10REM TRACKER M/Code Disassembler
20REM Original Program by Mark Bolton
30REM Electron User August 1988
40REM ROM version, Part 2 (TKRsrc2)
50REM By Richard Dimond, March 1997
60REM
70MODE134
80addr=&70:temp=&72:op=&74:mne=&75:fd=&78:inc=&79:index=&7A:counter=&7B:code=&7C:temp2=&7D:rom=&7F:stat=&80:x=&81:y=&82:loc=&83:jsr%=&84:jmp%=&85:ptr%=&86:flag=&87:old=&88:pointer=&8F:bot=23
90DIM Q% 4000
100FOR L%=4TO6STEP2
110O%=Q%:P%=&8237:[OPT L%
120LDA#0:STA&2A0:STA&84:STA&85:STA&86
130LDA#22:JSR&FFEE:LDA#6:JSR&FFEE
140JMPstart
150.hex PHA:LSRA:LSRA:LSRA:LSRA:JSRhex2:PLA
160.hex2 AND#&F:SED:CLC:ADC#&90:ADC#&40:CLD:JMP&FFEE
170.char STYtemp2:STA&60:LDA#&A:LDX#&60:LDY#0:JSR&FFF1
180LDA#23:JSR&FFEE:LDA#255:JSR&FFEE:LDA#0:JSR&FFEE:LDX#1:JSRvdu:INX:INX:JSRvdu
190INX:JSRvdu:INX:JSRvdu:INX:INX:JSRvdu:LDA#0:JSR&FFEE:JSR&FFEE
200LDAstat:BEQendv:LDA#17:JSR&FFEE:LDA#0:JSR&FFEE:LDA#17:JSR&FFEE:LDA#129:JSR&FFEE:.endv LDYtemp2:LDA#255:JSR&FFEE:LDA#17:JSR&FFEE:LDA#1:JSR&FFEE:LDA#17:JSR&FFEE:LDA#128:JMP&FFEE
210.vdu LDA&60,X:JMP&FFEE
220.vdu31 LDA#31:JSR&FFEE:TXA:JSR&FFEE:TYA:JMP&FFEE
230.main_loop
240JSRget_info:JSRptr_on:JSRaddress:LDA#0:STAstat:JSRmnemonic:LDA#6:JSRxpos
250JSRbytes:LDA#1:STAstat:JSRmnemonic:JSRascii:LDA#10:JSR&FFEE:LDA#13:JSR&FFEE:JSRptr_off:JSRfollow:JSR&FFE0:CMP#27:BEQstop
260CMP#ASC"B":BNEcont2:DECaddr+1:JSRstring:EQUS" -- Back --":BRK:JSR&FFE7:JMPmain_loop
270.cont2 CMP#ASC"F":BNEcont3:INCaddr+1:JSRstring:EQUS" -- Forward --":BRK:JSR&FFE7:JMPmain_loop
280.cont3 CMP#ASC"P":BNEcont4:JSRtogptr:JMPcont0
290.cont4 CMP#ASC"M":BNEcont5:JSRtogjmp:JMPcont0
300.cont5 CMP#ASC"J":BNEcont6:JSRtogjsr:JMPcont0
310.cont6 CMP#ASC"A":BNEcont7:JSRinput:JMPmain_loop
320.cont7 CMP#ASC"*":BNEcont0:JSRstarcom
330.cont0 CLC:LDAaddr:ADCinc:STAaddr:LDAaddr+1:ADC#0:STAaddr+1
340JMPmain_loop
350.stop JSR ptr_off:JMP&8105
360.get_info
370LDY#0:STYcounter:JSRread:STAop
380LDA#table1 MOD256:STAtemp:LDA#table1 DIV256:STAtemp+1
390.glp LDA(temp),Y:CMPop:BEQfound
400CLC:LDAtemp:ADC#3:STAtemp:LDAtemp+1:ADC#0:STAtemp+1:INCcounter
410LDAcounter:CMP#152:BNEglp
420LDA#0:STAfd:STAindex:RTS
430.found LDA#&FF:STAfd
440LDY#1:LDA(temp),Y:STAcode:DECcode:INY:LDA(temp),Y:STAindex
450LDA#table2 MOD256:STAtemp:LDA#table2 DIV256:STAtemp+1:LDAcode:BEQskip
460LDY#0:.flp LDAtemp:CLC:ADC#3:STAtemp:LDAtemp+1:ADC#0:STAtemp+1:INY:CPYcode:BNEflp
470.skip LDY#0:.lp2 LDA(temp),Y:STAmne,Y:INY:CPY#3:BNElp2
480RTS
490.read JSRwhat:STY&90:LDAaddr+1:CMP#&80:BPLread2:JMPread5
500.read2 CMP#&C0:BMIread3:JMPread5
510.read3
520STYtemp2:CLC:LDAaddr:ADCtemp2:STA&F6:LDAaddr+1:ADC#0:STA&F7:LDYrom:JSR&FFB9:LDY&90:RTS
530.read5 LDA(addr),Y:RTS
540.address LDAaddr+1:JSRhex:LDAaddr:JSRhex:LDA#32:JMP&FFEE
550.bytes LDY#0:.blp JSRread:JSRhex:LDA#32:JSR&FFEE:INY:CPYinc:BNEblp:LDA#16
560.xpos STAtemp2:.xlp LDA#134:JSR&FFF4:CPXtemp2:BPLendx:LDA#32:JSR&FFEE:JMPxlp:.endx RTS
570.mnemonic LDAstat:BNEmnemon:JMPnumber
580.mnemon
590LDAfd:BNEmne2:JSRstring:EQUS"No such code":EQUB0:RTS
600.mne2 LDY#0:.mlp LDAmne,Y:JSR&FFEE:INY:CPY#3:BNEmlp:.mne3
610LDAindex:BNEm1:JMP A0
620.m1 CMP#1:BNEm2:JMP A1
630.m2 CMP#2:BNEm3:JMP A2
640.m3 CMP#3:BNEm4:JMP A3
650.m4 CMP#4:BNEm5:JMP A4
660.m5 CMP#5:BNEm6:JMP A5
670.m6 CMP#6:BNEm7:JMP A6
680.m7 CMP#7:BNEm8:JMP A7
690.m8 CMP#8:BNEm9:JMP A8
700.m9 CMP#9:BNEm10:JMP A9
710.m10 CMP#10:BNEm11:JMP A10
720.m11 CMP#11:BNEm0:JMP A11
730.m0 RTS
740.ascii LDA#36:JSRxpos:LDY#0:.alp JSRread:CMP#32:BPLasc2:LDA#ASC".":JMPasc3
750.asc2 CMP#127:BMIasc3:LDA#ASC"."
760.asc3 JSR&FFEE:INY:CPYinc:BNEalp
770RTS
780.A0 LDA#32:JSR&FFEE:LDA#ASC"A":JMP&FFEE
790.A1 JSRhash:JSRamp:LDY#1:JSRread:JMPhex
800.A2 JSRamp:LDY#1:JSRread:JMPhex
810.A3 JSRamp:LDY#1:JSRread:JSRhex:JSRcomma:JMPpx
820.A4 JSRamp:LDY#2:JSRread:JSRhex:DEY:JSRread:JMPhex
830.A5 JSRamp:LDY#2:JSRread:JSRhex:DEY:JSRread:JSRhex:JSRcomma:JMPpy
840.A6 JSRamp:LDY#2:JSRread:JSRhex:DEY:JSRread:JSRhex:JSRcomma:JMPpx
850.A7 JSRbrack1:JSRamp:LDY#1:JSRread:JSRhex:JSRcomma:JSRpx:JMPbrack2
860.A8 JSRbrack1:JSRamp:LDY#1:JSRread:JSRhex:JSRbrack2:JSRcomma:JMPpy
870.A9 JSRamp:LDY#1:JSRread:STAtemp:CMP#&81:BMI B9:SEC:LDA#&FE:SBCtemp:STAtemp+1:SEC:LDAaddr:SBCtemp+1:PHA:LDAaddr+1:SBC#0:JSRhex:PLA:JMPhex
880.B9 CLC:LDA#2:ADCtemp:STAtemp+1:CLC:LDAaddr:ADCtemp+1:PHA:LDAaddr+1:ADC#0:JSRhex:PLA:JMPhex
890.A11 JSRbrack1:JSRamp:LDY#2:JSRread:JSRhex:DEY:JSRread:JSRhex:JMPbrack2
900.A10 RTS
910.px LDA#ASC"X":JMP&FFEE:.py LDA#ASC"Y":JMP&FFEE:.brack1 LDA#ASC"(":JMP&FFEE:.brack2 LDA#ASC")":JMP&FFEE
920.comma LDA#ASC",":JMP&FFEE:.amp LDA#ASC"&":JMP&FFEE:.hash LDA#ASC"#":JMP&FFEE
930.number LDAindex:CMP#1:BEQ I2:CMP#2:BEQ I2:CMP#3:BEQ I2:CMP#7:BEQ I2:CMP#8:BEQ I2:CMP#9:BEQ I2
940CMP#4:BEQ I3:CMP#5:BEQ I3:CMP#6:BEQ I3:CMP#11:BEQ I3:.I1 LDA#1:STAinc:RTS
950.I2 LDA#2:STAinc:RTS:.I3 LDA#3:STAinc:RTS
960.str PLA:STAtemp:PLA:STAtemp+1:LDY#0:BEQps2:.ps LDA(temp),Y:BEQps1:JSRchar:.ps2 INCtemp:BNEps:INCtemp+1:BNEps:.ps1 LDAtemp+1:PHA:LDAtemp:PHA:RTS
970.string PLA:STAtemp:PLA:STAtemp+1:LDY#0:BEQps5:.ps3 LDA(temp),Y:BEQps4:JSR&FFEE:.ps5 INCtemp:BNEps3:INCtemp+1:BNEps3:.ps4 LDAtemp+1:PHA:LDAtemp:PHA:RTS
980.start LDA#28:JSR&FFEE:LDA#0:JSR&FFEE:LDA#12:JSR&FFEE:LDA#39:JSR&FFEE:LDA#0:JSR&FFEE:LDA#12:JSR&FFEE:LDA#26:JSR&FFEE
990LDA#23:JSR&FFEE:LDA#255:JSR&FFEE:LDX#8:.llp LDA#0:CPX#5:BNEnoprt:LDA#255:.noprt JSR&FFEE:DEX:BNEllp
1000LDA#40:LDX#0:LDY#1:JSRchr:LDA#40:LDX#0:LDY#bot-1:JSRchr
1010LDAflag:BNEmiss:LDA&410:STAaddr:LDA&411:STAaddr+1:LDA#0:STAjsr%:STAjmp%:STAptr%:.miss
1020LDA#0:STAstat:JSRpjsr:JSRpjmp:JSRpptr
1030LDA#&FF:STAloc:STAflag
1040LDA#1:STAstat:LDAjsr%:BEQst2:JSRpjsr:.st2 LDAjmp%:BEQst3:JSRpjmp:.st3 LDAptr%:BEQst4:JSRpptr
1050.st4
1060LDA&410:STAaddr:LDA&411:STAaddr+1
1070LDA#0:STAx:STAy:JSRvdu28
1080JMPmain_loop
1090.vdu28 LDA#28:JSR&FFEE:LDA#0:JSR&FFEE:LDA#bot-2:JSR&FFEE:LDA#39:JSR&FFEE:LDA#2:JSR&FFEE:LDXx:LDYy:JSRvdu31:JMPptr_on
1100.vdu26 LDA#134:JSR&FFF4:STXx:STYy:JSRptr_off:LDA#26:JMP&FFEE
1110.pjsr JSRvdu26:LDX#0:LDY#0:JSRvdu31:JSRstr:EQUS" JSR ":BRK:JMPvdu28
1120.pjmp JSRvdu26:LDX#6:LDY#0:JSRvdu31:JSRstr:EQUS" JMP ":BRK:JMPvdu28
1130.pptr JSRvdu26:LDX#35:LDY#0:JSRvdu31:JSRstr:EQUS" PTR ":BRK:JMPvdu28
1140.pram JSRvdu26:LDX#12:LDY#0:JSRvdu31:JSRstr:EQUS" RAM ":BRK:JMPvdu28
1150.prom JSRvdu26:LDX#12:LDY#0:JSRvdu31:JSRstr:EQUS" ROM ":BRK:JMPvdu28
1160.pmos JSRvdu26:LDX#12:LDY#0:JSRvdu31:JSRstr:EQUS" MOS ":BRK:JMPvdu28
1170.what PHA:TXA:PHA:TYA:PHA:LDA#1:STAstat
1180LDAaddr+1:CMP#&80:BPLwhat2:LDAloc:BEQendwhat:LDA#0:STAloc:JSRpram:JMPendwhat
1190.what2 CMP#&C0:BPLwhat3:LDAloc:CMP#1:BEQendwhat:LDA#1:STAloc:JSRprom:JSRgetrom:JMPendwhat
1200.what3 LDAloc:CMP#2:BEQendwhat:LDA#2:STAloc:JSRpmos
1210.endwhat LDA#0:STAstat:PLA:TAY:PLA:TAX:PLA:RTS
1220.getrom JSRvdu26:LDY#0:STYstat:LDX#18:JSRvdu31:JSRstr:EQUS"ENTER ROM NUMBER":BRK
1230LDX#16:LDY#bot:JSRvdu31:JSRstring:EQUS"ROM - ":BRK
1240LDA#0:LDX#table3 MOD256:LDY#table3 DIV256:JSR&FFF1
1250LDY#0:.g1 LDAtable4,Y:CMP#13:BEQg2:SEC:SBC#48:STAtable4,Y:INY:JMPg1
1260.g2 CPY#0:BNEg3:LDA#0:STAtable4:STAtable4+1:JMPg6:.g3 CPY#1:BNEg6:LDAtable4:STAtable4+1:LDA#0:STAtable4
1270.g6 JSRdec:STArom
1280LDX#16:LDY#bot:LDA#9:JSRspc
1290LDX#18:LDY#0:LDA#16:JSRspc
1300JMPvdu28
1310.follow
1320LDAjmp%:BEQf2:JSRfjmp
1330.f2 LDAjsr%:BEQf3:JSRfjsr
1340.f3 RTS
1350.fjmp LDAop:CMP#&4C:BNEfjmp2:JSRprompt:BCSfjmp4:RTS:.fjmp4 JSRffw:LDY#1:JSRread:PHA:INY:JSRread:STAaddr+1:PLA:STAaddr:LDA#0:STAinc:RTS
1360.fjmp2 CMP#&6C:BEQfjmp5:RTS:.fjmp5 JSRprompt:BCSfjmp3:RTS
1370.fjmp3 JSRffw:LDY#1:JSRread:PHA:INY:JSRread:STAaddr+1:PLA:STAaddr:LDY#0:JSRread:PHA:INY:JSRread:STAaddr+1:PLA:STAaddr:LDA#0:STAinc:RTS
1380.fjsr LDAop:CMP#&20:BNEfjsr3:JSRprompt:BCSfjsr2:RTS:.fjsr2 JSRffw:LDYpointer
1390LDAaddr:STAstack,Y:INY:LDAaddr+1:STAstack,Y:INY:STYpointer:LDY#1:JSRread:PHA:INY:JSRread:STAaddr+1:PLA:STAaddr:LDA#0:STAinc:RTS
1400.fjsr3 CMP#&60:BNEfjsr5:LDApointer:BEQfjsr5:JSRptr_on:JSRstring:EQUS" -- Return --":BRK:JSR&FFE7:JSRptr_off
1410LDYpointer:DEY:LDAstack,Y:STAaddr+1:DEY:LDAstack,Y:STAaddr:STYpointer:LDA#3:STAinc
1420.fjsr5 RTS
1430.ffw JSRptr_on:JSRstring:EQUS" -- Follow --":BRK:JSR&FFE7:JMPptr_off
1440.togjsr LDAjsr%:EOR#&FF:STAjsr%:AND#1:STAstat:LDAjsr%:ANDpointer:STApointer:JMPpjsr
1450.togjmp LDAjmp%:EOR#&FF:STAjmp%:AND#1:STAstat:JMPpjmp
1460.togptr LDAptr%:EOR#&FF:STAptr%:AND#1:STAstat:JMPpptr
1470.ptr_on LDAptr%:BEQendptr:LDA#2:JSR&FFEE:.endptr RTS:.ptr_off LDAptr%:BEQendptr:LDA#3:JMP&FFEE
1480.input JSRvdu26:LDX#11:LDY#bot:JSRvdu31:JSRstring:EQUS"Continue at &":BRK:LDX#table3 MOD256:LDY#table3 DIV256:LDA#4:STAtable3+2:LDA#0:JSR&FFF1
1490.move LDAtable4+4:CMP#&D:BEQinp2:LDAtable4+3:STAtable4+4:LDAtable4+2:STAtable4+3:LDAtable4+1:STAtable4+2:LDAtable4:STAtable4+1:LDA#48:STAtable4:JMPmove
1500.inp2
1510LDA#2:STAtable3+2:LDA#20:LDX#11:LDY#bot:JSRspc:JSRvdu28
1520JSRstring:EQUS" -- New Address --":BRK:LDX#table4 MOD256:LDY#table4 DIV256:STX&F2:STY&F3
1530JSR&FFE7
1540LDY#0:JSRnum:STAaddr+1:INY:JSRnum:STAaddr:LDA#0:STAinc:.clr LDY#4:.lo STAtable4,Y:DEY:BPLlo:STAinc:RTS
1550.spc PHA:JSRvdu31:PLA:TAY:.sp LDA#32:JSR&FFEE:DEY:BNEsp:RTS
1560.chr PHA:JSRvdu31:PLA:TAY:.cp LDA#255:JSR&FFEE:DEY:BNEcp:RTS
1570.num LDA(&F2),Y:JSRinstr:CLC:ASLA:ASLA:ASLA:ASLA:STAtemp2:INY:LDA(&F2),Y:JSRinstr:CLC:ADCtemp2:RTS
1580.instr STYy:STAtemp:LDY#0:.loop LDA Idata,Y:CMPtemp:BEQendins:INY:CPY#16:BNEloop:LDY#0:.endins TYA:LDYy:RTS
1590.Idata EQUS"0123456789ABCDEF"
1600.table3 EQUB table4 MOD256:EQUB table4 DIV256:EQUB2:EQUB32:EQUB127
1610.table4 EQUS"00000"
1620.table5 EQUB table6 MOD256:EQUB table6 DIV256:EQUB31:EQUB32:EQUB127
1630.table6 EQUS"0000000000000000000000000000000"
1640.dec LDA#0:STAtemp2:LDAtable4:BEQdec2:LDYtable4:.dlp LDAtemp2:CLC:ADC#10:STAtemp2:DEY:BNEdlp
1650.dec2 CLC:LDAtable4+1:ADCtemp2:RTS
1660.prompt JSRvdu26:LDX#13:LDY#bot:JSRvdu31:JSRstring:EQUS"Follow? (Y/N)":BRK
1670.pr1 JSR&FFE0:CMP#ASC"Y":BNEpr2:SEC:JMPpr3
1680.pr2 CMP#ASC"N":BNEpr1:CLC:JMPpr3
1690.pr4 CMP#27:BNEpr1:JMPstop
1700.pr3 PHP:LDX#13:LDY#bot:LDA#14:JSRspc
1710JSRvdu28:PLP:RTS
1720.starcom JSRvdu26:LDX#2:LDY#bot:JSRvdu31:JSRstring
1730EQUS"Star command *":BRK
1740LDA#0:LDX#table5 MOD256:LDY#table5 DIV256:JSR&FFF1
1750LDA#&24:LDX#2:LDY#bot:JSRspc
1760JSRvdu28:JSRcls:JSRfx15
1770LDX#table6 MOD256:LDY#table6 DIV256:JSR&FFF7:JSR&FFE7
1780JSRvdu26:LDX#8:LDY#bot:JSRvdu31:JSRstring
1790EQUS"Press SPACE to continue":BRK
1800.osr JSR&FFE0
1810BCSret
1820LDA#&24:LDX#2:LDY#bot:JSRspc
1830CMP#&20:BNEosr
1840JSRvdu28:JSRcls:JSRfx15:.ret RTS
1850.cls LDA#12:JMP&FFEE
1860.fx15 LDA#15:JMP&FFF4
1870.stack EQUS STRING$(128,CHR$0)
1880.table1
1890]
1900RESTORE1910:FORI%=1TO152:READA$,b,c:?O%=EVAL("&"+A$):O%?1=b:O%?2=c:O%=O%+3:?P%=EVAL("&"+A$):P%?1=b:P%?2=c:P%=P%+3:NEXT
1910DATA 69,1,1,65,1,2,75,1,3,6D,1,4,79,1,5,7D,1,6,61,1,7,71,1,8,29,2,1,25,2,2,35,2,3,2D,2,4,3D,2,6,39,2,5,21,2,7,31,2,8
1920DATA A,3,0,6,3,2,16,3,3,E,3,4,1E,3,6,90,4,9,B0,5,9,F0,6,9,24,7,2,2C,7,4,30,8,9,D0,9,9,10,10,9,0,11,10,50,12,9,70,13,9
1930DATA 18,14,10,D8,15,10,58,16,10,B8,17,10,C9,18,1,C5,18,2,D5,18,3,CD,18,4,DD,18,6,D9,18,5,C1,18,7,D1,18,8,E0,19,1,E4,19,2,EC,19,4
1940DATA C0,20,1,C4,20,2,CC,20,4,C6,21,2,D6,21,3,CE,21,4,DE,21,6,CA,22,10,88,23,10,E8,24,10,C8,25,10,E6,27,2,F6,27,3,EE,27,4,FE,27,6
1950DATA 49,26,1,45,26,2,55,26,3,4D,26,4,5D,26,6,59,26,5,41,26,7,51,26,8,4C,28,4,6C,28,11,20,29,4,A9,30,1,A5,30,2,B5,30,3,AD,30,4
1960DATA BD,30,6,B9,30,5,A1,30,7,B1,30,8,A2,31,1,A6,31,2,B6,31,3,AE,31,4,BE,31,5,A0,32,1,A4,32,2,B4,32,3,AC,32,4,BC,32,6
1970DATA 4A,33,0,46,33,2,56,33,3,4E,33,4,5E,33,6,EA,34,10,48,35,10,8,36,10,68,37,10,28,38,10,40,39,10,60,40,10,38,41,10,F8,42,10
1980DATA 78,43,10,AA,44,10,A8,45,10,98,46,10,BA,47,10,8A,48,10,9A,49,10,9,50,1,5,50,2,15,50,3,D,50,4,19,50,5,1D,50,6,1,50,7,11,50,8
1990DATA 2A,51,0,26,51,2,36,51,3,2E,51,4,3E,51,6,6A,52,0,66,52,2,76,52,3,6E,52,4,7E,52,6,E9,53,1,E5,53,2,F5,53,3,ED,53,4,FD,53,6
2000DATA F9,53,5,E1,53,7,F1,53,8,85,54,2,95,54,3,8D,54,4,9D,54,6,99,54,5,81,54,7,91,54,8,86,55,2,96,55,3,8E,55,4,84,56,2,94,56,3,8C,56,4
2010DATA 0,0,0
2020[OPTL%:.table2
2030]:RESTORE2060
2040FORI%=1TO56:READA$:?O%=ASCLEFT$(A$,1):O%?1=ASCMID$(A$,2,1):O%?2=ASCRIGHT$(A$,1):?P%=ASCLEFT$(A$,1):P%?1=ASCMID$(A$,2,1):P%?2=ASCRIGHT$(A$,1)
2050O%=O%+3:P%=P%+3:NEXT
2060DATA ADC,AND,ASL,BCC,BCS,BEQ,BIT,BMI,BNE,BPL,BRK,BVC,BVS,CLC,CLD,CLI,CLV,CMP,CPX,CPY,DEC,DEX,DEY,INX,INY,EOR,INC,JMP,JSR,LDA,LDX,LDY,LSR,NOP,PHA,PHP,PLA,PLP,RTI,RTS,SEC,SED,SEI,TAX,TAY,TYA,TSX,TXA,TXS,ORA,ROL,ROR,SBC,STA,STX,STY
2070NEXT
2080OSCLI"SAVE TRACK2 "+STR$~Q%+" "+STR$~O%+" 8237"
!� TRACKER M/Code Disassembler
%� Original Program by Mark Bolton
� Electron User August 1988
(#� ROM version, Part 2 (TKRsrc2)
2#� By Richard Dimond, March 1997
<�
F�134
P�addr=&70:temp=&72:op=&74:mne=&75:fd=&78:inc=&79:index=&7A:counter=&7B:code=&7C:temp2=&7D:rom=&7F:stat=&80:x=&81:y=&82:loc=&83:jsr%=&84:jmp%=&85:ptr%=&86:flag=&87:old=&88:pointer=&8F:bot=23
Z
� Q% 4000
d� L%=4�6�2
nO%=Q%:P%=&8237:[OPT L%
x&LDA#0:STA&2A0:STA&84:STA&85:STA&86
�"LDA#22:JSR&FFEE:LDA#6:JSR&FFEE
� JMPstart
�,.hex PHA:LSRA:LSRA:LSRA:LSRA:JSRhex2:PLA
�3.hex2 �#&F:SED:CLC:ADC#&90:ADC#&40:CLD:JMP&FFEE
�7.char STYtemp2:STA&60:LDA#&A:LDX#&60:LDY#0:JSR&FFF1
�OLDA#23:JSR&FFEE:LDA#255:JSR&FFEE:LDA#0:JSR&FFEE:LDX#1:JSRvdu:INX:INX:JSRvdu
�@INX:JSRvdu:INX:JSRvdu:INX:INX:JSRvdu:LDA#0:JSR&FFEE:JSR&FFEE
ȳLDAstat:BEQendv:LDA#17:JSR&FFEE:LDA#0:JSR&FFEE:LDA#17:JSR&FFEE:LDA#129:JSR&FFEE:.endv LDYtemp2:LDA#255:JSR&FFEE:LDA#17:JSR&FFEE:LDA#1:JSR&FFEE:LDA#17:JSR&FFEE:LDA#128:JMP&FFEE
�.vdu LDA&60,X:JMP&FFEE
�4.vdu31 LDA#31:JSR&FFEE:TXA:JSR&FFEE:TYA:JMP&FFEE
�.main_loop
�LJSRget_info:JSRptr_on:JSRaddress:LDA#0:STAstat:JSRmnemonic:LDA#6:JSRxpos
�|JSRbytes:LDA#1:STAstat:JSRmnemonic:JSRascii:LDA#10:JSR&FFEE:LDA#13:JSR&FFEE:JSRptr_off:JSRfollow:JSR&FFE0:CMP#27:BEQstop
UCMP#�"B":BNEcont2:DECaddr+1:JSRstring:EQUS" -- Back --":BRK:JSR&FFE7:JMPmain_loop
_.cont2 CMP#�"F":BNEcont3:INCaddr+1:JSRstring:EQUS" -- Forward --":BRK:JSR&FFE7:JMPmain_loop
/.cont3 CMP#�"P":BNEcont4:JSRtogptr:JMPcont0
"/.cont4 CMP#�"M":BNEcont5:JSRtogjmp:JMPcont0
,0.cont5 CMP#�"J":BNEcont6:JSRtogjsr:JMPcont0
63.cont6 CMP#�"A":BNEcont7:JSRinput:JMPmain_loop
@'.cont7 CMP#�"*":BNEcont0:JSRstarcom
J?.cont0 CLC:LDAaddr:ADCinc:STAaddr:LDAaddr+1:ADC#0:STAaddr+1
TJMPmain_loop
^ .stop JSR ptr_off:JMP&8105
h
.get_info
r"LDY#0:STYcounter:JSRread:STAop
|5LDA#table1 �256:STAtemp:LDA#table1 �256:STAtemp+1
�#.glp LDA(temp),Y:CMPop:BEQfound
�BCLC:LDAtemp:ADC#3:STAtemp:LDAtemp+1:ADC#0:STAtemp+1:INCcounter
� LDAcounter:CMP#152:BNEglp
� LDA#0:STAfd:STAindex:RTS
�.found LDA#&FF:STAfd
�>LDY#1:LDA(temp),Y:STAcode:DECcode:INY:LDA(temp),Y:STAindex
�ELDA#table2 �256:STAtemp:LDA#table2 �256:STAtemp+1:LDAcode:BEQskip
�ULDY#0:.flp LDAtemp:CLC:ADC#3:STAtemp:LDAtemp+1:ADC#0:STAtemp+1:INY:CPYcode:BNEflp
�:.skip LDY#0:.lp2 LDA(temp),Y:STAmne,Y:INY:CPY#3:BNElp2
�RTS
�<.read JSRwhat:STY&90:LDAaddr+1:CMP#&80:BPLread2:JMPread5
�$.read2 CMP#&C0:BMIread3:JMPread5
�
.read3
ZSTYtemp2:CLC:LDAaddr:ADCtemp2:STA&F6:LDAaddr+1:ADC#0:STA&F7:LDYrom:JSR&FFB9:LDY&90:RTS
.read5 LDA(addr),Y:RTS
<.address LDAaddr+1:JSRhex:LDAaddr:JSRhex:LDA#32:JMP&FFEE
&M.bytes LDY#0:.blp JSRread:JSRhex:LDA#32:JSR&FFEE:INY:CPYinc:BNEblp:LDA#16
0Z.xpos STAtemp2:.xlp LDA#134:JSR&FFF4:CPXtemp2:BPLendx:LDA#32:JSR&FFEE:JMPxlp:.endx RTS
:).mnemonic LDAstat:BNEmnemon:JMPnumber
D .mnemon
N8LDAfd:BNEmne2:JSRstring:EQUS"No such code":EQUB0:RTS
X=.mne2 LDY#0:.mlp LDAmne,Y:JSR&FFEE:INY:CPY#3:BNEmlp:.mne3
bLDAindex:BNEm1:JMP A0
l.m1 CMP#1:BNEm2:JMP A1
v.m2 CMP#2:BNEm3:JMP A2
�.m3 CMP#3:BNEm4:JMP A3
�.m4 CMP#4:BNEm5:JMP A4
�.m5 CMP#5:BNEm6:JMP A5
�.m6 CMP#6:BNEm7:JMP A6
�.m7 CMP#7:BNEm8:JMP A7
�.m8 CMP#8:BNEm9:JMP A8
�.m9 CMP#9:BNEm10:JMP A9
� .m10 CMP#10:BNEm11:JMP A10
� .m11 CMP#11:BNEm0:JMP A11
� .m0 RTS
�L.ascii LDA#36:JSRxpos:LDY#0:.alp JSRread:CMP#32:BPLasc2:LDA#�".":JMPasc3
�".asc2 CMP#127:BMIasc3:LDA#�"."
�$.asc3 JSR&FFEE:INY:CPYinc:BNEalp
RTS
0.A0 LDA#32:JSR&FFEE:LDA#�"A":JMP&FFEE
+.A1 JSRhash:JSRamp:LDY#1:JSRread:JMPhex
#.A2 JSRamp:LDY#1:JSRread:JMPhex
*4.A3 JSRamp:LDY#1:JSRread:JSRhex:JSRcomma:JMPpx
47.A4 JSRamp:LDY#2:JSRread:JSRhex:DEY:JSRread:JMPhex
>F.A5 JSRamp:LDY#2:JSRread:JSRhex:DEY:JSRread:JSRhex:JSRcomma:JMPpy
HF.A6 JSRamp:LDY#2:JSRread:JSRhex:DEY:JSRread:JSRhex:JSRcomma:JMPpx
RJ.A7 JSRbrack1:JSRamp:LDY#1:JSRread:JSRhex:JSRcomma:JSRpx:JMPbrack2
\G.A8 JSRbrack1:JSRamp:LDY#1:JSRread:JSRhex:JSRbrack2:JSRcomma:JMPpy
f�.A9 JSRamp:LDY#1:JSRread:STAtemp:CMP#&81:BMI B9:SEC:LDA#&FE:SBCtemp:STAtemp+1:SEC:LDAaddr:SBCtemp+1:PHA:LDAaddr+1:SBC#0:JSRhex:PLA:JMPhex
p_.B9 CLC:LDA#2:ADCtemp:STAtemp+1:CLC:LDAaddr:ADCtemp+1:PHA:LDAaddr+1:ADC#0:JSRhex:PLA:JMPhex
zK.A11 JSRbrack1:JSRamp:LDY#2:JSRread:JSRhex:DEY:JSRread:JSRhex:JMPbrack2
� .A10 RTS
�d.px LDA#�"X":JMP&FFEE:.py LDA#�"Y":JMP&FFEE:.brack1 LDA#�"(":JMP&FFEE:.brack2 LDA#�")":JMP&FFEE
�K.comma LDA#�",":JMP&FFEE:.amp LDA#�"&":JMP&FFEE:.hash LDA#�"#":JMP&FFEE
�b.number LDAindex:CMP#1:BEQ I2:CMP#2:BEQ I2:CMP#3:BEQ I2:CMP#7:BEQ I2:CMP#8:BEQ I2:CMP#9:BEQ I2
�NCMP#4:BEQ I3:CMP#5:BEQ I3:CMP#6:BEQ I3:CMP#11:BEQ I3:.I1 LDA#1:STAinc:RTS
�-.I2 LDA#2:STAinc:RTS:.I3 LDA#3:STAinc:RTS
��.str PLA:STAtemp:PLA:STAtemp+1:LDY#0:BEQps2:.ps LDA(temp),Y:BEQps1:JSRchar:.ps2 INCtemp:BNEps:INCtemp+1:BNEps:.ps1 LDAtemp+1:PHA:LDAtemp:PHA:RTS
ʛ.string PLA:STAtemp:PLA:STAtemp+1:LDY#0:BEQps5:.ps3 LDA(temp),Y:BEQps4:JSR&FFEE:.ps5 INCtemp:BNEps3:INCtemp+1:BNEps3:.ps4 LDAtemp+1:PHA:LDAtemp:PHA:RTS
�x.start LDA#28:JSR&FFEE:LDA#0:JSR&FFEE:LDA#12:JSR&FFEE:LDA#39:JSR&FFEE:LDA#0:JSR&FFEE:LDA#12:JSR&FFEE:LDA#26:JSR&FFEE
�gLDA#23:JSR&FFEE:LDA#255:JSR&FFEE:LDX#8:.llp LDA#0:CPX#5:BNEnoprt:LDA#255:.noprt JSR&FFEE:DEX:BNEllp
�;LDA#40:LDX#0:LDY#1:JSRchr:LDA#40:LDX#0:LDY#bot-1:JSRchr
�ZLDAflag:BNEmiss:LDA&410:STAaddr:LDA&411:STAaddr+1:LDA#0:STAjsr%:STAjmp%:STAptr%:.miss
�)LDA#0:STAstat:JSRpjsr:JSRpjmp:JSRpptr
LDA#&FF:STAloc:STAflag
aLDA#1:STAstat:LDAjsr%:BEQst2:JSRpjsr:.st2 LDAjmp%:BEQst3:JSRpjmp:.st3 LDAptr%:BEQst4:JSRpptr
.st4
$%LDA&410:STAaddr:LDA&411:STAaddr+1
. LDA#0:STAx:STAy:JSRvdu28
8JMPmain_loop
Bx.vdu28 LDA#28:JSR&FFEE:LDA#0:JSR&FFEE:LDA#bot-2:JSR&FFEE:LDA#39:JSR&FFEE:LDA#2:JSR&FFEE:LDXx:LDYy:JSRvdu31:JMPptr_on
LE.vdu26 LDA#134:JSR&FFF4:STXx:STYy:JSRptr_off:LDA#26:JMP&FFEE
VG.pjsr JSRvdu26:LDX#0:LDY#0:JSRvdu31:JSRstr:EQUS" JSR ":BRK:JMPvdu28
`G.pjmp JSRvdu26:LDX#6:LDY#0:JSRvdu31:JSRstr:EQUS" JMP ":BRK:JMPvdu28
jI.pptr JSRvdu26:LDX#35:LDY#0:JSRvdu31:JSRstr:EQUS" PTR ":BRK:JMPvdu28
tI.pram JSRvdu26:LDX#12:LDY#0:JSRvdu31:JSRstr:EQUS" RAM ":BRK:JMPvdu28
~H.prom JSRvdu26:LDX#12:LDY#0:JSRvdu31:JSRstr:EQUS" ROM ":BRK:JMPvdu28
�J.pmos JSRvdu26:LDX#12:LDY#0:JSRvdu31:JSRstr:EQUS" MOS ":BRK:JMPvdu28
�+.what PHA:TXA:PHA:TYA:PHA:LDA#1:STAstat
�PLDAaddr+1:CMP#&80:BPLwhat2:LDAloc:BEQendwhat:LDA#0:STAloc:JSRpram:JMPendwhat
�].what2 CMP#&C0:BPLwhat3:LDAloc:CMP#1:BEQendwhat:LDA#1:STAloc:JSRprom:JSRgetrom:JMPendwhat
�7.what3 LDAloc:CMP#2:BEQendwhat:LDA#2:STAloc:JSRpmos
�2.endwhat LDA#0:STAstat:PLA:TAY:PLA:TAX:PLA:RTS
�T.getrom JSRvdu26:LDY#0:STYstat:LDX#18:JSRvdu31:JSRstr:EQUS"ENTER ROM NUMBER":BRK
�6LDX#16:LDY#bot:JSRvdu31:JSRstring:EQUS"ROM - ":BRK
�2LDA#0:LDX#table3 �256:LDY#table3 �256:JSR&FFF1
�GLDY#0:.g1 LDAtable4,Y:CMP#13:BEQg2:SEC:SBC#48:STAtable4,Y:INY:JMPg1
�k.g2 CPY#0:BNEg3:LDA#0:STAtable4:STAtable4+1:JMPg6:.g3 CPY#1:BNEg6:LDAtable4:STAtable4+1:LDA#0:STAtable4
�.g6 JSRdec:STArom
LDX#16:LDY#bot:LDA#9:JSRspc
LDX#18:LDY#0:LDA#16:JSRspc
JMPvdu28
.follow
(LDAjmp%:BEQf2:JSRfjmp
2 .f2 LDAjsr%:BEQf3:JSRfjsr
< .f3 RTS
F�.fjmp LDAop:CMP#&4C:BNEfjmp2:JSRprompt:BCSfjmp4:RTS:.fjmp4 JSRffw:LDY#1:JSRread:PHA:INY:JSRread:STAaddr+1:PLA:STAaddr:LDA#0:STAinc:RTS
P=.fjmp2 CMP#&6C:BEQfjmp5:RTS:.fjmp5 JSRprompt:BCSfjmp3:RTS
Z�.fjmp3 JSRffw:LDY#1:JSRread:PHA:INY:JSRread:STAaddr+1:PLA:STAaddr:LDY#0:JSRread:PHA:INY:JSRread:STAaddr+1:PLA:STAaddr:LDA#0:STAinc:RTS
dP.fjsr LDAop:CMP#&20:BNEfjsr3:JSRprompt:BCSfjsr2:RTS:.fjsr2 JSRffw:LDYpointer
n�LDAaddr:STAstack,Y:INY:LDAaddr+1:STAstack,Y:INY:STYpointer:LDY#1:JSRread:PHA:INY:JSRread:STAaddr+1:PLA:STAaddr:LDA#0:STAinc:RTS
xv.fjsr3 CMP#&60:BNEfjsr5:LDApointer:BEQfjsr5:JSRptr_on:JSRstring:EQUS" -- Return --":BRK:JSR&FFE7:JSRptr_off
�VLDYpointer:DEY:LDAstack,Y:STAaddr+1:DEY:LDAstack,Y:STAaddr:STYpointer:LDA#3:STAinc
�.fjsr5 RTS
�H.ffw JSRptr_on:JSRstring:EQUS" -- Follow --":BRK:JSR&FFE7:JMPptr_off
�Q.togjsr LDAjsr%:�#&FF:STAjsr%:�#1:STAstat:LDAjsr%:�pointer:STApointer:JMPpjsr
�5.togjmp LDAjmp%:�#&FF:STAjmp%:�#1:STAstat:JMPpjmp
�5.togptr LDAptr%:�#&FF:STAptr%:�#1:STAstat:JMPpptr
�b.ptr_on LDAptr%:BEQendptr:LDA#2:JSR&FFEE:.endptr RTS:.ptr_off LDAptr%:BEQendptr:LDA#3:JMP&FFEE
Ȏ.input JSRvdu26:LDX#11:LDY#bot:JSRvdu31:JSRstring:EQUS"Continue at &":BRK:LDX#table3 �256:LDY#table3 �256:LDA#4:STAtable3+2:LDA#0:JSR&FFF1
Ҝ.move LDAtable4+4:CMP#&D:BEQinp2:LDAtable4+3:STAtable4+4:LDAtable4+2:STAtable4+3:LDAtable4+1:STAtable4+2:LDAtable4:STAtable4+1:LDA#48:STAtable4:JMPmove
� .inp2
�;LDA#2:STAtable3+2:LDA#20:LDX#11:LDY#bot:JSRspc:JSRvdu28
�ZJSRstring:EQUS" -- New Address --":BRK:LDX#table4 �256:LDY#table4 �256:STX&F2:STY&F3
� JSR&FFE7
nLDY#0:JSRnum:STAaddr+1:INY:JSRnum:STAaddr:LDA#0:STAinc:.clr LDY#4:.lo STAtable4,Y:DEY:BPLlo:STAinc:RTS
?.spc PHA:JSRvdu31:PLA:TAY:.sp LDA#32:JSR&FFEE:DEY:BNEsp:RTS
@.chr PHA:JSRvdu31:PLA:TAY:.cp LDA#255:JSR&FFEE:DEY:BNEcp:RTS
"f.num LDA(&F2),Y:JSRinstr:CLC:ASLA:ASLA:ASLA:ASLA:STAtemp2:INY:LDA(&F2),Y:JSRinstr:CLC:ADCtemp2:RTS
,o.instr STYy:STAtemp:LDY#0:.loop LDA Idata,Y:CMPtemp:BEQendins:INY:CPY#16:BNEloop:LDY#0:.endins TYA:LDYy:RTS
6!.Idata EQUS"0123456789ABCDEF"
@B.table3 EQUB table4 �256:EQUB table4 �256:EQUB2:EQUB32:EQUB127
J.table4 EQUS"00000"
TC.table5 EQUB table6 �256:EQUB table6 �256:EQUB31:EQUB32:EQUB127
^1.table6 EQUS"0000000000000000000000000000000"
h`.dec LDA#0:STAtemp2:LDAtable4:BEQdec2:LDYtable4:.dlp LDAtemp2:CLC:ADC#10:STAtemp2:DEY:BNEdlp
r&.dec2 CLC:LDAtable4+1:ADCtemp2:RTS
|N.prompt JSRvdu26:LDX#13:LDY#bot:JSRvdu31:JSRstring:EQUS"Follow? (Y/N)":BRK
�,.pr1 JSR&FFE0:CMP#�"Y":BNEpr2:SEC:JMPpr3
�#.pr2 CMP#�"N":BNEpr1:CLC:JMPpr3
� .pr4 CMP#27:BNEpr1:JMPstop
�).pr3 PHP:LDX#13:LDY#bot:LDA#14:JSRspc
�JSRvdu28:PLP:RTS
�6.starcom JSRvdu26:LDX#2:LDY#bot:JSRvdu31:JSRstring
� EQUS"Star command *":BRK
�2LDA#0:LDX#table5 �256:LDY#table5 �256:JSR&FFF1
� LDA#&24:LDX#2:LDY#bot:JSRspc
�JSRvdu28:JSRcls:JSRfx15
�5LDX#table6 �256:LDY#table6 �256:JSR&FFF7:JSR&FFE7
�-JSRvdu26:LDX#8:LDY#bot:JSRvdu31:JSRstring
�%EQUS"Press SPACE to continue":BRK
.osr JSR&FFE0
BCSret
LDA#&24:LDX#2:LDY#bot:JSRspc
&CMP#&20:BNEosr
0$JSRvdu28:JSRcls:JSRfx15:.ret RTS
:.cls LDA#12:JMP&FFEE
D.fx15 LDA#15:JMP&FFF4
N.stack EQUS �128,�0)
X .table1
b]
le��DvG:�I%=1�152:�A$,b,c:?O%=�("&"+A$):O%?1=b:O%?2=c:O%=O%+3:?P%=�("&"+A$):P%?1=b:P%?2=c:P%=P%+3:�
vv� 69,1,1,65,1,2,75,1,3,6D,1,4,79,1,5,7D,1,6,61,1,7,71,1,8,29,2,1,25,2,2,35,2,3,2D,2,4,3D,2,6,39,2,5,21,2,7,31,2,8
�w� A,3,0,6,3,2,16,3,3,E,3,4,1E,3,6,90,4,9,B0,5,9,F0,6,9,24,7,2,2C,7,4,30,8,9,D0,9,9,10,10,9,0,11,10,50,12,9,70,13,9
��� 18,14,10,D8,15,10,58,16,10,B8,17,10,C9,18,1,C5,18,2,D5,18,3,CD,18,4,DD,18,6,D9,18,5,C1,18,7,D1,18,8,E0,19,1,E4,19,2,EC,19,4
��� C0,20,1,C4,20,2,CC,20,4,C6,21,2,D6,21,3,CE,21,4,DE,21,6,CA,22,10,88,23,10,E8,24,10,C8,25,10,E6,27,2,F6,27,3,EE,27,4,FE,27,6
�� 49,26,1,45,26,2,55,26,3,4D,26,4,5D,26,6,59,26,5,41,26,7,51,26,8,4C,28,4,6C,28,11,20,29,4,A9,30,1,A5,30,2,B5,30,3,AD,30,4
�v� BD,30,6,B9,30,5,A1,30,7,B1,30,8,A2,31,1,A6,31,2,B6,31,3,AE,31,4,BE,31,5,A0,32,1,A4,32,2,B4,32,3,AC,32,4,BC,32,6
�~� 4A,33,0,46,33,2,56,33,3,4E,33,4,5E,33,6,EA,34,10,48,35,10,8,36,10,68,37,10,28,38,10,40,39,10,60,40,10,38,41,10,F8,42,10
��� 78,43,10,AA,44,10,A8,45,10,98,46,10,BA,47,10,8A,48,10,9A,49,10,9,50,1,5,50,2,15,50,3,D,50,4,19,50,5,1D,50,6,1,50,7,11,50,8
�~� 2A,51,0,26,51,2,36,51,3,2E,51,4,3E,51,6,6A,52,0,66,52,2,76,52,3,6E,52,4,7E,52,6,E9,53,1,E5,53,2,F5,53,3,ED,53,4,FD,53,6
І� F9,53,5,E1,53,7,F1,53,8,85,54,2,95,54,3,8D,54,4,9D,54,6,99,54,5,81,54,7,91,54,8,86,55,2,96,55,3,8E,55,4,84,56,2,94,56,3,8C,56,4
� � 0,0,0
�[OPTL%:.table2
� ]:��TLH
�`�I%=1�56:�A$:?O%=��A$,1):O%?1=��A$,2,1):O%?2=��A$,1):?P%=��A$,1):P%?1=��A$,2,1):P%?2=��A$,1)
O%=O%+3:P%=P%+3:�
�� ADC,AND,ASL,BCC,BCS,BEQ,BIT,BMI,BNE,BPL,BRK,BVC,BVS,CLC,CLD,CLI,CLV,CMP,CPX,CPY,DEC,DEX,DEY,INX,INY,EOR,INC,JMP,JSR,LDA,LDX,LDY,LSR,NOP,PHA,PHP,PLA,PLP,RTI,RTS,SEC,SED,SEI,TAX,TAY,TYA,TSX,TXA,TXS,ORA,ROL,ROR,SBC,STA,STX,STY
�
)�"SAVE TRACK2 "+�~Q%+" "+�~O%+" 8237"
� 00000000 0d 00 0a 21 f4 20 54 52 41 43 4b 45 52 20 4d 2f |...!. TRACKER M/|
00000010 43 6f 64 65 20 44 69 73 61 73 73 65 6d 62 6c 65 |Code Disassemble|
00000020 72 0d 00 14 25 f4 20 4f 72 69 67 69 6e 61 6c 20 |r...%. Original |
00000030 50 72 6f 67 72 61 6d 20 62 79 20 4d 61 72 6b 20 |Program by Mark |
00000040 42 6f 6c 74 6f 6e 0d 00 1e 1f f4 20 45 6c 65 63 |Bolton..... Elec|
00000050 74 72 6f 6e 20 55 73 65 72 20 41 75 67 75 73 74 |tron User August|
00000060 20 31 39 38 38 0d 00 28 23 f4 20 52 4f 4d 20 76 | 1988..(#. ROM v|
00000070 65 72 73 69 6f 6e 2c 20 50 61 72 74 20 32 20 28 |ersion, Part 2 (|
00000080 54 4b 52 73 72 63 32 29 0d 00 32 23 f4 20 42 79 |TKRsrc2)..2#. By|
00000090 20 52 69 63 68 61 72 64 20 44 69 6d 6f 6e 64 2c | Richard Dimond,|
000000a0 20 4d 61 72 63 68 20 31 39 39 37 0d 00 3c 05 f4 | March 1997..<..|
000000b0 0d 00 46 08 eb 31 33 34 0d 00 50 c0 61 64 64 72 |..F..134..P.addr|
000000c0 3d 26 37 30 3a 74 65 6d 70 3d 26 37 32 3a 6f 70 |=&70:temp=&72:op|
000000d0 3d 26 37 34 3a 6d 6e 65 3d 26 37 35 3a 66 64 3d |=&74:mne=&75:fd=|
000000e0 26 37 38 3a 69 6e 63 3d 26 37 39 3a 69 6e 64 65 |&78:inc=&79:inde|
000000f0 78 3d 26 37 41 3a 63 6f 75 6e 74 65 72 3d 26 37 |x=&7A:counter=&7|
00000100 42 3a 63 6f 64 65 3d 26 37 43 3a 74 65 6d 70 32 |B:code=&7C:temp2|
00000110 3d 26 37 44 3a 72 6f 6d 3d 26 37 46 3a 73 74 61 |=&7D:rom=&7F:sta|
00000120 74 3d 26 38 30 3a 78 3d 26 38 31 3a 79 3d 26 38 |t=&80:x=&81:y=&8|
00000130 32 3a 6c 6f 63 3d 26 38 33 3a 6a 73 72 25 3d 26 |2:loc=&83:jsr%=&|
00000140 38 34 3a 6a 6d 70 25 3d 26 38 35 3a 70 74 72 25 |84:jmp%=&85:ptr%|
00000150 3d 26 38 36 3a 66 6c 61 67 3d 26 38 37 3a 6f 6c |=&86:flag=&87:ol|
00000160 64 3d 26 38 38 3a 70 6f 69 6e 74 65 72 3d 26 38 |d=&88:pointer=&8|
00000170 46 3a 62 6f 74 3d 32 33 0d 00 5a 0d de 20 51 25 |F:bot=23..Z.. Q%|
00000180 20 34 30 30 30 0d 00 64 0e e3 20 4c 25 3d 34 b8 | 4000..d.. L%=4.|
00000190 36 88 32 0d 00 6e 1a 4f 25 3d 51 25 3a 50 25 3d |6.2..n.O%=Q%:P%=|
000001a0 26 38 32 33 37 3a 5b 4f 50 54 20 4c 25 0d 00 78 |&8237:[OPT L%..x|
000001b0 26 4c 44 41 23 30 3a 53 54 41 26 32 41 30 3a 53 |&LDA#0:STA&2A0:S|
000001c0 54 41 26 38 34 3a 53 54 41 26 38 35 3a 53 54 41 |TA&84:STA&85:STA|
000001d0 26 38 36 0d 00 82 22 4c 44 41 23 32 32 3a 4a 53 |&86..."LDA#22:JS|
000001e0 52 26 46 46 45 45 3a 4c 44 41 23 36 3a 4a 53 52 |R&FFEE:LDA#6:JSR|
000001f0 26 46 46 45 45 0d 00 8c 0c 4a 4d 50 73 74 61 72 |&FFEE....JMPstar|
00000200 74 0d 00 96 2c 2e 68 65 78 20 50 48 41 3a 4c 53 |t...,.hex PHA:LS|
00000210 52 41 3a 4c 53 52 41 3a 4c 53 52 41 3a 4c 53 52 |RA:LSRA:LSRA:LSR|
00000220 41 3a 4a 53 52 68 65 78 32 3a 50 4c 41 0d 00 a0 |A:JSRhex2:PLA...|
00000230 33 2e 68 65 78 32 20 80 23 26 46 3a 53 45 44 3a |3.hex2 .#&F:SED:|
00000240 43 4c 43 3a 41 44 43 23 26 39 30 3a 41 44 43 23 |CLC:ADC#&90:ADC#|
00000250 26 34 30 3a 43 4c 44 3a 4a 4d 50 26 46 46 45 45 |&40:CLD:JMP&FFEE|
00000260 0d 00 aa 37 2e 63 68 61 72 20 53 54 59 74 65 6d |...7.char STYtem|
00000270 70 32 3a 53 54 41 26 36 30 3a 4c 44 41 23 26 41 |p2:STA&60:LDA#&A|
00000280 3a 4c 44 58 23 26 36 30 3a 4c 44 59 23 30 3a 4a |:LDX#&60:LDY#0:J|
00000290 53 52 26 46 46 46 31 0d 00 b4 4f 4c 44 41 23 32 |SR&FFF1...OLDA#2|
000002a0 33 3a 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 32 |3:JSR&FFEE:LDA#2|
000002b0 35 35 3a 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 |55:JSR&FFEE:LDA#|
000002c0 30 3a 4a 53 52 26 46 46 45 45 3a 4c 44 58 23 31 |0:JSR&FFEE:LDX#1|
000002d0 3a 4a 53 52 76 64 75 3a 49 4e 58 3a 49 4e 58 3a |:JSRvdu:INX:INX:|
000002e0 4a 53 52 76 64 75 0d 00 be 40 49 4e 58 3a 4a 53 |JSRvdu...@INX:JS|
000002f0 52 76 64 75 3a 49 4e 58 3a 4a 53 52 76 64 75 3a |Rvdu:INX:JSRvdu:|
00000300 49 4e 58 3a 49 4e 58 3a 4a 53 52 76 64 75 3a 4c |INX:INX:JSRvdu:L|
00000310 44 41 23 30 3a 4a 53 52 26 46 46 45 45 3a 4a 53 |DA#0:JSR&FFEE:JS|
00000320 52 26 46 46 45 45 0d 00 c8 b3 4c 44 41 73 74 61 |R&FFEE....LDAsta|
00000330 74 3a 42 45 51 65 6e 64 76 3a 4c 44 41 23 31 37 |t:BEQendv:LDA#17|
00000340 3a 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 30 3a |:JSR&FFEE:LDA#0:|
00000350 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 31 37 3a |JSR&FFEE:LDA#17:|
00000360 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 31 32 39 |JSR&FFEE:LDA#129|
00000370 3a 4a 53 52 26 46 46 45 45 3a 2e 65 6e 64 76 20 |:JSR&FFEE:.endv |
00000380 4c 44 59 74 65 6d 70 32 3a 4c 44 41 23 32 35 35 |LDYtemp2:LDA#255|
00000390 3a 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 31 37 |:JSR&FFEE:LDA#17|
000003a0 3a 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 31 3a |:JSR&FFEE:LDA#1:|
000003b0 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 31 37 3a |JSR&FFEE:LDA#17:|
000003c0 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 31 32 38 |JSR&FFEE:LDA#128|
000003d0 3a 4a 4d 50 26 46 46 45 45 0d 00 d2 1a 2e 76 64 |:JMP&FFEE.....vd|
000003e0 75 20 4c 44 41 26 36 30 2c 58 3a 4a 4d 50 26 46 |u LDA&60,X:JMP&F|
000003f0 46 45 45 0d 00 dc 34 2e 76 64 75 33 31 20 4c 44 |FEE...4.vdu31 LD|
00000400 41 23 33 31 3a 4a 53 52 26 46 46 45 45 3a 54 58 |A#31:JSR&FFEE:TX|
00000410 41 3a 4a 53 52 26 46 46 45 45 3a 54 59 41 3a 4a |A:JSR&FFEE:TYA:J|
00000420 4d 50 26 46 46 45 45 0d 00 e6 0e 2e 6d 61 69 6e |MP&FFEE.....main|
00000430 5f 6c 6f 6f 70 0d 00 f0 4c 4a 53 52 67 65 74 5f |_loop...LJSRget_|
00000440 69 6e 66 6f 3a 4a 53 52 70 74 72 5f 6f 6e 3a 4a |info:JSRptr_on:J|
00000450 53 52 61 64 64 72 65 73 73 3a 4c 44 41 23 30 3a |SRaddress:LDA#0:|
00000460 53 54 41 73 74 61 74 3a 4a 53 52 6d 6e 65 6d 6f |STAstat:JSRmnemo|
00000470 6e 69 63 3a 4c 44 41 23 36 3a 4a 53 52 78 70 6f |nic:LDA#6:JSRxpo|
00000480 73 0d 00 fa 7c 4a 53 52 62 79 74 65 73 3a 4c 44 |s...|JSRbytes:LD|
00000490 41 23 31 3a 53 54 41 73 74 61 74 3a 4a 53 52 6d |A#1:STAstat:JSRm|
000004a0 6e 65 6d 6f 6e 69 63 3a 4a 53 52 61 73 63 69 69 |nemonic:JSRascii|
000004b0 3a 4c 44 41 23 31 30 3a 4a 53 52 26 46 46 45 45 |:LDA#10:JSR&FFEE|
000004c0 3a 4c 44 41 23 31 33 3a 4a 53 52 26 46 46 45 45 |:LDA#13:JSR&FFEE|
000004d0 3a 4a 53 52 70 74 72 5f 6f 66 66 3a 4a 53 52 66 |:JSRptr_off:JSRf|
000004e0 6f 6c 6c 6f 77 3a 4a 53 52 26 46 46 45 30 3a 43 |ollow:JSR&FFE0:C|
000004f0 4d 50 23 32 37 3a 42 45 51 73 74 6f 70 0d 01 04 |MP#27:BEQstop...|
00000500 55 43 4d 50 23 97 22 42 22 3a 42 4e 45 63 6f 6e |UCMP#."B":BNEcon|
00000510 74 32 3a 44 45 43 61 64 64 72 2b 31 3a 4a 53 52 |t2:DECaddr+1:JSR|
00000520 73 74 72 69 6e 67 3a 45 51 55 53 22 20 2d 2d 20 |string:EQUS" -- |
00000530 42 61 63 6b 20 2d 2d 22 3a 42 52 4b 3a 4a 53 52 |Back --":BRK:JSR|
00000540 26 46 46 45 37 3a 4a 4d 50 6d 61 69 6e 5f 6c 6f |&FFE7:JMPmain_lo|
00000550 6f 70 0d 01 0e 5f 2e 63 6f 6e 74 32 20 43 4d 50 |op..._.cont2 CMP|
00000560 23 97 22 46 22 3a 42 4e 45 63 6f 6e 74 33 3a 49 |#."F":BNEcont3:I|
00000570 4e 43 61 64 64 72 2b 31 3a 4a 53 52 73 74 72 69 |NCaddr+1:JSRstri|
00000580 6e 67 3a 45 51 55 53 22 20 2d 2d 20 46 6f 72 77 |ng:EQUS" -- Forw|
00000590 61 72 64 20 2d 2d 22 3a 42 52 4b 3a 4a 53 52 26 |ard --":BRK:JSR&|
000005a0 46 46 45 37 3a 4a 4d 50 6d 61 69 6e 5f 6c 6f 6f |FFE7:JMPmain_loo|
000005b0 70 0d 01 18 2f 2e 63 6f 6e 74 33 20 43 4d 50 23 |p.../.cont3 CMP#|
000005c0 97 22 50 22 3a 42 4e 45 63 6f 6e 74 34 3a 4a 53 |."P":BNEcont4:JS|
000005d0 52 74 6f 67 70 74 72 3a 4a 4d 50 63 6f 6e 74 30 |Rtogptr:JMPcont0|
000005e0 0d 01 22 2f 2e 63 6f 6e 74 34 20 43 4d 50 23 97 |.."/.cont4 CMP#.|
000005f0 22 4d 22 3a 42 4e 45 63 6f 6e 74 35 3a 4a 53 52 |"M":BNEcont5:JSR|
00000600 74 6f 67 6a 6d 70 3a 4a 4d 50 63 6f 6e 74 30 0d |togjmp:JMPcont0.|
00000610 01 2c 30 2e 63 6f 6e 74 35 20 43 4d 50 23 97 22 |.,0.cont5 CMP#."|
00000620 4a 22 3a 42 4e 45 63 6f 6e 74 36 3a 4a 53 52 74 |J":BNEcont6:JSRt|
00000630 6f 67 6a 73 72 3a 4a 4d 50 63 6f 6e 74 30 20 0d |ogjsr:JMPcont0 .|
00000640 01 36 33 2e 63 6f 6e 74 36 20 43 4d 50 23 97 22 |.63.cont6 CMP#."|
00000650 41 22 3a 42 4e 45 63 6f 6e 74 37 3a 4a 53 52 69 |A":BNEcont7:JSRi|
00000660 6e 70 75 74 3a 4a 4d 50 6d 61 69 6e 5f 6c 6f 6f |nput:JMPmain_loo|
00000670 70 20 0d 01 40 27 2e 63 6f 6e 74 37 20 43 4d 50 |p ..@'.cont7 CMP|
00000680 23 97 22 2a 22 3a 42 4e 45 63 6f 6e 74 30 3a 4a |#."*":BNEcont0:J|
00000690 53 52 73 74 61 72 63 6f 6d 0d 01 4a 3f 2e 63 6f |SRstarcom..J?.co|
000006a0 6e 74 30 20 43 4c 43 3a 4c 44 41 61 64 64 72 3a |nt0 CLC:LDAaddr:|
000006b0 41 44 43 69 6e 63 3a 53 54 41 61 64 64 72 3a 4c |ADCinc:STAaddr:L|
000006c0 44 41 61 64 64 72 2b 31 3a 41 44 43 23 30 3a 53 |DAaddr+1:ADC#0:S|
000006d0 54 41 61 64 64 72 2b 31 0d 01 54 12 4a 4d 50 6d |TAaddr+1..T.JMPm|
000006e0 61 69 6e 5f 6c 6f 6f 70 20 20 0d 01 5e 1e 2e 73 |ain_loop ..^..s|
000006f0 74 6f 70 20 4a 53 52 20 70 74 72 5f 6f 66 66 3a |top JSR ptr_off:|
00000700 4a 4d 50 26 38 31 30 35 0d 01 68 0d 2e 67 65 74 |JMP&8105..h..get|
00000710 5f 69 6e 66 6f 0d 01 72 22 4c 44 59 23 30 3a 53 |_info..r"LDY#0:S|
00000720 54 59 63 6f 75 6e 74 65 72 3a 4a 53 52 72 65 61 |TYcounter:JSRrea|
00000730 64 3a 53 54 41 6f 70 0d 01 7c 35 4c 44 41 23 74 |d:STAop..|5LDA#t|
00000740 61 62 6c 65 31 20 83 32 35 36 3a 53 54 41 74 65 |able1 .256:STAte|
00000750 6d 70 3a 4c 44 41 23 74 61 62 6c 65 31 20 81 32 |mp:LDA#table1 .2|
00000760 35 36 3a 53 54 41 74 65 6d 70 2b 31 0d 01 86 23 |56:STAtemp+1...#|
00000770 2e 67 6c 70 20 4c 44 41 28 74 65 6d 70 29 2c 59 |.glp LDA(temp),Y|
00000780 3a 43 4d 50 6f 70 3a 42 45 51 66 6f 75 6e 64 0d |:CMPop:BEQfound.|
00000790 01 90 42 43 4c 43 3a 4c 44 41 74 65 6d 70 3a 41 |..BCLC:LDAtemp:A|
000007a0 44 43 23 33 3a 53 54 41 74 65 6d 70 3a 4c 44 41 |DC#3:STAtemp:LDA|
000007b0 74 65 6d 70 2b 31 3a 41 44 43 23 30 3a 53 54 41 |temp+1:ADC#0:STA|
000007c0 74 65 6d 70 2b 31 3a 49 4e 43 63 6f 75 6e 74 65 |temp+1:INCcounte|
000007d0 72 0d 01 9a 1d 4c 44 41 63 6f 75 6e 74 65 72 3a |r....LDAcounter:|
000007e0 43 4d 50 23 31 35 32 3a 42 4e 45 67 6c 70 0d 01 |CMP#152:BNEglp..|
000007f0 a4 1c 4c 44 41 23 30 3a 53 54 41 66 64 3a 53 54 |..LDA#0:STAfd:ST|
00000800 41 69 6e 64 65 78 3a 52 54 53 0d 01 ae 18 2e 66 |Aindex:RTS.....f|
00000810 6f 75 6e 64 20 4c 44 41 23 26 46 46 3a 53 54 41 |ound LDA#&FF:STA|
00000820 66 64 0d 01 b8 3e 4c 44 59 23 31 3a 4c 44 41 28 |fd...>LDY#1:LDA(|
00000830 74 65 6d 70 29 2c 59 3a 53 54 41 63 6f 64 65 3a |temp),Y:STAcode:|
00000840 44 45 43 63 6f 64 65 3a 49 4e 59 3a 4c 44 41 28 |DECcode:INY:LDA(|
00000850 74 65 6d 70 29 2c 59 3a 53 54 41 69 6e 64 65 78 |temp),Y:STAindex|
00000860 0d 01 c2 45 4c 44 41 23 74 61 62 6c 65 32 20 83 |...ELDA#table2 .|
00000870 32 35 36 3a 53 54 41 74 65 6d 70 3a 4c 44 41 23 |256:STAtemp:LDA#|
00000880 74 61 62 6c 65 32 20 81 32 35 36 3a 53 54 41 74 |table2 .256:STAt|
00000890 65 6d 70 2b 31 3a 4c 44 41 63 6f 64 65 3a 42 45 |emp+1:LDAcode:BE|
000008a0 51 73 6b 69 70 0d 01 cc 55 4c 44 59 23 30 3a 2e |Qskip...ULDY#0:.|
000008b0 66 6c 70 20 4c 44 41 74 65 6d 70 3a 43 4c 43 3a |flp LDAtemp:CLC:|
000008c0 41 44 43 23 33 3a 53 54 41 74 65 6d 70 3a 4c 44 |ADC#3:STAtemp:LD|
000008d0 41 74 65 6d 70 2b 31 3a 41 44 43 23 30 3a 53 54 |Atemp+1:ADC#0:ST|
000008e0 41 74 65 6d 70 2b 31 3a 49 4e 59 3a 43 50 59 63 |Atemp+1:INY:CPYc|
000008f0 6f 64 65 3a 42 4e 45 66 6c 70 0d 01 d6 3a 2e 73 |ode:BNEflp...:.s|
00000900 6b 69 70 20 4c 44 59 23 30 3a 2e 6c 70 32 20 4c |kip LDY#0:.lp2 L|
00000910 44 41 28 74 65 6d 70 29 2c 59 3a 53 54 41 6d 6e |DA(temp),Y:STAmn|
00000920 65 2c 59 3a 49 4e 59 3a 43 50 59 23 33 3a 42 4e |e,Y:INY:CPY#3:BN|
00000930 45 6c 70 32 0d 01 e0 07 52 54 53 0d 01 ea 3c 2e |Elp2....RTS...<.|
00000940 72 65 61 64 20 4a 53 52 77 68 61 74 3a 53 54 59 |read JSRwhat:STY|
00000950 26 39 30 3a 4c 44 41 61 64 64 72 2b 31 3a 43 4d |&90:LDAaddr+1:CM|
00000960 50 23 26 38 30 3a 42 50 4c 72 65 61 64 32 3a 4a |P#&80:BPLread2:J|
00000970 4d 50 72 65 61 64 35 0d 01 f4 24 2e 72 65 61 64 |MPread5...$.read|
00000980 32 20 43 4d 50 23 26 43 30 3a 42 4d 49 72 65 61 |2 CMP#&C0:BMIrea|
00000990 64 33 3a 4a 4d 50 72 65 61 64 35 0d 01 fe 0a 2e |d3:JMPread5.....|
000009a0 72 65 61 64 33 0d 02 08 5a 53 54 59 74 65 6d 70 |read3...ZSTYtemp|
000009b0 32 3a 43 4c 43 3a 4c 44 41 61 64 64 72 3a 41 44 |2:CLC:LDAaddr:AD|
000009c0 43 74 65 6d 70 32 3a 53 54 41 26 46 36 3a 4c 44 |Ctemp2:STA&F6:LD|
000009d0 41 61 64 64 72 2b 31 3a 41 44 43 23 30 3a 53 54 |Aaddr+1:ADC#0:ST|
000009e0 41 26 46 37 3a 4c 44 59 72 6f 6d 3a 4a 53 52 26 |A&F7:LDYrom:JSR&|
000009f0 46 46 42 39 3a 4c 44 59 26 39 30 3a 52 54 53 0d |FFB9:LDY&90:RTS.|
00000a00 02 12 1a 2e 72 65 61 64 35 20 4c 44 41 28 61 64 |....read5 LDA(ad|
00000a10 64 72 29 2c 59 3a 52 54 53 0d 02 1c 3c 2e 61 64 |dr),Y:RTS...<.ad|
00000a20 64 72 65 73 73 20 4c 44 41 61 64 64 72 2b 31 3a |dress LDAaddr+1:|
00000a30 4a 53 52 68 65 78 3a 4c 44 41 61 64 64 72 3a 4a |JSRhex:LDAaddr:J|
00000a40 53 52 68 65 78 3a 4c 44 41 23 33 32 3a 4a 4d 50 |SRhex:LDA#32:JMP|
00000a50 26 46 46 45 45 0d 02 26 4d 2e 62 79 74 65 73 20 |&FFEE..&M.bytes |
00000a60 4c 44 59 23 30 3a 2e 62 6c 70 20 4a 53 52 72 65 |LDY#0:.blp JSRre|
00000a70 61 64 3a 4a 53 52 68 65 78 3a 4c 44 41 23 33 32 |ad:JSRhex:LDA#32|
00000a80 3a 4a 53 52 26 46 46 45 45 3a 49 4e 59 3a 43 50 |:JSR&FFEE:INY:CP|
00000a90 59 69 6e 63 3a 42 4e 45 62 6c 70 3a 4c 44 41 23 |Yinc:BNEblp:LDA#|
00000aa0 31 36 0d 02 30 5a 2e 78 70 6f 73 20 53 54 41 74 |16..0Z.xpos STAt|
00000ab0 65 6d 70 32 3a 2e 78 6c 70 20 4c 44 41 23 31 33 |emp2:.xlp LDA#13|
00000ac0 34 3a 4a 53 52 26 46 46 46 34 3a 43 50 58 74 65 |4:JSR&FFF4:CPXte|
00000ad0 6d 70 32 3a 42 50 4c 65 6e 64 78 3a 4c 44 41 23 |mp2:BPLendx:LDA#|
00000ae0 33 32 3a 4a 53 52 26 46 46 45 45 3a 4a 4d 50 78 |32:JSR&FFEE:JMPx|
00000af0 6c 70 3a 2e 65 6e 64 78 20 52 54 53 0d 02 3a 29 |lp:.endx RTS..:)|
00000b00 2e 6d 6e 65 6d 6f 6e 69 63 20 4c 44 41 73 74 61 |.mnemonic LDAsta|
00000b10 74 3a 42 4e 45 6d 6e 65 6d 6f 6e 3a 4a 4d 50 6e |t:BNEmnemon:JMPn|
00000b20 75 6d 62 65 72 0d 02 44 0b 2e 6d 6e 65 6d 6f 6e |umber..D..mnemon|
00000b30 0d 02 4e 38 4c 44 41 66 64 3a 42 4e 45 6d 6e 65 |..N8LDAfd:BNEmne|
00000b40 32 3a 4a 53 52 73 74 72 69 6e 67 3a 45 51 55 53 |2:JSRstring:EQUS|
00000b50 22 4e 6f 20 73 75 63 68 20 63 6f 64 65 22 3a 45 |"No such code":E|
00000b60 51 55 42 30 3a 52 54 53 0d 02 58 3d 2e 6d 6e 65 |QUB0:RTS..X=.mne|
00000b70 32 20 4c 44 59 23 30 3a 2e 6d 6c 70 20 4c 44 41 |2 LDY#0:.mlp LDA|
00000b80 6d 6e 65 2c 59 3a 4a 53 52 26 46 46 45 45 3a 49 |mne,Y:JSR&FFEE:I|
00000b90 4e 59 3a 43 50 59 23 33 3a 42 4e 45 6d 6c 70 3a |NY:CPY#3:BNEmlp:|
00000ba0 2e 6d 6e 65 33 0d 02 62 19 4c 44 41 69 6e 64 65 |.mne3..b.LDAinde|
00000bb0 78 3a 42 4e 45 6d 31 3a 4a 4d 50 20 41 30 0d 02 |x:BNEm1:JMP A0..|
00000bc0 6c 1a 2e 6d 31 20 43 4d 50 23 31 3a 42 4e 45 6d |l..m1 CMP#1:BNEm|
00000bd0 32 3a 4a 4d 50 20 41 31 0d 02 76 1a 2e 6d 32 20 |2:JMP A1..v..m2 |
00000be0 43 4d 50 23 32 3a 42 4e 45 6d 33 3a 4a 4d 50 20 |CMP#2:BNEm3:JMP |
00000bf0 41 32 0d 02 80 1a 2e 6d 33 20 43 4d 50 23 33 3a |A2.....m3 CMP#3:|
00000c00 42 4e 45 6d 34 3a 4a 4d 50 20 41 33 0d 02 8a 1a |BNEm4:JMP A3....|
00000c10 2e 6d 34 20 43 4d 50 23 34 3a 42 4e 45 6d 35 3a |.m4 CMP#4:BNEm5:|
00000c20 4a 4d 50 20 41 34 0d 02 94 1a 2e 6d 35 20 43 4d |JMP A4.....m5 CM|
00000c30 50 23 35 3a 42 4e 45 6d 36 3a 4a 4d 50 20 41 35 |P#5:BNEm6:JMP A5|
00000c40 0d 02 9e 1a 2e 6d 36 20 43 4d 50 23 36 3a 42 4e |.....m6 CMP#6:BN|
00000c50 45 6d 37 3a 4a 4d 50 20 41 36 0d 02 a8 1a 2e 6d |Em7:JMP A6.....m|
00000c60 37 20 43 4d 50 23 37 3a 42 4e 45 6d 38 3a 4a 4d |7 CMP#7:BNEm8:JM|
00000c70 50 20 41 37 0d 02 b2 1a 2e 6d 38 20 43 4d 50 23 |P A7.....m8 CMP#|
00000c80 38 3a 42 4e 45 6d 39 3a 4a 4d 50 20 41 38 0d 02 |8:BNEm9:JMP A8..|
00000c90 bc 1b 2e 6d 39 20 43 4d 50 23 39 3a 42 4e 45 6d |...m9 CMP#9:BNEm|
00000ca0 31 30 3a 4a 4d 50 20 41 39 0d 02 c6 1e 2e 6d 31 |10:JMP A9.....m1|
00000cb0 30 20 43 4d 50 23 31 30 3a 42 4e 45 6d 31 31 3a |0 CMP#10:BNEm11:|
00000cc0 4a 4d 50 20 41 31 30 0d 02 d0 1d 2e 6d 31 31 20 |JMP A10.....m11 |
00000cd0 43 4d 50 23 31 31 3a 42 4e 45 6d 30 3a 4a 4d 50 |CMP#11:BNEm0:JMP|
00000ce0 20 41 31 31 0d 02 da 0b 2e 6d 30 20 52 54 53 0d | A11.....m0 RTS.|
00000cf0 02 e4 4c 2e 61 73 63 69 69 20 4c 44 41 23 33 36 |..L.ascii LDA#36|
00000d00 3a 4a 53 52 78 70 6f 73 3a 4c 44 59 23 30 3a 2e |:JSRxpos:LDY#0:.|
00000d10 61 6c 70 20 4a 53 52 72 65 61 64 3a 43 4d 50 23 |alp JSRread:CMP#|
00000d20 33 32 3a 42 50 4c 61 73 63 32 3a 4c 44 41 23 97 |32:BPLasc2:LDA#.|
00000d30 22 2e 22 3a 4a 4d 50 61 73 63 33 0d 02 ee 22 2e |".":JMPasc3...".|
00000d40 61 73 63 32 20 43 4d 50 23 31 32 37 3a 42 4d 49 |asc2 CMP#127:BMI|
00000d50 61 73 63 33 3a 4c 44 41 23 97 22 2e 22 0d 02 f8 |asc3:LDA#."."...|
00000d60 24 2e 61 73 63 33 20 4a 53 52 26 46 46 45 45 3a |$.asc3 JSR&FFEE:|
00000d70 49 4e 59 3a 43 50 59 69 6e 63 3a 42 4e 45 61 6c |INY:CPYinc:BNEal|
00000d80 70 0d 03 02 07 52 54 53 0d 03 0c 30 2e 41 30 20 |p....RTS...0.A0 |
00000d90 4c 44 41 23 33 32 3a 4a 53 52 26 46 46 45 45 3a |LDA#32:JSR&FFEE:|
00000da0 4c 44 41 23 97 22 41 22 3a 4a 4d 50 26 46 46 45 |LDA#."A":JMP&FFE|
00000db0 45 20 20 20 20 20 20 20 0d 03 16 2b 2e 41 31 20 |E ...+.A1 |
00000dc0 4a 53 52 68 61 73 68 3a 4a 53 52 61 6d 70 3a 4c |JSRhash:JSRamp:L|
00000dd0 44 59 23 31 3a 4a 53 52 72 65 61 64 3a 4a 4d 50 |DY#1:JSRread:JMP|
00000de0 68 65 78 0d 03 20 23 2e 41 32 20 4a 53 52 61 6d |hex.. #.A2 JSRam|
00000df0 70 3a 4c 44 59 23 31 3a 4a 53 52 72 65 61 64 3a |p:LDY#1:JSRread:|
00000e00 4a 4d 50 68 65 78 0d 03 2a 34 2e 41 33 20 4a 53 |JMPhex..*4.A3 JS|
00000e10 52 61 6d 70 3a 4c 44 59 23 31 3a 4a 53 52 72 65 |Ramp:LDY#1:JSRre|
00000e20 61 64 3a 4a 53 52 68 65 78 3a 4a 53 52 63 6f 6d |ad:JSRhex:JSRcom|
00000e30 6d 61 3a 4a 4d 50 70 78 20 20 0d 03 34 37 2e 41 |ma:JMPpx ..47.A|
00000e40 34 20 4a 53 52 61 6d 70 3a 4c 44 59 23 32 3a 4a |4 JSRamp:LDY#2:J|
00000e50 53 52 72 65 61 64 3a 4a 53 52 68 65 78 3a 44 45 |SRread:JSRhex:DE|
00000e60 59 3a 4a 53 52 72 65 61 64 3a 4a 4d 50 68 65 78 |Y:JSRread:JMPhex|
00000e70 20 0d 03 3e 46 2e 41 35 20 4a 53 52 61 6d 70 3a | ..>F.A5 JSRamp:|
00000e80 4c 44 59 23 32 3a 4a 53 52 72 65 61 64 3a 4a 53 |LDY#2:JSRread:JS|
00000e90 52 68 65 78 3a 44 45 59 3a 4a 53 52 72 65 61 64 |Rhex:DEY:JSRread|
00000ea0 3a 4a 53 52 68 65 78 3a 4a 53 52 63 6f 6d 6d 61 |:JSRhex:JSRcomma|
00000eb0 3a 4a 4d 50 70 79 20 0d 03 48 46 2e 41 36 20 4a |:JMPpy ..HF.A6 J|
00000ec0 53 52 61 6d 70 3a 4c 44 59 23 32 3a 4a 53 52 72 |SRamp:LDY#2:JSRr|
00000ed0 65 61 64 3a 4a 53 52 68 65 78 3a 44 45 59 3a 4a |ead:JSRhex:DEY:J|
00000ee0 53 52 72 65 61 64 3a 4a 53 52 68 65 78 3a 4a 53 |SRread:JSRhex:JS|
00000ef0 52 63 6f 6d 6d 61 3a 4a 4d 50 70 78 20 0d 03 52 |Rcomma:JMPpx ..R|
00000f00 4a 2e 41 37 20 4a 53 52 62 72 61 63 6b 31 3a 4a |J.A7 JSRbrack1:J|
00000f10 53 52 61 6d 70 3a 4c 44 59 23 31 3a 4a 53 52 72 |SRamp:LDY#1:JSRr|
00000f20 65 61 64 3a 4a 53 52 68 65 78 3a 4a 53 52 63 6f |ead:JSRhex:JSRco|
00000f30 6d 6d 61 3a 4a 53 52 70 78 3a 4a 4d 50 62 72 61 |mma:JSRpx:JMPbra|
00000f40 63 6b 32 20 20 20 20 0d 03 5c 47 2e 41 38 20 4a |ck2 ..\G.A8 J|
00000f50 53 52 62 72 61 63 6b 31 3a 4a 53 52 61 6d 70 3a |SRbrack1:JSRamp:|
00000f60 4c 44 59 23 31 3a 4a 53 52 72 65 61 64 3a 4a 53 |LDY#1:JSRread:JS|
00000f70 52 68 65 78 3a 4a 53 52 62 72 61 63 6b 32 3a 4a |Rhex:JSRbrack2:J|
00000f80 53 52 63 6f 6d 6d 61 3a 4a 4d 50 70 79 20 0d 03 |SRcomma:JMPpy ..|
00000f90 66 8d 2e 41 39 20 4a 53 52 61 6d 70 3a 4c 44 59 |f..A9 JSRamp:LDY|
00000fa0 23 31 3a 4a 53 52 72 65 61 64 3a 53 54 41 74 65 |#1:JSRread:STAte|
00000fb0 6d 70 3a 43 4d 50 23 26 38 31 3a 42 4d 49 20 42 |mp:CMP#&81:BMI B|
00000fc0 39 3a 53 45 43 3a 4c 44 41 23 26 46 45 3a 53 42 |9:SEC:LDA#&FE:SB|
00000fd0 43 74 65 6d 70 3a 53 54 41 74 65 6d 70 2b 31 3a |Ctemp:STAtemp+1:|
00000fe0 53 45 43 3a 4c 44 41 61 64 64 72 3a 53 42 43 74 |SEC:LDAaddr:SBCt|
00000ff0 65 6d 70 2b 31 3a 50 48 41 3a 4c 44 41 61 64 64 |emp+1:PHA:LDAadd|
00001000 72 2b 31 3a 53 42 43 23 30 3a 4a 53 52 68 65 78 |r+1:SBC#0:JSRhex|
00001010 3a 50 4c 41 3a 4a 4d 50 68 65 78 0d 03 70 5f 2e |:PLA:JMPhex..p_.|
00001020 42 39 20 43 4c 43 3a 4c 44 41 23 32 3a 41 44 43 |B9 CLC:LDA#2:ADC|
00001030 74 65 6d 70 3a 53 54 41 74 65 6d 70 2b 31 3a 43 |temp:STAtemp+1:C|
00001040 4c 43 3a 4c 44 41 61 64 64 72 3a 41 44 43 74 65 |LC:LDAaddr:ADCte|
00001050 6d 70 2b 31 3a 50 48 41 3a 4c 44 41 61 64 64 72 |mp+1:PHA:LDAaddr|
00001060 2b 31 3a 41 44 43 23 30 3a 4a 53 52 68 65 78 3a |+1:ADC#0:JSRhex:|
00001070 50 4c 41 3a 4a 4d 50 68 65 78 0d 03 7a 4b 2e 41 |PLA:JMPhex..zK.A|
00001080 31 31 20 4a 53 52 62 72 61 63 6b 31 3a 4a 53 52 |11 JSRbrack1:JSR|
00001090 61 6d 70 3a 4c 44 59 23 32 3a 4a 53 52 72 65 61 |amp:LDY#2:JSRrea|
000010a0 64 3a 4a 53 52 68 65 78 3a 44 45 59 3a 4a 53 52 |d:JSRhex:DEY:JSR|
000010b0 72 65 61 64 3a 4a 53 52 68 65 78 3a 4a 4d 50 62 |read:JSRhex:JMPb|
000010c0 72 61 63 6b 32 0d 03 84 0c 2e 41 31 30 20 52 54 |rack2.....A10 RT|
000010d0 53 0d 03 8e 64 2e 70 78 20 4c 44 41 23 97 22 58 |S...d.px LDA#."X|
000010e0 22 3a 4a 4d 50 26 46 46 45 45 3a 2e 70 79 20 4c |":JMP&FFEE:.py L|
000010f0 44 41 23 97 22 59 22 3a 4a 4d 50 26 46 46 45 45 |DA#."Y":JMP&FFEE|
00001100 3a 2e 62 72 61 63 6b 31 20 4c 44 41 23 97 22 28 |:.brack1 LDA#."(|
00001110 22 3a 4a 4d 50 26 46 46 45 45 3a 2e 62 72 61 63 |":JMP&FFEE:.brac|
00001120 6b 32 20 4c 44 41 23 97 22 29 22 3a 4a 4d 50 26 |k2 LDA#.")":JMP&|
00001130 46 46 45 45 20 0d 03 98 4b 2e 63 6f 6d 6d 61 20 |FFEE ...K.comma |
00001140 4c 44 41 23 97 22 2c 22 3a 4a 4d 50 26 46 46 45 |LDA#.",":JMP&FFE|
00001150 45 3a 2e 61 6d 70 20 4c 44 41 23 97 22 26 22 3a |E:.amp LDA#."&":|
00001160 4a 4d 50 26 46 46 45 45 3a 2e 68 61 73 68 20 4c |JMP&FFEE:.hash L|
00001170 44 41 23 97 22 23 22 3a 4a 4d 50 26 46 46 45 45 |DA#."#":JMP&FFEE|
00001180 0d 03 a2 62 2e 6e 75 6d 62 65 72 20 4c 44 41 69 |...b.number LDAi|
00001190 6e 64 65 78 3a 43 4d 50 23 31 3a 42 45 51 20 49 |ndex:CMP#1:BEQ I|
000011a0 32 3a 43 4d 50 23 32 3a 42 45 51 20 49 32 3a 43 |2:CMP#2:BEQ I2:C|
000011b0 4d 50 23 33 3a 42 45 51 20 49 32 3a 43 4d 50 23 |MP#3:BEQ I2:CMP#|
000011c0 37 3a 42 45 51 20 49 32 3a 43 4d 50 23 38 3a 42 |7:BEQ I2:CMP#8:B|
000011d0 45 51 20 49 32 3a 43 4d 50 23 39 3a 42 45 51 20 |EQ I2:CMP#9:BEQ |
000011e0 49 32 0d 03 ac 4e 43 4d 50 23 34 3a 42 45 51 20 |I2...NCMP#4:BEQ |
000011f0 49 33 3a 43 4d 50 23 35 3a 42 45 51 20 49 33 3a |I3:CMP#5:BEQ I3:|
00001200 43 4d 50 23 36 3a 42 45 51 20 49 33 3a 43 4d 50 |CMP#6:BEQ I3:CMP|
00001210 23 31 31 3a 42 45 51 20 49 33 3a 2e 49 31 20 4c |#11:BEQ I3:.I1 L|
00001220 44 41 23 31 3a 53 54 41 69 6e 63 3a 52 54 53 20 |DA#1:STAinc:RTS |
00001230 0d 03 b6 2d 2e 49 32 20 4c 44 41 23 32 3a 53 54 |...-.I2 LDA#2:ST|
00001240 41 69 6e 63 3a 52 54 53 3a 2e 49 33 20 4c 44 41 |Ainc:RTS:.I3 LDA|
00001250 23 33 3a 53 54 41 69 6e 63 3a 52 54 53 0d 03 c0 |#3:STAinc:RTS...|
00001260 94 2e 73 74 72 20 50 4c 41 3a 53 54 41 74 65 6d |..str PLA:STAtem|
00001270 70 3a 50 4c 41 3a 53 54 41 74 65 6d 70 2b 31 3a |p:PLA:STAtemp+1:|
00001280 4c 44 59 23 30 3a 42 45 51 70 73 32 3a 2e 70 73 |LDY#0:BEQps2:.ps|
00001290 20 4c 44 41 28 74 65 6d 70 29 2c 59 3a 42 45 51 | LDA(temp),Y:BEQ|
000012a0 70 73 31 3a 4a 53 52 63 68 61 72 3a 2e 70 73 32 |ps1:JSRchar:.ps2|
000012b0 20 49 4e 43 74 65 6d 70 3a 42 4e 45 70 73 3a 49 | INCtemp:BNEps:I|
000012c0 4e 43 74 65 6d 70 2b 31 3a 42 4e 45 70 73 3a 2e |NCtemp+1:BNEps:.|
000012d0 70 73 31 20 4c 44 41 74 65 6d 70 2b 31 3a 50 48 |ps1 LDAtemp+1:PH|
000012e0 41 3a 4c 44 41 74 65 6d 70 3a 50 48 41 3a 52 54 |A:LDAtemp:PHA:RT|
000012f0 53 0d 03 ca 9b 2e 73 74 72 69 6e 67 20 50 4c 41 |S.....string PLA|
00001300 3a 53 54 41 74 65 6d 70 3a 50 4c 41 3a 53 54 41 |:STAtemp:PLA:STA|
00001310 74 65 6d 70 2b 31 3a 4c 44 59 23 30 3a 42 45 51 |temp+1:LDY#0:BEQ|
00001320 70 73 35 3a 2e 70 73 33 20 4c 44 41 28 74 65 6d |ps5:.ps3 LDA(tem|
00001330 70 29 2c 59 3a 42 45 51 70 73 34 3a 4a 53 52 26 |p),Y:BEQps4:JSR&|
00001340 46 46 45 45 3a 2e 70 73 35 20 49 4e 43 74 65 6d |FFEE:.ps5 INCtem|
00001350 70 3a 42 4e 45 70 73 33 3a 49 4e 43 74 65 6d 70 |p:BNEps3:INCtemp|
00001360 2b 31 3a 42 4e 45 70 73 33 3a 2e 70 73 34 20 4c |+1:BNEps3:.ps4 L|
00001370 44 41 74 65 6d 70 2b 31 3a 50 48 41 3a 4c 44 41 |DAtemp+1:PHA:LDA|
00001380 74 65 6d 70 3a 50 48 41 3a 52 54 53 0d 03 d4 78 |temp:PHA:RTS...x|
00001390 2e 73 74 61 72 74 20 4c 44 41 23 32 38 3a 4a 53 |.start LDA#28:JS|
000013a0 52 26 46 46 45 45 3a 4c 44 41 23 30 3a 4a 53 52 |R&FFEE:LDA#0:JSR|
000013b0 26 46 46 45 45 3a 4c 44 41 23 31 32 3a 4a 53 52 |&FFEE:LDA#12:JSR|
000013c0 26 46 46 45 45 3a 4c 44 41 23 33 39 3a 4a 53 52 |&FFEE:LDA#39:JSR|
000013d0 26 46 46 45 45 3a 4c 44 41 23 30 3a 4a 53 52 26 |&FFEE:LDA#0:JSR&|
000013e0 46 46 45 45 3a 4c 44 41 23 31 32 3a 4a 53 52 26 |FFEE:LDA#12:JSR&|
000013f0 46 46 45 45 3a 4c 44 41 23 32 36 3a 4a 53 52 26 |FFEE:LDA#26:JSR&|
00001400 46 46 45 45 0d 03 de 67 4c 44 41 23 32 33 3a 4a |FFEE...gLDA#23:J|
00001410 53 52 26 46 46 45 45 3a 4c 44 41 23 32 35 35 3a |SR&FFEE:LDA#255:|
00001420 4a 53 52 26 46 46 45 45 3a 4c 44 58 23 38 3a 2e |JSR&FFEE:LDX#8:.|
00001430 6c 6c 70 20 4c 44 41 23 30 3a 43 50 58 23 35 3a |llp LDA#0:CPX#5:|
00001440 42 4e 45 6e 6f 70 72 74 3a 4c 44 41 23 32 35 35 |BNEnoprt:LDA#255|
00001450 3a 2e 6e 6f 70 72 74 20 4a 53 52 26 46 46 45 45 |:.noprt JSR&FFEE|
00001460 3a 44 45 58 3a 42 4e 45 6c 6c 70 0d 03 e8 3b 4c |:DEX:BNEllp...;L|
00001470 44 41 23 34 30 3a 4c 44 58 23 30 3a 4c 44 59 23 |DA#40:LDX#0:LDY#|
00001480 31 3a 4a 53 52 63 68 72 3a 4c 44 41 23 34 30 3a |1:JSRchr:LDA#40:|
00001490 4c 44 58 23 30 3a 4c 44 59 23 62 6f 74 2d 31 3a |LDX#0:LDY#bot-1:|
000014a0 4a 53 52 63 68 72 0d 03 f2 5a 4c 44 41 66 6c 61 |JSRchr...ZLDAfla|
000014b0 67 3a 42 4e 45 6d 69 73 73 3a 4c 44 41 26 34 31 |g:BNEmiss:LDA&41|
000014c0 30 3a 53 54 41 61 64 64 72 3a 4c 44 41 26 34 31 |0:STAaddr:LDA&41|
000014d0 31 3a 53 54 41 61 64 64 72 2b 31 3a 4c 44 41 23 |1:STAaddr+1:LDA#|
000014e0 30 3a 53 54 41 6a 73 72 25 3a 53 54 41 6a 6d 70 |0:STAjsr%:STAjmp|
000014f0 25 3a 53 54 41 70 74 72 25 3a 2e 6d 69 73 73 20 |%:STAptr%:.miss |
00001500 0d 03 fc 29 4c 44 41 23 30 3a 53 54 41 73 74 61 |...)LDA#0:STAsta|
00001510 74 3a 4a 53 52 70 6a 73 72 3a 4a 53 52 70 6a 6d |t:JSRpjsr:JSRpjm|
00001520 70 3a 4a 53 52 70 70 74 72 0d 04 06 1a 4c 44 41 |p:JSRpptr....LDA|
00001530 23 26 46 46 3a 53 54 41 6c 6f 63 3a 53 54 41 66 |#&FF:STAloc:STAf|
00001540 6c 61 67 0d 04 10 61 4c 44 41 23 31 3a 53 54 41 |lag...aLDA#1:STA|
00001550 73 74 61 74 3a 4c 44 41 6a 73 72 25 3a 42 45 51 |stat:LDAjsr%:BEQ|
00001560 73 74 32 3a 4a 53 52 70 6a 73 72 3a 2e 73 74 32 |st2:JSRpjsr:.st2|
00001570 20 20 4c 44 41 6a 6d 70 25 3a 42 45 51 73 74 33 | LDAjmp%:BEQst3|
00001580 3a 4a 53 52 70 6a 6d 70 3a 2e 73 74 33 20 4c 44 |:JSRpjmp:.st3 LD|
00001590 41 70 74 72 25 3a 42 45 51 73 74 34 3a 4a 53 52 |Aptr%:BEQst4:JSR|
000015a0 70 70 74 72 0d 04 1a 09 2e 73 74 34 20 0d 04 24 |pptr.....st4 ..$|
000015b0 25 4c 44 41 26 34 31 30 3a 53 54 41 61 64 64 72 |%LDA&410:STAaddr|
000015c0 3a 4c 44 41 26 34 31 31 3a 53 54 41 61 64 64 72 |:LDA&411:STAaddr|
000015d0 2b 31 0d 04 2e 1c 4c 44 41 23 30 3a 53 54 41 78 |+1....LDA#0:STAx|
000015e0 3a 53 54 41 79 3a 4a 53 52 76 64 75 32 38 0d 04 |:STAy:JSRvdu28..|
000015f0 38 10 4a 4d 50 6d 61 69 6e 5f 6c 6f 6f 70 0d 04 |8.JMPmain_loop..|
00001600 42 78 2e 76 64 75 32 38 20 4c 44 41 23 32 38 3a |Bx.vdu28 LDA#28:|
00001610 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 30 3a 4a |JSR&FFEE:LDA#0:J|
00001620 53 52 26 46 46 45 45 3a 4c 44 41 23 62 6f 74 2d |SR&FFEE:LDA#bot-|
00001630 32 3a 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 33 |2:JSR&FFEE:LDA#3|
00001640 39 3a 4a 53 52 26 46 46 45 45 3a 4c 44 41 23 32 |9:JSR&FFEE:LDA#2|
00001650 3a 4a 53 52 26 46 46 45 45 3a 4c 44 58 78 3a 4c |:JSR&FFEE:LDXx:L|
00001660 44 59 79 3a 4a 53 52 76 64 75 33 31 3a 4a 4d 50 |DYy:JSRvdu31:JMP|
00001670 70 74 72 5f 6f 6e 0d 04 4c 45 2e 76 64 75 32 36 |ptr_on..LE.vdu26|
00001680 20 4c 44 41 23 31 33 34 3a 4a 53 52 26 46 46 46 | LDA#134:JSR&FFF|
00001690 34 3a 53 54 58 78 3a 53 54 59 79 3a 4a 53 52 70 |4:STXx:STYy:JSRp|
000016a0 74 72 5f 6f 66 66 3a 4c 44 41 23 32 36 3a 4a 4d |tr_off:LDA#26:JM|
000016b0 50 26 46 46 45 45 20 20 20 20 20 0d 04 56 47 2e |P&FFEE ..VG.|
000016c0 70 6a 73 72 20 4a 53 52 76 64 75 32 36 3a 4c 44 |pjsr JSRvdu26:LD|
000016d0 58 23 30 3a 4c 44 59 23 30 3a 4a 53 52 76 64 75 |X#0:LDY#0:JSRvdu|
000016e0 33 31 3a 4a 53 52 73 74 72 3a 45 51 55 53 22 20 |31:JSRstr:EQUS" |
000016f0 4a 53 52 20 22 3a 42 52 4b 3a 4a 4d 50 76 64 75 |JSR ":BRK:JMPvdu|
00001700 32 38 0d 04 60 47 2e 70 6a 6d 70 20 4a 53 52 76 |28..`G.pjmp JSRv|
00001710 64 75 32 36 3a 4c 44 58 23 36 3a 4c 44 59 23 30 |du26:LDX#6:LDY#0|
00001720 3a 4a 53 52 76 64 75 33 31 3a 4a 53 52 73 74 72 |:JSRvdu31:JSRstr|
00001730 3a 45 51 55 53 22 20 4a 4d 50 20 22 3a 42 52 4b |:EQUS" JMP ":BRK|
00001740 3a 4a 4d 50 76 64 75 32 38 0d 04 6a 49 2e 70 70 |:JMPvdu28..jI.pp|
00001750 74 72 20 4a 53 52 76 64 75 32 36 3a 4c 44 58 23 |tr JSRvdu26:LDX#|
00001760 33 35 3a 4c 44 59 23 30 3a 4a 53 52 76 64 75 33 |35:LDY#0:JSRvdu3|
00001770 31 3a 4a 53 52 73 74 72 3a 45 51 55 53 22 20 50 |1:JSRstr:EQUS" P|
00001780 54 52 20 22 3a 42 52 4b 3a 4a 4d 50 76 64 75 32 |TR ":BRK:JMPvdu2|
00001790 38 20 0d 04 74 49 2e 70 72 61 6d 20 4a 53 52 76 |8 ..tI.pram JSRv|
000017a0 64 75 32 36 3a 4c 44 58 23 31 32 3a 4c 44 59 23 |du26:LDX#12:LDY#|
000017b0 30 3a 4a 53 52 76 64 75 33 31 3a 4a 53 52 73 74 |0:JSRvdu31:JSRst|
000017c0 72 3a 45 51 55 53 22 20 52 41 4d 20 22 3a 42 52 |r:EQUS" RAM ":BR|
000017d0 4b 3a 4a 4d 50 76 64 75 32 38 20 0d 04 7e 48 2e |K:JMPvdu28 ..~H.|
000017e0 70 72 6f 6d 20 4a 53 52 76 64 75 32 36 3a 4c 44 |prom JSRvdu26:LD|
000017f0 58 23 31 32 3a 4c 44 59 23 30 3a 4a 53 52 76 64 |X#12:LDY#0:JSRvd|
00001800 75 33 31 3a 4a 53 52 73 74 72 3a 45 51 55 53 22 |u31:JSRstr:EQUS"|
00001810 20 52 4f 4d 20 22 3a 42 52 4b 3a 4a 4d 50 76 64 | ROM ":BRK:JMPvd|
00001820 75 32 38 0d 04 88 4a 2e 70 6d 6f 73 20 4a 53 52 |u28...J.pmos JSR|
00001830 76 64 75 32 36 3a 4c 44 58 23 31 32 3a 4c 44 59 |vdu26:LDX#12:LDY|
00001840 23 30 3a 4a 53 52 76 64 75 33 31 3a 4a 53 52 73 |#0:JSRvdu31:JSRs|
00001850 74 72 3a 45 51 55 53 22 20 4d 4f 53 20 22 3a 42 |tr:EQUS" MOS ":B|
00001860 52 4b 3a 4a 4d 50 76 64 75 32 38 20 20 0d 04 92 |RK:JMPvdu28 ...|
00001870 2b 2e 77 68 61 74 20 50 48 41 3a 54 58 41 3a 50 |+.what PHA:TXA:P|
00001880 48 41 3a 54 59 41 3a 50 48 41 3a 4c 44 41 23 31 |HA:TYA:PHA:LDA#1|
00001890 3a 53 54 41 73 74 61 74 0d 04 9c 50 4c 44 41 61 |:STAstat...PLDAa|
000018a0 64 64 72 2b 31 3a 43 4d 50 23 26 38 30 3a 42 50 |ddr+1:CMP#&80:BP|
000018b0 4c 77 68 61 74 32 3a 4c 44 41 6c 6f 63 3a 42 45 |Lwhat2:LDAloc:BE|
000018c0 51 65 6e 64 77 68 61 74 3a 4c 44 41 23 30 3a 53 |Qendwhat:LDA#0:S|
000018d0 54 41 6c 6f 63 3a 4a 53 52 70 72 61 6d 3a 4a 4d |TAloc:JSRpram:JM|
000018e0 50 65 6e 64 77 68 61 74 0d 04 a6 5d 2e 77 68 61 |Pendwhat...].wha|
000018f0 74 32 20 43 4d 50 23 26 43 30 3a 42 50 4c 77 68 |t2 CMP#&C0:BPLwh|
00001900 61 74 33 3a 4c 44 41 6c 6f 63 3a 43 4d 50 23 31 |at3:LDAloc:CMP#1|
00001910 3a 42 45 51 65 6e 64 77 68 61 74 3a 4c 44 41 23 |:BEQendwhat:LDA#|
00001920 31 3a 53 54 41 6c 6f 63 3a 4a 53 52 70 72 6f 6d |1:STAloc:JSRprom|
00001930 3a 4a 53 52 67 65 74 72 6f 6d 3a 4a 4d 50 65 6e |:JSRgetrom:JMPen|
00001940 64 77 68 61 74 0d 04 b0 37 2e 77 68 61 74 33 20 |dwhat...7.what3 |
00001950 4c 44 41 6c 6f 63 3a 43 4d 50 23 32 3a 42 45 51 |LDAloc:CMP#2:BEQ|
00001960 65 6e 64 77 68 61 74 3a 4c 44 41 23 32 3a 53 54 |endwhat:LDA#2:ST|
00001970 41 6c 6f 63 3a 4a 53 52 70 6d 6f 73 0d 04 ba 32 |Aloc:JSRpmos...2|
00001980 2e 65 6e 64 77 68 61 74 20 4c 44 41 23 30 3a 53 |.endwhat LDA#0:S|
00001990 54 41 73 74 61 74 3a 50 4c 41 3a 54 41 59 3a 50 |TAstat:PLA:TAY:P|
000019a0 4c 41 3a 54 41 58 3a 50 4c 41 3a 52 54 53 0d 04 |LA:TAX:PLA:RTS..|
000019b0 c4 54 2e 67 65 74 72 6f 6d 20 4a 53 52 76 64 75 |.T.getrom JSRvdu|
000019c0 32 36 3a 4c 44 59 23 30 3a 53 54 59 73 74 61 74 |26:LDY#0:STYstat|
000019d0 3a 4c 44 58 23 31 38 3a 4a 53 52 76 64 75 33 31 |:LDX#18:JSRvdu31|
000019e0 3a 4a 53 52 73 74 72 3a 45 51 55 53 22 45 4e 54 |:JSRstr:EQUS"ENT|
000019f0 45 52 20 52 4f 4d 20 4e 55 4d 42 45 52 22 3a 42 |ER ROM NUMBER":B|
00001a00 52 4b 0d 04 ce 36 4c 44 58 23 31 36 3a 4c 44 59 |RK...6LDX#16:LDY|
00001a10 23 62 6f 74 3a 4a 53 52 76 64 75 33 31 3a 4a 53 |#bot:JSRvdu31:JS|
00001a20 52 73 74 72 69 6e 67 3a 45 51 55 53 22 52 4f 4d |Rstring:EQUS"ROM|
00001a30 20 2d 20 22 3a 42 52 4b 0d 04 d8 32 4c 44 41 23 | - ":BRK...2LDA#|
00001a40 30 3a 4c 44 58 23 74 61 62 6c 65 33 20 83 32 35 |0:LDX#table3 .25|
00001a50 36 3a 4c 44 59 23 74 61 62 6c 65 33 20 81 32 35 |6:LDY#table3 .25|
00001a60 36 3a 4a 53 52 26 46 46 46 31 0d 04 e2 47 4c 44 |6:JSR&FFF1...GLD|
00001a70 59 23 30 3a 2e 67 31 20 4c 44 41 74 61 62 6c 65 |Y#0:.g1 LDAtable|
00001a80 34 2c 59 3a 43 4d 50 23 31 33 3a 42 45 51 67 32 |4,Y:CMP#13:BEQg2|
00001a90 3a 53 45 43 3a 53 42 43 23 34 38 3a 53 54 41 74 |:SEC:SBC#48:STAt|
00001aa0 61 62 6c 65 34 2c 59 3a 49 4e 59 3a 4a 4d 50 67 |able4,Y:INY:JMPg|
00001ab0 31 0d 04 ec 6b 2e 67 32 20 43 50 59 23 30 3a 42 |1...k.g2 CPY#0:B|
00001ac0 4e 45 67 33 3a 4c 44 41 23 30 3a 53 54 41 74 61 |NEg3:LDA#0:STAta|
00001ad0 62 6c 65 34 3a 53 54 41 74 61 62 6c 65 34 2b 31 |ble4:STAtable4+1|
00001ae0 3a 4a 4d 50 67 36 3a 2e 67 33 20 43 50 59 23 31 |:JMPg6:.g3 CPY#1|
00001af0 3a 42 4e 45 67 36 3a 4c 44 41 74 61 62 6c 65 34 |:BNEg6:LDAtable4|
00001b00 3a 53 54 41 74 61 62 6c 65 34 2b 31 3a 4c 44 41 |:STAtable4+1:LDA|
00001b10 23 30 3a 53 54 41 74 61 62 6c 65 34 0d 04 f6 15 |#0:STAtable4....|
00001b20 2e 67 36 20 4a 53 52 64 65 63 3a 53 54 41 72 6f |.g6 JSRdec:STAro|
00001b30 6d 0d 05 00 1f 4c 44 58 23 31 36 3a 4c 44 59 23 |m....LDX#16:LDY#|
00001b40 62 6f 74 3a 4c 44 41 23 39 3a 4a 53 52 73 70 63 |bot:LDA#9:JSRspc|
00001b50 0d 05 0a 1e 4c 44 58 23 31 38 3a 4c 44 59 23 30 |....LDX#18:LDY#0|
00001b60 3a 4c 44 41 23 31 36 3a 4a 53 52 73 70 63 0d 05 |:LDA#16:JSRspc..|
00001b70 14 0c 4a 4d 50 76 64 75 32 38 0d 05 1e 0b 2e 66 |..JMPvdu28.....f|
00001b80 6f 6c 6c 6f 77 0d 05 28 19 4c 44 41 6a 6d 70 25 |ollow..(.LDAjmp%|
00001b90 3a 42 45 51 66 32 3a 4a 53 52 66 6a 6d 70 0d 05 |:BEQf2:JSRfjmp..|
00001ba0 32 1d 2e 66 32 20 4c 44 41 6a 73 72 25 3a 42 45 |2..f2 LDAjsr%:BE|
00001bb0 51 66 33 3a 4a 53 52 66 6a 73 72 0d 05 3c 0b 2e |Qf3:JSRfjsr..<..|
00001bc0 66 33 20 52 54 53 0d 05 46 8b 2e 66 6a 6d 70 20 |f3 RTS..F..fjmp |
00001bd0 4c 44 41 6f 70 3a 43 4d 50 23 26 34 43 3a 42 4e |LDAop:CMP#&4C:BN|
00001be0 45 66 6a 6d 70 32 3a 4a 53 52 70 72 6f 6d 70 74 |Efjmp2:JSRprompt|
00001bf0 3a 42 43 53 66 6a 6d 70 34 3a 52 54 53 3a 2e 66 |:BCSfjmp4:RTS:.f|
00001c00 6a 6d 70 34 20 4a 53 52 66 66 77 3a 4c 44 59 23 |jmp4 JSRffw:LDY#|
00001c10 31 3a 4a 53 52 72 65 61 64 3a 50 48 41 3a 49 4e |1:JSRread:PHA:IN|
00001c20 59 3a 4a 53 52 72 65 61 64 3a 53 54 41 61 64 64 |Y:JSRread:STAadd|
00001c30 72 2b 31 3a 50 4c 41 3a 53 54 41 61 64 64 72 3a |r+1:PLA:STAaddr:|
00001c40 4c 44 41 23 30 3a 53 54 41 69 6e 63 3a 52 54 53 |LDA#0:STAinc:RTS|
00001c50 20 0d 05 50 3d 2e 66 6a 6d 70 32 20 43 4d 50 23 | ..P=.fjmp2 CMP#|
00001c60 26 36 43 3a 42 45 51 66 6a 6d 70 35 3a 52 54 53 |&6C:BEQfjmp5:RTS|
00001c70 3a 2e 66 6a 6d 70 35 20 4a 53 52 70 72 6f 6d 70 |:.fjmp5 JSRpromp|
00001c80 74 3a 42 43 53 66 6a 6d 70 33 3a 52 54 53 0d 05 |t:BCSfjmp3:RTS..|
00001c90 5a 8b 2e 66 6a 6d 70 33 20 4a 53 52 66 66 77 3a |Z..fjmp3 JSRffw:|
00001ca0 4c 44 59 23 31 3a 4a 53 52 72 65 61 64 3a 50 48 |LDY#1:JSRread:PH|
00001cb0 41 3a 49 4e 59 3a 4a 53 52 72 65 61 64 3a 53 54 |A:INY:JSRread:ST|
00001cc0 41 61 64 64 72 2b 31 3a 50 4c 41 3a 53 54 41 61 |Aaddr+1:PLA:STAa|
00001cd0 64 64 72 3a 4c 44 59 23 30 3a 4a 53 52 72 65 61 |ddr:LDY#0:JSRrea|
00001ce0 64 3a 50 48 41 3a 49 4e 59 3a 4a 53 52 72 65 61 |d:PHA:INY:JSRrea|
00001cf0 64 3a 53 54 41 61 64 64 72 2b 31 3a 50 4c 41 3a |d:STAaddr+1:PLA:|
00001d00 53 54 41 61 64 64 72 3a 4c 44 41 23 30 3a 53 54 |STAaddr:LDA#0:ST|
00001d10 41 69 6e 63 3a 52 54 53 20 0d 05 64 50 2e 66 6a |Ainc:RTS ..dP.fj|
00001d20 73 72 20 4c 44 41 6f 70 3a 43 4d 50 23 26 32 30 |sr LDAop:CMP#&20|
00001d30 3a 42 4e 45 66 6a 73 72 33 3a 4a 53 52 70 72 6f |:BNEfjsr3:JSRpro|
00001d40 6d 70 74 3a 42 43 53 66 6a 73 72 32 3a 52 54 53 |mpt:BCSfjsr2:RTS|
00001d50 3a 2e 66 6a 73 72 32 20 4a 53 52 66 66 77 3a 4c |:.fjsr2 JSRffw:L|
00001d60 44 59 70 6f 69 6e 74 65 72 0d 05 6e 84 4c 44 41 |DYpointer..n.LDA|
00001d70 61 64 64 72 3a 53 54 41 73 74 61 63 6b 2c 59 3a |addr:STAstack,Y:|
00001d80 49 4e 59 3a 4c 44 41 61 64 64 72 2b 31 3a 53 54 |INY:LDAaddr+1:ST|
00001d90 41 73 74 61 63 6b 2c 59 3a 49 4e 59 3a 53 54 59 |Astack,Y:INY:STY|
00001da0 70 6f 69 6e 74 65 72 3a 4c 44 59 23 31 3a 4a 53 |pointer:LDY#1:JS|
00001db0 52 72 65 61 64 3a 50 48 41 3a 49 4e 59 3a 4a 53 |Rread:PHA:INY:JS|
00001dc0 52 72 65 61 64 3a 53 54 41 61 64 64 72 2b 31 3a |Rread:STAaddr+1:|
00001dd0 50 4c 41 3a 53 54 41 61 64 64 72 3a 4c 44 41 23 |PLA:STAaddr:LDA#|
00001de0 30 3a 53 54 41 69 6e 63 3a 52 54 53 20 0d 05 78 |0:STAinc:RTS ..x|
00001df0 76 2e 66 6a 73 72 33 20 43 4d 50 23 26 36 30 3a |v.fjsr3 CMP#&60:|
00001e00 42 4e 45 66 6a 73 72 35 3a 4c 44 41 70 6f 69 6e |BNEfjsr5:LDApoin|
00001e10 74 65 72 3a 42 45 51 66 6a 73 72 35 3a 4a 53 52 |ter:BEQfjsr5:JSR|
00001e20 70 74 72 5f 6f 6e 3a 4a 53 52 73 74 72 69 6e 67 |ptr_on:JSRstring|
00001e30 3a 45 51 55 53 22 20 2d 2d 20 52 65 74 75 72 6e |:EQUS" -- Return|
00001e40 20 2d 2d 22 3a 42 52 4b 3a 4a 53 52 26 46 46 45 | --":BRK:JSR&FFE|
00001e50 37 3a 4a 53 52 70 74 72 5f 6f 66 66 20 20 20 20 |7:JSRptr_off |
00001e60 20 20 20 0d 05 82 56 4c 44 59 70 6f 69 6e 74 65 | ...VLDYpointe|
00001e70 72 3a 44 45 59 3a 4c 44 41 73 74 61 63 6b 2c 59 |r:DEY:LDAstack,Y|
00001e80 3a 53 54 41 61 64 64 72 2b 31 3a 44 45 59 3a 4c |:STAaddr+1:DEY:L|
00001e90 44 41 73 74 61 63 6b 2c 59 3a 53 54 41 61 64 64 |DAstack,Y:STAadd|
00001ea0 72 3a 53 54 59 70 6f 69 6e 74 65 72 3a 4c 44 41 |r:STYpointer:LDA|
00001eb0 23 33 3a 53 54 41 69 6e 63 0d 05 8c 0e 2e 66 6a |#3:STAinc.....fj|
00001ec0 73 72 35 20 52 54 53 0d 05 96 48 2e 66 66 77 20 |sr5 RTS...H.ffw |
00001ed0 4a 53 52 70 74 72 5f 6f 6e 3a 4a 53 52 73 74 72 |JSRptr_on:JSRstr|
00001ee0 69 6e 67 3a 45 51 55 53 22 20 2d 2d 20 46 6f 6c |ing:EQUS" -- Fol|
00001ef0 6c 6f 77 20 2d 2d 22 3a 42 52 4b 3a 4a 53 52 26 |low --":BRK:JSR&|
00001f00 46 46 45 37 3a 4a 4d 50 70 74 72 5f 6f 66 66 0d |FFE7:JMPptr_off.|
00001f10 05 a0 51 2e 74 6f 67 6a 73 72 20 4c 44 41 6a 73 |..Q.togjsr LDAjs|
00001f20 72 25 3a 82 23 26 46 46 3a 53 54 41 6a 73 72 25 |r%:.#&FF:STAjsr%|
00001f30 3a 80 23 31 3a 53 54 41 73 74 61 74 3a 4c 44 41 |:.#1:STAstat:LDA|
00001f40 6a 73 72 25 3a 80 70 6f 69 6e 74 65 72 3a 53 54 |jsr%:.pointer:ST|
00001f50 41 70 6f 69 6e 74 65 72 3a 4a 4d 50 70 6a 73 72 |Apointer:JMPpjsr|
00001f60 0d 05 aa 35 2e 74 6f 67 6a 6d 70 20 4c 44 41 6a |...5.togjmp LDAj|
00001f70 6d 70 25 3a 82 23 26 46 46 3a 53 54 41 6a 6d 70 |mp%:.#&FF:STAjmp|
00001f80 25 3a 80 23 31 3a 53 54 41 73 74 61 74 3a 4a 4d |%:.#1:STAstat:JM|
00001f90 50 70 6a 6d 70 0d 05 b4 35 2e 74 6f 67 70 74 72 |Ppjmp...5.togptr|
00001fa0 20 4c 44 41 70 74 72 25 3a 82 23 26 46 46 3a 53 | LDAptr%:.#&FF:S|
00001fb0 54 41 70 74 72 25 3a 80 23 31 3a 53 54 41 73 74 |TAptr%:.#1:STAst|
00001fc0 61 74 3a 4a 4d 50 70 70 74 72 0d 05 be 62 2e 70 |at:JMPpptr...b.p|
00001fd0 74 72 5f 6f 6e 20 4c 44 41 70 74 72 25 3a 42 45 |tr_on LDAptr%:BE|
00001fe0 51 65 6e 64 70 74 72 3a 4c 44 41 23 32 3a 4a 53 |Qendptr:LDA#2:JS|
00001ff0 52 26 46 46 45 45 3a 2e 65 6e 64 70 74 72 20 52 |R&FFEE:.endptr R|
00002000 54 53 3a 2e 70 74 72 5f 6f 66 66 20 4c 44 41 70 |TS:.ptr_off LDAp|
00002010 74 72 25 3a 42 45 51 65 6e 64 70 74 72 3a 4c 44 |tr%:BEQendptr:LD|
00002020 41 23 33 3a 4a 4d 50 26 46 46 45 45 0d 05 c8 8e |A#3:JMP&FFEE....|
00002030 2e 69 6e 70 75 74 20 4a 53 52 76 64 75 32 36 3a |.input JSRvdu26:|
00002040 4c 44 58 23 31 31 3a 4c 44 59 23 62 6f 74 3a 4a |LDX#11:LDY#bot:J|
00002050 53 52 76 64 75 33 31 3a 4a 53 52 73 74 72 69 6e |SRvdu31:JSRstrin|
00002060 67 3a 45 51 55 53 22 43 6f 6e 74 69 6e 75 65 20 |g:EQUS"Continue |
00002070 61 74 20 26 22 3a 42 52 4b 3a 4c 44 58 23 74 61 |at &":BRK:LDX#ta|
00002080 62 6c 65 33 20 83 32 35 36 3a 4c 44 59 23 74 61 |ble3 .256:LDY#ta|
00002090 62 6c 65 33 20 81 32 35 36 3a 4c 44 41 23 34 3a |ble3 .256:LDA#4:|
000020a0 53 54 41 74 61 62 6c 65 33 2b 32 3a 4c 44 41 23 |STAtable3+2:LDA#|
000020b0 30 3a 4a 53 52 26 46 46 46 31 0d 05 d2 9c 2e 6d |0:JSR&FFF1.....m|
000020c0 6f 76 65 20 4c 44 41 74 61 62 6c 65 34 2b 34 3a |ove LDAtable4+4:|
000020d0 43 4d 50 23 26 44 3a 42 45 51 69 6e 70 32 3a 4c |CMP#&D:BEQinp2:L|
000020e0 44 41 74 61 62 6c 65 34 2b 33 3a 53 54 41 74 61 |DAtable4+3:STAta|
000020f0 62 6c 65 34 2b 34 3a 4c 44 41 74 61 62 6c 65 34 |ble4+4:LDAtable4|
00002100 2b 32 3a 53 54 41 74 61 62 6c 65 34 2b 33 3a 4c |+2:STAtable4+3:L|
00002110 44 41 74 61 62 6c 65 34 2b 31 3a 53 54 41 74 61 |DAtable4+1:STAta|
00002120 62 6c 65 34 2b 32 3a 4c 44 41 74 61 62 6c 65 34 |ble4+2:LDAtable4|
00002130 3a 53 54 41 74 61 62 6c 65 34 2b 31 3a 4c 44 41 |:STAtable4+1:LDA|
00002140 23 34 38 3a 53 54 41 74 61 62 6c 65 34 3a 4a 4d |#48:STAtable4:JM|
00002150 50 6d 6f 76 65 20 0d 05 dc 09 2e 69 6e 70 32 0d |Pmove .....inp2.|
00002160 05 e6 3b 4c 44 41 23 32 3a 53 54 41 74 61 62 6c |..;LDA#2:STAtabl|
00002170 65 33 2b 32 3a 4c 44 41 23 32 30 3a 4c 44 58 23 |e3+2:LDA#20:LDX#|
00002180 31 31 3a 4c 44 59 23 62 6f 74 3a 4a 53 52 73 70 |11:LDY#bot:JSRsp|
00002190 63 3a 4a 53 52 76 64 75 32 38 0d 05 f0 5a 4a 53 |c:JSRvdu28...ZJS|
000021a0 52 73 74 72 69 6e 67 3a 45 51 55 53 22 20 2d 2d |Rstring:EQUS" --|
000021b0 20 4e 65 77 20 41 64 64 72 65 73 73 20 2d 2d 22 | New Address --"|
000021c0 3a 42 52 4b 3a 4c 44 58 23 74 61 62 6c 65 34 20 |:BRK:LDX#table4 |
000021d0 83 32 35 36 3a 4c 44 59 23 74 61 62 6c 65 34 20 |.256:LDY#table4 |
000021e0 81 32 35 36 3a 53 54 58 26 46 32 3a 53 54 59 26 |.256:STX&F2:STY&|
000021f0 46 33 20 20 0d 05 fa 0c 4a 53 52 26 46 46 45 37 |F3 ....JSR&FFE7|
00002200 0d 06 04 6e 4c 44 59 23 30 3a 4a 53 52 6e 75 6d |...nLDY#0:JSRnum|
00002210 3a 53 54 41 61 64 64 72 2b 31 3a 49 4e 59 3a 4a |:STAaddr+1:INY:J|
00002220 53 52 6e 75 6d 3a 53 54 41 61 64 64 72 3a 4c 44 |SRnum:STAaddr:LD|
00002230 41 23 30 3a 53 54 41 69 6e 63 3a 2e 63 6c 72 20 |A#0:STAinc:.clr |
00002240 4c 44 59 23 34 3a 2e 6c 6f 20 53 54 41 74 61 62 |LDY#4:.lo STAtab|
00002250 6c 65 34 2c 59 3a 44 45 59 3a 42 50 4c 6c 6f 3a |le4,Y:DEY:BPLlo:|
00002260 53 54 41 69 6e 63 3a 52 54 53 20 20 20 20 0d 06 |STAinc:RTS ..|
00002270 0e 3f 2e 73 70 63 20 50 48 41 3a 4a 53 52 76 64 |.?.spc PHA:JSRvd|
00002280 75 33 31 3a 50 4c 41 3a 54 41 59 3a 2e 73 70 20 |u31:PLA:TAY:.sp |
00002290 4c 44 41 23 33 32 3a 4a 53 52 26 46 46 45 45 3a |LDA#32:JSR&FFEE:|
000022a0 44 45 59 3a 42 4e 45 73 70 3a 52 54 53 0d 06 18 |DEY:BNEsp:RTS...|
000022b0 40 2e 63 68 72 20 50 48 41 3a 4a 53 52 76 64 75 |@.chr PHA:JSRvdu|
000022c0 33 31 3a 50 4c 41 3a 54 41 59 3a 2e 63 70 20 4c |31:PLA:TAY:.cp L|
000022d0 44 41 23 32 35 35 3a 4a 53 52 26 46 46 45 45 3a |DA#255:JSR&FFEE:|
000022e0 44 45 59 3a 42 4e 45 63 70 3a 52 54 53 0d 06 22 |DEY:BNEcp:RTS.."|
000022f0 66 2e 6e 75 6d 20 4c 44 41 28 26 46 32 29 2c 59 |f.num LDA(&F2),Y|
00002300 3a 4a 53 52 69 6e 73 74 72 3a 43 4c 43 3a 41 53 |:JSRinstr:CLC:AS|
00002310 4c 41 3a 41 53 4c 41 3a 41 53 4c 41 3a 41 53 4c |LA:ASLA:ASLA:ASL|
00002320 41 3a 53 54 41 74 65 6d 70 32 3a 49 4e 59 3a 4c |A:STAtemp2:INY:L|
00002330 44 41 28 26 46 32 29 2c 59 3a 4a 53 52 69 6e 73 |DA(&F2),Y:JSRins|
00002340 74 72 3a 43 4c 43 3a 41 44 43 74 65 6d 70 32 3a |tr:CLC:ADCtemp2:|
00002350 52 54 53 0d 06 2c 6f 2e 69 6e 73 74 72 20 53 54 |RTS..,o.instr ST|
00002360 59 79 3a 53 54 41 74 65 6d 70 3a 4c 44 59 23 30 |Yy:STAtemp:LDY#0|
00002370 3a 2e 6c 6f 6f 70 20 4c 44 41 20 49 64 61 74 61 |:.loop LDA Idata|
00002380 2c 59 3a 43 4d 50 74 65 6d 70 3a 42 45 51 65 6e |,Y:CMPtemp:BEQen|
00002390 64 69 6e 73 3a 49 4e 59 3a 43 50 59 23 31 36 3a |dins:INY:CPY#16:|
000023a0 42 4e 45 6c 6f 6f 70 3a 4c 44 59 23 30 3a 2e 65 |BNEloop:LDY#0:.e|
000023b0 6e 64 69 6e 73 20 54 59 41 3a 4c 44 59 79 3a 52 |ndins TYA:LDYy:R|
000023c0 54 53 0d 06 36 21 2e 49 64 61 74 61 20 45 51 55 |TS..6!.Idata EQU|
000023d0 53 22 30 31 32 33 34 35 36 37 38 39 41 42 43 44 |S"0123456789ABCD|
000023e0 45 46 22 0d 06 40 42 2e 74 61 62 6c 65 33 20 45 |EF"..@B.table3 E|
000023f0 51 55 42 20 74 61 62 6c 65 34 20 83 32 35 36 3a |QUB table4 .256:|
00002400 45 51 55 42 20 74 61 62 6c 65 34 20 81 32 35 36 |EQUB table4 .256|
00002410 3a 45 51 55 42 32 3a 45 51 55 42 33 32 3a 45 51 |:EQUB2:EQUB32:EQ|
00002420 55 42 31 32 37 0d 06 4a 17 2e 74 61 62 6c 65 34 |UB127..J..table4|
00002430 20 45 51 55 53 22 30 30 30 30 30 22 0d 06 54 43 | EQUS"00000"..TC|
00002440 2e 74 61 62 6c 65 35 20 45 51 55 42 20 74 61 62 |.table5 EQUB tab|
00002450 6c 65 36 20 83 32 35 36 3a 45 51 55 42 20 74 61 |le6 .256:EQUB ta|
00002460 62 6c 65 36 20 81 32 35 36 3a 45 51 55 42 33 31 |ble6 .256:EQUB31|
00002470 3a 45 51 55 42 33 32 3a 45 51 55 42 31 32 37 0d |:EQUB32:EQUB127.|
00002480 06 5e 31 2e 74 61 62 6c 65 36 20 45 51 55 53 22 |.^1.table6 EQUS"|
00002490 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 |0000000000000000|
000024a0 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 22 |000000000000000"|
000024b0 0d 06 68 60 2e 64 65 63 20 4c 44 41 23 30 3a 53 |..h`.dec LDA#0:S|
000024c0 54 41 74 65 6d 70 32 3a 4c 44 41 74 61 62 6c 65 |TAtemp2:LDAtable|
000024d0 34 3a 42 45 51 64 65 63 32 3a 4c 44 59 74 61 62 |4:BEQdec2:LDYtab|
000024e0 6c 65 34 3a 2e 64 6c 70 20 4c 44 41 74 65 6d 70 |le4:.dlp LDAtemp|
000024f0 32 3a 43 4c 43 3a 41 44 43 23 31 30 3a 53 54 41 |2:CLC:ADC#10:STA|
00002500 74 65 6d 70 32 3a 44 45 59 3a 42 4e 45 64 6c 70 |temp2:DEY:BNEdlp|
00002510 0d 06 72 26 2e 64 65 63 32 20 43 4c 43 3a 4c 44 |..r&.dec2 CLC:LD|
00002520 41 74 61 62 6c 65 34 2b 31 3a 41 44 43 74 65 6d |Atable4+1:ADCtem|
00002530 70 32 3a 52 54 53 0d 06 7c 4e 2e 70 72 6f 6d 70 |p2:RTS..|N.promp|
00002540 74 20 4a 53 52 76 64 75 32 36 3a 4c 44 58 23 31 |t JSRvdu26:LDX#1|
00002550 33 3a 4c 44 59 23 62 6f 74 3a 4a 53 52 76 64 75 |3:LDY#bot:JSRvdu|
00002560 33 31 3a 4a 53 52 73 74 72 69 6e 67 3a 45 51 55 |31:JSRstring:EQU|
00002570 53 22 46 6f 6c 6c 6f 77 3f 20 28 59 2f 4e 29 22 |S"Follow? (Y/N)"|
00002580 3a 42 52 4b 0d 06 86 2c 2e 70 72 31 20 4a 53 52 |:BRK...,.pr1 JSR|
00002590 26 46 46 45 30 3a 43 4d 50 23 97 22 59 22 3a 42 |&FFE0:CMP#."Y":B|
000025a0 4e 45 70 72 32 3a 53 45 43 3a 4a 4d 50 70 72 33 |NEpr2:SEC:JMPpr3|
000025b0 0d 06 90 23 2e 70 72 32 20 43 4d 50 23 97 22 4e |...#.pr2 CMP#."N|
000025c0 22 3a 42 4e 45 70 72 31 3a 43 4c 43 3a 4a 4d 50 |":BNEpr1:CLC:JMP|
000025d0 70 72 33 0d 06 9a 1e 2e 70 72 34 20 43 4d 50 23 |pr3.....pr4 CMP#|
000025e0 32 37 3a 42 4e 45 70 72 31 3a 4a 4d 50 73 74 6f |27:BNEpr1:JMPsto|
000025f0 70 0d 06 a4 29 2e 70 72 33 20 50 48 50 3a 4c 44 |p...).pr3 PHP:LD|
00002600 58 23 31 33 3a 4c 44 59 23 62 6f 74 3a 4c 44 41 |X#13:LDY#bot:LDA|
00002610 23 31 34 3a 4a 53 52 73 70 63 0d 06 ae 14 4a 53 |#14:JSRspc....JS|
00002620 52 76 64 75 32 38 3a 50 4c 50 3a 52 54 53 0d 06 |Rvdu28:PLP:RTS..|
00002630 b8 36 2e 73 74 61 72 63 6f 6d 20 4a 53 52 76 64 |.6.starcom JSRvd|
00002640 75 32 36 3a 4c 44 58 23 32 3a 4c 44 59 23 62 6f |u26:LDX#2:LDY#bo|
00002650 74 3a 4a 53 52 76 64 75 33 31 3a 4a 53 52 73 74 |t:JSRvdu31:JSRst|
00002660 72 69 6e 67 0d 06 c2 1c 45 51 55 53 22 53 74 61 |ring....EQUS"Sta|
00002670 72 20 63 6f 6d 6d 61 6e 64 20 2a 22 3a 42 52 4b |r command *":BRK|
00002680 0d 06 cc 32 4c 44 41 23 30 3a 4c 44 58 23 74 61 |...2LDA#0:LDX#ta|
00002690 62 6c 65 35 20 83 32 35 36 3a 4c 44 59 23 74 61 |ble5 .256:LDY#ta|
000026a0 62 6c 65 35 20 81 32 35 36 3a 4a 53 52 26 46 46 |ble5 .256:JSR&FF|
000026b0 46 31 0d 06 d6 20 4c 44 41 23 26 32 34 3a 4c 44 |F1... LDA#&24:LD|
000026c0 58 23 32 3a 4c 44 59 23 62 6f 74 3a 4a 53 52 73 |X#2:LDY#bot:JSRs|
000026d0 70 63 0d 06 e0 1b 4a 53 52 76 64 75 32 38 3a 4a |pc....JSRvdu28:J|
000026e0 53 52 63 6c 73 3a 4a 53 52 66 78 31 35 0d 06 ea |SRcls:JSRfx15...|
000026f0 35 4c 44 58 23 74 61 62 6c 65 36 20 83 32 35 36 |5LDX#table6 .256|
00002700 3a 4c 44 59 23 74 61 62 6c 65 36 20 81 32 35 36 |:LDY#table6 .256|
00002710 3a 4a 53 52 26 46 46 46 37 3a 4a 53 52 26 46 46 |:JSR&FFF7:JSR&FF|
00002720 45 37 0d 06 f4 2d 4a 53 52 76 64 75 32 36 3a 4c |E7...-JSRvdu26:L|
00002730 44 58 23 38 3a 4c 44 59 23 62 6f 74 3a 4a 53 52 |DX#8:LDY#bot:JSR|
00002740 76 64 75 33 31 3a 4a 53 52 73 74 72 69 6e 67 0d |vdu31:JSRstring.|
00002750 06 fe 25 45 51 55 53 22 50 72 65 73 73 20 53 50 |..%EQUS"Press SP|
00002760 41 43 45 20 74 6f 20 63 6f 6e 74 69 6e 75 65 22 |ACE to continue"|
00002770 3a 42 52 4b 0d 07 08 11 2e 6f 73 72 20 4a 53 52 |:BRK.....osr JSR|
00002780 26 46 46 45 30 0d 07 12 0a 42 43 53 72 65 74 0d |&FFE0....BCSret.|
00002790 07 1c 20 4c 44 41 23 26 32 34 3a 4c 44 58 23 32 |.. LDA#&24:LDX#2|
000027a0 3a 4c 44 59 23 62 6f 74 3a 4a 53 52 73 70 63 0d |:LDY#bot:JSRspc.|
000027b0 07 26 12 43 4d 50 23 26 32 30 3a 42 4e 45 6f 73 |.&.CMP#&20:BNEos|
000027c0 72 0d 07 30 24 4a 53 52 76 64 75 32 38 3a 4a 53 |r..0$JSRvdu28:JS|
000027d0 52 63 6c 73 3a 4a 53 52 66 78 31 35 3a 2e 72 65 |Rcls:JSRfx15:.re|
000027e0 74 20 52 54 53 0d 07 3a 18 2e 63 6c 73 20 4c 44 |t RTS..:..cls LD|
000027f0 41 23 31 32 3a 4a 4d 50 26 46 46 45 45 0d 07 44 |A#12:JMP&FFEE..D|
00002800 19 2e 66 78 31 35 20 4c 44 41 23 31 35 3a 4a 4d |..fx15 LDA#15:JM|
00002810 50 26 46 46 46 34 0d 07 4e 18 2e 73 74 61 63 6b |P&FFF4..N..stack|
00002820 20 45 51 55 53 20 c4 31 32 38 2c bd 30 29 0d 07 | EQUS .128,.0)..|
00002830 58 0b 2e 74 61 62 6c 65 31 0d 07 62 05 5d 0d 07 |X..table1..b.]..|
00002840 6c 65 f7 8d 44 76 47 3a e3 49 25 3d 31 b8 31 35 |le..DvG:.I%=1.15|
00002850 32 3a f3 41 24 2c 62 2c 63 3a 3f 4f 25 3d a0 28 |2:.A$,b,c:?O%=.(|
00002860 22 26 22 2b 41 24 29 3a 4f 25 3f 31 3d 62 3a 4f |"&"+A$):O%?1=b:O|
00002870 25 3f 32 3d 63 3a 4f 25 3d 4f 25 2b 33 3a 3f 50 |%?2=c:O%=O%+3:?P|
00002880 25 3d a0 28 22 26 22 2b 41 24 29 3a 50 25 3f 31 |%=.("&"+A$):P%?1|
00002890 3d 62 3a 50 25 3f 32 3d 63 3a 50 25 3d 50 25 2b |=b:P%?2=c:P%=P%+|
000028a0 33 3a ed 0d 07 76 76 dc 20 36 39 2c 31 2c 31 2c |3:...vv. 69,1,1,|
000028b0 36 35 2c 31 2c 32 2c 37 35 2c 31 2c 33 2c 36 44 |65,1,2,75,1,3,6D|
000028c0 2c 31 2c 34 2c 37 39 2c 31 2c 35 2c 37 44 2c 31 |,1,4,79,1,5,7D,1|
000028d0 2c 36 2c 36 31 2c 31 2c 37 2c 37 31 2c 31 2c 38 |,6,61,1,7,71,1,8|
000028e0 2c 32 39 2c 32 2c 31 2c 32 35 2c 32 2c 32 2c 33 |,29,2,1,25,2,2,3|
000028f0 35 2c 32 2c 33 2c 32 44 2c 32 2c 34 2c 33 44 2c |5,2,3,2D,2,4,3D,|
00002900 32 2c 36 2c 33 39 2c 32 2c 35 2c 32 31 2c 32 2c |2,6,39,2,5,21,2,|
00002910 37 2c 33 31 2c 32 2c 38 20 0d 07 80 77 dc 20 41 |7,31,2,8 ...w. A|
00002920 2c 33 2c 30 2c 36 2c 33 2c 32 2c 31 36 2c 33 2c |,3,0,6,3,2,16,3,|
00002930 33 2c 45 2c 33 2c 34 2c 31 45 2c 33 2c 36 2c 39 |3,E,3,4,1E,3,6,9|
00002940 30 2c 34 2c 39 2c 42 30 2c 35 2c 39 2c 46 30 2c |0,4,9,B0,5,9,F0,|
00002950 36 2c 39 2c 32 34 2c 37 2c 32 2c 32 43 2c 37 2c |6,9,24,7,2,2C,7,|
00002960 34 2c 33 30 2c 38 2c 39 2c 44 30 2c 39 2c 39 2c |4,30,8,9,D0,9,9,|
00002970 31 30 2c 31 30 2c 39 2c 30 2c 31 31 2c 31 30 2c |10,10,9,0,11,10,|
00002980 35 30 2c 31 32 2c 39 2c 37 30 2c 31 33 2c 39 20 |50,12,9,70,13,9 |
00002990 0d 07 8a 82 dc 20 31 38 2c 31 34 2c 31 30 2c 44 |..... 18,14,10,D|
000029a0 38 2c 31 35 2c 31 30 2c 35 38 2c 31 36 2c 31 30 |8,15,10,58,16,10|
000029b0 2c 42 38 2c 31 37 2c 31 30 2c 43 39 2c 31 38 2c |,B8,17,10,C9,18,|
000029c0 31 2c 43 35 2c 31 38 2c 32 2c 44 35 2c 31 38 2c |1,C5,18,2,D5,18,|
000029d0 33 2c 43 44 2c 31 38 2c 34 2c 44 44 2c 31 38 2c |3,CD,18,4,DD,18,|
000029e0 36 2c 44 39 2c 31 38 2c 35 2c 43 31 2c 31 38 2c |6,D9,18,5,C1,18,|
000029f0 37 2c 44 31 2c 31 38 2c 38 2c 45 30 2c 31 39 2c |7,D1,18,8,E0,19,|
00002a00 31 2c 45 34 2c 31 39 2c 32 2c 45 43 2c 31 39 2c |1,E4,19,2,EC,19,|
00002a10 34 20 0d 07 94 82 dc 20 43 30 2c 32 30 2c 31 2c |4 ..... C0,20,1,|
00002a20 43 34 2c 32 30 2c 32 2c 43 43 2c 32 30 2c 34 2c |C4,20,2,CC,20,4,|
00002a30 43 36 2c 32 31 2c 32 2c 44 36 2c 32 31 2c 33 2c |C6,21,2,D6,21,3,|
00002a40 43 45 2c 32 31 2c 34 2c 44 45 2c 32 31 2c 36 2c |CE,21,4,DE,21,6,|
00002a50 43 41 2c 32 32 2c 31 30 2c 38 38 2c 32 33 2c 31 |CA,22,10,88,23,1|
00002a60 30 2c 45 38 2c 32 34 2c 31 30 2c 43 38 2c 32 35 |0,E8,24,10,C8,25|
00002a70 2c 31 30 2c 45 36 2c 32 37 2c 32 2c 46 36 2c 32 |,10,E6,27,2,F6,2|
00002a80 37 2c 33 2c 45 45 2c 32 37 2c 34 2c 46 45 2c 32 |7,3,EE,27,4,FE,2|
00002a90 37 2c 36 20 0d 07 9e 7f dc 20 34 39 2c 32 36 2c |7,6 ..... 49,26,|
00002aa0 31 2c 34 35 2c 32 36 2c 32 2c 35 35 2c 32 36 2c |1,45,26,2,55,26,|
00002ab0 33 2c 34 44 2c 32 36 2c 34 2c 35 44 2c 32 36 2c |3,4D,26,4,5D,26,|
00002ac0 36 2c 35 39 2c 32 36 2c 35 2c 34 31 2c 32 36 2c |6,59,26,5,41,26,|
00002ad0 37 2c 35 31 2c 32 36 2c 38 2c 34 43 2c 32 38 2c |7,51,26,8,4C,28,|
00002ae0 34 2c 36 43 2c 32 38 2c 31 31 2c 32 30 2c 32 39 |4,6C,28,11,20,29|
00002af0 2c 34 2c 41 39 2c 33 30 2c 31 2c 41 35 2c 33 30 |,4,A9,30,1,A5,30|
00002b00 2c 32 2c 42 35 2c 33 30 2c 33 2c 41 44 2c 33 30 |,2,B5,30,3,AD,30|
00002b10 2c 34 20 0d 07 a8 76 dc 20 42 44 2c 33 30 2c 36 |,4 ...v. BD,30,6|
00002b20 2c 42 39 2c 33 30 2c 35 2c 41 31 2c 33 30 2c 37 |,B9,30,5,A1,30,7|
00002b30 2c 42 31 2c 33 30 2c 38 2c 41 32 2c 33 31 2c 31 |,B1,30,8,A2,31,1|
00002b40 2c 41 36 2c 33 31 2c 32 2c 42 36 2c 33 31 2c 33 |,A6,31,2,B6,31,3|
00002b50 2c 41 45 2c 33 31 2c 34 2c 42 45 2c 33 31 2c 35 |,AE,31,4,BE,31,5|
00002b60 2c 41 30 2c 33 32 2c 31 2c 41 34 2c 33 32 2c 32 |,A0,32,1,A4,32,2|
00002b70 2c 42 34 2c 33 32 2c 33 2c 41 43 2c 33 32 2c 34 |,B4,32,3,AC,32,4|
00002b80 2c 42 43 2c 33 32 2c 36 20 0d 07 b2 7e dc 20 34 |,BC,32,6 ...~. 4|
00002b90 41 2c 33 33 2c 30 2c 34 36 2c 33 33 2c 32 2c 35 |A,33,0,46,33,2,5|
00002ba0 36 2c 33 33 2c 33 2c 34 45 2c 33 33 2c 34 2c 35 |6,33,3,4E,33,4,5|
00002bb0 45 2c 33 33 2c 36 2c 45 41 2c 33 34 2c 31 30 2c |E,33,6,EA,34,10,|
00002bc0 34 38 2c 33 35 2c 31 30 2c 38 2c 33 36 2c 31 30 |48,35,10,8,36,10|
00002bd0 2c 36 38 2c 33 37 2c 31 30 2c 32 38 2c 33 38 2c |,68,37,10,28,38,|
00002be0 31 30 2c 34 30 2c 33 39 2c 31 30 2c 36 30 2c 34 |10,40,39,10,60,4|
00002bf0 30 2c 31 30 2c 33 38 2c 34 31 2c 31 30 2c 46 38 |0,10,38,41,10,F8|
00002c00 2c 34 32 2c 31 30 20 0d 07 bc 81 dc 20 37 38 2c |,42,10 ..... 78,|
00002c10 34 33 2c 31 30 2c 41 41 2c 34 34 2c 31 30 2c 41 |43,10,AA,44,10,A|
00002c20 38 2c 34 35 2c 31 30 2c 39 38 2c 34 36 2c 31 30 |8,45,10,98,46,10|
00002c30 2c 42 41 2c 34 37 2c 31 30 2c 38 41 2c 34 38 2c |,BA,47,10,8A,48,|
00002c40 31 30 2c 39 41 2c 34 39 2c 31 30 2c 39 2c 35 30 |10,9A,49,10,9,50|
00002c50 2c 31 2c 35 2c 35 30 2c 32 2c 31 35 2c 35 30 2c |,1,5,50,2,15,50,|
00002c60 33 2c 44 2c 35 30 2c 34 2c 31 39 2c 35 30 2c 35 |3,D,50,4,19,50,5|
00002c70 2c 31 44 2c 35 30 2c 36 2c 31 2c 35 30 2c 37 2c |,1D,50,6,1,50,7,|
00002c80 31 31 2c 35 30 2c 38 20 0d 07 c6 7e dc 20 32 41 |11,50,8 ...~. 2A|
00002c90 2c 35 31 2c 30 2c 32 36 2c 35 31 2c 32 2c 33 36 |,51,0,26,51,2,36|
00002ca0 2c 35 31 2c 33 2c 32 45 2c 35 31 2c 34 2c 33 45 |,51,3,2E,51,4,3E|
00002cb0 2c 35 31 2c 36 2c 36 41 2c 35 32 2c 30 2c 36 36 |,51,6,6A,52,0,66|
00002cc0 2c 35 32 2c 32 2c 37 36 2c 35 32 2c 33 2c 36 45 |,52,2,76,52,3,6E|
00002cd0 2c 35 32 2c 34 2c 37 45 2c 35 32 2c 36 2c 45 39 |,52,4,7E,52,6,E9|
00002ce0 2c 35 33 2c 31 2c 45 35 2c 35 33 2c 32 2c 46 35 |,53,1,E5,53,2,F5|
00002cf0 2c 35 33 2c 33 2c 45 44 2c 35 33 2c 34 2c 46 44 |,53,3,ED,53,4,FD|
00002d00 2c 35 33 2c 36 20 0d 07 d0 86 dc 20 46 39 2c 35 |,53,6 ..... F9,5|
00002d10 33 2c 35 2c 45 31 2c 35 33 2c 37 2c 46 31 2c 35 |3,5,E1,53,7,F1,5|
00002d20 33 2c 38 2c 38 35 2c 35 34 2c 32 2c 39 35 2c 35 |3,8,85,54,2,95,5|
00002d30 34 2c 33 2c 38 44 2c 35 34 2c 34 2c 39 44 2c 35 |4,3,8D,54,4,9D,5|
00002d40 34 2c 36 2c 39 39 2c 35 34 2c 35 2c 38 31 2c 35 |4,6,99,54,5,81,5|
00002d50 34 2c 37 2c 39 31 2c 35 34 2c 38 2c 38 36 2c 35 |4,7,91,54,8,86,5|
00002d60 35 2c 32 2c 39 36 2c 35 35 2c 33 2c 38 45 2c 35 |5,2,96,55,3,8E,5|
00002d70 35 2c 34 2c 38 34 2c 35 36 2c 32 2c 39 34 2c 35 |5,4,84,56,2,94,5|
00002d80 36 2c 33 2c 38 43 2c 35 36 2c 34 20 0d 07 da 0b |6,3,8C,56,4 ....|
00002d90 dc 20 30 2c 30 2c 30 0d 07 e4 12 5b 4f 50 54 4c |. 0,0,0....[OPTL|
00002da0 25 3a 2e 74 61 62 6c 65 32 0d 07 ee 0b 5d 3a f7 |%:.table2....]:.|
00002db0 8d 54 4c 48 0d 07 f8 60 e3 49 25 3d 31 b8 35 36 |.TLH...`.I%=1.56|
00002dc0 3a f3 41 24 3a 3f 4f 25 3d 97 c0 41 24 2c 31 29 |:.A$:?O%=..A$,1)|
00002dd0 3a 4f 25 3f 31 3d 97 c1 41 24 2c 32 2c 31 29 3a |:O%?1=..A$,2,1):|
00002de0 4f 25 3f 32 3d 97 c2 41 24 2c 31 29 3a 3f 50 25 |O%?2=..A$,1):?P%|
00002df0 3d 97 c0 41 24 2c 31 29 3a 50 25 3f 31 3d 97 c1 |=..A$,1):P%?1=..|
00002e00 41 24 2c 32 2c 31 29 3a 50 25 3f 32 3d 97 c2 41 |A$,2,1):P%?2=..A|
00002e10 24 2c 31 29 0d 08 02 15 4f 25 3d 4f 25 2b 33 3a |$,1)....O%=O%+3:|
00002e20 50 25 3d 50 25 2b 33 3a ed 0d 08 0c e5 dc 20 41 |P%=P%+3:...... A|
00002e30 44 43 2c 41 4e 44 2c 41 53 4c 2c 42 43 43 2c 42 |DC,AND,ASL,BCC,B|
00002e40 43 53 2c 42 45 51 2c 42 49 54 2c 42 4d 49 2c 42 |CS,BEQ,BIT,BMI,B|
00002e50 4e 45 2c 42 50 4c 2c 42 52 4b 2c 42 56 43 2c 42 |NE,BPL,BRK,BVC,B|
00002e60 56 53 2c 43 4c 43 2c 43 4c 44 2c 43 4c 49 2c 43 |VS,CLC,CLD,CLI,C|
00002e70 4c 56 2c 43 4d 50 2c 43 50 58 2c 43 50 59 2c 44 |LV,CMP,CPX,CPY,D|
00002e80 45 43 2c 44 45 58 2c 44 45 59 2c 49 4e 58 2c 49 |EC,DEX,DEY,INX,I|
00002e90 4e 59 2c 45 4f 52 2c 49 4e 43 2c 4a 4d 50 2c 4a |NY,EOR,INC,JMP,J|
00002ea0 53 52 2c 4c 44 41 2c 4c 44 58 2c 4c 44 59 2c 4c |SR,LDA,LDX,LDY,L|
00002eb0 53 52 2c 4e 4f 50 2c 50 48 41 2c 50 48 50 2c 50 |SR,NOP,PHA,PHP,P|
00002ec0 4c 41 2c 50 4c 50 2c 52 54 49 2c 52 54 53 2c 53 |LA,PLP,RTI,RTS,S|
00002ed0 45 43 2c 53 45 44 2c 53 45 49 2c 54 41 58 2c 54 |EC,SED,SEI,TAX,T|
00002ee0 41 59 2c 54 59 41 2c 54 53 58 2c 54 58 41 2c 54 |AY,TYA,TSX,TXA,T|
00002ef0 58 53 2c 4f 52 41 2c 52 4f 4c 2c 52 4f 52 2c 53 |XS,ORA,ROL,ROR,S|
00002f00 42 43 2c 53 54 41 2c 53 54 58 2c 53 54 59 0d 08 |BC,STA,STX,STY..|
00002f10 16 05 ed 0d 08 20 29 ff 22 53 41 56 45 20 54 52 |..... )."SAVE TR|
00002f20 41 43 4b 32 20 22 2b c3 7e 51 25 2b 22 20 22 2b |ACK2 "+.~Q%+" "+|
00002f30 c3 7e 4f 25 2b 22 20 38 32 33 37 22 0d ff |.~O%+" 8237"..|
00002f3e
P/TKRsrc2.m0
P/TKRsrc2.m1
P/TKRsrc2.m2
P/TKRsrc2.m4
P/TKRsrc2.m5
.
