This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.

Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.

Tape/disk: Home » Personal collection » Acorn tapes » Electron_User » Electron_User_tape26b_acorn_eu_1991_august.wav
Filename: TV/Test
Read OK:
File size: 09D0 bytes
Load address: FFFF1A00
Exec address: FFFF8023
File contents
   10REM > <BasicSave$Dir>.TV/Test
   20REM TV PATTERN GENERATER
   30REM by Brian Webb
   40REM (c) The Micro User
   50MODE6:VDU19,0,4;0;
   60PRINT'TAB(7)"Pattern Generator"
   70PRINT'TAB(7)"A______Cross-hatch & circle"
   80PRINT'TAB(7)"B______Dots"
   90PRINT'TAB(7)"C______E.H.T."
  100PRINT'TAB(7)"D______Chroma bars"
  110PRINT'TAB(7)"E______High frequency"
  120PRINT'TAB(7)"F______R G B rasters"
  130PRINT'TAB(7)"G______Complementary colours"
  140PRINT'TAB(7)"H______PAL cross colour demo"
  150PRINT'TAB(7)"I______Chequer display"
  160PRINT'TAB(7)"J______Decay"
  170PRINT'TAB(7)"Press Space bar to return here"
  180REPEAT VDU7
  190select%=INSTR("ABCDEFGHIJ",CHR$(GETAND&5F))
  200UNTIL select%>0
  210ONselect%GOSUB250,340,420,500,590,640,770,990,1130,1230
  220GOTO50
  230:
  240REM CROSS-HATCH AND CIRCLE
  250MODE1:FORI=40TO1300STEP 100
  260MOVE I,0 :DRAW I,1023 :NEXT
  270VDU20:FORI=10TO1100 STEP 100
  280MOVE0,I:DRAW1300,I:NEXT
  290MOVE638,965:FORI=0TO2*PI+.1 STEP .1
  300DRAW638+450*SIN(I),515+450*COS(I):NEXT
  310PROCspace:RETURN
  320:
  330REM DOTS
  340MODE2:FOR X=91 TO 1188 STEP 91
  350FOR Y=0 TO 1023 STEP 64
  360MOVE X,Y:DRAW X,Y+1
  370NEXT:NEXT
  380VDU23,1,0;0;0;0;
  390PROCspace:RETURN
  400:
  410REM EHT
  420MODE0:MOVE2,2:DRAW1277,2
  430DRAW1277,1021:DRAW2,1021:DRAW2,2
  440REPEAT
  450VDU19,2,0;0;:PROCwait(55)
  460VDU19,2,7;0;:PROCwait(55)
  470UNTILINKEY0=32:RETURN
  480:
  490REM CHROMA BARS
  500MODE2:RESTORE 560
  510VDU20:FORI=0TO1247 STEP 208
  520READC:GCOL0,C:PLOT4,I,0
  530PLOT4,I,1023:PLOT85,I+207,0
  540PLOT85,I+207,1023:NEXT
  550PROCspace:RETURN
  560DATA 3,6,2,5,1,4
  570:
  580REM HIGH FREQUENCY
  590MODE0:FOR N%=1 TO 2560
  600VDU RND(26)+96;:NEXT
  610PROCspace:RETURN
  620:
  630REM RGB RASTERS
  640MODE2
  650COLOUR1:PRINT"PRESS 1 FOR RED"
  660COLOUR2:PRINT"PRESS 2 FOR GREEN"
  670COLOUR4:PRINT"PRESS 4 FOR BLUE"
  680COLOUR7:PRINT"PRESS 7 FOR WHITE"
  690REPEAT K%=INSTR("1247 ",GET$)
  700Q%=VALMID$("1247 ",K%,1)
  710UNTIL K%>0
  720IF K%<5 VDU19,0,Q%;0;
  730IF K%=5 RETURN
  740GOTO690
  750:
  760REM COMPLEMENTARY COLOURS
  770MODE2
  780VDU24,0;0;620;335;
  790GCOL0,132:CLG
  800VDU24,0;336;620;670;
  810GCOL0,130:CLG
  820VDU24,0;671;620;1005;
  830GCOL0,129:CLG
  840VDU24,620;0;1239;335;
  850GCOL0,131:CLG:
  860VDU24,620;336;1239;670;
  870GCOL0,133:CLG
  880VDU24,620;671;1239;1005;
  890GCOL0,134:CLG:COLOUR0
  900COLOUR129:PRINTTAB(2,5)"RED"
  910COLOUR134:PRINTTAB(11,5)"CYAN"
  920COLOUR130:PRINTTAB(2,16)"GREEN"
  930COLOUR133:PRINTTAB(11,16)"MAGENTA"
  940COLOUR132:PRINTTAB(2,26)"BLUE"
  950COLOUR131:PRINTTAB(11,26)"YELLOW"
  960PROCspace:RETURN
  970:
  980REM CROSS COLOUR DEMONSTRATION
  990MODE0:D%=10
 1000VDU19,2.RAD(3)+1,0,0,0
 1010VDU19,3.RAD(3)+4,0,0,0
 1020VDU29,694;512;:J1%=0
 1030FORK%=500TO380 STEP-40
 1040REPEAT J2%=RND(3):UNTILJ2%<>J1%
 1050J1%=J2%:GCOL3,J1%
 1060FORI%=-K%TOK% STEP D%
 1070MOVEK%,I%:DRAW-K%,-I%
 1080MOVEI%,-K%:DRAWI%,-K%
 1090DRAW-I%,K%:NEXT:NEXT
 1100PROCspace:RETURN
 1110:
 1120REM CHEQUER BOARD
 1130MODE0:VDU20
 1140FORI=0TO1250STEP100
 1150FORJ=0TO1050STEP100
 1160C=C+1:IFC/2=INT(C/2)THEN1190
 1170MOVEI,J:PLOT4,I,J+92
 1180PLOT85,I+92,J:PLOT85,I+92,J+92
 1190NEXT:NEXT
 1200PROCspace:RETURN
 1210:
 1220REM DECAY
 1230MODE1:*FX9,20
 1240VDU19,3,15;0;:*FX10,100
 1250FORX%=1TO10
 1260PRINT"DECAY*DECAY*DECAY"'
 1270NEXT
 1280PROCspace:RETURN
 1290:
 1300DEFPROCspace
 1310REPEATUNTILGET=32
 1320ENDPROC
 1330:
 1340DEFPROCwait(T%)T%=TIME+T%
 1350REPEATUNTILTIME>T%:ENDPROC
