Filename: BioBot/BBReal3
Read OK: ✔
File size: 20B2 bytes
Load address: FFFFFB47
Exec address: F3C7F1B0
Duplicates

There are 2 duplicate copies of this file in the archive:

File contents
   10 REM BallBot V2.0
   20 REM Real-Time Version
   30 REM (C) Dominic Ford 1997
   40 :
   50 REM Welcome screen
   60 MODE6:PRINT" BallBot Artificial Intelligence Module"'"Simulation Tester V2.0 Real Time Version"''"Programmed and Designed by Dominic Ford"''SPC(16);"(C) 1997"
   70 PRINT'''"Press <SPACE>"
   80 REPEAT UNTIL INKEY(-99)
   90 :
  100 REM Setup variables
  110 VOICE 1,"StringLib-Soft":*STEREO 1 0
  120 VOICE 2,"StringLib-Soft":*STEREO 2 -127
  130 VOICE 3,"StringLib-Soft":*STEREO 3 127
  140 current=0:DIMball(4,1):bbx=640:bby=950:dir=270:PROCsetupbb
  150 MODE15:MOUSE ON:PROCdrawfull
  160 :
  170 REM Start main loop
  180 REPEAT:T=TIME
  190 PROCuser
  200 IF idle THEN UNTIL FALSE
  210 PROCsense
  220 mov=FNai(freqa,freqb,freqc)
  230 fwd=(mov AND 1)<>0
  240 reverse=(mov AND 2)<>0
  250 left=(mov AND 4)<>0
  260 right=(mov AND 8)<>0
  270 turbo=(mov AND 16)<>0
  280 open=(mov AND 32)<>0
  290 PROCmoveit
  300 REPEAT UNTIL TIME>(T+30)
  310 UNTIL FALSE
  320 :
  330 REM Graphic interface
  340 DEFPROCdrawfull
  350 REM Set up constants
  360 LOCALsx,sy,width
  370 sx=1:sy=2:width=10
  380 REM Draw green court area
  390 CLS:GCOL0,%001100:RECTANGLE FILL 0,0,1279,1023
  400 REM Mark out white lines onto court
  410 GCOL0,%111111:RECTANGLE FILL sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:RECTANGLE FILL sx/(23.77+2*sx)*1280,(1.37+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
  420 RECTANGLE FILL sx/(23.77+2*sx)*1280,(9.6+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width:RECTANGLE FILL sx/(23.77+2*sx)*1280,(10.97+sy)/(10.97+2*sy)*1024,23.77/(23.77+2*sx)*1280,width
  430 RECTANGLE FILL (sx+5.47)/(23.77+2*sx)*1280,(sy+5.49)/(10.97+2*sy)*1024,12.8/(23.77+2*sx)*1280,width
  440 RECTANGLE FILL sx/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024:RECTANGLE FILL (sx+23.77)/(23.77+2*sx)*1280,sy/(10.97+2*sy)*1024,width,10.97/(10.97+2*sy)*1024+width
  450 RECTANGLE FILL (sx+5.47)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024:RECTANGLE FILL (sx+18.3)/(23.77+2*sx)*1280,(sy+1.37)/(10.97+2*sy)*1024,width,8.23/(10.97+2*sy)*1024
  460 :
  470 REM Draw net
  480 GCOL0,0:FORl=100TO924STEP10:MOVE 640,l:DRAW 680,l+50:NEXT:FORl=0TO40STEP10:MOVE 640+l,100+l:DRAW640+l,924+l:NEXT:FORl=0TO5:MOVE637+l,100:DRAW677+l,150:MOVE637+l,924:DRAW677+l,974:NEXT
  490 GCOL0,%111111:MOVE 682,142:DRAW682,966
  500 PROCdrawmini
  510 ENDPROC
  520 :
  530 REM Draw ballbot and balls
  540 DEFPROCdrawmini
  550 GCOL3,%000011:FORb=0TO4
  560 IF ball(b,0)<>0 OR ball(b,1)<>0 THEN RECTANGLE FILL ball(b,0),ball(b,1),5,5
  570 NEXT
  580 GCOL3,%001111:RECTANGLE FILL bbx,bby,5,5
  590 ENDPROC
  600 :
  610 REM User interface (putting balls down)
  620 DEFPROCuser
  630 MOUSE x,y,c
  640 IF c=0 THEN ENDPROC
  650 IF (c AND 4)<>0 THEN PROCdrawmini:ball(current,0)=x:ball(current,1)=y:current=(current+1)MOD5:PROCdrawmini
  660 IF (c AND 2)<>0 THEN idle=FALSE:stage=0:start=TIME
  670 REPEAT
  680 MOUSE x,y,c
  690 UNTIL c=0
  700 ENDPROC
  710 :
  720 REM Calculate ballbot's new position
  730 DEFPROCmoveit
  740 IF (left AND fwd) OR (right AND reverse) THEN dir=dir-2.5*(1-3*turbo)
  750 IF (right AND fwd) OR (left AND reverse) THEN dir=dir+2.5*(1-3*turbo)
  760 :
  770 REM Get direction in range 0<theta<360
  780 REPEAT IF dir<0 THEN dir=dir+360
  790 IF dir>=360 THEN dir=dir-360
  800 UNTIL dir>=0 AND dir<360
  810 :
  820 fr=0:IF fwd THEN fr=fr+0.25
  830 IF reverse THEN fr=fr-0.25
  840 IF turbo THEN fr=fr*4
  850 PROCdrawmini:bbx=bbx+16*SIN(PI*dir/180)*fr
  860 bby=bby+16*COS(PI*dir/180)*fr
  870 FORball=0TO4:IF open AND ABS(bbx-ball(ball,0))<10 AND ABS(bby-ball(ball,1))<10 THEN ball(ball,0)=0
  880 NEXT:PROCdrawmini
  890 ENDPROC
  900 :
  910 REM Calculate ballbot's background echo reading (-balls), using several points to check out where net posts are.
  920 DEFFNback(x,y,freq)
  930 LOCAL freqa,dummy
  940 freqa=FNback2(x,y,freq,100,923):ftype$=ft$
  950 IF ft$="U" THEN =freqa
  960 dummy=FNback2(x,y,freq,100,125):IF ft$="N" AND dummy<=freqa THEN ftype$="P"
  970 dummy=FNback2(x,y,freq,898,923):IF ft$="N" AND dummy<=freqa THEN ftype$="P"
  980 =freqa
  990 :
 1000 REM Calculate reading from one point
 1010 DEFFNback2(x,y,freq,min,max)
 1020 ft$="U":REM Set up general value of frequency type (UNIDENTIFIED)
 1030 REM Calculate Angle of net as seen by Ballbot
 1040 LOCAL freqa
 1050 netlow=(FNangle(640,max,x,y)-dir) MOD 360
 1060 IF netlow<0 THEN netlow=netlow+360
 1070 IF netlow>180 THEN netlow=netlow-360
 1080 nethi=(FNangle(640,min,x,y)-dir) MOD 360
 1090 IF nethi<0 THEN nethi=nethi+360
 1100 IF nethi>180 THEN nethi=nethi-360
 1110 :
 1120 REM Calculate reading
 1130 freqa=freq+RND(6)-3
 1140 IF ABS(SIN(PI*dir/180))>0.01 THEN IF ((netlow<0 AND nethi>0) OR (nethi<0 AND netlow>0)) AND (640-x)/SIN(PI*dir/180)>0 THEN freqa=(640-x)/SIN(PI*dir/180):ft$="N"
 1150 =freqa
 1160 :
 1170 REM Calculate Ballbot's readings (MAIN ROUTINE)
 1180 :
 1190 DEFPROCsense
 1200 REM Get background readings from FNback
 1210 freq=RND(250)+1500
 1220 freqa=FNback(bbx,bby,freq):fa$=ftype$
 1230 dir=dir-30:freqb=FNback(bbx,bby,freq):fb$=ftype$
 1240 dir=dir+60:freqc=FNback(bbx,bby,freq):fc$=ftype$
 1250 dir=dir-105:freqd=FNback(bbx,bby,freq):dir=dir+75:fd$=ftype$
 1260 :
 1270 REM Add any relevant balls to readings (using hairy trigonometry)
 1280 :
 1290 FORball=0TO4
 1300 d%=SQR((ball(ball,0)-bbx)^2+(ball(ball,1)-bby)^2)
 1310 IF ball(ball,0)=0 THEN d%=9999
 1320 a=FNangle(ball(ball,0),ball(ball,1),bbx,bby)-dir
 1330 IF ABS(a)<15 AND freqa>d% THEN freqa=d%:fa$="B"
 1340 IF a>-46 AND a<=-15 AND freqb>d% THEN freqb=d%:fb$="B"
 1350 IF a>=15 AND a<46 AND freqc>d% THEN freqc=d%:fc$="B"
 1360 IF a>-90 AND a<=-46 AND freqd>d% THEN freqd=d%:fd$="B"
 1370 NEXT
 1380 :
 1390 REM Update user displays
 1400 :
 1410 PRINTTAB(0,0)INT((TIME-start)/12000);":";(INT((TIME-start)/200)MOD60);" "
 1420 PRINTTAB(0,31)fd$,fb$,fa$,fc$,stage,INT(searching),left,right;
 1430 SOUND 1,-1,freqa/4,5:SOUND 2,-1,freqb/4,5:SOUND 3,-1,freqc/4,5
 1440 ENDPROC
 1450:
 1460 REM Calculate bearing of B from A
 1470 DEFFNangle(x1,y1,x2,y2)
 1480 IF y2=y1 THEN ang=90 ELSE ang=180*ATN((x2-x1)/(y2-y1))/PI
 1490 IF (y2>y1) THEN ang=ang+180
 1500 IF ang<0 THEN ang=ang+360
 1510 =ang MOD 360
 1520 :
 1530 REM BALLBOT ROBOTIC INTELLIGENCE MODULE
 1540 :
 1550 DEFFNai(freqa,freqb,freqc)
 1560 REM Artificial intelligence routines (ie. What Next??)
 1570 LOCALfwd,reverse,left,right,turbo
 1580 fwd=TRUE:reverse=FALSE:left=FALSE:right=FALSE:turbo=FALSE
 1590 :
 1600 REM What stage are we in? Hunt for balls or move to new area?
 1610 IF near<>0 AND stage<8 THEN PROCdonearstuff
 1620 IF near=0 AND (stage=0 OR stage=2) THEN PROChunt
 1630 IF near=0 AND (stage=1 OR stage=3) THEN PROCmoveout
 1640 IF stage=4 THEN PROCreleaseb
 1650 :
 1660 REM Prepare output into binary for transmission
 1670 feed=0:IF fwd THEN feed=feed+1
 1680 IF reving THEN turbo=TRUE
 1690 IF reverse THEN feed=feed+2
 1700 IF left THEN feed=feed+4
 1710 IF right THEN feed=feed+8
 1720 IF turbo THEN feed=feed+16
 1730 IF opencter>0 THEN feed=feed+32
 1740 =feed
 1750 :
 1760 REM Perform a sweep to find any balls
 1770 DEFPROChunt
 1780 REM Watch out if too near to net
 1790 IF((freqa<20AND fa$<>"B")OR(freqb<20AND fb$<>"B")OR(freqc<20AND fc$<>"B"))OR(reving AND((freqa<150AND fa$<>"B")OR(freqb<150AND fb$<>"B")OR(freqc<150AND fc$<>"B")))THENreving=TRUE:reverse=TRUE:fwd=FALSE:left=FALSE:right=TRUE:ENDPROC
 1800 reving=FALSE
 1810 :
 1820 REM If Ball is out of reach in the "D" sector, reverse!
 1830 FDR=freqd*1.25:IFfreqd<150ANDfd$="B"ANDFDR<freqa ANDFDR<freqb ANDFDR<freqc AND(fa$<>"B"ORfreqa>100)AND(fb$<>"B"ORfreqb>100)AND(fc$<>"B"ORfreqc>100)THEN turbo=TRUE:reverse=TRUE:fwd=FALSE:right=TRUE:farleft=-6*(freqd>40):ENDPROC
 1840 IF farleft>0 THEN
 1850  farleft=farleft-1:reverse=TRUE:fwd=FALSE:right=TRUE:turbo=TRUE
 1860  IF fa$="B" OR (fd$<>"B" AND fb$<>"B") THEN farleft=0
 1870  ENDPROC
 1880 ENDIF
 1890 :
 1900 REM Rotate to face ball
 1910 opencter=-5*(((freqa<20)ANDfa$="B")OR((freqb<20)ANDfb$="B")OR((freqc<20)ANDfc$="B")OR((freqd<20)ANDfd$="B"))
 1920 IF fa$="B" THEN searching=searching/2:turbo=freqa>100:ENDPROC
 1930 IF fb$="B" THEN left=TRUE:ENDPROC
 1940 IF fc$="B" THEN right=TRUE:ENDPROC
 1950 REM If no ball in sight, continue rotation...
 1960 align=FALSE:searching=searching+1:IF searching<5 THEN right=TRUE ELSE left=TRUE
 1970 IF searching>150 THEN stage=stage+1
 1980 ENDPROC
 1990 :
 2000 REM Find edge of net and aim for it to move to other side
 2010 DEFPROCmoveout
 2020 REM Watch out if too near to net
 2030 IF (freqa<30 OR freqb<30 OR freqc<30) OR (reving AND (freqa<125 OR freqb<125 OR freqc<125)) THEN reving=TRUE:farleft=0:reverse=TRUE:fwd=FALSE:left=FALSE:right=FALSE:ENDPROC
 2040 reving=FALSE
 2050 REM Align ballbot to face the net post...
 2060 IF freqd<75 AND fb$="N" THEN farleft=5:left=TRUE:turbo=TRUE:ENDPROC
 2070 IF farleft>0 THEN farleft=farleft-1:left=TRUE:turbo=TRUE:ENDPROC
 2080 IF freqa<350 THEN right=TRUE:ENDPROC
 2090 IF fd$="N" AND fb$="P" AND freqb<150 THEN right=TRUE:near=1:ENDPROC
 2100 IF freqa<200 AND freqb<200 AND freqc<200 THEN right=TRUE:ENDPROC
 2110 IF (freqb*1.5)>freqc THEN left=TRUE:ENDPROC
 2120 IF freqb>100 THEN turbo=TRUE
 2130 ENDPROC
 2140 :
 2150 REM Nearly there... Just need a little nudge in the right direction.
 2160 DEFPROCdonearstuff
 2170 near=near+1
 2180 IF near<8 THEN right=TRUE:ENDPROC
 2190 left=TRUE
 2200 IF near>16 THEN near=0:stage=stage+1:searching=0
 2210 ENDPROC
 2220 :
 2230 REM Initialise BallBot variables at the beginning of a run
 2240 DEFPROCsetupbb
 2250 reving=FALSE:left=FALSE:right=FALSE:fwd=FALSE:reverse=FALSE:searching=0:idle=TRUE
 2260 near=FALSE:farleft=0:opencter=0
 2270 ENDPROC
 2280 :
 2290 DEFPROCreleaseb
 2300 REM Got all the balls, now just dump them!
 2310 near=near+1:reverse=TRUE:fwd=FALSE
 2320 IF near>9 THEN idle=TRUE:near=FALSE
 2330 ENDPROC
 2340 REPEAT:FORX=1TO12:OSCLI"CHANNELVOICE 1 "+STR$X:SOUND1,-10,52,100:FORR=0TO10000:NEXT,:UNTIL FALSE
 2350 :
 2360 REM Whizz-back to line up with D - what if whizz back into net?
 2370 REM Reverse if BallBot knows that balls are behind it.
