6 Bollinbrook road,
MACCLESFIELD,
Cheshire.
SK10 3DJ.
Dear Mike Bellis,
All the mice I have ever seen for the BBC B and Master
series were user prort jobs.It is possible however to connect a serial
mouse to the RS423 port,and by altering the 5 pin BBC plug a little you
can fool the mouse into thinking it is connected to a 9 pin PC.
The next challenge is to work out what the numbers it sends do.That is
where I am stuck - the hardware was the easy part.
I have isolated the button status byte so I can at least tell which
buttons are pressed,and the remaining 4 bytes of the packet of 5 either
toggle between 00 for still of 01 or FF in hex.
The 5 byte packet is thus:
1.Button status (low 3 bits=buttons)
2.X1
3.Y1
4.X2
5.Y2
The adapter plug you'll need to make,as most serial mice come with 9
pin sockets on is:
Pin1 -> CONNECT TO PIN 4
Pin2 -> (A) DATA IN
Pin3 -> (B) DATA OUT
Pin4 -> CONNECT TO PIN 8
Pin5 -> (C) GND
Pin6 -> NC
Pin7 -> (D) RTS
Pin8 -> (E) CTS
Pin9 -> NC
I hope this is right as I can never remember which way round the
plug is printed on P504 of the user guide.
Sorry I didn't have time to draw a fancy diagram,but I have sent you
the BASIC software to read it.Perhaps machine code would allow us to see
some bytes tha BASIC is too slow to read.The Acorn RISC PC returned
values other than 00,01,FF which is why I question BASIC.
Let me know how you get on,if you need a cheap experimental mouse to
work as a guinea pig try:
CCL Computers
Tele 01274 664110
They accept switch over the phone and the BRAND NEW serial mouse I am
experimenting on cost `3.30 + VAT + P&P from them.
R.P.Sprowson.
----------------------------------------------------------
MOUSEY
======
Plug serial mouse into RS423 port.
Run the program.
Move the mouse to initialise the
display.
Puzzle about how on earth to write a
mouse driver.
Click a few buttons on the mouse and
watch the bits toggling on the top of
the screen.
Write the software and submit it to
EUG!
Happy computing,
R.P.Sprowson.
NOW THIS IS INTERESTING. I JUST HOPE THAT SOME EUG MEMBERS WILL TRY
THIS OUT AND SEND IN THEIR RESULTS FOR ALL TO READ.
