NEW TELEPHONE CODES
Well I got some information on the new telephone codes.
It seems that all the area codes will now begin with 01 as
opposed to 0 so EUG's area code is 01705. Not too
complicated.
Meanwhile if you live in or want to contact one of these
five cities there is an new number altogether.
Leeds is now 0113 2
Sheffield is now 0114 2
Nottingham is now 0115 9
Leicester is now 0116 2
Bristol is now 0117 9
The effect of this especially upon the cities with
completely new codes will undoubtedly cause confusion
especially for the first few months. I know when the London
codes changed I started dealing with companies else where
rather than waste time trying to find the new London code.
So some firms in London lost my business and presumably
other business as well. What the effect all this will have
on the mysterious ecconomic recovery which we are all
suppose to be experiencing soon we shall have to wait and
see. I'm just glad that my business is not in one of those
five cities.
I saw a van the other day with the new code written on the
side like this 01 703 000 000
Apparently BT are thinking of bringing back alpha nurmeric
dialing for some business customers but many phone users now
don't have any letters on their telephones. Why they ever
abandoned it in the first place is anyones guess. When you
consider the improtance of the telephone to the ecconomy
the incompetance of these people is almost beyond belief.
On the subject of telephones. We can all now fit out own
extensions to a main line. Instructions are usually supplied
with kits but I can give you some more information which is
not usually supplied.
Strip some telephone cable back about 4 inches. Ther should
be 6 wires each colour coded. These colour codes are
arranged in pairs.
Green with White White with Green
Blue with White White with Blue
Orange with White White with Orange
Some cables may only have four wires in which case there
will be no green pair.
You should have a master socket fitted by your telephone
company. The main difference between these and the extension
socket is that the master socket has a big yellow capacitor
while the extension socket doesn't.
Most extension sockets supplied to the public now have screw
terminals. The telephone engineer will use a different type
called IDC. These need special tools which are expensive,
mine cost about `16.00. Originally a small plasic device
was supplied but these are quite frankly useless. So stick
to the screw terminals and as with everything make sure you
use the correctly sized tool, if you can't afford the tool,
then to be frank you can't afford to do the job
In the socket are six terminals. These should be numbered 1
to 6.
Terminal 1 is for Green with White
Terminal 6 is for White with Green
Terminal 2 is for Blue with White
Terminal 5 is for White with Blue
Terminal 3 is for Orange with White
Terminal 4 is for White with Orange.
---------------------------
:--------:
: :
:--------:
--- 1 6 ---
--- 2 5 ---
--- 3 4 ---
---------------------------
Diagram of telephone socket layout.
Terminals 1 and 6 are not really necessary in most home
telephone lines. They can be useful for connecting some
types of intercoms but these are quite rare.
Terminals 2 and 5 are the business end. These are the actual
telephone line. 2 being the live in 5 being the neutral.
Terminals 3 and 4 are Bell and earth respectivly. 3 isn't
essential in a home telephone, 4 is. Without terminal 4
connected the extension bell probably won't ring and any
functions on the 'phone such as redial, and * and #
functions won't work.
Now Some very old lines have a cable which has four wires.
The colour codes for these are Blue, Orange, Brown and
Green. Really us mortals shouldn't have to touch this cable
since the friendly BT engineer will connect this to a modern
BT telephone socket for a huge fee. However if you do come
across this type of cable then the codes are these:
Blue - Line live. To terminal 2
Orange - Line neutral. To terminal 5
Brown - Earth. To terminal 4
Green can be left disconnected.
One final point which is very important. This earth terminal
is not the same as the earth in a 240 volt socket. The
telephone earth is a functional earth. It is connected as
necessary at the telephone exchange and does not normally
need to be attached to the house earth unless done by a BT
engineer.
