                          BASIC ROM ROUTINES
                         Christopher Dewhurst

THE Basic Rom is that dark and mysterious area of memory that lies
beyond the screen, starting at &8000 and stretching up to &BFFF. It's
the backstage department containing the machine code needed to interpret
your Basic commands. But have you ever wondered if we can use some of
that machine code in our own programs? Have you, for instance, struggled
to write an assembler routine to print a number on the screen, when one
must surely exist somewhere in the Basic Rom? Well, wonder no more,
because there is indeed such a routine, and in this article we'll be
exploring that and a lot more besides.
   Before we go any further, however, a word of caution. The best
machine code is specific machine code written for a specific job; Basic
Rom routines are general-purpose routines, and are not the answer to
everything. Having said that, if speed is not your main priority, then
the Rom routines are ideal. They make your programs smaller and smarter,
provided you use them properly - and this usually involves some fairly
tricky setting up - so listen carefully.
   I learnt a lot about the Basic Rom by exploring around it and experi-
menting with it myself. I also picked up a few tips from THE ADVANCED
BASIC ROM USER GUIDE by Colin Pharo (Cambridge Micro Centre, 1984).
Roland Waddilove also presented a series of excellent articles on the
subject in ELECTRON USER; if you still have these paper beauties, dig
out the November 1988 issue for a rundown on mathematical Rom routines.
However, I will be concentrating on routines which print numbers in hex
or decimal, the random number generator, and printing strings of text.
   In case you're wondering, BBC Master owners won't be left out of the
discussion this time. I have done quite a bit of disassembling of the
Basic 4 Rom to find out where equivalent routines to Basic 2 reside.
Basic 2 is the Rom fitted in the BBC B and Electron, and Basic 4 is the
one fitted in the Master (Like the Plus 2, for some reason Basic 3
never was). When I talk about a Rom routine, I will specify both the
Basic 2 and Basic 4 addresses - together with examples and commentaries
on how to use them - so it is up to you to use the correct one depending
on which computer you have. If you experience any difficulties - or if
you have additional hints and tips - just write in.
   Right, down to business. We must first get to know what is called the
Integer Work Area, or IWA for short. This is just a sequence of four
bytes in zero page, located at &2A-&2D. Before Basic can work on an
integer variable, be it adding a number to it or printing it out, it
must be put into the IWA. Fortunately, life is made easier with the help
of a couple of routines which copy an integer variable, either from zero
page or from the main memory, to the IWA:

1.      Routine: Copy 4-byte integer from zero page to the IWA
        Basic 2 address: &AF56
        Basic 4 address: &AA80

        Entry: X = zero page offset at which the integer to be copied is
        located.
        Exit: IWA contains the integer.
        Ex.:    LDX #&70  \integer at &70-3
                JSR &AF56  \copy to IWA

2.      Routine: Copy 4-byte integer from memory to the IWA
        Basic 2: &B336
        Basic 4: &B1AA

        Entry: &2A/&2B contain address of the integer.
        Exit: IWA contains the integer.
        Ex.:    LDA #integer MOD 256
                STA &2A
                LDA #integer DIV 256
                STA &2B
                JSR &B336
                ...
                .integer EQUD &12345678

There are also two routines which do the opposite of above. The one at
&BE44 (Basic 2)/&BDC6 (Basic 4) copies the IWA to a zero-page location,
X being set to the zero page location on entry. The routine at &B4C6
(Basic 2)/&B347 (Basic 4) copies the IWA to a location in main memory
whose address is held in &37/&38.

3.      Routine: Print a string
        Basic 2: &BFCF
        Basic 4: &BECF

        Entry: The string must follow the JSR &BFCF instruction, and be
        terminated by a byte of value &80 or greater.
        Ex.:    JSR &BFCF
                EQUS "Hello there.":NOP
                ...

Notice how I've used the NOP instruction to terminate the string. The
NOP opcode has a value of &EA, which satisfies the condition of being
&80 or greater. The important point to remember is that program
execution continues AFTER that NOP instruction. In machine code, every
time a JSR instruction is executed the current address is pushed onto
the stack. Basic pulls this address from the stack, stores it in zero
page locations &37/&38 and uses indirect addressing to get the bytes of
the string. By the time the string has been printed, &37/&38 contains
the address of the next instruction after the string in the program
that called the routine. The disadvantage of this routine, however, is
that while you can include control codes (to turn off the cursor for
instance) you can't print out a string of graphics characters because
they have an ASCII value of &80 or above, which, as we said, is used to
terminate the string.

This article continued in V.+BRR2. First published EUG #55.
