Autostereogram Generator
An autostereogram is a repeating pattern of dots which
reveals aconvincing 3-dimensional illusion if viewed
correctly. They have becomepopularly known as "Magic Eye"
pictures after the recent series of books,and can also be
found on posters in art shops. They are generated using
computer programs, so I set about writing a program to produce
them on theElectron.
I found a simple routine to do this, in the New
Scientist magazinelast year, written in the "C" programming
language, and understood enoughof it to write a version in
BASIC. Unfortunately, this took over 4 hoursto run, and was
only capable of producing images of very simple shapes, soit
soon became evident that a machine code version was needed. I
have nowwritten a version which can produce virtually any
image, and never takesmore than 45 minutes to run (it will
often run in under 10). I admit thisis still slow - the
program is held up by needing to use BASIC's RNDfunction to
generate random numbers.
To produce an autostereogram, you will need a picture,
to supplythe 3-D image that you will see. This can be a
screen file in any graphicsmode (0,1,2,4,5), but must have a
very clear outline, particularly on thefirst one you try. The
colours of the picture are used to tell the programhow far in
front of the page each part of the image will appear - so
don'tuse them to make the picture look pretty or realistic.
There is no conceptof colour in the illusions themselves.
If the picture is fairly simple, you can draw it just
using BASIC'sgrapics commands, and PLOT 85 to fill areas with
colour, then save itusing "*SAVE <filename> 3000 8000" for a
MODE 0,1 or 2 screen, or "*SAVE<filename> 5800 8000" for a
MODE 4 or 5 screen. However, it is probablyeasier to use an
art program such as Elkpaint (Electon User, October1989). You
will find a copy of this on the disc, with a couple of minor
improvements made to the load/save routine. The keys are as
follows:
Z,X,*,? : Move cursor
S : Store screen in memory
0-3 : Choose colour
U : Swap to stored screen
SHIFT+1-6 : Choose speed
T : Text
B : Rubberband
Q+W : Clear screen
C : Circle
K : Save screen
E : Ellipse
L : Load screen
R : Rectangle
M : Magnify (cursors scroll view)
A then 1-5 : Brush mode
F : Fill
P : Cut + paste ( use space bar to fix area to cut,
drag box to new position, press Return, then:
Space for a normal copy
H : horizontal flip
V : vertical flip
R : rotate (Z and X rotate about bottom
left corner, then space to fix)
Space : Confirm/fix/draw in brush and magnify modes
Return : Exit brush/magnify modes
When you have a picture ready, run the autostereogram
generator.You will first need to enter the filename of the
source picture, and itsmode (this will be 5 if you used
Elkpaint). Next, enter the filename youwish to save the
autostereogram under, and its mode (0 or 4). The dot
resolution in mode 0 is twice that in mode 4, but in my
opinion, theimages are easier to see in mode 4. They are also
much quicker to producein mode 4.
Next you must enter the "eye separation". This will be
the distancebetween the repeating patterns on the page, and
hence relates to theamount you have to cross your eyes to see
the illusion (if you use mysmall screen dump, this will be in
millimetres). I find it easiest to seethe images if I use an
eye separation of about 20, though this is muchless than in
most commercial autostereograms.
Next, you will be asked to enter an "elevation number"
for eachlogical colour used in the source picture. This is a
measure of how far infront of the page each part of the image
will appear. The higher thenumber, the more the illusion
stands out, so you should enter 0 for thebackground colour. I
use a value of 4 for most images, though you can varythis
from about 2 to 10 to get a good 3-D effect. It is important
that youremember which logical colours you used for which
parts of the picture. Ifyou use mode 0, you should double the
values mentioned above (which referto mode 4). Similarly, if
you alter the eye separation, you should changethe elevation
numbers in approximately the same ratio.
Finally, you will be asked if you want a printed copy.
I havewritten my own single-shade screen dump for this
purpose. This must besaved in the same directory as the
autostereogram generator, under thefilename "ScrDump" (sorry
about the total lack of meaningful labels andvariable names
in this program!). You may prefer to use the dump from
"Diagram", which I have also improved. This is twice as fast
as mine, andthe same shape, but is 50% wider, filling the
full width of the carriage.This machine code program is saved
as "UCODE". There is an option toselect between these two
dumps (small and large respectively).
Now just sit back and wait for the result. This could
take up to 45minutes if you are using mode 0, so be patient
if the computer appears tobe doing nothing for a long period.
All these parameters will sound rather complicated if
you havenever actually seen an autostereogram before, but
don't worry - just usemy suggested values to get you started.
Then you can try varying themlater, one at a time, to see the
effects.
You may be able to see the effect on your TV/monitor
screen if itis not too flickery, though it is generally
easier on paper. My preferredmethod is to stare blankly at
the page, and slowly refocus my eyes untiltwo columns of the
repeating pattern appear to merge into one. Then, ifyou can
hold your focus long enough on the merged pattern, the image
should lift out.
Other people prefer the following method: Hold the
paper againstyour face, and stare through it blankly. Slowly
move the paper away fromyour face without altering your
focus, until the image appears, then waituntil it becomes
clear. You will have to concentrate very hard to prevent
yourself from refocusing on the image as it appears.
Another method is to place a reflective surface over
the page, andfocus on your reflection (a TV/monitor screen
might also work). I havenever found this method useful
myself.
