*    0060.25 GST 295/0.01
*
*****************************************************************
*                                                               *
*                                                               *
*                                                               *
*                  IBM PROPRINTER CONFIGURATION                 *
*                  ============================                 *
*                                                               *
*                                                               *
*    This file contains configuration details for the printer   *
*    described below.  To modify the printer configuration,     *
*    you must:                                                  *
*                                                               *
*    (a)  Read the chapter PRINTER CONFIGURATION in your User   *
*         Manual - THOROUGHLY!                                  *
*                                                               *
*    (b)  Edit this file using 1st Word Plus to make the        *
*         required changes (all values are HEXADECIMAL).        *
*                                                               *
*    (c)  Run the !1stConvrt program to install the new driver. *
*                                                               *
*    Consult your User Manual for details of how to load your   *
*    custom driver from the 1st Word Plus desktop, and how to   *
*    make it your default printer.                              *
*                                                               *
*    Copyright (C) 1986, 1987, 1988, GST Holdings Ltd           *
*    Copyright (C) 1989, GST Holdings plc                       *
*****************************************************************


*    Printer name
*    ============
*
*    For display on the 1st Word Plus desktop keypad
*    and 1st Mail Printer Configuration form
*    (max 32 characters)
*



IBM Proprinter (9-pin matrix)


*    Configuration variables
*    =======================
*
*    These six variables define certain printer
*    configuration details required by 1st Word Plus:
*
*    (1)  1 for microspacing daisywheel, else 0
*    (2)  Character width in printer units (daisy)
*    (3)  Linefeed height in printer units
*    (4)  Mid-carriage (daisy) pixels/inch (matrix)
*    (5)  Bold offset in printer units (daisy)
*    (6)  1 to pause printing between pages, else 0


0, 0, C, 3C, 0, 0


*    Printer characteristics
*    =======================
*
*    This table defines values to be sent to the
*    printer by 1st Word Plus to control its operation.
*
*    An entry consists of:
*
*    (1)  Function number (these must be kept in order)
*    (2)  Command bytes (hex commands and placeholders)
*
*    A placeholder has the top bit set and is substituted
*    by an actual value by 1st Word Plus when printing.
*
*    Lines preceded by an asterisk are commented out.


* 0                           * Character width
1,   D,  A                    * Carriage return and line feed
* 2                           * Forward print
* 3                           * Reverse print
* 4                           * Vertical tab to line
* 5                           * Absolute horizontal tab
6,  1B, 47                    * Draft bold on
7,  1B, 48                    * Draft bold off
8,  1B, 45                    * NLQ bold on
9,  1B, 46                    * NLQ bold off
* A                           * Draft italic on
* B                           * Draft italic off
* C                           * NLQ italic on
* D                           * NLQ italic off
* E                           * Draft light on
* F                           * Draft light off
10, 1B, 49,  0                * NLQ light on
11, 1B, 49,  2                * NLQ light off
12, 1B, 53,  0                * Draft superscript on
13, 1B, 54                    * Draft superscript off
* 14                          * NLQ superscript on
* 15                          * NLQ superscript off
16, 1B, 53,  1                * Draft subscript on
17, 1B, 54                    * Draft subscript off
* 18                          * NLQ subscript on
* 19                          * NLQ subscript off
1A, 1B, 2D,  1                * Draft underline on
1B, 1B, 2D,  0                * Draft underline off
* 1C                          * NLQ underline on
* 1D                          * NLQ underline off
1E,  C                        * Formfeed
1F, 12                        * Horizontal initialization
20, 1B, 36                    * Vertical initialization: set 2
* 21                          * Termination: printer reset
22,  8                        * Backspace
23,  D                        * Carriage return
24, 1B, 43, 80                * Form length in lines
25, 1B, 41, 80, 1B, 32        * Set line feed to N units
26, 1B, 4B                    * Start graphics (60 dots/inch)
* 27                          * Reserved
28, 1B,49,0,12,1B,57,0        * Draft Pica      (10   cpi)
29, 12,1B,57,0,1B,49,2        * NLQ   Pica      (10   cpi)
2A, 1B,49,0,12,1B,57,0,1B,3A  * Draft Elite     (12   cpi)
2B, 12,1B,57,0,1B,3A,1B,49,2  * NLQ   Elite     (12   cpi)
2C, 1B,49,0,1B,57,0,F         * Draft Condensed (17.2 cpi)
* 2D                          * NLQ   Condensed (17.2 cpi)
2E, 1B,49,0,12,1B,3A,1B,57,1  * Draft Expanded  ( 6   cpi)
2F, 12,1B,3A,1B,57,1,1B,49,2  * NLQ   Expanded  ( 6   cpi)
* 30                          * Black   ink
* 31                          * Magenta ink
* 32                          * Cyan    ink
* 33                          * Yellow  ink
0                             * NULL termination byte


*    Translation Table
*    =================
*
*    This table is used to translate the Archimedes
*    character codes for output to the printer.
*
*    Each entry consists of:
*
*    (1)  Archimedes character code (these must be in order)
*    (2)  The (possibly null) byte string to be output
*
*    Archimedes character codes with a NULL translation
*    string are printed as spaces.
*
*    Archimedes character codes NOT in the table are sent
*    directly to the printer without translation.

A0
A1
A2                            * � - N/A
A3
A4
A5, 4F, 8, 2F                 * � - O BS /
A6
A7
A8                            * � - N/A
A9                            * � - N/A
AA
AB
AC
AD
AE                            * � - N/A
AF
B0
B1
B2
B3                            * � - N/A
B4                            * � - N/A
B5
B6, 1B, 5E, 14                * �
B7
B8
B9
BA
BB
BC
BD
BE
BF
C0                            * � - N/A
C1
C2
C3                            * � - N/A
C4
C5
C6
C7
C8
C9
CA
CB
CC
CD
CE
CF
D0
D1
D2
D3
D4
D5                            * � - N/A
D6
D7
D8
D9
DA
DB
DC
DD
DE
DF
E0
E1
E2
E3, 61, 8, 7E                 * � - a BS ~
E4
E5
E6
E7
E8
E9
EA
EB
EC
ED
EE
EF
F0
F1
F2
F3
F4
F5, 6F, 8, 7E                 * � - o BS ~
F6
F7
F8
F9
FA
FB
FC
FD
FE
FF


0                             * NULL terminator
