File contents
section "EXMP2"
get "exmphdr"
// This section of EXAMPLE contains the procedure to play a tune.
// PLAYTUNE uses the ENVELOPE and SOUND procedures to play a simple tune. The
// tune is stored in a string. Each note is represented by 3 characters - the
// octave number, the note (a-g) and +, - or space for sharp, flat or
// natural. The note is in lower case for a quaver and upper case for a
// crotchet. The first note in a bar is preceded by '!'. The string is assumed
// to be valid.
let playtune() be
$( let envnumber = 1 // envelope to use
let pitch = ? // pitch parameter for SOUND
let sbuffsz = adval(-6) // size of sound buffer 1 (number of free slots)
let soundvec = vec 3 // parameter for SOUND
let tune = "!3b-*
*!4e-4e-4e-4e-4e-4e-*
*!4d 4f 4b-4b-4a-4f *
*!4e-4e-4e-4e-4d 4e-*
*!4f 3b-3b-3B-3b-*
*!4e-4e-4e-4e-4e-4e-*
*!4d 4f 4b-4b-4a-4f *
*!4g 4b-4e-4f 4e-4f *
*!4e-3e-3e-3E-"
// NOTEVAL is a table of the pitch for the notes in one octave,
// starting with A and taking C as 0.
let noteval = table 36, 44, 0, 8, 16, 20, 28
// Set up screen display then set up envelopes. Envelope 1
// is for quaver. Envelope 2 is for crotchet. Envelope 3
// is for accented quaver at start of bar. (There are no
// accented crotchets.)
dodisplay()
envelope(table 1, 2, 0, 0, 0, 0, 0, 0, 30, -2, -127, -127, 120, 105)
envelope(table 2, 2, 0, 0, 0, 0, 0, 0, 60, -6, -30, -127, 120, 60)
envelope(table 3, 2, 0, 0, 0, 0, 0, 0, 64, -10, -65, -127, 126, 59)
soundvec!0 := 1 // initialise channel number
// Process each character in the tune string.
for i = 1 to tune%0 do
$( let ch = tune%i
test '1' <= ch <= '7' then
// Octave number - initialise pitch.
pitch := 48*(ch-'0') - 91
else test 'a' <= ch <= 'g' then
// Note (quaver) - update pitch and leave envelope as 1 (or 3).
pitch := pitch + noteval!(ch-'a')
else test 'A' <= ch <= 'G' then
// Note (crotchet) - update pitch and select envelope 2.
$( pitch := pitch + noteval!(ch-'A')
envnumber := 2
$)
else test ch = '!' then
// Start of bar so set envelope 3 for following note.
envnumber := 3
else
// Assume '+', '-' or space so adjust pitch for sharp or
// flat if appropriate then play the note.
$( test ch = '+' then
pitch := pitch + 4
else if ch = '-' then
pitch := pitch - 4
soundvec!1 := envnumber
soundvec!2 := pitch
soundvec!3 := envnumber = 2 -> 6, 3 // duration (longer for crotchet)
sound(soundvec)
envnumber := 1 // reset envelope number to quaver.
$)
$) // back for next character
// All notes put in buffer. Wait until they have been played
// before returning to the menu.
until adval(-6) = sbuffsz loop // wait for tune to end
$)
// DISPNOTE displays a note symbol in flashing white at a specified x position.
and dispnote(x) be
$( let chartab = table 160,160,234,228, // 4x5 array of graphics chars
141,160,234,160, // double height
141,160,234,160,
160,248,254,160,
160,181,234,160,
160,171,167,160
for i=0 to 5 do
$( txtcursor(x, 3+i) // position character on line 3
wrbin(136) // flashing
wrbin(151) // graphic white
for j=4*i to 4*i+3 do
wrbin(chartab!j)
wrbin(137) // steady
$)
$)
// DODISPLAY sets up the display.
and dodisplay() be
$( mode(7)
for i = 0 to 1 do // double height title
$( txtcursor(10, i+4)
writes("*x8D*x81*x9D*x86M U S I C *x9C")
$)
dispnote(1); dispnote(29) // note symbols
txtcursor(1, 10)
for i = 0 to 14 do
$( wrbin(129 + (i rem 3)) // select one of three colours
writes("MUSIC")
wrbin(10) // cursor down then 4 left
for j = 1 to 4 do wrbin(8)
$)
txtcursor(0, 23) // leave cursor at end of screen
$)
.
