File contents
6 Bollinbrook road,
MACCLESFIELD,
Cheshire.
SK10 3DJ.
Dear All,
The idea of using the second catalogue is excellent,sitting here
with a dual sided 80 track drive I was tired of 'flippy'ing it over all
the time.
However,with Acorn's DFS 1.20 there appears to be a bug.There is a
persistent 'Not found' error whenever the second catalogue has been
copied into tracks 0 and 1.
I tried modifying the menu programs by adding a *DISC command to
restart the DFS and the following that by a VDU21,*CAT,VDU6 to copy the
disk's catalogue into ram.
This didn't work either,as the printer was turned on,which,as I
hadn't got a printer connected locked up the machine.
Using the printer sink (*FX5,0) didn't help much,and it would appear
that the following fixes it:
You must wait for the drive to come to a stand still.ie.typing *RUN
CAT2 then (while the drive is whirring) using the type ahead facility to
do a *CAT resulted in the bug appearing and the catalogue had not
changed.But typing *RUN CAT2 then waiting for the drive to stop followed
by a *CAT was ok.
To fix this,load the MENU (or PMENU or SMENU or GMENU) into RAM and
add the line
451TIME=0:REPEAT:UNTILTIME>300
and save it.This gives a 3 second software delay for my drive to
stop.The value may need to be altered depending on what drive speed
settings you have.
R.P.Sprowson.
YOUR MODIFICATIONS TO RICHARD'S PROGRAMS HAVE NEVER FAILED YET SO THIS ONE
WILL BE ADDED.
FOR THE ADFS MEMBERS, AS YOU KNOW THE DFS CATALOGUE CAN ONLY HOLD 30 OR SO
FILES. TO GET OVER THIS I HAVE BEEN USING FLIPPYS WHERE 5.25" DISCS WERE
PHYSICALLY TURNED OVER TO ACCESS THE SECOND SIDE. NOW THANKS OF COURSE TO
RICHARD DIMOND, WHO ELSE, WE HAVE A DUAL CATALOGUE FACILITY FOR EUG DFS.
AS IT HAPPENS WE ALSO HAVE ANOTHER PROGRAM WHICH IS STILL BEING EVALUATED
WHICH WILL PUT MULTIPUL CATALOGUES, UP TO 90 I THINK ON A SINGLE DISC.
***********************************************************************
6 Bollinbrook road,
MACCLESFIELD,
Cheshire.
SK10 3DJ.
Dear Alan Richardson,
The only company
that I can think of to help you with
flyback transformers is "Grandata"
here in the UK.
I couldn't see an exact equivalent,
but maybe a nice letter from NZ would
prompt them:
Grandata Limited,
KP House,Unit 15,
Pop in Commercial centre,
Southway,
WEMBLEY.Middlesex.
HA9 0HB.
Tele: 0181 900 2329
Fax: 0181 903 6126
You may want to mention P192 of their
catalogue.
R.P.Sprowson.
***********************************************************************
6 Bollinbrook road,
MACCLESFIELD,
Cheshire.
SK10 3DJ.
Dear Mark Bellis,
You were wondering about how Citadel/Thrust screen
scrolling worked,and,judging by your other comments in your letter you
know what you're doing.
If getting the loader program to EOR the file and then disassembling
this to find out how the screen works is too hard,let IT do the work for
you.
Write a rom which traps the 'BRK occured' service call (number 6)
then,having detected that,issue a *TAPE (ie.*FX140,baud) and *SAVE the
whole of the BBC's memory to tape.
Tape is obviously used as it does not gobble the 2.75k that DFS
does,and also most games relocate themselves over the language and NMI
workspace from &DFF and below (in the BBC).
Now all you need to do is cause an error - Escape usually works - but
this may have been turned off to allow it to be used instead to toggle
between the scoreboard and the game.If this is the case then trap service
call 5 (IRQ not recognised) instead ,and short pin 7 to pin 8 on the 1MHz
bus.
Hope this has been of some help,look forward to seeing the games
you're producing.
R.P.Sprowson.
