File contents
Nearly all the calls to alter an index file are made through one routine,
with a reason code: ISAM.
ISAM uses some workspace in the language workspace area. If you're not
using the index system, the utility can use this workspace for its own
purposes.
ADJVAL Routine to adjust values of different key types.
CCRTIX Create an index file.
GETIXN Return index name for a given field number.
IDXSCH Search for an index, given a field name.
ISAM General entry point to ISAM package.
ADJVAL
This routine is called before sending a key to ISAM for an operation. It
adjusts the value of number and date fields into "index format", ready for
ISAM.
If you give it a date value to adjust, it will check the validity of the
date as it is processing the value. An error code is returned if a problem
is found with the date; in this case the value left in the buffer will be
legal, but will be an incorrect conversion from the date that you supplied.
On entry: X has field number of field being adjusted.
LINBUF has field value to be adjusted, delimited
with an end of field marker.
On exit: LINBUF contains adjusted field value.
CS error was found in date value.
CRTIX
CRTIX is used to create a new index file. You must supply the name of the
file, and the number of bytes of disk space that you wish to reserve for the
file. If a file with the name that you have exists already, it will be
overwritten.
The maximum amount of space that you can reserve is 65535 bytes.
On entry: FBLOCK has filename of file that you wish to create,
with PREFIX already inserted.
A contains keysize of file.
X contains low byte of number of bytes to
reserve.
Y contains high byte of number of bytes to
reserve.
On exit: VC file created OK.
VS error occurred; error code in A.
GETIXN
GETIXN extracts the name of the index for a particular field from the format
file, and places it in FBLOCK, with the index prefix automatically inserted.
On entry: X contains the field number of the field for
which you require the index name.
On exit: CC no error; name is in FBLOCK with prefix.
CS error occurred; error code is in A.
IDXSCH
Given a field name specification (which may include the wildcards "?" and
"*"), IDXSCH looks for a field with this name, and checks whether this field
has an index switched on.
On entry: LWORK contains field name to search for, which may
contain wildcards.
A contains field number of field to start
searching from.
On exit: CC field found OK; X contains number of field
found.
CS no field found; error code in A.
ISAM
ISAM is the routine that you call to perform operations on an index file.
The reason code of the operation you wish to perform is loaded into A. A
summary of reason code values is given at the end in table 4.
All calls to ISAM update the Carry and Overflow flags. The carry flag
indicates whether an "internal" error occurred - such as "No key found".
The Overflow flag indicates when a filing system error occurred - such as
"Disk fault". A list of internal ISAM errors is given in table 5. Note
that you can't call the error reporting routine REPERL with an internal ISAM
error code; the internal code is only for checking within a program.
Key values are passed to ISAM in LINBUFl 4 byte pointer values are passed in
REG1. ISAM can handle a maximum of nine indexes open at one time. The
maximum size of a key is 105 bytes.
Indexed sequential files have the two features that you can locate a
particular key by giving its value, and that you can also read up and down
the index in key order. ISAM works by having a "position". Certain calls
set the file "position", some move the position up and down, and some calls
destroy the position altogether. The "Search" call sets the file position;
the "Next" and "Previous" calls move the position, and the "Insert" and
"Delete" calls destroy the position.
If you execute a "Next", or a "Previous" call on an index file with no
position, the index is said to be set at the beginning.
The A, X and Y registers are all undefined after a call to ISAM.
Reason code Effect
A=ISMFLO Tell ISAM that file is open.
Before you make this call, you should have opened the file
with the filing system. This call just informs ISAM that
you have opened the file, and tells it to reverse some
workspace for the file.
On entry: Y contains handle of already opened
file, as returned by the filing
system.
On exit: The file position is reset.
VS file already open; internal error
code in A.
CS internal error occurred; internal
error code in A.
