                            MANUAL FOR RAMFS
                  A 6502 ROM image by Robert Sprowson

THIS file describes the ROM image RAMFS which drives the RAM board
connected via a 24 bit latched address bus to the 1MHz port.
   The image requires at least one 16k bank of Sideways RAM, or to be
put onto a ROM, to work.

Instructions:
AT the prompt, type:
On A Master:             *SRLOAD U.RAMFS 8000 <socket#>
                         *INSERT <socket#>
                         where socket# may be 7, 6, 5 or 4
On A Machine With SWRam: *LOAD U.RAMFS 8000

Then press CTRL-BREAK to initialise.
   The image will then be installed into the chosen socket where it will
wait until selected as the current filing system. To do this, you can
either type *RAM <RETURN>, press <R>-<BREAK>, issue a sideways ROM ser-
vice call with FS id 23 or, only on the Master series, by the inclusion
of "-RAM-" in the filename.
   One page (256 bytes) of memory is claimed as private workspace above
OSHWM in the BBC or in the hidden RAM on a Master. This contains
pointers, etc, that RAMFS uses. It must not be tampered with.
   Note that a hard or power on reset has the effect of 'formatting' the
disk and all information will be lost.
   Looking at performance, a BASIC program using BGETs/BPUTs/OSGbPb
noted the following performance increases over DFS 1.20:
      Multiple 411 byte OSGbPb reads ................. x4.05 faster
      Multiple 10 byte BGet sequences ................ x1.32 faster
      Random setting of PTR then OSGbPb .............. x1.72 faster

Plus of course, there is no overhead for waiting to spin the disk up to
speed.

Properties:
FILENAMES can be up to ten letters long with a 1 letter directory name.
There can be up to 127 files in the catalogue.
   The media title can be up to 16 letters long.
   The drive number must always be zero where drive numbers are
requested.
   File attributes are ignored. Attributes are read/writeable via the
OSFile call though there is no *ACCESS command. By default access is set
to local RW access.
   The filing system id is 23 for RAMFS.
   The 'cycle number' does not increment with each write to the RAM
disk. Instead it is a 'number of files currently open' status byte, tak-
ing the value 0-3. Up to three files may be open at once for any mixture
of input, output or random access. The SPOOL/EXEC files are not held
open over a filing system change.

Supported OS Calls:
OSArgs
   Y=0 A=0 (Read fs id)
   Y=0 A=1 (Read address of *RUN parameters)
   Y=0 A=255 (Update all files to media)
   Y=handle A=0 (Read sequential pointer)
   Y=handle A=1 (Write sequential pointer)
   Y=handle A=2 (Read file length)
   Y=handle A=255 (Update this file to media)
OSBGet
   Y=handle, byte returned in A is valid only if C=0
OSBPut
   Y=handle, A=byte to write
OSFile
   A=0 (Save a section of memory)
       If this call fails due to lack of disk space and the filename
       given already existed, this results in the DELETION of that file!
   A=1 (Write cat info)
   A=2 (Write load address for file)
   A=3 (Write exec address for file)
   A=4 (Write attributes for file)
   A=5 (Read cat info)
   A=6 (Delete named file)
   A=255 (Load named file,using stored/given address)
OSGbPb
   A=1,2 (Put bytes to media)
   A=3,4 (Get bytes from media)
   A=5 (Read media title and boot option)
   A=6 (Read device name and current dir)
   A=7 (Read device name and current lib)
   A=8 (Read names from current dir)
OSFind
   A=0 (Close file, or files)
   A=&40 (openin an existing file)
   A=&80 (openout a file,deleting the old if it already exists)
   A=&C0 (openup an existing file)
OSFSControl
   A=0  (Set option)
        X=0,Y=0 (Reset default OPTions)
        X=1,Y=0/1 (Turn off/on extended messages)
        X=4,Y=0/1/2/3 (Set boot option)
   A=1  (test for EOF)
   A=2/3/4 (Run the given file)
   A=5  (Produce catalogue)
   A=6  (Shut down filing system)
   A=7  (Return handle range)
   A=8  (Command about to be executed)
   A=9  (Do a *EX)
   A=10 (Do a *INFO)

The file V.+RAMFS2 contains the additional OS commands and exit messages
for the RAMFS ROM.
