11 RNW/READY
This has different functions on the Electron and the Master 128.
On the Electron: READY - CPU wait state control : Open collector
output.When driven low, this line will cause the
CPU to extend its cycle until READY is released.
This will only work on Electrons with CMOS CPUs.
With NMOS CPUs it will only work on read cycles.
On the Master 128:
R/W - Data Direction Control : Input with TTL levels
This is the system data buffer direction control. If low,
cartridges are being written to.If high and selected they may
drive the bus during PH12.
12 nNMI - Non maskable interrupt : Open collector output
This signal is connected to the system NMI line. It is active low.
13 nIRQ - Interrupt request : Open collector output
This signal is connected to the system IRQ line. It is active low.
14 nINFC - Internal Page &FC : Memory active decode input : TTL active
low When bit IFJ is set in the Master 128 ACCCON register, all
accesses to the address range &FC00 to &FCFF will cause this select
to become active. The ACCCON access is not applicable to the
Electron.
15 nINFD - Internal page &FD : Memory active decode input : TTL active
low.When bit IFJ is set in the Master 128 ACCCON register, all
accesses to the address range &FD00 to &FDFF will cause this select
to become active. The ACCCON access is not applicable to the
Electron.
16 ROMQA - Memory paging select : Input with TTL levels
This is the least significant bit of the ROM select latch located
at &FE30 in the Master 128 and at &FE05 in the Electron.
17 Clock
This connection has different uses in the Electron and Master 128:
In the Electron: Clock is a 16MHz input with TTL levels.
In the Master 128:
Clock is a strap selectable function:
a) 16MHz input with TTL levels.
b) 8 MHz input with TTL levels.
The functions are selected by links on the host computer. The user
should ensure that the links are correct for a given application
and that proper termination is provided.
18 nROMSTB/nCRTCRST
This has different functions on the Electron and Master 128:
On the Electron:
nROMSTB is an active low input using TTL levels which selects the
location &FC73. This is intended to be used as a paging register.
On the Master 128:
nCRTCRST is an active low output signal meeting TTL levels of the
system CRTC reset input. It is provided for use in genlock
applications.
19 ADOUT - System audio output
This is the filtered output of the sum of all audio inputs to the
host computer.Significant load should not be taken from this node.
20 AGND - Audio Ground
This is the zero volt return for ADOUT. It should be used instead
of the system zero volt connection to reduce audio noise.
21 ADIN - Cartridge audio output
In the Electron: This is merely a connection from one cartridge to
the other.
In the Master 128: This is an output to the host computer audio
circuitry. It 'sees' an impedance of at least
1.0kOhms. Two cartridges with audio output should
not be inserted into the host computer together.
22 0V - Zero volts
This is the system earth return for digital signals.
SIDE 'B'
1 +5V - Power supply
This is the system logic supply rail. No more than 150mA should be
drawn by a cartridge in a fully configured Master 128 computer, ie
with internal Second Processor fitted. No more than 10mA should be
drawn by a cartridge fitted to the Electron.
2 A10 - Address line 10 : Input with TTL levels
3 D3 - Data bus line 3 : Input/Output with TTL levels
4 A11 - Address line 11 : Input with TTL levels
5 A9 - Address line 9 : Input with TTL levels
6 D7 - Most significant data bus line : Input/Output with TTL levels
7 D6 - Data bus line 6 : Input/Output with TTL levels
8 D5 - Data bus line 5 : Input/Output with TTL levels
9 D4 - Data bus line 4 : Input/Output with TTL levels
