USING THE ASSEMBLER 4
~~~~~~~~~~~~~~~~~~~~~
By Richard Dimond
I hope that you are following me all right and that you have been able to
create some characters as I will be showing how to move these about the
screen and also selecting menu options.
Firstly, I must explain about where M/code can be stored as we shall need
more room from now as page &C is used for the characters. Loading M/code
to &900 is useful for short routines and utilities but not for a game.
There are three other options -
1. Using a DIM statement to reserve space above TOP
2. Lowering HIMEM to reserve space above this
3. Raising PAGE to reverve space below
Options 2 & 3 are perhaps best for a completed game which is fully M/coded
but for the present I shall use option 1 as this is easier to set up.
The disadvantage is that the M/code has to be assembled each time as the
area used varies as the assembler listing lengthens.
I have re-written the assembler listing for this method and included all
the subroutines so far. These have been revised to make them clearer and
include the variables as explained last time.
I have put the data for the character on page 94 of the manual for those
who have not created one yet. Also I have put a basic main loop in so
that the program will run and you can move the character around though,
since the M/code is very fast, you will not have much control yet.
MOVEMENT
~~~~~~~~
This routine uses the OS subroutine OSBYTE. This is used for the M/code
equivalent of the *FX calls.
Register A is loaded with the value of the FX call and registers X & Y the
parameters needed. Thus -
LDA#15:LDX#0:LDY#0:JMPosbyte
is the equivalent of *FX15,0 used for clearing the buffers.
for reading the keys, we use OSBYTE with register A loaded with 129. Y is
loaded with &FF and X with the negative INKEY value of the key. With this
routine, the Carry flag is clear until the key is pressed and so a test on
the Carry flag will show whether or not the key is pressed.
I have put the subroutine 'move' in for using keys Z, X, : & / for Left,
Right, Up and Down.
Thus for the Z key is -
.lt LDA#129:LDX#&9E:LDY#&FF:JSRosbyte \ INKEY-98
BCCrt:JSRleft
For the present, the movement subroutines simply increase or decrease the
co-ordinates for printing the character. They will need to be added to
later.
As I said, it is too fast to control so I have added the subroutine delay
-
.delay PHA:TXA:PHA:TYA:PHA: \ save register values on stack
LDXspeed:.xloop :LDY#255:.yloop DEY:BNEyloop:DEX:BNExloop:
PLA:TAY:PLA:TAX:PLA:RTS \ restore register values
The subroutine will need to be called in the main loop by -
320 JSRdelay
350 JSRdelay
It is entered twice so that the character is flashes evenly.
The value entered in speed can be varied to alter the speed. Also for
longer delays you can add some NOPs into the loops. This opcode does not
do anything as it's name suggests but does cause a little delay in the
operation of the code.
While it is only really necessary to save the values in X and Y registers
in this routine, I have included the 3 to illustrate the use of the stack.
This is often done in this way. Note that the three values must be PULLed
off in reverse order.
I suggest you should experiment with this and also try changing the MODE.
I have used MODE 4. If you use MODE 2 or 5, you will need to alter the 39
in PROCright to 19 to prevent the character moving off the screen.
At present, to stop the program you will need to press BREAK. It is best
to provide for pressing ESCAPE and this can be done by using -
LDA#129:LDX#&8F:LDY#&FF:JSRosbyte \ INKEY-113 ESCAPE
BCCcont:RTS \ Return to BASIC
.cont
This must be in the main loop since, if it were in a subroutine, it would
simply end the routine and not return to BASIC.
MAKING CHOICES
~~~~~~~~~~~~~~
Whether it is to select from a menu or simply to answer a yes or no
question, we shall need to make our choice.
For this we use the OS routine OSRDCH (&FFE0).
The routine will stop the program and wait for a key to be pressed when it
will put the ASC value of the key into register A.
If ESCAPE is pressed, the Carry flag is set so a test of this flag can be
used for breaking out of the program and returning to BASIC -
.rdch JSRosrdch
BCCcont
RTS \ to BASIC
.cont (rest of program)
For answering a question add -
CMP#ASC"Y":BEQ yes
CMP#ASC"N":BEQ no
JMPrdch
.yes JSR instructions \ (or whatever)
.no (rest of program)
This can be extended or altered to any keys.
You can select 3 or more choices by a series of letters or numbers by
using -
.rdch JSRosrdch
CMP#ASC"1":BCCrdch \ back if <ASC"1"
CMP#ASC"4":BCSdrch \ back if >ASC"3"
CMP#ASC"1":BEQchoice1
CMP#ASC"2":BEQchoice2
CMP#ASC"3":BEQchoice3
.choice1 JSRoption1:JMPrep
JSRoption2:JMPrep
JSRoption3:JMPrep
.rep (rest of program)
The speed of the game can be selected by -
200 .spset JSRosrdch
CMP#ASC"1":BCCspset
CMP#ASC"4":BCSspset
SEC:SBC#48
ASL A:ASL A:ASL A:ASL A
STAspeed
Enter this in the program before the main loop.
The keys 1 - 3 are selected again then 48 is subtracted from the ASC value
so that the values given are 1, 2 & 3. The 4 ASL A shift the bytes left 4
times, this multiplies by 2 each time and thus gives valuues for speed of
16, 32 & 48.
Note that the Carry flag must be set before the subtraction.
I hope my articles are giving some ideas for writing programs in M/code.
If there are any problems or questions so far, I am always happy to try to
help. As I said last time, the more we experiment, the more we learn.
I am hoping to show how to set up a screen and how they may be loaded next
time.
