� Print Electron Memory Map
!� by R.A.Dimond February 1993
(!� ***************************
2
� Pages 3
<�6
F�6,1)"Memory Map (Page 3)"
P �'"Screen or Printer? (S/P)"
Z���-82 ��-56
d3�-82 �3:�14 ��3:�15,2,1,27,1,54,1,27,1,116,1,1
n�0);�201;�68,�205);�187
x,�printct("ELECTRON MEMORY MAP - Page 3")
�'�199;�13,�196);�194;�54,�196);�182
��print("  Address","Use")
�'�199;�13,�196);�197;�54,�196);�182
�@�print(" &300/&301","Graphics window left column in pixels")
�?�print(" &302/&303","Graphics window bottom row in pixels")
�A�print(" &304/&305","Graphics window right column in pixels")
�<�print(" &306/&307","Graphics window top row in pixels")
�2�print(" &308","Text window left hand column")
�,�print(" &309","Text window bottom row")
�3�print(" &30A","Text window right hand column")
�)�print(" &30B","Text window top row")
�J�print(" &30C-&30F","Current graphics origin in external coordinates")
�J�print(" &310-&313","Current graphics cursor in external coordinates")

F�print(" &314-&317","Old graphics cursor in external coordinates")

6�print(" &318","Current text cursor X coordinate")

6�print(" &319","Current text cursor Y coordinate")

"B�print(" &31A","Line within current graphics cell containing")

,+�print("","the current graphics point")

67�print(" &31B-&31E","Either graphics workspace or")

@(�print("","first part of VDU queue")

J(�print(" &31F-&323","The VDU queue")

TJ�print(" &324-&327","Current graphics cursor in internal coordinates")

^8�print(" &329-&349","Graphics coordinate workspace")

h/�print(" &34A/&34B","Text cuesor position")

r5�print(" &34C/&34D","Text window width in bytes")

|:�print(" &34E","High byte of bottom of screen memory")

�B�print(" &34F","Character size in bytes for the current mode")

�<�print(" &350/&351","Address of screen top left corner")

�<�print(" &352/&353","Number of bytes per character row")

�5�print(" &354","High byte of screen memory size")

�)�print(" &355","Current screen mode")

�*�print(" &356","Screen display type:")

��print("","    0=20k mode")

��print("","    1=16k mode")

��print("","    2=10k mode")

��print("","    3=8k mode")

�4�print(" &357","Current text foreground colour")

�4�print(" &358","Current text background colour")

�8�print(" &359","Current graphics foreground colour")
8�print(" &35A","Current graphics background colour")
J�print(" &35B","Current foreground graphics PLOT mode as set by GCOL")
J�print(" &35C","Current background graphics PLOT mode as set by GCOL")
&*�print(" &35D/&35E","VDU jump vector")
0:�print(" &35F","Old setting of cursor start register")
:6�print(" &360","Number of logical colours in the")
D'�print("","current mode minus one")
NI�print(" &361","Number of pixels per byte minus one for the current")
X0�print("","mode, or zero if text only mode")
b+�print(" &362","Left hand colour mask")
l,�print(" &363","Right hand colour mask")
v7�print(" &364","X coordinate of text input cursor")
�7�print(" &365","Y coordinate of text input cursor")
�"�print(" &366","Normally 127")
�'�200;�13,�205);�207;�54,�205);�188
�
�'''''
��201;�68,�205);�187
�4�printct("ELECTRON MEMORY MAP - Page 3 (contd)")
�'�199;�13,�196);�194;�54,�196);�182
��print("  Address","Use")
�'�199;�13,�196);�197;�54,�196);�182
�I�print(" &367","Font flag. If bit is set, the corresponding section")
�4�print("","of the character set is held in ram")
�*�print("","    Bit 7 for chars 32-63")
�*�print("","    Bit 6 for chars 64-95")
+�print("","    Bit 5 for chars 96-127")
,�print("","    Bit 4 for chars 128-159")
,�print("","    Bit 3 for chars 160-191")
 ,�print("","    Bit 2 for chars 192-223")
*,�print("","    Bit 1 for chars 224-255")
4H�print(" &368-&36E","Font location bytes. Each entry in this block")
>D�print("","contains the high address byte of the corresponding")
H&�print("","zone block (see &367)")
RG�print(" &36F-&37E","The current palette. These bytes contain the")
\3�print("","currently defined logical colours,")
f$�print("","in descending order")
p1�print(" &380-&39C","BPUT file header block")
zI�print(" &39D","BPUT buffer offset for next byte in cassette buffer")
�I�print(" &39E","BGET buffer offset for next byte in cassette buffer")
�+�print(" &39F-&3A6","Unused in OS 1.2")
�(�print(" &3A7-&3B1","BGET filename")
�6�print(" &3B2-&3BD","Filename terminated by zero")
�/�print(" &3BE-&3C1","Load address of file")
�4�print(" &3C2-&3C5","Execution address of file")
�6�print(" &3C6/&3C7","16 bit current block number")
�'�print(" &3C8/&3C9","Block length")
�I�print(" &3CA","Block flag type. Indicates whether a file is locked")
�$�print(" &3CB-&3CE","RFS EOF+1")
�*�print(" &3CF/&3D0","16 bit checksum")
�<�print(" &3D1","Sequential block gap as set by *OPT3,n")
�?�print(" &3D2-&3DC","Filename of file being searched for,")
#�print("","terminated by zero")
=�print(" &3DD/&3DE","Number of next expected BGET block")
2�print(" &3DF","Copy of last block flag read")
$0�print(" &3E0-&3FF","Kwyboard input buffer")
.'�200;�13,�205);�207;�54,�205);�188
8�
B�3
C:�''"PLEASE PRESS <F> FOR NEXT FILE, <M> FOR MAIN MENU"
D�:� �="F" � �="M"
E� �="F" � �"$.MM4"
F� �="M" � �"$.MENU"
L�
V3��printct(t$):�186;�68/2-�t$/2);t$;�69);�186:�
`<��print(a$,b$):�186;�2)a$;�14);�179;�16);b$;�69);�186:�
�
