MANUAL FOR PRETTYPRINT (6502 ROM image)
This file describes the ROM image PRETTYPRINT which adds 'OS_PrettyPrint'
support to the BBC in an identical manner to that supplied on Risc OS
based machines.
The manual is (C)1998 SPROW and software is (C)1997 SPROW
INSTRUCTIONS
-At any command line prompt,eg.the BASIC command prompt '>' type
ON A MASTER:
*SRLOAD DRDIR 8000 <socket#>
*INSERT <socket#>
where <socket#> may be 7,6,5,4
ON A MACHINE WITH SWRAM: *LOAD DRDIR 8000 and press CTRL-BREAK to
initialise.
The image will then be installed into the chosen socket where it will wait for the
user to issue one of the following two stimuli
OSWORD CALL-A =&47 and X&Y
point to a control block in memory
XY+00 4 byte pointer to null terminated string to print (low byte first)
XY+04 4 byte pointer to user dictionary,or 0 to use built in dictionary
(low byte first)
XY+08 4 byte pointer to null terminated 'special string' (low byte first)
XY+12 Source of string to print,00=RAM 128 + socket=ROM
XY+13 Source of user dictionary,00=RAM 128+socket=ROM if XY+04 is non
zero
XY+14 Source of 'special string',00=RAM 128+socket=ROM
COMMAND LINE-
*HELP "filename" where "filename" contains a valid wadge of text and
starts with a 15 byte block as though it had been
entered as an OSWord.
To make a file that is suitable for use in this manner
is really easy. You just take your prettyprint text
and then put the 15 byte OSWord block at the beginning
of the file.
Because the OSWord block needs addresses putting in it,
you'll need to specify a SENSIBLE load address in the
file's catalogue entry.
EXIT MESSAGES
-Missing " - the command line had a closing ditto missing
Dictionary entry not found - an escape sequence number was out of range
Load address too low - the file specified on the command line loaded in at
a silly place in the memory map
File not found - the file specified on the command line doesn't exist
Tube hardware not found - the OSWord block specified data to come form the
tube
KNOWN PROBLEMS/FUTURE ENHANCEMENTS
-No known problems
Text doesn't word wrap yet
HISTORY-V0.90 First release version,to the EUG disk user group along with
an article on word wrapping text
WHAT PRETTY PRINT IS
-Pretty print writes a string pointed to
by an osword control block,in additionthere are some special properties
that it looks out for though:
* A carriage return causes a newline to be generated
* TAB causes a tabulation to the next multiple of eight chars
* Word wraps, unless the words are separated by CHR$31 (used as a hard
space)
* ESC (ASCII 27) indicates that a dictionary entry should be
substituted
To use a dictionary entry, place a CHR$ 27 followed by an entry number to
look up in the range 1-255 (the entry '0' is used to look up the 'special
string' pointed to by XY+8). There is a default dictionary, which doesn't
contain all 255 entries, but you may of course specify your own 'User
dictionary' if the application you have in mind uses a lot of the same
strings. eg. a chemistry related program.
Effectively this will result in text being compacted since whole words are
replaced by just two bytes.
DICTIONARY FORMAT
- Dictionary entries may recursively refer to other dictionary
entries,nested no deeper than 32 levels (otherwise the stack overflows)
.The first byte of theentry points to the next entry,then there's text
terminated by a 0 byte.So fora file of N strings:
<offsettostartofstringTWO><1STstring$of255chr$orless><00>
<offsettostartofstringTHREE><2NDstring$of255chr$orless><00>
: : :
: : :
<offsettostartofstring(N-1)><(N-1)THstring$of255chr$orless><00>
<00><NTHstring$of255chr$orless><00>
DEFAULT DICTIONARY
-00=><string pointed to by XY+8>
01=>"Syntax: *"+<string pointed to by XY+8>
02=>" the "
03=>"director"
04=>"filing system"
05=>"current"
06=>" to a variable. Other types of values can be assigned with *"
07=>"file"
08=>"default "
09=>"tion"
10=>"*Configure"
11=>"name"
12=>" server"
13=>"number"
14=>"Syntax: *"+<string pointed to by XY+8>+ " <"
15=>" one or more files that match the given wildcard"
16=>" and"
17=>"relocatable module"
18=>CR+"C(onfirm)"+TAB+"Prompt for conf irmation of each"
19=>"sets the"
20=>Syntax: *"+<string pointed to by XY+8>+" [<disc spec.>]"
21=>")"+CR+"V(erbose)"+TAB+"Print informa tion on each file"
22=>"spriteLandscape [<XScale> [<YScale> [<Margin>[<Threshold>]]]]]"
23=>"is used to print a hard copy of the screen on EPSON-"
24=>"."+CR+"Options: (use ~ to force off, eg.~"
25=>"printe"
26=>"Syntax: *"+<string pointed to by XY+8>+" <filename>"
27=>"select"
28=>"xpression"
29=>Syntax: *"+<string pointed to by XY+8>+"["
30=>"sprite"
31=>" displays"
32=>"free space"
33=>" {off}"
34=>"library"
35=>"parameter"
36=>"object"
37=>" all "
38=>"disc"
39=>" to "
40=>" is "
