[ MANUAL FOR 2ND SERIAL PORT - CONTINUATION ]
Supported FX Calls
WHEN preceded by a *COM2 command, the following OSBytes are listened for
by the second serial card firmware. You may either type them directly at
the command line with *FX or by calling the OSByte routine from your
programs.
For calls with A > 165 the operation performed is:
<newvalue> = (<oldvalue> AND Y> EOR X
and returns with: A = preserved, X = <oldvalue>, Y = undefined
FX 2 (Select input stream)
*FX 2, 0 disables RS423 input interrupts
*FX 2, 2 enables RS423 input interrupts
Note that to read or write bytes from the serial port you must use
OSByte 138 to insert bytes into the output buffer and OSByte 145
to get bytes from the input buffer, you cannot use *FX 2, 1 and
*FX 3, 7 to redirect keyboard and screen activity to te port as
this only works with the built in serial interface.
FX 7 (Set receive rate)
Rates between 75 and 19200 baud are possible. This call returns
with the X and Y register set to the old ULA contents (See *FX 242
below). The default, set with *FX 7, 0 is 9600 baud.
FX 8 (Set transmit rate)
Rates between 75 and 19200 baud are possible. This call returns
with the X and Y register set to the old ULA contents (See *FX 242
below). The default, set with *FX 8, 0 is 9600 baud.
FX 156 (Read/write 6850 control register plus OS copy)
This call writes to the control register of the 6850 chip and the
OS copy. By consulting the 6850 data sheet, it is possible to im-
plement serial standards other than the "8N1" default.
The action of this OSByte is:
<register> = (<oldregister> AND Y) EOR X
returning with X = <oldregister> and A, Y preserved.
FX 181 (Determine action on receiving escape/soft key)
Unimplemented. No expansion of escape or soft keys occur.
FX 191 (Read/write RS423 in use flag)
This call tests whether the RS423 hardware is busy, returning with
bit 7 set if it is free, bits 0 to 6 are undefined. Value 'busy'
means that either transmit or receive interrupts are enabled,
writes to this location are ignored.
FX 191 (Read/write 6850 control register OS copy only)
This call reads or writes the OS copy of the control register on
the 6850 chip. Do not write to this location as it would make the
copy inconsistent with the value in the chip.
FX 203 (Read/write input buffer handshake ceiling)
If the number of free bytes in the input buffer falls below the
number held in this location the RTS line will go high to stop any
further bytes being sent from the other computer.
It contains 9 by default on soft and hard resets.
FX 204 (Read/write serial suppression flag)
Unimplemented. The second serial card RS423 input cannot be
suppressed.
FX 205 (Read/write hardware use flag)
This location contains &00 if the hardware is used in RS423 data
mode &40 if the hardware is used in cassette mode. It will always
contain 0 for the second serial card.
FX 232 (Read/write IRQ mask)
Unimplemented. The IRQ mask is always 255, and handled internally.
FX 242 (Read/write serial ULA register OS copy only)
This call reads or writes the second serial card's serial ULA. The
byte is set out as %msrrrtttm where:
m=motor relay state (always 0, there is no relay on the card)
s=system select (always 1, the card is always in RS423 mode)
rrr=receive baud rate (see table)
ttt=transmit baud rate (see table)
The baud rates read from the ULA are:
%000 = 19200 %001 = 1200
%100 = 9600 %101 = 300
%010 = 4800 %011 = 150
%110 = 2400 %111 = 75
Do not write to this location as it would make the copy inconsis-
tent with the value in the ULA.
Robert Sprowson, EUG #56
