Earlier in the article, I mentioned several examples of screens which I have
done for EUG using saved screens using this technique. These included the
title screens for both Shipwrecked games, and also several EUG title
screens. You may have noticed that these were actually animated (see the
starfield in Jupiter 3 and the EUG 35 title). This was achieved by palette
switching as used in the previous article. If you look again at the
programming technique demonstration from this article (on EUG 36), and
select option 5, the same effect will appear on your screen. The same
principal was applied in both animated screens mentioned above - the only
difference is that in these title screens the pattern on screen which is
being palette switched is rather more complex. Shipwreck's title screen
(with the animated water scene) was also created in this way, except that
for this screen there was also a machine code program altering the contents
of screen memory as well, to enhance the effect.

So, we have a technique which allows us to store a small number of very
detailed screens on floppy, and recall then at very great speed. But what if
we want to use this method for a large number of screens? And what if we
want a situation like a game, where the user can move sprites on the screen
around. This can also be done by altering the values in screen memory
directly, but in a different way...

2. Editing screen memory

The basic idea is this: in any program, you only usually require a
certain, small number of little 'blocks' to make up a whole picture. In a
word processor, for example, you only need the letters of the alphabet to
appear on the screen. These letters are small blocks of graphics which
appear on your screen (called characters). Because only these 26 blocks
are required, the word processor does not need to store every letter as
all of the pixels which make it up (ie. as a bitmap), but just as a code
for that particular letter. When the word processor wants to display a
letter on the screen, it looks up the letter code, and then copies the
graphic data for what that letter looks like onto the screen. Therefore,
the graphic data for what colour all of the pixels should be for that
particular letter (which might take several bytes) need only be stored
once, and that letter can be stored in your script in just one byte, for
the letter code. Thus, the memory taken up by your script is reduced
dramatically.

The same principal can be used in graphics. Look at two brick walls in an
arcade adventure such as Shipwrecked - can you see the difference between
them? If they are the same, surely you only need to store the graphic data
for a brick wall once, and then copy it onto the screen whenever you want
a brick wall. In Shipwrecked, for example, the graphic data to describe
what a brick wall looks like took 128 bytes. Yet every time I wanted that
brick wall (which was over a hundred times) I could simply use one byte to
say "Put a brick wall here!".

The easiest way to use this block idea, as you may already have realised,
is using user defined characters. You redefine the letters of the alphabet
as different pictures, and then use the standard BASIC PRINT command to
output these pictures to the screen, as and when they are required. But,
as we already realised in the last article, this only allows you to use
one colour in each character. Even so, this is a reasonable technique if
you don't mind the lack of colour. Many commercial games actually never
addressed this problem, and had graphics which lacked colour somewhat.
Even Dizzy (for those who have never heard of it, a great arcade adventure
of the 1980s, which caused quite a cult following at the time on the
Spectrum and C64, but never quite reached the Elk) did not have more than
one colour (other than black) per block. Different blocks were, however,
different colours - trees were green and the ground was red - but there
was never any overlap between the two colour areas.

There is, however, a way of creating an effect just like user defined
characters, but in full colour, and the principal is very similar to that
used before in saving screen memory. Basically, you design you small block
on the screen, using whatever technique you like to draw it, and then save
the small part of screen memory which contains your design. This time,
however, you will not save it to floppy disc, but to another area of
memory. You can then copy this block back to screen memory whenever and
wherever you want it. If you want it, say, in the fifth row down, and
twelve characters along, you can calculate where abouts this corresponds
to in screen memory, and copy the block to this location. As the block is
stored in your computer's RAM, as opposed to on floppy, this transfer can
be done by machine code at very great speed (taking only a small fraction
of a second). For those programmers who are not familiar with machine
code, a module is included with this tutorial allowing you to do this. The
program code for this module is actually taken directly from Shipwrecked.

If you are not familiar with machine code, then you can probably skip the
next section on how to directly access screen memory, as it is impossible
to achieve any speed by accessing screen memory directly in BASIC - your
program will crawl along incredibly slowly. You could still use such a
technique in preparing a screen which you intend to save to floppy using
the technique described before with *SAVE and *LOAD.
