 23 48 25 0d  |$....$buf%=.#H%.|
00000ee0  04 ce 08 49 25 3d 30 0d  04 d8 23 c8 95 20 a4 74  |...I%=0...#.. .t|
00000ef0  61 67 63 68 61 72 28 62  75 66 25 3f 49 25 29 3a  |agchar(buf%?I%):|
00000f00  20 49 25 20 2b 3d 20 31  3a ce 0d 04 e2 16 e7 20  | I% += 1:...... |
00000f10  62 75 66 25 3f 49 25 20  3d 20 97 22 3a 22 20 8c  |buf%?I% = .":" .|
00000f20  0d 04 ec 10 20 f4 20 67  6f 74 20 61 20 74 61 67  |.... . got a tag|
00000f30  0d 04 f6 20 20 74 61 67  24 3d a4 6c 6f 77 65 72  |...  tag$=.lower|
00000f40  63 61 73 65 28 c0 24 62  75 66 25 2c 49 25 29 29  |case(.$buf%,I%))|
00000f50  0d 05 00 0c 20 49 25 20  2b 3d 20 31 0d 05 0a 1f  |.... I% += 1....|
00000f60  20 c8 95 20 62 75 66 25  3f 49 25 3d 97 22 20 22  | .. buf%?I%=." "|
00000f70  3a 20 49 25 20 2b 3d 20  31 3a ce 0d 05 14 0e 20  |: I% += 1:..... |
00000f80  c8 8e 20 74 61 67 24 20  ca 0d 05 1e 16 20 20 c9  |.. tag$ .....  .|
00000f90  20 22 70 72 69 6e 74 65  72 5f 6e 61 6d 65 22 0d  | "printer_name".|
00000fa0  05 28 15 20 20 20 f4 20  62 75 69 6c 64 20 61 20  |.(.   . build a |
00000fb0  6e 61 6d 65 0d 05 32 23  20 20 20 de 20 64 65 73  |name..2#   . des|
00000fc0  63 72 69 70 74 69 6f 6e  25 20 a9 24 62 75 66 25  |cription% .$buf%|
00000fd0  20 2d 49 25 20 2b 31 0d  05 3c 28 20 20 20 24 64  | -I% +1..<(   $d|
00000fe0  65 73 63 72 69 70 74 69  6f 6e 25 20 3d 20 c2 24  |escription% = .$|
00000ff0  62 75 66 25 2c a9 24 62  75 66 25 2d 49 25 29 0d  |buf%,.$buf%-I%).|
00001000  05 46 3b 20 20 20 f4 20  6e 6f 77 20 61 64 64 20  |.F;   . now add |
00001010  61 20 62 6c 6f 63 6b 20  74 6f 20 6f 75 72 20 6c  |a block to our l|
00001020  69 73 74 20 6f 66 20 70  72 69 6e 74 65 72 20 64  |ist of printer d|
00001030  61 74 61 20 62 6c 6f 63  6b 73 0d 05 50 29 20 20  |ata blocks..P)  |
00001040  20 de 20 70 72 69 6e 74  65 72 5f 64 61 74 61 25  | . printer_data%|
00001050  20 70 72 69 6e 74 65 72  5f 64 61 74 61 5f 73 69  | printer_data_si|
00001060  7a 65 25 0d 05 5a 28 20  20 20 e3 20 49 25 3d 30  |ze%..Z(   . I%=0|
00001070  20 b8 20 70 72 69 6e 74  65 72 5f 64 61 74 61 5f  | . printer_data_|
00001080  73 69 7a 65 25 2d 34 20  88 20 34 0d 05 64 28 20  |size%-4 . 4..d( |
00001090  20 20 20 20 70 72 69 6e  74 65 72 5f 64 61 74 61  |    printer_data|
000010a0  25 21 49 25 20 3d 20 64  65 66 61 75 6c 74 73 25  |%!I% = defaults%|
000010b0  21 49 25 0d 05 6e 08 20  20 20 ed 0d 05 78 36 20  |!I%..n.   ...x6 |
000010c0  20 20 70 72 69 6e 74 65  72 5f 64 61 74 61 25 21  |  printer_data%!|
000010d0  64 65 73 63 72 69 70 74  69 6f 6e 5f 66 69 65 6c  |description_fiel|
000010e0  64 25 20 3d 20 64 65 73  63 72 69 70 74 69 6f 6e  |d% = description|
000010f0  25 0d 05 82 0f 20 20 20  e7 20 50 25 3d 30 20 8c  |%....   . P%=0 .|
00001100  0d 05 8c 2a 20 20 20 20  70 72 69 6e 74 65 72 5f  |...*    printer_|
00001110  64 61 74 61 5f 6c 69 73  74 25 20 3d 20 70 72 69  |data_list% = pri|
00001120  6e 74 65 72 5f 64 61 74  61 25 0d 05 96 08 20 20  |nter_data%....  |
00001130  20 cc 0d 05 a0 2e 20 20  20 20 50 25 21 6c 69 73  | .....    P%!lis|
00001140  74 5f 70 6f 69 6e 74 65  72 5f 66 69 65 6c 64 25  |t_pointer_field%|
00001150  20 3d 20 70 72 69 6e 74  65 72 5f 64 61 74 61 25  | = printer_data%|
00001160  0d 05 aa 08 20 20 20 cd  0d 05 b4 19 20 20 20 50  |....   .....   P|
00001170  25 20 3d 20 70 72 69 6e  74 65 72 5f 64 61 74 61  |% = printer_data|
00001180  25 0d 05 be a2 20 20 c9  20 22 70 78 72 65 73 22  |%....  . "pxres"|
00001190  2c 22 70 79 72 65 73 22  2c 22 66 65 61 74 75 72  |,"pyres","featur|
000011a0  65 73 22 2c 22 70 78 72  65 73 5f 68 61 6c 66 74  |es","pxres_halft|
000011b0  6f 6e 65 22 2c 22 70 79  72 65 73 5f 68 61 6c 66  |one","pyres_half|
000011c0  74 6f 6e 65 22 2c 22 70  72 69 6e 74 65 72 5f 6e  |tone","printer_n|
000011d0  75 6d 62 65 72 22 2c 22  70 61 67 65 5f 77 69 64  |umber","page_wid|
000011e0  74 68 22 2c 22 70 61 67  65 5f 68 65 69 67 68 74  |th","page_height|
000011f0  22 2c 22 70 61 67 65 5f  62 6f 74 74 6f 6d 22 2c  |","page_bottom",|
00001200  22 70 61 67 65 5f 74 6f  70 22 2c 22 70 61 67 65  |"page_top","page|
00001210  5f 6c 65 66 74 22 2c 22  70 61 67 65 5f 72 69 67  |_left","page_rig|
00001220  68 74 22 0d 05 c8 48 20  20 20 f4 20 6e 6f 74 65  |ht"...H   . note|
00001230  20 74 68 61 74 20 61 6c  6c 20 74 61 67 73 20 61  | that all tags a|
00001240  72 65 20 74 68 65 20 73  61 6d 65 20 61 73 20 74  |re the same as t|
00001250  68 65 69 72 20 72 65 73  70 65 63 74 69 76 65 20  |heir respective |
00001260  66 69 65 6c 64 20 6e 61  6d 65 73 0d 05 d2 54 20  |field names...T |
00001270  20 20 70 72 69 6e 74 65  72 5f 64 61 74 61 25 21  |  printer_data%!|
00001280  a0 28 74 61 67 24 2b 22  5f 66 69 65 6c 64 25 22  |.(tag$+"_field%"|
00001290  29 20 3d 20 a4 72 65 61  64 5f 69 6e 74 65 67 65  |) = .read_intege|
000012a0  72 5f 65 78 70 72 65 73  73 69 6f 6e 28 c2 24 62  |r_expression(.$b|
000012b0  75 66 25 2c a9 24 62 75  66 25 2d 49 25 29 29 0d  |uf%,.$buf%-I%)).|
000012c0  05 dc 20 20 20 c9 20 22  64 75 6d 70 5f 64 65 70  |..   . "dump_dep|
000012d0  74 68 22 2c 22 69 6e 74  65 72 6c 61 63 65 22 0d  |th","interlace".|
000012e0  05 e6 54 20 20 20 70 72  69 6e 74 65 72 5f 64 61  |..T   printer_da|
000012f0  74 61 25 3f a0 28 74 61  67 24 2b 22 5f 66 69 65  |ta%?.(tag$+"_fie|
00001300  6c 64 25 22 29 20 3d 20  a4 72 65 61 64 5f 69 6e  |ld%") = .read_in|
00001310  74 65 67 65 72 5f 65 78  70 72 65 73 73 69 6f 6e  |teger_expression|
00001320  28 c2 24 62 75 66 25 2c  a9 24 62 75 66 25 2d 49  |(.$buf%,.$buf%-I|
00001330  25 29 29 0d 05 f0 56 20  20 c9 20 22 6c 69 6e 65  |%))...V  . "line|
00001340  5f 70 72 6f 6c 6f 67 75  65 22 2c 22 6c 69 6e 65  |_prologue","line|
00001350  5f 65 70 69 6c 6f 67 75  65 22 2c 22 6c 69 6e 65  |_epilogue","line|
00001360  5f 69 6e 74 65 72 6c 61  63 65 22 2c 22 6a 6f 62  |_interlace","job|
00001370  5f 70 72 6f 6c 6f 67 75  65 22 2c 22 6a 6f 62 5f  |_prologue","job_|
00001380  65 70 69 6c 6f 67 75 65  22 0d 05 fa 1e 20 20 20  |epilogue"....   |
00001390  c8 95 20 62 75 66 25 3f  49 25 3d 97 22 20 22 3a  |.. buf%?I%=." ":|
000013a0  49 25 2b 3d 31 3a ce 0d  06 04 1d 20 20 20 4a 25  |I%+=1:.....   J%|
000013b0  20 3d 20 a0 28 74 61 67  24 2b 22 5f 66 69 65 6c  | = .(tag$+"_fiel|
000013c0  64 25 22 29 0d 06 0e 3b  20 20 20 c8 99 20 22 4f  |d%")...;   .. "O|
000013d0  53 5f 47 53 54 72 61 6e  73 22 2c 62 75 66 25 2b  |S_GSTrans",buf%+|
000013e0  49 25 2c 70 72 69 6e 74  65 72 5f 64 61 74 61 25  |I%,printer_data%|
000013f0  2b 31 2b 4a 25 2c 32 30  20 b8 20 2c 2c 49 25 0d  |+1+J%,20 . ,,I%.|
00001400  06 18 1c 20 20 20 70 72  69 6e 74 65 72 5f 64 61  |...   printer_da|
00001410  74 61 25 3f 4a 25 20 3d  20 49 25 0d 06 22 10 20  |ta%?J% = I%..". |
00001420  20 c9 20 22 73 65 72 76  65 72 22 0d 06 2c 0e 20  | . "server"..,. |
00001430  20 20 4a 25 20 3d 20 49  25 0d 06 36 27 20 20 20  |  J% = I%..6'   |
00001440  c8 95 20 62 75 66 25 3f  4a 25 3e 3d 97 22 20 22  |.. buf%?J%>=." "|
00001450  20 80 20 62 75 66 25 3f  4a 25 3c 3e 97 22 3b 22  | . buf%?J%<>.";"|
00001460  0d 06 40 0f 20 20 20 20  4a 25 20 2b 3d 20 31 0d  |..@.    J% += 1.|
00001470  06 4a 08 20 20 20 ce 0d  06 54 24 20 20 20 f4 20  |.J.   ...T$   . |
00001480  66 72 6f 6d 20 49 25 20  74 6f 20 4a 25 20 69 73  |from I% to J% is|
00001490  20 74 68 65 20 73 74 72  69 6e 67 0d 06 5e 1e 20  | the string..^. |
000014a0  20 20 73 65 72 76 65 72  5f 70 74 72 25 20 3d 20  |  server_ptr% = |
000014b0  70 74 72 25 20 2b 20 49  25 0d 06 68 2c 20 20 20  |ptr% + I%..h,   |
000014c0  73 65 72 76 65 72 5f 63  6f 6e 66 69 67 24 20 3d  |server_config$ =|
000014d0  20 c1 24 62 75 66 25 2c  20 49 25 2b 31 2c 20 4a  | .$buf%, I%+1, J|
000014e0  25 2d 49 25 29 0d 06 72  11 20 20 c9 20 22 70 72  |%-I%)..r.  . "pr|
000014f0  69 6e 74 65 72 22 0d 06  7c 1e 20 20 20 70 72 69  |inter"..|.   pri|
00001500  6e 74 65 72 5f 63 6f 6e  66 69 67 25 20 3d 20 a4  |nter_config% = .|
00001510  72 65 61 64 0d 06 86 25  20 20 20 70 72 69 6e 74  |read...%   print|
00001520  65 72 5f 6e 65 77 25 20  3d 20 70 72 69 6e 74 65  |er_new% = printe|
00001530  72 5f 63 6f 6e 66 69 67  25 0d 06 90 1f 20 20 20  |r_config%....   |
00001540  70 72 69 6e 74 65 72 5f  70 74 72 25 20 3d 20 70  |printer_ptr% = p|
00001550  74 72 25 20 2b 20 49 25  0d 06 9a 12 20 20 c9 20  |tr% + I%....  . |
00001560  22 6c 6f 63 61 74 69 6f  6e 22 0d 06 a4 1f 20 20  |"location"....  |
00001570  20 6c 6f 63 61 74 69 6f  6e 5f 63 6f 6e 66 69 67  | location_config|
00001580  25 20 3d 20 a4 72 65 61  64 0d 06 ae 20 20 20 20  |% = .read...    |
00001590  6c 6f 63 61 74 69 6f 6e  5f 70 74 72 25 20 3d 20  |location_ptr% = |
000015a0  70 74 72 25 20 2b 20 49  25 0d 06 b8 0e 20 20 c9  |ptr% + I%....  .|
000015b0  20 22 62 61 75 64 22 0d  06 c2 1b 20 20 20 62 61  | "baud"....   ba|
000015c0  75 64 5f 63 6f 6e 66 69  67 25 20 3d 20 a4 72 65  |ud_config% = .re|
000015d0  61 64 0d 06 cc 1c 20 20  20 62 61 75 64 5f 70 74  |ad....   baud_pt|
000015e0  72 25 20 3d 20 70 74 72  25 20 2b 20 49 25 0d 06  |r% = ptr% + I%..|
000015f0  d6 0e 20 20 c9 20 22 64  61 74 61 22 0d 06 e0 1b  |..  . "data"....|
00001600  20 20 20 64 61 74 61 5f  63 6f 6e 66 69 67 25 20  |   data_config% |
00001610  3d 20 a4 72 65 61 64 0d  06 ea 1c 20 20 20 64 61  |= .read....   da|
00001620  74 61 5f 70 74 72 25 20  3d 20 70 74 72 25 20 2b  |ta_ptr% = ptr% +|
00001630  20 49 25 0d 06 f4 0d 20  20 c9 20 22 78 6f 6e 22  | I%....  . "xon"|
00001640  0d 06 fe 1a 20 20 20 58  4f 4e 5f 63 6f 6e 66 69  |....   XON_confi|
00001650  67 25 20 3d 20 a4 72 65  61 64 0d 07 08 1d 20 20  |g% = .read....  |
00001660  20 58 4f 4e 5f 6e 65 77  25 20 3d 20 58 4f 4e 5f  | XON_new% = XON_|
00001670  63 6f 6e 66 69 67 25 0d  07 12 1b 20 20 20 58 4f  |config%....   XO|
00001680  4e 5f 70 74 72 25 20 3d  20 70 74 72 25 20 2b 20  |N_ptr% = ptr% + |
00001690  49 25 0d 07 1c 0e 20 20  c9 20 22 6c 69 6e 65 22  |I%....  . "line"|
000016a0  0d 07 26 1b 20 20 20 6c  69 6e 65 5f 63 6f 6e 66  |..&.   line_conf|
000016b0  69 67 25 20 3d 20 a4 72  65 61 64 0d 07 30 1f 20  |ig% = .read..0. |
000016c0  20 20 6c 69 6e 65 5f 6e  65 77 25 20 3d 20 6c 69  |  line_new% = li|
000016d0  6e 65 5f 63 6f 6e 66 69  67 25 0d 07 3a 1c 20 20  |ne_config%..:.  |
000016e0  20 6c 69 6e 65 5f 70 74  72 25 20 3d 20 70 74 72  | line_ptr% = ptr|
000016f0  25 20 2b 20 49 25 0d 07  44 06 20 cb 0d 07 4e 05  |% + I%..D. ...N.|
00001700  cd 0d 07 58 05 e1 0d 07  62 05 3a 0d 07 6c 36 dd  |...X....b.:..l6.|
00001710  a4 72 65 61 64 3d a4 72  65 61 64 5f 69 6e 74 65  |.read=.read_inte|
00001720  67 65 72 5f 65 78 70 72  65 73 73 69 6f 6e 28 c2  |ger_expression(.|
00001730  24 62 75 66 25 2c a9 24  62 75 66 25 2d 49 25 29  |$buf%,.$buf%-I%)|
00001740  29 0d 07 76 05 3a 0d 07  80 2d f4 20 2a 2a 2a 2a  |)..v.:...-. ****|
00001750  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00001770  2a 2a 2a 0d 07 8a 24 f4  20 63 6f 6e 76 65 72 74  |***...$. convert|
00001780  20 61 20 73 74 72 69 6e  67 20 74 6f 20 61 6e 20  | a string to an |
00001790  69 6e 74 65 67 65 72 0d  07 94 2d f4 20 2a 2a 2a  |integer...-. ***|
000017a0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
000017c0  2a 2a 2a 2a 0d 07 9e 21  dd a4 72 65 61 64 5f 69  |****...!..read_i|
000017d0  6e 74 65 67 65 72 5f 65  78 70 72 65 73 73 69 6f  |nteger_expressio|
000017e0  6e 28 53 24 29 0d 07 a8  14 ea 20 52 25 2c 20 54  |n(S$)..... R%, T|
000017f0  25 2c 20 45 24 2c 20 50  25 0d 07 b2 09 45 24 3d  |%, E$, P%....E$=|
00001800  22 22 0d 07 bc 1c f4 20  67 65 74 20 72 69 64 20  |""..... get rid |
00001810  6f 66 20 61 6e 79 20 63  6f 6d 6d 65 6e 74 0d 07  |of any comment..|
00001820  c6 1f c8 95 20 c0 53 24  2c 31 29 20 3c 3e 20 22  |.... .S$,1) <> "|
00001830  3b 22 20 80 20 a9 53 24  20 3c 3e 20 30 0d 07 d0  |;" . .S$ <> 0...|
00001840  11 20 45 24 20 2b 3d 20  c0 53 24 2c 31 29 0d 07  |. E$ += .S$,1)..|
00001850  da 14 20 53 24 20 3d 20  c2 53 24 2c a9 53 24 2d  |.. S$ = .S$,.S$-|
00001860  31 29 0d 07 e4 05 ce 0d  07 ee 36 c8 99 22 58 4f  |1)........6.."XO|
00001870  53 5f 45 76 61 6c 75 61  74 65 45 78 70 72 65 73  |S_EvaluateExpres|
00001880  73 69 6f 6e 22 2c 45 24  2c 62 75 66 25 2c 32 35  |sion",E$,buf%,25|
00001890  36 20 b8 20 2c 54 25 2c  52 25 3b 50 25 0d 07 f8  |6 . ,T%,R%;P%...|
000018a0  40 e7 20 54 25 20 3c 3e  20 30 20 84 20 28 50 25  |@. T% <> 0 . (P%|
000018b0  20 80 20 31 29 20 85 20  31 30 30 2c 20 22 49 6e  | . 1) . 100, "In|
000018c0  74 65 67 65 72 20 76 61  6c 75 65 20 6e 65 65 64  |teger value need|
000018d0  65 64 20 66 6f 72 20 22  2b 74 61 67 24 0d 08 02  |ed for "+tag$...|
000018e0  07 3d 52 25 0d 08 0c 05  3a 0d 08 16 2d f4 20 2a  |.=R%....:...-. *|
000018f0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00001910  2a 2a 2a 2a 2a 2a 0d 08  20 2c f4 20 61 6c 6c 6f  |******.. ,. allo|
00001920  77 20 6f 6e 6c 79 20 61  6c 70 68 61 6e 75 6d 65  |w only alphanume|
00001930  72 69 63 73 20 69 6e 20  74 61 67 20 66 69 65 6c  |rics in tag fiel|
00001940  64 73 0d 08 2a 2d f4 20  2a 2a 2a 2a 2a 2a 2a 2a  |ds..*-. ********|
00001950  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
00001960  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 0d  |***************.|
00001970  08 34 11 dd a4 74 61 67  63 68 61 72 28 43 25 29  |.4...tagchar(C%)|
00001980  0d 08 3e 24 e7 20 28 43  25 20 3e 3d 20 97 22 41  |..>$. (C% >= ."A|
00001990  22 20 80 20 43 25 20 3c  3d 20 97 22 5a 22 29 20  |" . C% <= ."Z") |
000019a0  8c 20 3d b9 0d 08 48 24  e7 20 28 43 25 20 3e 3d  |. =...H$. (C% >=|
000019b0  20 97 22 61 22 20 80 20  43 25 20 3c 3d 20 97 22  | ."a" . C% <= ."|
000019c0  7a 22 29 20 8c 20 3d b9  0d 08 52 2c 3d 20 20 28  |z") . =...R,=  (|
000019d0  43 25 20 3e 3d 20 97 22  30 22 20 80 20 43 25 20  |C% >= ."0" . C% |
000019e0  3c 3d 20 97 22 39 22 29  20 84 20 43 25 20 3d 20  |<= ."9") . C% = |
000019f0  97 22 5f 22 0d 08 5c 05  3a 0d 08 66 4b f4 20 2a  |."_"..\.:..fK. *|
00001a00  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00001a40  2a 2a 2a 2a 0d 08 70 4b  f4 20 73 65 74 20 74 68  |****..pK. set th|
00001a50  65 20 70 72 69 6e 74 65  72 20 64 72 69 76 65 72  |e printer driver|
00001a60  20 6d 6f 64 75 6c 65 27  73 20 73 74 61 74 65 20  | module's state |
00001a70  74 6f 20 72 65 66 6c 65  63 74 20 74 68 65 20 63  |to reflect the c|
00001a80  75 72 72 65 6e 74 20 73  65 74 74 69 6e 67 73 0d  |urrent settings.|
00001a90  08 7a 4b f4 20 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |.zK. ***********|
00001aa0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00001ad0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 0d 08 84 1d dd f2  |**********......|
00001ae0  50 72 69 6e 74 65 72 5f  73 65 74 5f 6d 6f 64 75  |Printer_set_modu|
00001af0  6c 65 5f 64 61 74 61 0d  08 8e 17 ea 20 41 25 2c  |le_data..... A%,|
00001b00  42 25 2c 43 25 2c 44 25  2c 45 25 2c 46 25 0d 08  |B%,C%,D%,E%,F%..|
00001b10  98 1d 41 25 3d 64 65 66  61 75 6c 74 73 25 21 70  |..A%=defaults%!p|
00001b20  78 72 65 73 5f 66 69 65  6c 64 25 0d 08 a2 1d 42  |xres_field%....B|
00001b30  25 3d 64 65 66 61 75 6c  74 73 25 21 70 79 72 65  |%=defaults%!pyre|
00001b40  73 5f 66 69 65 6c 64 25  0d 08 ac 20 43 25 3d 64  |s_field%... C%=d|
00001b50  65 66 61 75 6c 74 73 25  21 66 65 61 74 75 72 65  |efaults%!feature|
00001b60  73 5f 66 69 65 6c 64 25  0d 08 b6 26 44 25 3d 64  |s_field%...&D%=d|
00001b70  65 66 61 75 6c 74 73 25  21 70 78 72 65 73 5f 68  |efaults%!pxres_h|
00001b80  61 6c 66 74 6f 6e 65 5f  66 69 65 6c 64 25 0d 08  |alftone_field%..|
00001b90  c0 26 45 25 3d 64 65 66  61 75 6c 74 73 25 21 70  |.&E%=defaults%!p|
00001ba0  79 72 65 73 5f 68 61 6c  66 74 6f 6e 65 5f 66 69  |yres_halftone_fi|
00001bb0  65 6c 64 25 0d 08 ca 26  46 25 3d 64 65 66 61 75  |eld%...&F%=defau|
00001bc0  6c 74 73 25 21 70 72 69  6e 74 65 72 5f 6e 75 6d  |lts%!printer_num|
00001bd0  62 65 72 5f 66 69 65 6c  64 25 0d 08 d4 2c c8 99  |ber_field%...,..|
00001be0  20 22 50 44 72 69 76 65  72 5f 53 65 74 49 6e 66  | "PDriver_SetInf|
00001bf0  6f 22 2c 2c 41 25 2c 42  25 2c 43 25 2c 2c 44 25  |o",,A%,B%,C%,,D%|
00001c00  2c 45 25 2c 46 25 0d 08  de 0d 6d 73 67 25 21 30  |,E%,F%....msg%!0|
00001c10  3d 32 30 0d 08 e8 0d 6d  73 67 25 21 31 32 3d 30  |=20....msg%!12=0|
00001c20  0d 08 f2 1f 6d 73 67 25  21 31 36 3d 4d 65 73 73  |....msg%!16=Mess|
00001c30  61 67 65 5f 53 65 74 50  72 69 6e 74 65 72 25 0d  |age_SetPrinter%.|
00001c40  08 fc 26 c8 99 20 22 57  69 6d 70 5f 53 65 6e 64  |..&.. "Wimp_Send|
00001c50  4d 65 73 73 61 67 65 22  2c 20 31 38 2c 20 6d 73  |Message", 18, ms|
00001c60  67 25 2c 20 30 0d 09 06  22 41 25 3d 64 65 66 61  |g%, 0..."A%=defa|
00001c70  75 6c 74 73 25 21 70 61  67 65 5f 77 69 64 74 68  |ults%!page_width|
00001c80  5f 66 69 65 6c 64 25 0d  09 10 23 42 25 3d 64 65  |_field%...#B%=de|
00001c90  66 61 75 6c 74 73 25 21  70 61 67 65 5f 68 65 69  |faults%!page_hei|
00001ca0  67 68 74 5f 66 69 65 6c  64 25 0d 09 1a 21 43 25  |ght_field%...!C%|
00001cb0  3d 64 65 66 61 75 6c 74  73 25 21 70 61 67 65 5f  |=defaults%!page_|
00001cc0  6c 65 66 74 5f 66 69 65  6c 64 25 0d 09 24 23 44  |left_field%..$#D|
00001cd0  25 3d 64 65 66 61 75 6c  74 73 25 21 70 61 67 65  |%=defaults%!page|
00001ce0  5f 62 6f 74 74 6f 6d 5f  66 69 65 6c 64 25 0d 09  |_bottom_field%..|
00001cf0  2e 22 45 25 3d 64 65 66  61 75 6c 74 73 25 21 70  |."E%=defaults%!p|
00001d00  61 67 65 5f 72 69 67 68  74 5f 66 69 65 6c 64 25  |age_right_field%|
00001d10  0d 09 38 20 46 25 3d 64  65 66 61 75 6c 74 73 25  |..8 F%=defaults%|
00001d20  21 70 61 67 65 5f 74 6f  70 5f 66 69 65 6c 64 25  |!page_top_field%|
00001d30  0d 09 42 2f c8 99 20 22  50 44 72 69 76 65 72 5f  |..B/.. "PDriver_|
00001d40  53 65 74 50 61 67 65 53  69 7a 65 22 2c 2c 41 25  |SetPageSize",,A%|
00001d50  2c 42 25 2c 43 25 2c 44  25 2c 45 25 2c 46 25 0d  |,B%,C%,D%,E%,F%.|
00001d60  09 4c 37 c8 99 20 22 50  44 72 69 76 65 72 5f 53  |.L7.. "PDriver_S|
00001d70  65 74 50 72 69 6e 74 65  72 22 2c 64 65 66 61 75  |etPrinter",defau|
00001d80  6c 74 73 25 2b 64 75 6d  70 5f 64 65 70 74 68 5f  |lts%+dump_depth_|
00001d90  66 69 65 6c 64 25 0d 09  56 05 e1 0d 09 60 05 3a  |field%..V....`.:|
00001da0  0d 09 6a 2d f4 20 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |..j-. **********|
00001db0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
00001dc0  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 0d 09 74  |*************..t|
00001dd0  2d f4 20 73 65 74 20 74  68 65 20 64 65 73 63 72  |-. set the descr|
00001de0  69 70 74 69 6f 6e 20 66  69 65 6c 64 20 69 6e 20  |iption field in |
00001df0  6f 75 72 20 77 69 6e 64  6f 77 0d 09 7e 2d f4 20  |our window..~-. |
00001e00  2a 2a 2a 2a 2a 2a 2a 2a  2a 2a 2a 2a 2a 2a 2a 2a  |****************|
*
00001e20  2a 2a 2a 2a 2a 2a 2a 0d  09 88 1d dd f2 50 72 69  |*******......Pri|
00001e30  6e 74 65 72 5f 73 65 74  5f 64 65 73 63 72 69 70  |nter_set_descrip|
00001e40  74 69 6f 6e 0d 09 92 0c  ea 20 53 25 2c 20 53 24  |tion..... S%, S$|
00001e50  0d 09 9c 27 e3 20 53 25  20 3d 20 30 20 b8 20 70  |...'. S% = 0 . p|
00001e60  72 69 6e 74 65 72 5f 64  61 74 61 5f 73 69 7a 65  |rinter_data_size|
00001e70  25 2d 34 20 88 20 34 0d  09 a6 28 64 65 66 61 75  |%-4 . 4...(defau|
00001e80  6c 74 73 25 21 53 25 20  3d 20 70 72 69 6e 74 65  |lts%!S% = printe|
00001e90  72 5f 64 61 74 61 5f 6c  69 73 74 25 21 53 25 0d  |r_data_list%!S%.|
00001ea0  09 b0 05 ed 0d 09 ba 48  f2 50 72 69 6e 74 65 72  |.......H.Printer|
00001eb0  5f 73 65 74 5f 69 63 6f  6e 28 6d 61 69 6e 5f 64  |_set_icon(main_d|
00001ec0  65 73 63 72 69 70 74 69  6f 6e 25 2c 24 28 64 65  |escription%,$(de|
00001ed0  66 61 75 6c 74 73 25 21  64 65 73 63 72 69 70 74  |faults%!descript|
00001ee0  69 6f 6e 5f 66 69 65 6c  64 25 29 29 0d 09 c4 4a  |ion_field%))...J|
00001ef0  c8 99 20 22 58 4f 53 5f  43 4c 49 22 2c 22 53 45  |.. "XOS_CLI","SE|
00001f00  54 20 50 72 69 6e 74 65  72 24 22 2b 22 20 22 22  |T Printer$"+" ""|
00001f10  22 2b 24 28 64 65 66 61  75 6c 74 73 25 21 64 65  |"+$(defaults%!de|
00001f20  73 63 72 69 70 74 69 6f  6e 5f 66 69 65 6c 64 25  |scription_field%|
00001f30  29 2b 22 22 22 22 0d 09  ce 05 e1 0d 09 d8 05 3a  |)+"""".........:|
00001f40  0d 09 e2 2e dd f2 50 72  69 6e 74 65 72 5f 73 65  |......Printer_se|
00001f50  74 5f 6e 75 6d 65 72 69  63 5f 69 63 6f 6e 28 49  |t_numeric_icon(I|
00001f60  25 2c 46 25 2c 53 25 2c  20 f8 20 53 24 29 0d 09  |%,F%,S%, . S$)..|
00001f70  ec 1b 53 24 20 3d 20 c3  28 64 65 66 61 75 6c 74  |..S$ = .(default|
00001f80  73 25 21 46 25 2f 53 25  29 0d 09 f6 1c f2 50 72  |s%!F%/S%).....Pr|
00001f90  69 6e 74 65 72 5f 73 65  74 5f 69 63 6f 6e 28 49  |inter_set_icon(I|
00001fa0  25 2c 53 24 29 0d 0a 00  05 e1 0d 0a 0a 05 3a 0d  |%,S$).........:.|
00001fb0  0a 14 1d dd f2 50 72 69  6e 74 65 72 5f 73 65 74  |.....Printer_set|
00001fc0  5f 69 63 6f 6e 28 49 25  2c 53 24 29 0d 0a 1e 08  |_icon(I%,S$)....|
00001fd0  ea 20 53 25 0d 0a 28 1a  53 25 3d a4 69 63 6f 6e  |. S%..(.S%=.icon|
00001fe0  61 64 64 72 28 6d 61 69  6e 25 2c 49 25 29 0d 0a  |addr(main%,I%)..|
00001ff0  32 0c 24 53 25 20 3d 20  53 24 0d 0a 3c 17 f2 7a  |2.$S% = S$..<..z|
00002000  65 72 6f 5f 74 65 72 6d  69 6e 61 74 65 28 53 25  |ero_terminate(S%|
00002010  29 0d 0a 46 31 f2 73 65  74 5f 69 63 6f 6e 5f 73  |)..F1.set_icon_s|
00002020  74 61 74 65 28 6d 61 69  6e 25 2c 49 25 2c 30 2c  |tate(main%,I%,0,|
00002030  30 29 3a 20 f4 20 66 6f  72 63 65 20 72 65 64 72  |0): . force redr|
00002040  61 77 0d 0a 50 05 e1 0d  0a 5a 05 3a 0d 0a 64 1a  |aw..P....Z.:..d.|
00002050  dd 20 f2 50 72 69 6e 74  65 72 5f 41 6d 65 6e 64  |. .Printer_Amend|
00002060  43 6f 6e 66 69 67 0d 0a  6e 21 e7 20 6c 69 6e 65  |Config..n!. line|
00002070  5f 63 6f 6e 66 69 67 25  20 3c 3e 20 6c 69 6e 65  |_config% <> line|
00002080  5f 6e 65 77 25 20 8c 0d  0a 78 1a 20 cf 23 6f 75  |_new% ...x. .#ou|
00002090  74 5f 66 69 6c 65 25 3d  6c 69 6e 65 5f 70 74 72  |t_file%=line_ptr|
000020a0  25 0d 0a 82 1c 20 d5 23  6f 75 74 5f 66 69 6c 65  |%.... .#out_file|
000020b0  25 2c c3 6c 69 6e 65 5f  6e 65 77 25 3b 0d 0a 8c  |%,.line_new%;...|
000020c0  1d 20 6c 69 6e 65 5f 63  6f 6e 66 69 67 25 20 3d  |. line_config% =|
000020d0  20 6c 69 6e 65 5f 6e 65  77 25 0d 0a 96 05 cd 0d  | line_new%......|
000020e0  0a a0 05 e1 0d 0a aa 05  3a 0d 0a b4 15 dd 20 f2  |........:..... .|
000020f0  50 72 69 6e 74 65 72 5f  49 67 6e 6f 72 65 0d 0a  |Printer_Ignore..|
00002100  be 05 e1 0d 0a c8 05 3a  0d 0a d2 1d dd 20 f2 50  |.......:..... .P|
00002110  72 69 6e 74 65 72 5f 58  6f 6e 58 6f 66 66 28 66  |rinter_XonXoff(f|
00002120  6c 61 67 25 29 0d 0a dc  0d e7 20 66 6c 61 67 25  |lag%)..... flag%|
00002130  20 8c 0d 0a e6 0c 20 2a  66 78 20 32 2c 32 0d 0a  | ..... *fx 2,2..|
00002140  f0 05 cc 0d 0a fa 0c 20  2a 66 78 20 32 2c 30 0d  |....... *fx 2,0.|
00002150  0b 04 05 cd 0d 0b 0e 05  e1 0d 0b 18 05 3a 0d 0b  |.............:..|
00002160  22 15 dd 20 f2 50 72 69  6e 74 65 72 5f 48 65 61  |".. .Printer_Hea|
00002170  64 65 72 0d 0b 2c 14 60  65 78 74 25 3d a2 23 69  |der..,.`ext%=.#i|
00002180  6e 5f 66 69 6c 65 25 0d  0b 36 0d 60 6c 61 73 74  |n_file%..6.`last|
00002190  25 3d 2d 31 0d 0b 40 05  e1 0d 0b 4a 05 3a 0d 0b  |%=-1..@....J.:..|
000021a0  54 15 dd 20 f2 50 72 69  6e 74 65 72 5f 46 6f 6f  |T.. .Printer_Foo|
000021b0  74 65 72 0d 0b 5e 05 e1  0d 0b 68 05 3a 0d 0b 72  |ter..^....h.:..r|
000021c0  19 dd 20 a4 50 72 69 6e  74 65 72 5f 53 65 6e 64  |.. .Printer_Send|
000021d0  28 6c 65 6e 25 29 0d 0b  7c 0a f2 45 73 63 4f 6e  |(len%)..|..EscOn|
000021e0  0d 0b 86 0e ea 20 4c 25  2c 49 25 2c 43 25 0d 0b  |..... L%,I%,C%..|
000021f0  90 19 4c 25 3d 60 65 78  74 25 20 2d 20 8f 23 69  |..L%=`ext% - .#i|
00002200  6e 5f 66 69 6c 65 25 0d  0b 9a 16 e7 20 6c 65 6e  |n_file%..... len|
00002210  25 3e 3d 4c 25 20 6c 65  6e 25 3d 4c 25 0d 0b a4  |%>=L% len%=L%...|
00002220  11 e7 20 6c 69 6e 65 5f  6e 65 77 25 20 8c 0d 0b  |.. line_new% ...|
00002230  ae 0c 20 49 25 3d 6c 65  6e 25 0d 0b b8 0c 20 c8  |.. I%=len%.... .|
00002240  95 20 49 25 3e 30 0d 0b  c2 13 20 20 43 25 3d 9a  |. I%>0....  C%=.|
00002250  23 69 6e 5f 66 69 6c 65  25 0d 0b cc 22 20 20 e7  |#in_file%..."  .|
00002260  20 43 25 3d 31 30 20 d5  23 6f 75 74 5f 66 69 6c  | C%=10 .#out_fil|
00002270  65 25 2c 31 33 3a 49 25  2d 3d 31 0d 0b d6 14 20  |e%,13:I%-=1.... |
00002280  20 d5 23 6f 75 74 5f 66  69 6c 65 25 2c 43 25 0d  | .#out_file%,C%.|
00002290  0b e0 22 20 20 e7 20 43  25 3d 31 33 20 d5 23 6f  |.."  . C%=13 .#o|
000022a0  75 74 5f 66 69 6c 65 25  2c 31 30 3a 49 25 2d 3d  |ut_file%,10:I%-=|
000022b0  31 0d 0b ea 0b 20 20 49  25 2d 3d 31 0d 0b f4 0f  |1....  I%-=1....|
000022c0  20 20 60 6c 61 73 74 25  3d 43 25 0d 0b fe 06 20  |  `last%=C%.... |
000022d0  ce 0d 0c 08 05 cc 0d 0c  12 2a 20 c8 99 20 22 4f  |.........* .. "O|
000022e0  53 5f 47 42 50 42 22 2c  20 34 2c 20 69 6e 5f 66  |S_GBPB", 4, in_f|
000022f0  69 6c 65 25 2c 20 62 75  66 25 2c 20 6c 65 6e 25  |ile%, buf%, len%|
00002300  0d 0c 1c 2b 20 c8 99 20  22 4f 53 5f 47 42 50 42  |...+ .. "OS_GBPB|
00002310  22 2c 20 32 2c 20 6f 75  74 5f 66 69 6c 65 25 2c  |", 2, out_file%,|
00002320  20 62 75 66 25 2c 20 6c  65 6e 25 0d 0c 26 05 cd  | buf%, len%..&..|
00002330  0d 0c 30 0b f2 45 73 63  4f 66 66 0d 0c 3a 0f 3d  |..0..EscOff..:.=|
00002340  28 6c 65 6e 25 3e 3d 4c  25 29 0d ff              |(len%>=L%)..|
0000234c
PrinterDMs/!PrinterDM/Library.m0
PrinterDMs/!PrinterDM/Library.m1
PrinterDMs/!PrinterDM/Library.m2
PrinterDMs/!PrinterDM/Library.m4
PrinterDMs/!PrinterDM/Library.m5
