On checking the coding, I realised that, while a CR character was replaced
with a space, it still caused a CR where this was not wanted resulting in
some shorter lines. This can be corrected with a small change to line
1100. This line should be altered to end -
....LDA#&20:JMPspace
This makes the check as if the byte had been a space.
The routine 'prt' prints the characters normally if neither of the
highlight flags is set. The first two instructions of this routine ensure
that a CR character is printed normally and not sent to the highlight
routines.
If one of the highlight flags is set, the program junps to the
corresponding subroutine. Also, if the printer flag is set, 'style+1' is
loaded with the high byte of the address of 'bold' (line 850).
These routines were taken from a program in Electron User (Mar 1990) which
gave extra fonts for the Electron. A short additional routine has been
added as explained to make the coding work on the Master.
The routines are similar except for the character definitions.
For printing to screen, the character definition is split in the usual way
using OSWORD with A=10 and the 8 bytes loaded to &CF7 (block+1) using the
routine 'getdef' lines 1130 - 1160.
For bold printing, each byte is loaded into A register and ORed with the
byte in block and then stored in the block. This has the effect of
doubling the width of the vertical parts of the character.
For italics, the bits of the upper two bytes are shifted right and those
of the lower two bytes are shifted left to give a slanted character.
For the Electron, this is sufficient to set CHR$255 to the new font but
for the Master, I have added the routine 'makchar' lines 761 -767 to set
up the character using VDU23.
Each of the two routines first saves the values of the X and Y registers
by PUSHing them on to the stack.
If the print flag is set the low byte of the address of the data for the
selected character is loaded into A register and the printer routine
called. This sets up the printer for the selected character. The routine
first compares the value in 'style' and if equal the routine ends as the
character is already set. If this is not set, the value in A is stored in
'style'. The 'prtloop' then sets up the printer by a VDU1 command
followed by the character read from the data for each of 4 paases through
the loop. If the flag is not set, the printer routine is skipped.
The character is then set up as described above and further check on the
print flag made. If this is not set, A registe is loaded with the new
character number (&FF) and the program jumps to 'newchend', and prints the
character to screen and jumps to 'ntprt'. The values of X and Y pulled
from the stack, and then returns to print loop at 'inc' for the next
character.
If the print flag had been set after the new character had been set up,
the program would jump to 'prtrenab'. This sends the normal character
number to the printer followed by character &FF to the screen.
The printer is then returned to normal printing so that, if the highlight
is turned off and the routine not called again, the printer is reset.
THE MENUS
~~~~~~~~~
Having explained the coding, I thought a brief explanation of the menus
would be of interest. These have had various small mods at different
times with the result that there are some oddities in both programs and I
might tidy them up sometime!!
After the variables are set in line 20, the values of 'lines' and
'skiplines' are set in line 30. These values may be altered to suit your
printer.
The code is then loaded and line 50 sets MODE4 (VDU22,6) and HIMEM to
&2600. All MODE changes must be given by VDU22 so that HIMEM is not
changed. Line 60 changes the background colour and turns the flashing
cursor off. Line 70 resets the three variables to the normal start
values and line 90 sets the four flags used as described later.
Line 90 draws the border line and the PROCmenu is called to print the
menu. This is the variable part of programs and is put at the end of the
program for convenience.
The title is entered as a string variable so as to centralise it at line
450 and line 460 prints the underline correctly underneath. The menu is
printed in the usual way and the following line makes the program wait for
a key press.
The lines which are selected by a number first set the flag R=TRUE if a
program is to be run, then sets f$ to the text filename without suffix
number. In future this will include a prefix +. This identifies the text
files for 'print all files' routine.
This is followed by the varible fl% which indicates the number of files of
the same filename. The PROCtext is then called and, if flag D is FALSE,
on completion of the printing, f% will equal fl%, and the procedure ends
and the prpgram returns to display the menu.
Flag D is set when a diagram is to be shown and PROCpict is called when
the text has been printed.
The line which does the printing is line 140. This first sets MODE 6 with
VDU22,6 and increases f% (initially 0). After calling &900, the clear
routine, the file is loaded. The OSCLI command is equivalent of for
example - *LOAD LETT1 2600.
MODE 3 or 6 is selected by the flag M% which the sets the value of m% and
the print routine called at &9AA.
If more one file of the same filename is to be printed, the program loops
back and f% increased again to load the next file
The PROCpict operates in a similar manner. The three parameters are -
P$ - the filename, n% - the MODE number and d% the number of files
If flag P is TRUE the screen dump program, UCODE, is called and the cues
again omiitted.
On pressing T the flag M% is toggled TRUE or FALSE to set MODE 3 or 6 and
also the value 40 or 80 in the menu line.
Key R returns to the root directory and loads the main menu.
**************************************************************************
